Starting - Service Information: Specifications Dodge Caliber I facelift

TORQUE

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. Disconnect and isolate the negative battery cable.
2. If equipped, remove the belly pan (2).
3. Disconnect the electrical connector (1) and the B+ cable (2) from the starter (3).
4. Remove the upper starter mounting bolt.
5. Remove the lower starter mounting bolt (1) and remove the starter (2).

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

1. Remove air cleaner box and air tube.
2. Disconnect and isolate the battery negative cable
3. Remove starter motor mounting bolt.
4. Disconnect the electrical connector at throttle body.
5. Remove throttle body bolts and remove throttle body.
6. Push starter under intake manifold.
7. Tip starter nose toward cooling module.
8. Pull starter up and out.
9. Disconnect starter motor wiring.
10. Remove starter motor from vehicle.
