Power Windows - Non-Dtc-Based Diagnostics Dodge Caliber I facelift

Scheme 2

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Note. The graphics in this test show the Left Rear connectors, the Right side connectors are similar, refer to the Wiring Information for the connector pinouts.

THEORY OF OPERATION

By studying the schematic above, you will notice that the window driver circuits both go to ground when the switches are in the neutral position. In the driver switch, when a switch is moved to lower or raise a window, the switch leaves the ground contact, and supplies 12 volts to the Master Window Switch Rear Up or Down circuit. Likewise in the rear switch, when a switch is moved it leaves the ground contact and supplies 12 volts (through the window lockout switch output circuit) to the Rear Window Driver Up or Down circuit.

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

1. TEST FOR DIAGNOSTIC TROUBLE CODES Turn the ignition on. With the scan tool, read the DTCs. Does the scan tool display any Power Window related DTCs? Yes Refer to «DIAGNOSIS AND TESTING»(ref-484090-S14872865702012070400000) and perform the appropriate diagnostic procedure. No Go To 2.
2. CHECK FOR OPEN OR SHORTED TOGETHER CIRCUIT Turn the ignition off. Disconnect the Driver Window Switch C1 connector. Measure the resistance between the Master Window Switch Left Rear (Up) circuit and the Master Window Switch Left Rear (Down) circuit in the Driver Switch C1 connector. Select the appropriate reading. Below.05 of an Ohm Go To 11 . Between 0.6 and 15.5 Ohms Go To 3 . Above 15.6 Ohms Go To 5 .
3. CHECK FOR SHORTED CIRCUIT Measure the resistance between ground and the Master Window Switch Left Rear (Up) circuit in the Driver Switch C1 connector. Measure the resistance between ground and the Master Window Switch Left Rear (Down) circuit in the Driver Switch C1 connector. Is the resistance below 20k Ohms on either or both circuits? Yes Go To 14 . No Go To 4 .
4. DRIVER WINDOW SWITCH OR MOTOR Disconnect the Driver Window Switch C2 connector. Turn the ignition on. Connect a Jumper wire between the Ignition Switch Output circuit (cavity 2 in the Driver Switch C2 connector) and the Master Window Switch Left Rear (Down) circuit (Cavity 4 in the Driver Switch C1 connector). Connect a Jumper wire between the Master Window Switch Left Rear (Up) circuit (Cavity 1 in the Driver Switch C1 connector) and momentarily touch it to the Ground circuit (cavity 4 in the Driver Switch C2 connector). Reverse the wires at the C1 connector if there is a short to ground. NOTE: For the Right Rear Motor, substitute cavities 2 and 3 for cavities 1 and 4. If the motor ran in one direction, reverse the jumper wires (in the C1 connector) to run the motor in the opposite direction. Did the window motor operate properly in both directions? Yes Replace the Driver Window Switch in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(/dodge/caliber/i-facelift-2009-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) and perform the BODY VERIFICATION TEST. No Replace the Window Motor (regulator) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(/dodge/caliber/i-facelift-2009-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) and perform the BODY VERIFICATION TEST.
5. OPEN WINDOW (UP) CIRCUIT Disconnect the Left Rear Window Motor connector. Measure the resistance between the Master Window Switch Left Rear (Up) circuit in the Driver Window Switch C1 connector and the Left Rear Window Driver (Up) circuit in the Left Rear Window Motor connector. Is the resistance below 3.0 Ohms? Yes Go To 8 . No Go To 6 .
6. OPEN MASTER WINDOW SWITCH LEFT REAR (UP) CIRCUIT Disconnect the Left Rear Window Switch connector. Measure the resistance of the Master Window Switch Left Rear (Up) circuit between the Driver Window Switch C1 connector and the Left Rear Window Switch connector. Is the resistance below 3.0 Ohms? Yes Go To 7 . No Repair the open in the Master Window Switch Left Rear (Up) circuit. Refer to «STANDARD PROCEDURE»(/dodge/caliber/i-facelift-2009-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) and perform the BODY VERIFICATION TEST.
7. OPEN LEFT REAR WINDOW DRIVER (UP) CIRCUIT Measure the resistance of the Left Rear Window Driver (Up) circuit between the Left Rear Window Switch connector and the Left Rear Window Motor connector. Is the resistance below 3.0 Ohms? Yes Replace the Left Rear Window Switch. Refer to «STANDARD PROCEDURE»(/dodge/caliber/i-facelift-2009-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) and perform the BODY VERIFICATION TEST. No Repair the open in the Left Rear Window Driver (Up) circuit. Refer to «STANDARD PROCEDURE»(/dodge/caliber/i-facelift-2009-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) and perform the BODY VERIFICATION TEST.
8. OPEN WINDOW (DOWN) CIRCUIT Measure the resistance between the Master Window Switch Left Rear (Down) circuit in the Driver Window Switch C1 connector and the Left Rear Window Driver (Down) circuit in the Left Rear Window Motor connector. Is the resistance below 3.0 Ohms? Yes Replace the Left Rear Window Motor in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(/dodge/caliber/i-facelift-2009-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) and perform the BODY VERIFICATION TEST. No Go To 9 .
9. OPEN MASTER WINDOW SWITCH LEFT REAR (DOWN) CIRCUIT Disconnect the Left Rear Window Switch connector. Measure the resistance of the Master Window Switch Left Rear (Down) circuit between the Driver Window Switch C1 connector and the Left Rear Window Switch connector. Is the resistance below 3.0 Ohms? Yes Go To 10 . No Repair the open in the Master Window Switch Left Rear (Down) circuit. Refer to «STANDARD PROCEDURE»(/dodge/caliber/i-facelift-2009-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) and perform the BODY VERIFICATION TEST.
10. OPEN LEFT REAR WINDOW DRIVER (DOWN) CIRCUIT Measure the resistance of the Left Rear Window Driver (Down) circuit between the Left Rear Window Switch connector and the Left Rear Window Motor connector. Is the resistance below 3.0 Ohms? Yes Replace the Left Rear Window Switch. Refer to «STANDARD PROCEDURE»(/dodge/caliber/i-facelift-2009-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) and perform the BODY VERIFICATION TEST. No Repair the open in the Left Rear Window Driver (Down) circuit. Refer to «STANDARD PROCEDURE»(/dodge/caliber/i-facelift-2009-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) and perform the BODY VERIFICATION TEST.
11. SHORTED REAR MOTOR NOTE: The graphics show the Left Rear Motor circuit, the Right Rear uses Cavities 2 and 3. Disconnect the Rear Window Motor connector. Measure the resistance between the Master Window Switch Left Rear (Up) circuit and the Master Window Switch Left Rear (Down) circuit in the Driver Window Switch C1 connector. Is the resistance below 20k Ohms? Yes Go To 12 . No Replace the Rear Window Motor in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(/dodge/caliber/i-facelift-2009-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) and perform the BODY VERIFICATION TEST.
12. MASTER WINDOW SWITCH LEFT REAR (UP) CIRCUIT SHORTED TO THE MASTER WINDOW SWITCH LEFT REAR (DOWN) CIRCUIT Disconnect the Left Rear Window Switch connector. Measure the resistance between the Master Window Switch Left Rear (Up) circuit and the Master Window Switch Left Rear (Down) circuit in the Driver Window Switch C1 connector. Is the resistance below 20k Ohms? Yes Repair the short between the Master Window Switch Left Rear (Up) circuit and the Master Window Switch Left Rear (Down) circuit. Refer to «STANDARD PROCEDURE»(/dodge/caliber/i-facelift-2009-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) and perform the BODY VERIFICATION TEST. No Go To 13 .
13. REAR WINDOW DRIVER (UP) CIRCUIT SHORTED TO THE REAR WINDOW DRIVER (DOWN) CIRCUIT Measure the resistance between the Left Rear Window Driver (Up) circuit and the Left Rear Window Driver (Down) circuit in the Left Rear Window Motor connector. Is the resistance below 20k Ohms? Yes Repair the short between the Left Rear Window Driver (Up) circuit and the Left Rear Window Driver (Down) circuit. Refer to «STANDARD PROCEDURE»(/dodge/caliber/i-facelift-2009-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) and perform the BODY VERIFICATION TEST. No Replace the Rear Window Switch. Refer to «STANDARD PROCEDURE»(/dodge/caliber/i-facelift-2009-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) and perform the BODY VERIFICATION TEST.
14. CHECK FOR SHORTED MOTOR Disconnect the Left Rear Window Motor connector. Measure the resistance between ground and the Master Window Switch Left Rear (Up) circuit in the Driver Switch C1 connector. Measure the resistance between ground and the Master Window Switch Left Rear (Down) circuit in the Driver Switch C1 connector. Is the resistance below 20k Ohms on either or both circuits? Yes Go To 15 . No Replace the Window Motor (regulator) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(/dodge/caliber/i-facelift-2009-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) and perform the BODY VERIFICATION TEST.
15. CHECK FOR SHORT TO GROUND Disconnect the Left Rear Window Switch connector. Measure the resistance between ground and the Master Window Switch Left Rear (Up) circuit in the Driver Switch C1 connector. Measure the resistance between ground and the Master Window Switch Left Rear (Down) circuit in the Driver Switch C1 connector. Is the resistance below 20k Ohms on either or both circuits? Yes Repair the short to ground in the Master Window Switch Left Rear (Up) or (Down) circuit. Refer to «STANDARD PROCEDURE»(/dodge/caliber/i-facelift-2009-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) and perform the BODY VERIFICATION TEST. No Repair the short to ground in the Left Rear Window Driver (Up) or (Down) circuit between the Motor and the Rear Window Switch. Refer to «STANDARD PROCEDURE»(/dodge/caliber/i-facelift-2009-2013/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) and perform the BODY VERIFICATION TEST.
