Power Window System - Electrical Diagnostics: Other Dodge Cab & Chassis R3500 HD

Monitor Conditions

1. When Monitored: Whenever the module is awake.

Set Conditions

1. Set Condition: When the Totally Integrated Power Module (TIPM) senses a draw of between 65 and 100 amps for 80 ms, this code will set.

Possible Causes

1. When Monitored: Whenever the module is awake.

1. Set Condition: When the Totally Integrated Power Module (TIPM) senses a draw of over 35 amps for over 120 ms. on the (F30) Ignition Switch Output circuit, this code will set

Scheme 2

Scheme 3

Scheme 4

1. 1) TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTC's Cycle the ignition switch off then on. Ensure the Window Lock Out Switch is ON. Operate the Driver Window Switch in all positions several times. Operate each Passenger Window Switch in both directions several times. Wait 30 seconds. With the scan tool, read DTC's. Does the scan tool display B191D-WINDOW CONTROL CIRCUIT OVERCURRENT? Yes Go To 2) . No The conditions that caused this code to set are not present at this time. Check for a sticking switch and using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform «BODY VERIFICATION TEST - VER 1»(ref-303801-S12649440912008103100000) .
2. 2) TEST WINDOW MOTORS Do all window motors operate properly at this time? No Go To 3) . Perform «BODY VERIFICATION TEST - VER 1»(ref-303801-S12649440912008103100000) . Yes Check for any sticking switches, restrictions in any window channels or binding regulators and repair or replace as necessary. If equipped, check the power sliding backlite for proper operation. Perform «BODY VERIFICATION TEST - VER 1»(ref-303801-S12649440912008103100000) .
3. 3) WINDOW MOTOR Turn the ignition off. Disconnect the inoperative window motor connector. Turn the ignition on. Connect a 12 volt test light between the Window Driver (UP) circuit and the Window Driver (DOWN) circuit. NOTE: The graphic shows the Left Front Window Motor, all others are similar, Turn the ignition on. Operate the Window Switch in both directions while observing the test light. Does the test light illuminate brightly when the switch in held in both directions? No Go To 4) . Yes Replace the window motor or regulator as necessary in accordance with service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-303801-S12649440912008103100000) .
4. 4) WINDOW DRIVER (UP) CIRCUIT SHORT TO GROUND Turn the ignition off. Disconnect the Driver Power Window Switch C1 and C2 connectors. Measure the resistance between ground and the Window Driver (Up) circuit in the motor connector. Is the resistance below 10,000.0 ohms? Yes Repair the Window Driver (Up) circuit for a short to ground. If this is not the driver window, the short could be from the master switch to the motor. Using the Power Window Schematic, check for the proper circuit. Perform «BODY VERIFICATION TEST - VER 1»(ref-303801-S12649440912008103100000) . No Go To 5) .
5. 5) WINDOW DRIVER (DOWN) CIRCUIT SHORT TO GROUND Measure the resistance between ground and the Window Driver (Down) circuit in the motor connector. Is the resistance below 10,000.0 ohms? Yes Repair the Window Driver (Down) circuit for a short to ground. If this is not the driver window, the short could be from the master switch to the motor. Check the Power Window Schematic for the proper circuit. Perform «BODY VERIFICATION TEST - VER 1»(ref-303801-S12649440912008103100000) . No Check the Window Driver (Up) circuit for a short to the Window Driver Down circuit. Repair if the resistance is under 10,000.0 ohms. If okay, check all the windows for alignment or any reason for the heavy current draw. If no reason was found, check the possible causes in the B18BB DTC Perform «BODY VERIFICATION TEST - VER 1»(ref-303801-S12649440912008103100000) .
