Frames & Bumpers: Overhaul Dodge Cab & Chassis R3500 HD

FRONT TOW HOOK ASSEMBLY

1. Install the tow hook assembly (3) and bolts (2) hand tight.
2. If vehicle is a Heavy Duty , install the tow hook (2) and bolts (1) hand tight.
3. Install the front bumper. See «INSTALLATION»(ref-303885-S36715666412008103100000) .
4. Line up the tow hooks/tow hook assembly and tighten the bolts to 68 N.m (50 ft. lbs.).

Scheme 7

Scheme 8

Scheme 9

Scheme 10

1. Raise and support the vehicle. Refer to «STANDARD PROCEDURE»(ref-303775-S36253149762008103100000) .
2. Remove the transfer case skid plate (3 - if equipped). See «REMOVAL»(ref-303885-S02164440702008103100000) .
3. Support the transmission (1) with a transmission jack (2) or suitable lifting device.
4. 2WD Vehicles - Remove the transmission mount nuts (3).
5. Remove the bolts and remove the crossmember (2).
6. 4WD Vehicles - Remove the transmission mount nuts (5).
7. Remove the bolts (3) and remove the crossmember (4).
