WIPER BLADES
- Ensure wiper blades and wiper arm spring tension are okay. While applying water to windshield, observe wiper low speed operation. If wiper element is not rolling over when wiper direction reverses, extension bar portion of wiper arm needs to be twisted in proper direction.
- To twist extension bar portion of wiper arm, use 2 small adjustable wrenches positioned 2" (50 mm) apart on wiper arm extension rod. Twist extension rod slightly in opposite direction while holding wrench closest to pivot stationary.
- Cycle wipers to park position. Ensure distances between wiper blades and above cowling are as specified in illustration. (Scheme 4)
Scheme 4
Motor Stops, Blades Do Not Park Properly
Wiper arm set at incorrect position. Arms loose on pivot shaft. Loose wiper motor linkage.
Motor Stops In Any Position When Switch Is Turned Off
Open wiper motor park circuit. Check for faulty wiper switch, wiper motor, or BCM.
Motor Does Not Stop When Switch Is Turned Off
Check for faulty wiper switch, wiper motor, or BCM.
Blades Chatter
Foreign substance on blades or glass. Twisted arm holding blade at wrong angle to glass. Bent or damaged blades.
Blades Slap Against Windshield Molding On Dry Glass
Check for loose or improperly positioned arms on pivot shaft. Check for loose wiper motor crank or drive components. Repair or replace as necessary.
Wiper Knock At Reversal
Check for worn linkage bushings. Check for armature endplay in wiper motor.
Wiper Fuse Blows
Disconnect wiper motor. If fuse does not blow, replace wiper motor. If fuse blows, check wiper switch or wiring.
Motor Will Not Run
Check voltage at motor. If voltage is present, replace wiper motor. If no voltage is present, check wiper switch, ground circuit and wiring.
FRONT WIPER/WASHER SWITCH
Note. Wiper/washer switch is part of multifunction steering column switch. If wiper/washer switch fails, entire multifunction switch must be replaced.
Disconnect wiper/washer switch connector. Using ohmmeter, test for continuity between switch terminals with switch position as indicated. See WIPER/WASHER SWITCH CONTINUITY TEST table. (Scheme 5) If continuity is not as specified, replace multifunction switch.
| Position | Between Terminals No. | Ohms | |
|---|---|---|---|
| Off | 6 & 7 | Max. 1 | |
| Delay | |||
| 1 | 6 & 7 | 1905-1915 | |
| 2 | 6 & 7 | 995-1005 | |
| 3 | 6 & 7 | 612-622 | |
| 4 | 6 & 7 | 387-391 | |
| 5 | 6 & 7 | 254-258 | |
| 6 | 6 & 7 | 155-157 | |
| Low | 6 & 7 | 64.9-65.9 | |
| High | 5 & 8 | Max. 1 | |
| Wash | 8 & 11 | Continuity | |
WIPER/WASHER SWITCH CONTINUITY TEST
Scheme 5
WIPER MODULE
| CAUTION | DO NOT allow wiper module to rest on master cylinder reservoir, or damage to brake system may result. |
Note. Wiper/washer switch is part of multifunction steering column switch. If wiper/washer switch fails, entire multifunction switch must be replaced.
