Electronic Control Modules - Service Information: Overview Dodge Caliber I

OPERATION

The Data Link Connector (DLC) is an industry-standard 16-way connector that permits the connection of a diagnostic scan tool to the Controller Area Network (CAN) data bus for interfacing with, configuring, and retrieving Diagnostic Trouble Code (DTC) data from the electronic modules that reside on the data bus network of the vehicle.

Scheme 112

The ECM is located in the left side of engine compartment attached to the left inner fender behind the air cleaner housing (2).

DESCRIPTION

The All Wheel Drive (AWD) Control Module controls the Electronically Controlled Coupling (ECC) mounted on the rear axle. It is located in the left kick panel area and gets signals over the vehicle bus.

The all-wheel-drive system requires no driver input or control. Under most driving conditions, it is passive and power is transmitted to the front wheels alone. Unlike all-wheel drive systems that rely on pumps or viscous fluids to transfer torque, this system requires no front-to-rear slippage for activation. This allows the system to transfer torque solely in response to accelerator pedal position. If the driver is asking for a lot of power, the system immediately starts clamping the electronically controlled coupling (ECC), transferring a high percentage of power to the rear wheels. This avoids front wheel slippage, as power to propel the car is transmitted through all four tires. This mode of operation is called open-loop operation in that there is no feedback to affect the torque transfer.

A second, closed loop, operating mode uses feedback from the wheel-speed sensors to determine the appropriate torque transfer. When the front wheels slip, the All Wheel Drive (AWD) Control Module tells the ECC to start clamping, sending power to the rear wheels. Attempting the same aggressive launch described above with the front wheels on ice and the rear wheels on dry pavement, the ECC sends even more torque to the rear wheels to minimize slippage and launch the vehicle. Both modes are always active with the closed loop mode layered on top of open loop mode to increase torque to the rear wheels when needed to maintain traction in extreme cases.

Power to the rear wheels is modulated under the following conditions

1. Slipping on ice while backing up will send a lot of power to the rear axle
2. Loss of traction while traveling at freeway speeds, for example hydroplaning on a puddle of water, will send very little power to the rear wheels because the controller knows at those speeds a lot of power is not needed at the rear wheels
3. A third condition, which is independent of the others, uses wheel speed differences to determine when the vehicle is turning in a tight circle. This condition, which is indicated by a large discrepancy in side-to-side wheel speeds, causes the electronic control module to reduce torque to the rear wheels to prevent binding in the driveline. The electronic control module is always checking for this condition as well.
4. A fourth condition that is unique to this system is to influence vehicle dynamics. Other systems limit AWD to aiding traction or providing off-road capability. The primary focus is on launching the vehicle or going off road at speeds up to about 25 mph (40 km/hr). Above that speed range, they use it to limit wheel slip for traction. On this system, additional ECM calibration controls torque to the rear wheels for improved handling in the 25-65 mph (40-105 km/hr) range. In this speed range, the system increases torque to the rear wheels during cornering with the throttle open to make the car turn more easily - make the handling more neutral. This is more readily accomplished with an electronically controlled system, than with viscous-coupling or gerotor systems that require some degree of front-to-rear slip to transfer torque to the rear wheels. Above 70 mph (113 km/hr), the control strategy provides minimal torque to the rear wheels under normal driving conditions to aid fuel economy.

The control module also interfaces with the Electronic Stability Program (ESP) and traction control systems. The interface allows the ESP system to use the ECC to help gain control of the vehicle. For this purpose, torque transmitted to the rear wheels by the ECC can be reduced. This system is not traction control. It only works on situations where front-to-rear traction varies, for instance, front wheels on ice, rear wheels on dry pavement or climbing steep grades. AWD does not aid side-to-side traction. ESP does that through brake intervention on this system.

Scheme 113

1. Remove the left front kick panel. Refer to «REMOVAL»(ref-284864-S31339429052008051600000) .
2. Remove module retaining bolts (2).
3. Remove electrical connector (3).
4. Remove ECC module (1).

The Antilock Brake Module (ABM) is a microprocessor-based device which monitors the antilock brake system (ABS) during normal braking and controls it when the vehicle is in an ABS stop or when in a traction control or Electronic Stability Program (ESP) situation. The ABM utilizes a 47-way electrical connector on the vehicle wiring harness. The power source for the ABM is through the ignition switch in the RUN or ON position.

Scheme 114

The ABM (1) is mounted to the HCU (2) as part of the Integrated Control Unit (ICU). The ICU is located in the engine compartment on the inboard side of the right body frame rail behind the strut tower. For information on the ICU, refer to DESCRIPTION .

The primary functions of the Antilock Brake Module (ABM) are to

1. Monitor the Antilock Brake System (ABS) and Electronic Stability Program (ESP) for proper operation.
2. Detect wheel locking or wheel slipping tendencies by monitoring the speed of all four wheels of the vehicle.
3. Control fluid modulation to the wheel brakes while the system is in ABS or traction control mode.
4. Modulates fluid pressure to the wheel brakes to control vehicle yaw rate in ESP mode.
5. Store diagnostic information.
6. Provide communication to the scan tool while in diagnostic mode.
7. Illuminate the amber ABS indicator in the instrument cluster.
8. Illuminate the yellow ESP/BAS indicator in the instrument cluster (if equipped).

The ABM constantly monitors the ABS and ESP (if equipped) for proper operation. If the ABM detects a fault, it will turn on the amber ABS and yellow ESP/BAS indicators and disable the ABS or ESP if so equipped. The normal base braking system will remain operational at that time.

The ABM continuously monitors the speed of each wheel through the signals generated by the wheel speed sensors to determine if any wheel is beginning to lock. When a wheel locking tendency is detected, the ABM commands the ABM solenoid coils to actuate. The coils then open and close the valves in the HCU that modulate brake fluid pressure in some or all of the hydraulic circuits. The ABM continues to control pressure in individual hydraulic circuits until a locking tendency is no longer present.

The heated seat module operates on fused battery current received from the ignition switch. The module is grounded to the body at all times through the electrical connector. Inputs to the module include Local Interface Network (LIN) data bus messages and standard hardwired 12 volt power and ground. In response to the LIN inputs the heated seat module will control the battery current to the appropriate heated seat elements.

When a heated seat switch LIN data bus signal is received by the heated seat module, the module energizes the selected heated seat element. The Low heat set point is about 38°C (100.4°F), and the High heat set point is about 42°C (107.6°F).

In addition to operating the heated seat elements, the heated seat module sends LED illumination messages to the CCN via the LIN data bus. The CCN then sends the LED illumination message to the accessory switch bank so that the appropriate LEDs are illuminated for any given heating level. Pressing the switch once will select high-level heating. Pressing the switch a second time will select low-level heating. Pressing the switch a third time will shut the heating elements off.

If the heated seat module detects a heated seat element OPEN or SHORT circuit, it will record and store the appropriate diagnostic trouble code (DTC).
