BATTERY SPECIFICATIONS
| Application & Group | Cold Cranking Amps | Amp Hr. Rating |
|---|
| Caravan & Grand Caravan (As Applicable) |
| 2.4L (Group 34) | 600 | 66 |
| 3.0L (Group 34) | 500 | 60 |
| 3.3L (Group 34) | 500 | 60 |
| 3.8L |
| Std. Battery (Group 34) | 600 | 66 |
| Opt. Battery (Group 34) | 685 | 72 |
| Dakota & Durango |
| Std. Battery (Group 27) | 600 | 66 |
| Opt. Battery (Group 27) | 750 | 75 |
| Ram Pickup |
| 3.9L, 5.2L & 5.9L (Gasoline) |
| Std. Battery (Group 27) | 600 | 66 |
| Opt. Battery (Group 27) | 750 | 75 |
| 5.9L (Diesel) (1) & 8.0L | 750 | 75 |
| Ram Van & Ram Wagon |
| Std. Battery (Group 27) | 600 | 66 |
| Opt. Battery (Group 27) | 750 | 75 |
| Town & Country |
| 3.3L (Group 34) | 500 | 60 |
| 3.8L |
| Std. Battery (Group 34) | 600 | 66 |
| Opt. Battery (Group 34) | 685 | 72 |
| Voyager & Grand Voyager (As Applicable) |
| 2.4L (Group 34) | 600 | 66 |
| 3.0L (Group 34) | 500 | 60 |
| 3.3L (Group 34) | 500 | 60 |
| (1) Two batteries. |
FLUID CAPACITIES (CARAVAN, GRAND CARAVAN, TOWN & COUNTRY, VOYAGER & GRAND VOYAGER)
| Application | (1) Quantity |
|---|
| Crankcase (Includes Filter) (2) |
| 2.4L, 3.0L, 3.3L & 3.8L | 4.5 Qts. (4.3L) |
| Cooling System (3) |
| 2.4L | 11.2 Qts. (10.6L) |
| 3.0L | 13.0 Qts. (12.3L) |
| 3.3L & 3.8L | 13.2 Qts. (12.5L) |
| Automatic Transaxle (Mopar ATF Plus Type 7176) |
| 3-Speed |
| Drain & Refill | (4) 4.0 Qts. (3.8L) |
| Dry Refill | 8.5 Qts. (8.0L) |
| 4-Speed |
| Drain & Refill | (4) 4.0 Qts. (3.8L) |
| Dry Refill | 9.1 Qts. (8.6L) |
| Overrunning Clutch (Mopar ATF Plus Type 7176) |
| AWD Models | (5) |
| Power Steering Fluid (6) | 1.7 Pts. (.8L) |
| Power Transfer Unit (SAE 80W-90/API GL-5) |
| AWD Models | 1.2 Qts. (1.14L) |
| Rear Differential (SAE 80W-90/API GL-5) (5) |
| AWD Models | (7) |
| (1) Approximate quantity listed. (2) Use an API energy conserving engine oil that is certified for gasoline engines on all engines except 3.3L flex-fuel models. On 3.3L flex-fuel models, use Mopar Flex-Fuel 5W-30 engine oil or an equivalent that meets Chrysler Standard MS-9214. Proper engine oil MUST BE used to prevent engine damage. The 3.3L flex-fuel model may be referred to as Flex-Fuel Vehicle (FFV) model and is used in all vehicles except California emission vehicles. Flex-fuel model may be also referred to as an E85 application and may be identified by label attached to inside of gasoline filler door. (3) Quantity includes heater and coolant recovery tank. Add 2 qts. (1.9L) if equipped with rear heater. (4) Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/8" below the ADD mark on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range dipstick. (5) An overrunning clutch is bolted on front of rear differential, between torque tube for drive shaft and rear differential. Overrunning clutch contains a separate reservoir from rear differential. Ensure fluids are checked at appropriate component, as different types of fluids are used. Fluid capacity is not available from manufacturer. (6) Use only Mopar power steering fluid. DO NOT use automatic transmission fluid. (7) Capacity is not available from manufacturer. Fill unit until fluid level is even with bottom of filler plug hole. |
| (1) | Approximate quantity listed. |
| (2) | Use an API energy conserving engine oil that is certified for gasoline engines on all engines except 3.3L flex-fuel models. On 3.3L flex-fuel models, use Mopar Flex-Fuel 5W-30 engine oil or an equivalent that meets Chrysler Standard MS-9214. Proper engine oil MUST BE used to prevent engine damage. The 3.3L flex-fuel model may be referred to as Flex-Fuel Vehicle (FFV) model and is used in all vehicles except California emission vehicles. Flex-fuel model may be also referred to as an E85 application and may be identified by label attached to inside of gasoline filler door. |
| (3) | Quantity includes heater and coolant recovery tank. Add 2 qts. (1.9L) if equipped with rear heater. |
| (4) | Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/8" below the ADD mark on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range dipstick. |
| (5) | An overrunning clutch is bolted on front of rear differential, between torque tube for drive shaft and rear differential. Overrunning clutch contains a separate reservoir from rear differential. Ensure fluids are checked at appropriate component, as different types of fluids are used. Fluid capacity is not available from manufacturer. |
| (6) | Use only Mopar power steering fluid. DO NOT use automatic transmission fluid. |
| (7) | Capacity is not available from manufacturer. Fill unit until fluid level is even with bottom of filler plug hole. |
FLUID CAPACITIES (CARAVAN, GRAND CARAVAN, TOWN & COUNTRY, VOYAGER & GRAND VOYAGER)
FLUID CAPACITIES (DAKOTA)
| Application | (1) Quantity |
|---|
| Crankcase (Includes Filter) (2) |
| 2.5L | 4.5 Qts. (4.3L) |
| 3.9L | 4.0 Qts. (3.8L) |
| 5.2L & 5.9L | 5.0 Qts. (4.7L) |
| Cooling System (Includes Heater) |
| 2.5L | 9.8 Qts. (9.3L) |
| 3.9L | 14.0 Qts. (13.2L) |
| 5.2L & 5.9L | 14.3 Qts. (13.5L) |
| Automatic Transmission (Mopar ATF Plus Type 7176) |
| Drain & Refill | (3) 1.5 Qts. (1.4L) |
| Dry Refill | (4) 10.0-11.5 Qts. (9.5-10.8L) |
| Manual Transmission (5) |
| AX 15 (SAE 75W-90/API GL-5) |
| 2.5L & 3.9L | 3.3 Qts. (3.1L) |
| NV 3500 (Mopar M/T Lube P/N 4761526) |
| 5.2L | 2.1 Qts. (2.0L) |
| Front Differential (SAE 80W-90/API GL-5) | 3.0 Pts. (1.4L) |
| Rear Differential (SAE 80W-90/API GL-5) (6) |
| 8 1/4" Ring Gear (7) | 4.4 Pts. (2.1L) |
| 9 1/4" Ring Gear (7) | 4.8 Pts. (2.3L) |
| Power Steering Fluid (8) |
| 2WD | 1.7 Pts. (.8L) |
| 4WD | 2.5 Pts. (1.2L) |
| Transfer Case (Mopar ATF Plus Type 7176) | 2.5 Pts. (1.2L) |
| (1) Approximate quantity listed. (2) Use an API energy conserving engine oil that is certified for gasoline engines. (3) Add this amount of fluid. Start engine and shift transmission through all gears and back to Neutral. Add additional fluid to bring fluid level to the MIN mark on dipstick. Recheck fluid level with transmission at normal operating temperature. Adjust fluid level to MAX mark on dipstick. Approximate drain and refill capacity is 4.0 qts. (3.8L). (4) Quantity may vary by type of oil cooler and oil cooler lines. (5) Verify type of transmission used before servicing. The AX 15 uses a flywheel housing bolted to the front of the transmission. The NV 3500 uses a flywheel housing which is an integral part of the transmission housing. (6) Models with Trac-Lok limited slip differential must have 5 ozs. (.15L) of Mopar Trac-Lok Friction Modifier added if lubricant is changed. (7) Rear differential may be identified by number of bolts on rear cover. The 8 1/4" ring gear has 10 bolts on rear cover and 9 1/4" ring gear has 12 bolts on rear cover. (8) Use only Mopar power steering fluid. DO NOT use automatic transmission fluid. |
| (1) | Approximate quantity listed. |
| (2) | Use an API energy conserving engine oil that is certified for gasoline engines. |
| (3) | Add this amount of fluid. Start engine and shift transmission through all gears and back to Neutral. Add additional fluid to bring fluid level to the MIN mark on dipstick. Recheck fluid level with transmission at normal operating temperature. Adjust fluid level to MAX mark on dipstick. Approximate drain and refill capacity is 4.0 qts. (3.8L). |
| (4) | Quantity may vary by type of oil cooler and oil cooler lines. |
| (5) | Verify type of transmission used before servicing. The AX 15 uses a flywheel housing bolted to the front of the transmission. The NV 3500 uses a flywheel housing which is an integral part of the transmission housing. |
| (6) | Models with Trac-Lok limited slip differential must have 5 ozs. (.15L) of Mopar Trac-Lok Friction Modifier added if lubricant is changed. |
| (7) | Rear differential may be identified by number of bolts on rear cover. The 8 1/4" ring gear has 10 bolts on rear cover and 9 1/4" ring gear has 12 bolts on rear cover. |
| (8) | Use only Mopar power steering fluid. DO NOT use automatic transmission fluid. |
FLUID CAPACITIES (DAKOTA)
FLUID CAPACITIES (DURANGO)
| Application | (1) Quantity |
|---|
| Crankcase (Includes Filter) (2) |
| 3.9L | 4.0 Qts. (3.8L) |
| 5.2L & 5.9L | 5.0 Qts. (4.7L) |
| Cooling System (Includes Heater) |
| 3.9L | 14.0 Qts. (13.2L) |
| 5.2L & 5.9L | 14.3 Qts. (13.5L) |
| Automatic Transmission (Mopar ATF Plus Type 7176) |
| Drain & Refill | (3) 1.5 Qts. (1.4L) |
| Dry Refill | (4) 10.0-11.5 Qts. (9.5-10.8L) |
| Front Differential (SAE 80W-90/API GL-5) | 3.0 Pts. (1.4L) |
| Rear Differential (SAE 80W-90/API GL-5) (5) |
| 8 1/4" Ring Gear (6) | 4.4 Pts. (2.1L) |
| 9 1/4" Ring Gear (6) | 4.8 Pts. (2.3L) |
| Power Steering Fluid (7) | 2.5 Pts. (1.2L) |
| Transfer Case (Mopar ATF Plus Type 7176) (8) |
| NV 231 & NV 231HD | 2.5 Pts. (1.2L) |
| NV 242 | 3.0 Pts. (1.4L) |
| (1) Approximate quantity listed. (2) Use an API energy conserving engine oil that is certified for gasoline engines. (3) Add this amount of fluid. Start engine and shift transmission through all gears and back to Neutral. Add additional fluid to bring fluid level to the MIN mark on dipstick. Recheck fluid level with transmission at normal operating temperature. Adjust fluid level to MAX mark on dipstick. Approximate drain and refill capacity is 4.0 qts. (3.8L). (4) Quantity may vary by type of oil cooler and oil cooler lines. (5) Models with Trac-Lok limited slip differential must have 5 ozs. (.15L) of Mopar Trac-Lok Friction Modifier added if lubricant is changed. (6) Rear differential may be identified by number of bolts on rear cover. The 8 1/4" ring gear has 10 bolts on rear cover and 9 1/4" ring gear has 12 bolts on rear cover. (7) Use only Mopar power steering fluid. DO NOT use automatic transmission fluid. (8) Transfer case may be identified by model number stamped on identification tag on rear of transfer case, just above filler plug. |
| (1) | Approximate quantity listed. |
| (2) | Use an API energy conserving engine oil that is certified for gasoline engines. |
| (3) | Add this amount of fluid. Start engine and shift transmission through all gears and back to Neutral. Add additional fluid to bring fluid level to the MIN mark on dipstick. Recheck fluid level with transmission at normal operating temperature. Adjust fluid level to MAX mark on dipstick. Approximate drain and refill capacity is 4.0 qts. (3.8L). |
| (4) | Quantity may vary by type of oil cooler and oil cooler lines. |
| (5) | Models with Trac-Lok limited slip differential must have 5 ozs. (.15L) of Mopar Trac-Lok Friction Modifier added if lubricant is changed. |
| (6) | Rear differential may be identified by number of bolts on rear cover. The 8 1/4" ring gear has 10 bolts on rear cover and 9 1/4" ring gear has 12 bolts on rear cover. |
| (7) | Use only Mopar power steering fluid. DO NOT use automatic transmission fluid. |
| (8) | Transfer case may be identified by model number stamped on identification tag on rear of transfer case, just above filler plug. |
FLUID CAPACITIES (DURANGO)
FLUID CAPACITIES (RAM PICKUP)
| Application | (1) Quantity |
|---|
| Crankcase (Includes Filter) (2) |
| 3.9L | 4.0 Qts. (3.8L) |
| 5.2L & 5.9L (Gasoline) | 5.0 Qts. (4.7L) |
| 5.9L (Diesel) | 11.0 Qts. (10.4L) |
| 8.0L | 7.0 Qts. (6.6L) |
| Cooling System (Includes Heater) |
| 3.9L, 5.2L & 5.9L (Gasoline) | 20.0 Qts. (18.9L) |
| 5.9L (Diesel) | 24.0 Qts. (22.7L) |
| 8.0L | 26.0 Qts. (24.6L) |
| Automatic Transmission (Mopar ATF Plus Type 7176) |
| 42RE (3.9L) |
| Drain & Refill | (3) 1.5 Qts. (1.4L) |
| Dry Refill | (4) 8.5-11.0 Qts. (8.0-10.4L) |
| 46RE (3.9L, 5.2L & 5.9L Gasoline) |
| Drain & Refill | (3) 1.5 Qts. (1.4L) |
| Dry Refill | (4) 9.5-11.5 Qts. (8.9-10.8L) |
| 47RE (5.9L Diesel & 8.0L) |
| Drain & Refill | (3) 1.5 Qts. (1.4L) |
| Dry Refill | (4) 14.5-16.5 Qts. (13.7-15.6L) |
| Manual Transmission (5) |
| NV 3500 (Mopar M/T Lube P/N 4761526) |
| 3.9L & 5.2L | 2.1 Qts. (2.0L) |
| NV 4500 (Mopar M/T Lube P/N 4637579) (6) |
| 5.9L (Gas & Diesel) & 8.0 | 4.0 Qts. (3.8L) |
| NV5600 (Mopar M/T Lube P/N 4761526) (6) | 4.75 Qts. (4.5L) |
| Front Differential (SAE 80W-90/API GL-5) |
| Dana 44 (Model 216) |
| 1500 & 2500 | 4.8 Pts. (2.3L) |
| Dana 60 (Model 248) |
| 2500 & 3500 | 7.6 Pts. (3.6L) |
| Rear Differential |
| 9 1/4" Ring Gear (SAE 75W-90/API GL-5) (7) |
| 1500 & 2500 | 4.8 Pts. (2.3L) |
| Dana 60 (Model 248) (SAE 90W/API GL-5) (8) |
| 2500 | 6.3 Pts. (3.0L) |
| Dana 70 (Model 267) (SAE 90W/API GL-5) (9) |
| 2500 | 7.0 Pts. (3.3L) |
| Dana 80 (Model 286) (SAE 85W-90/API GL-5) (10) |
| 2WD 3500 | 6.8 Pts. (3.2L) |
| 4WD 3500 | 10.1 Pts. (4.8L) |
| Power Steering Fluid (11) | 2.7 Pts. (1.3L) |
| Power Take-Off (PTO) Adapter (Mopar ATF Plus Type 7176) |
| 2500 & 3500 Models 2WD With A/T | 4.6 Pts. (2.2L) |
| Transfer Case (Mopar ATF Plus Type 7176) (12) |
| NV 231HD | 2.5 Pts. (1.2L) |
| NV 241 | 5.0 Pts. (2.4L) |
| NV 241HD | 6.5 Pts. (3.1L) |
| NV 241HD With Power Take-Off (PTO) | 9.0 Pts. (4.3L) |
| (1) Approximate quantity listed. (2) On gasoline engines, use an API energy conserving engine oil that is certified for gasoline engines. On diesel engines, use engine oil with API CF-4/SH or CG-4/SH rating for diesel engines. (3) Add this amount of fluid. Start engine and shift transmission through all gears and back to Neutral. Add additional fluid to bring fluid level to the MIN mark on dipstick. Recheck fluid level with transmission at normal operating temperature. Adjust fluid level to MAX mark on dipstick. Approximate drain and refill capacity is 4.0 qts. (3.8L). (4) Quantity may vary by type of oil cooler and oil cooler lines. (5) Verify type of transmission used before servicing. The NV 3500 uses a flywheel housing which is an integral part of the transmission housing. The NV 4500 uses a flywheel housing which is bolted to the front of the transmission and transmission contains a Power Take-Off (PTO) cover on passenger's side of transmission. (6) Heavy-duty transmission is used with 5.9L diesel and 8.0L. (7) Models with Trac-Lok limited slip differential must have 5 ozs. (.15L) of Mopar Trac-Lok Friction Modifier added if lubricant is changed. (8) Models with Trac-Lok limited slip differential must have 6 ozs. (.18L) of Mopar Trac-Lok Friction Modifier added if lubricant is changed. (9) Models with Power-Lok limited slip differential must have 8 ozs. (.24L) of Mopar Trac-Lok Friction Modifier added if lubricant is changed. (10) Models with Trac-Lok limited slip differential must have Mopar Trac-Lok Friction Modifier added if lubricant is changed. Add 7 ozs. (.24L) of modifier on 2WD models or 10 ozs. (.30L) on 4WD models. (11) Use only Mopar power steering fluid. DO NOT use automatic transmission fluid. (12) Transfer case may be identified by model number stamped on identification tag on rear of transfer case, just above filler plug. |
| (1) | Approximate quantity listed. |
| (2) | On gasoline engines, use an API energy conserving engine oil that is certified for gasoline engines. On diesel engines, use engine oil with API CF-4/SH or CG-4/SH rating for diesel engines. |
| (3) | Add this amount of fluid. Start engine and shift transmission through all gears and back to Neutral. Add additional fluid to bring fluid level to the MIN mark on dipstick. Recheck fluid level with transmission at normal operating temperature. Adjust fluid level to MAX mark on dipstick. Approximate drain and refill capacity is 4.0 qts. (3.8L). |
| (4) | Quantity may vary by type of oil cooler and oil cooler lines. |
| (5) | Verify type of transmission used before servicing. The NV 3500 uses a flywheel housing which is an integral part of the transmission housing. The NV 4500 uses a flywheel housing which is bolted to the front of the transmission and transmission contains a Power Take-Off (PTO) cover on passenger's side of transmission. |
| (6) | Heavy-duty transmission is used with 5.9L diesel and 8.0L. |
| (7) | Models with Trac-Lok limited slip differential must have 5 ozs. (.15L) of Mopar Trac-Lok Friction Modifier added if lubricant is changed. |
| (8) | Models with Trac-Lok limited slip differential must have 6 ozs. (.18L) of Mopar Trac-Lok Friction Modifier added if lubricant is changed. |
| (9) | Models with Power-Lok limited slip differential must have 8 ozs. (.24L) of Mopar Trac-Lok Friction Modifier added if lubricant is changed. |
| (10) | Models with Trac-Lok limited slip differential must have Mopar Trac-Lok Friction Modifier added if lubricant is changed. Add 7 ozs. (.24L) of modifier on 2WD models or 10 ozs. (.30L) on 4WD models. |
| (11) | Use only Mopar power steering fluid. DO NOT use automatic transmission fluid. |
| (12) | Transfer case may be identified by model number stamped on identification tag on rear of transfer case, just above filler plug. |
FLUID CAPACITIES (RAM PICKUP)
FLUID CAPACITIES (RAM VAN & RAM WAGON)
| Application | (1) Quantity |
|---|
| Crankcase (Includes Filter) (2) |
| 3.9L | 4.0 Qts. (3.8L) |
| 5.2L & 5.9L | 5.0 Qts. (4.7L) |
| Cooling System (Includes Heater) |
| 3.9L | 14.6 Qts. (13.8L) |
| 5.2L | 16.5 Qts. (15.6L) |
| 5.9L |
| With Rear Heater | 16.0 Qts. (15.1L) |
| Without Rear Heater | 15.0 Qts. (14.2L) |
| Automatic Transmission (Mopar ATF Plus Type 7176) |
| 32RH (3.9L) |
| Drain & Refill | (3) 1.5 Qts. (1.4L) |
| Dry Refill | (4) 8.5-8.8 Qts. (8.0-8.3L) |
| 46RE (5.2L & 5.9L) |
| Drain & Refill | (3) 1.5 Qts. (1.4L) |
| Dry Refill | (4) 11.5-11.7 Qts. (10.8-11.1L) |
| Power Steering Fluid (5) | 2.7 Pts. (1.3L) |
| Rear Differential |
| Dana 60 (Model 248) (SAE 90/API GL-5) (6) (7) | 6.3 Pts. (2.9L) |
| 8 1/4" & 9 1/4" Ring Gear (SAE 80W-90/API GL-5) (8) (9) | 4.8 Pts. (2.3L) |
| (1) Approximate quantity listed. (2) Use an API energy conserving engine oil that is certified for gasoline engines. (3) Add this amount of fluid. Start engine and shift transmission through all gears and back to Neutral. Add additional fluid to bring fluid level to the MIN mark on dipstick. Recheck fluid level with transmission at normal operating temperature. Adjust fluid level to MAX mark on dipstick. Approximate drain and refill capacity is 4.0 qts. (3.8L). (4) Quantity may vary by type of oil cooler and oil cooler lines. (5) Use only Mopar power steering fluid. DO NOT use automatic transmission fluid. (6) Rear differential may be identified by full-floating axles shafts. (7) Models with Trac-Lok limited slip differential must have 6 ozs. (.18L) of Mopar Trac-Lok Friction Modifier added if lubricant is changed. (8) Rear differential may be identified by number of bolts on rear cover. The 8 1/4" ring gear has 10 bolts on rear cover and 9 1/4" ring gear has 12 bolts on rear cover. (9) Models with Trac-Lok limited slip differential must have 5 ozs. (.15L) of Mopar Trac-Lok Friction Modifier added if lubricant is changed. |
| (1) | Approximate quantity listed. |
| (2) | Use an API energy conserving engine oil that is certified for gasoline engines. |
| (3) | Add this amount of fluid. Start engine and shift transmission through all gears and back to Neutral. Add additional fluid to bring fluid level to the MIN mark on dipstick. Recheck fluid level with transmission at normal operating temperature. Adjust fluid level to MAX mark on dipstick. Approximate drain and refill capacity is 4.0 qts. (3.8L). |
| (4) | Quantity may vary by type of oil cooler and oil cooler lines. |
| (5) | Use only Mopar power steering fluid. DO NOT use automatic transmission fluid. |
| (6) | Rear differential may be identified by full-floating axles shafts. |
| (7) | Models with Trac-Lok limited slip differential must have 6 ozs. (.18L) of Mopar Trac-Lok Friction Modifier added if lubricant is changed. |
| (8) | Rear differential may be identified by number of bolts on rear cover. The 8 1/4" ring gear has 10 bolts on rear cover and 9 1/4" ring gear has 12 bolts on rear cover. |
| (9) | Models with Trac-Lok limited slip differential must have 5 ozs. (.15L) of Mopar Trac-Lok Friction Modifier added if lubricant is changed. |
FLUID CAPACITIES (RAM VAN & RAM WAGON)
REPLACEMENT INTERVALS (CARAVAN, GRAND CARAVAN, TOWN & COUNTRY, VOYAGER & GRAND VOYAGER)
| Component | Months | Miles |
|---|
| Air Filter |
| Normal Service | 24 | 30,000 |
| Severe Service | (2) | (3) 15,000 |
| Camshaft Timing Belt |
| 2.4L |
| Normal Service | 96 | 120,000 |
| Severe Service | (2) | 120,000 |
| 3.0L |
| Normal Service (4) | 48 | 60,000 |
| Severe Service (4) | (2) | 60,000 |
| Coolant | (5) | (5) |
| Drive Belt | 48 | 60,000 |
| Engine Oil |
| Normal Service | 6 | 7500 |
| Severe Service | (2) | 3000 |
| Engine Oil Filter |
| Normal Service |
| 2.4L | 6 | 7500 |
| All Others | 12 | 15,000 |
| Severe Service |
| 2.4L | (2) | 3000 |
| All Others | (2) | 6000 |
| PCV Valve (4) |
| Normal Service | 48 | 60,000 |
| Severe Service | (2) | 30,000 |
| Spark Plugs |
| 2.4L & 3.0L |
| Normal Service | 24 | 30,000 |
| Severe Service | (2) | 30,000 |
| 3.3L & 3.8L |
| Normal Service | (2) | 100,000 |
| Severe Service | (2) | 75,000 |
| Spark Plug Wires |
| 2.4L & 3.0L |
| Normal Service | 48 | 60,000 |
| Severe Service | (2) | 60,000 |
| 3.3L & 3.8L |
| Normal Service | (2) | 100,000 |
| Severe Service | (2) | 75,000 |
| Automatic Transaxle Fluid, Filter & Band Adjustment (6) |
| Normal Service | 24 | 30,000 |
| Severe Service | (2) | 15,000 |
| Power Transfer Unit Fluid (7) |
| AWD Models |
| Severe Service | (2) | 15,000 |
| Rear Differential & Overrunning Clutch Fluid (7) |
| AWD Models |
| Severe Service | (2) | 21,000 |
| (1) Different interval may be required for normal and severe service. Severe service is described as use of ethanol fuel, frequent short trip operation of less than 5 miles, long periods of engine idling, trailer towing, police, taxi, local delivery service, or operating in dusty or excessively hot conditions. (2) Monthly interval is not available from manufacturer. (3) Inspect air filter every 15,000 miles and replace as necessary. Replace at 30,000 miles unless previously replaced during inspection. (4) Inspect at scheduled interval and replace as necessary. Inspect every 30,000 miles after first scheduled interval if not previously replaced at scheduled interval listed. (5) Replace coolant at 45,000 miles or 36 months whichever occurs first. Replace coolant at 36 months regardless of mileage. After first coolant change, replace coolant every 24 months or 30,000 miles thereafter. (6) Band adjustment required on 3-speed automatic transaxle. (7) Normal service interval is not available from manufacturer. Manufacturer lists service schedule only under severe service conditions. |
| (1) | Different interval may be required for normal and severe service. Severe service is described as use of ethanol fuel, frequent short trip operation of less than 5 miles, long periods of engine idling, trailer towing, police, taxi, local delivery service, or operating in dusty or excessively hot conditions. |
| (2) | Monthly interval is not available from manufacturer. |
| (3) | Inspect air filter every 15,000 miles and replace as necessary. Replace at 30,000 miles unless previously replaced during inspection. |
| (4) | Inspect at scheduled interval and replace as necessary. Inspect every 30,000 miles after first scheduled interval if not previously replaced at scheduled interval listed. |
| (5) | Replace coolant at 45,000 miles or 36 months whichever occurs first. Replace coolant at 36 months regardless of mileage. After first coolant change, replace coolant every 24 months or 30,000 miles thereafter. |
| (6) | Band adjustment required on 3-speed automatic transaxle. |
| (7) | Normal service interval is not available from manufacturer. Manufacturer lists service schedule only under severe service conditions. |
REPLACEMENT INTERVALS (CARAVAN, GRAND CARAVAN, TOWN & COUNTRY, VOYAGER & GRAND VOYAGER) (1)
REPLACEMENT INTERVALS (DAKOTA)
| Component | Months | Miles |
|---|
| Air Filter |
| Normal Service | 24 | 30,000 |
| Severe Service | (2) | (3) 15,000 |
| Coolant | (4) | (4) |
| Drive Belt | 48 | 60,000 |
| Engine Oil |
| Normal Service | 6 | 7500 |
| Severe Service | (2) | 3000 |
| Engine Oil Filter |
| Normal Service | 12 | 15,000 |
| Severe Service | (2) | 6000 |
| PCV Valve (5) |
| 3.9L, 5.2L & 5.9L |
| Normal Service | 48 | 60,000 |
| Severe Service | (2) | 30,000 |
| Spark Plugs |
| Normal Service | 24 | 30,000 |
| Severe Service | (2) | 30,000 |
| Spark Plug Wires |
| Normal Service | 48 | 60,000 |
| Severe Service | (2) | 60,000 |
| Automatic Transmission Fluid, Filter & Band Adjustment |
| Normal Service | 30 | 37,500 |
| Severe Service | (2) | 12,000 |
| Manual Transmission Fluid |
| 3.9L |
| Normal Service | 30 | 37,500 |
| Severe Service | (2) | 18,000 |
| Transfer Case Fluid (4WD) |
| Normal Service | 30 | 37,500 |
| Severe Service | (2) | 36,000 |
| Front Differential Fluid (4WD) (6) |
| Severe Service | (2) | 12,000 |
| Rear Differential Fluid (6) |
| Severe Service | (2) | 12,000 |
| Repack Front Wheel Bearings |
| Normal Service | 18 | 22,500 |
| Severe Service | (2) | 21,000 |
| (1) Different interval may be required for normal and severe service. Severe service is described as long periods of engine idling, frequent short trip operation of less than 5 miles, trailer towing, off-highway operation, snow removal operation, or operating in dusty or excessively hot conditions. (2) Monthly interval is not available from manufacturer. (3) Inspect air filter every 15,000 miles and replace as necessary. Replace at 30,000 miles unless previously replaced during inspection. (4) Replace coolant at 45,000 miles or 36 months whichever occurs first. Replace coolant at 36 months regardless of mileage. After first coolant change, replace coolant every 24 months or 30,000 miles thereafter. (5) Inspect at scheduled interval and replace as necessary. (6) Normal service interval is not available from manufacturer. Manufacturer lists service schedule only under severe service conditions. |
| (1) | Different interval may be required for normal and severe service. Severe service is described as long periods of engine idling, frequent short trip operation of less than 5 miles, trailer towing, off-highway operation, snow removal operation, or operating in dusty or excessively hot conditions. |
| (2) | Monthly interval is not available from manufacturer. |
| (3) | Inspect air filter every 15,000 miles and replace as necessary. Replace at 30,000 miles unless previously replaced during inspection. |
| (4) | Replace coolant at 45,000 miles or 36 months whichever occurs first. Replace coolant at 36 months regardless of mileage. After first coolant change, replace coolant every 24 months or 30,000 miles thereafter. |
| (5) | Inspect at scheduled interval and replace as necessary. |
| (6) | Normal service interval is not available from manufacturer. Manufacturer lists service schedule only under severe service conditions. |
REPLACEMENT INTERVALS (DAKOTA) (1)
REPLACEMENT INTERVALS (DURANGO)
| Component | Months | Miles |
|---|
| Air Filter |
| Normal Service | 24 | 30,000 |
| Severe Service | (2) | (3) 15,000 |
| Coolant | (4) | (4) |
| Engine Oil |
| Normal Service | 6 | 7500 |
| Severe Service | (2) | 3000 |
| Engine Oil Filter |
| Normal Service | 12 | 15,000 |
| Severe Service | (2) | 6000 |
| PCV Valve (5) |
| Normal Service | 48 | 60,000 |
| Severe Service | (2) | 30,000 |
| Spark Plugs |
| Normal Service | 24 | 30,000 |
| Severe Service | (2) | 30,000 |
| Spark Plug Wires |
| Normal Service | 48 | 60,000 |
| Severe Service | (2) | 60,000 |
| Automatic Transmission Fluid, Filter & Band Adjustment |
| Normal Service | 30 | 37,500 |
| Severe Service | (2) | 12,000 |
| Transfer Case Fluid (4WD) |
| Normal Service | 30 | 37,500 |
| Severe Service | (2) | 36,000 |
| Front Differential Fluid (4WD) (6) |
| Severe Service | (2) | 12,000 |
| Rear Differential Fluid (6) |
| Severe Service | (2) | 12,000 |
| Repack Front Wheel Bearings |
| Normal Service | 18 | 22,500 |
| Severe Service | (2) | 21,000 |
| (1) Different interval may be required for normal and severe service. Severe service is described as long periods of engine idling, frequent short trip operation of less than 5 miles, trailer towing, off-highway operation, snow removal operation, or operating in dusty or excessively hot conditions. (2) Monthly interval is not available from manufacturer. (3) Inspect air filter every 15,000 miles and replace as necessary. Replace at 30,000 miles unless previously replaced during inspection. (4) Replace coolant at 45,000 miles or 36 months whichever occurs first. Replace coolant at 36 months regardless of mileage. After first coolant change, replace coolant every 24 months or 30,000 miles thereafter. (5) Inspect at scheduled interval and replace as necessary. (6) Normal service interval is not available from manufacturer. Manufacturer lists service schedule only under severe service conditions. |
| (1) | Different interval may be required for normal and severe service. Severe service is described as long periods of engine idling, frequent short trip operation of less than 5 miles, trailer towing, off-highway operation, snow removal operation, or operating in dusty or excessively hot conditions. |
| (2) | Monthly interval is not available from manufacturer. |
| (3) | Inspect air filter every 15,000 miles and replace as necessary. Replace at 30,000 miles unless previously replaced during inspection. |
| (4) | Replace coolant at 45,000 miles or 36 months whichever occurs first. Replace coolant at 36 months regardless of mileage. After first coolant change, replace coolant every 24 months or 30,000 miles thereafter. |
| (5) | Inspect at scheduled interval and replace as necessary. |
| (6) | Normal service interval is not available from manufacturer. Manufacturer lists service schedule only under severe service conditions. |
REPLACEMENT INTERVALS (DURANGO) (1)
REPLACEMENT INTERVALS (RAM PICKUP - LIGHT-DUTY)
| Component | Months | Miles |
|---|
| Air Filter |
| Normal Service | 24 | 30,000 |
| Severe Service | (3) | (4) 15,000 |
| Coolant | (5) | (5) |
| Engine Oil |
| Normal Service | 6 | 7500 |
| Severe Service | (3) | 3000 |
| Engine Oil Filter |
| Normal Service | 12 | 15,000 |
| Severe Service | (3) | 6000 |
| PCV Valve (6) |
| Normal Service | 48 | 60,000 |
| Severe Service | (3) | 30,000 |
| Spark Plugs |
| Normal Service | 24 | 30,000 |
| Severe Service | (3) | 30,000 |
| Spark Plug Wires |
| Normal Service | 48 | 60,000 |
| Severe Service | (3) | 60,000 |
| Automatic Transmission Fluid, Filter & Band Adjustment |
| Normal Service | 30 | 37,500 |
| Severe Service | (3) | 12,000 |
| Manual Transmission Fluid | (7) | (7) |
| Transfer Case Fluid (4WD) |
| Normal Service | 30 | 37,500 |
| Severe Service | (3) | 36,000 |
| Front Differential Fluid (4WD) (8) |
| Severe Service | (3) | 12,000 |
| Rear Differential Fluid (8) |
| Severe Service | (3) | 12,000 |
| Repack Front Wheel Bearings (2WD) |
| Normal Service | 18 | 22,500 |
| Severe Service | (3) | 21,000 |
| (1) Light-duty vehicles apply to all 1500 models and 2500 except 5.9L diesel or 8.0L engines. (2) Different interval may be required for normal and severe service. Severe service is described as long periods of engine idling, frequent short trip operation of less than 5 miles, trailer towing, off-highway operation, snow removal operation, or operating in dusty or excessively hot conditions. (3) Monthly interval is not available from manufacturer. (4) Inspect air filter every 15,000 miles and replace as necessary. Replace at 30,000 miles unless previously replaced during inspection. (5) Replace coolant at 45,000 miles or 36 months whichever occurs first. Replace coolant at 36 months regardless of mileage. After first coolant change, replace coolant every 24 months or 30,000 miles thereafter. (6) Inspect at scheduled interval and replace as necessary. (7) Service interval is not available from manufacturer. (8) Normal service interval is not available from manufacturer. Manufacturer lists service schedule only under severe service conditions. |
| (1) | Light-duty vehicles apply to all 1500 models and 2500 except 5.9L diesel or 8.0L engines. |
| (2) | Different interval may be required for normal and severe service. Severe service is described as long periods of engine idling, frequent short trip operation of less than 5 miles, trailer towing, off-highway operation, snow removal operation, or operating in dusty or excessively hot conditions. |
| (3) | Monthly interval is not available from manufacturer. |
| (4) | Inspect air filter every 15,000 miles and replace as necessary. Replace at 30,000 miles unless previously replaced during inspection. |
| (5) | Replace coolant at 45,000 miles or 36 months whichever occurs first. Replace coolant at 36 months regardless of mileage. After first coolant change, replace coolant every 24 months or 30,000 miles thereafter. |
| (6) | Inspect at scheduled interval and replace as necessary. |
| (7) | Service interval is not available from manufacturer. |
| (8) | Normal service interval is not available from manufacturer. Manufacturer lists service schedule only under severe service conditions. |
REPLACEMENT INTERVALS (RAM PICKUP - LIGHT-DUTY) (1) (2)
REPLACEMENT INTERVALS (RAM PICKUP - MEDIUM-DUTY - GASOLINE)
| Component | Months | Miles |
|---|
| Air Filter |
| Normal Service | 30 | 30,000 |
| Severe Service | (3) | (4) 15,000 |
| Coolant | (5) | (5) |
| Engine Oil & Filter |
| Normal Service | 6 | 6000 |
| Severe Service | (3) | 3000 |
| Spark Plugs |
| Normal Service | 30 | 30,000 |
| Severe Service | (3) | 30,000 |
| Spark Plug Wires |
| Normal Service | 60 | 60,000 |
| Severe Service | (3) | 60,000 |
| Automatic Transmission Fluid, Filter & Band Adjustment |
| Normal Service | 24 | 24,000 |
| Severe Service | (3) | 12,000 |
| Manual Transmission Fluid | (6) | (6) |
| Transfer Case Fluid (4WD) |
| Normal Service | 36 | 36,000 |
| Severe Service | (3) | 36,000 |
| Front Differential Fluid (4WD) (7) |
| Severe Service | (3) | 12,000 |
| Rear Differential Fluid (7) |
| Severe Service | (3) | 12,000 |
| Repack Front Wheel Bearings (2WD) |
| Normal Service | 18 | 18,000 |
| Severe Service | (3) | 24,000 |
| (1) Medium-duty vehicles apply to 2500 and 3500 Calif. models with 8.0L engine. (2) Different interval may be required for normal and severe service. Severe service is described as long periods of engine idling, frequent short trip operation of less than 5 miles, trailer towing, off-highway operation, snow removal operation, or operating in dusty or excessively hot conditions. (3) Monthly interval is not available from manufacturer. (4) Inspect air filter every 15,000 miles and replace as necessary. Replace at 30,000 miles unless previously replaced during inspection. (5) Replace coolant at 36,000 miles or 36 months whichever occurs first. Replace coolant at 36 months regardless of mileage. After first coolant change, replace coolant every 24 months or 30,000 miles thereafter. (6) Service interval is not available from manufacturer. (7) Normal service interval is not available from manufacturer. Manufacturer lists service schedule only under severe service conditions. |
| (1) | Medium-duty vehicles apply to 2500 and 3500 Calif. models with 8.0L engine. |
| (2) | Different interval may be required for normal and severe service. Severe service is described as long periods of engine idling, frequent short trip operation of less than 5 miles, trailer towing, off-highway operation, snow removal operation, or operating in dusty or excessively hot conditions. |
| (3) | Monthly interval is not available from manufacturer. |
| (4) | Inspect air filter every 15,000 miles and replace as necessary. Replace at 30,000 miles unless previously replaced during inspection. |
| (5) | Replace coolant at 36,000 miles or 36 months whichever occurs first. Replace coolant at 36 months regardless of mileage. After first coolant change, replace coolant every 24 months or 30,000 miles thereafter. |
| (6) | Service interval is not available from manufacturer. |
| (7) | Normal service interval is not available from manufacturer. Manufacturer lists service schedule only under severe service conditions. |
REPLACEMENT INTERVALS (RAM PICKUP - MEDIUM-DUTY - GASOLINE) (1) (2)
REPLACEMENT INTERVALS (RAM PICKUP - HEAVY-DUTY - GASOLINE)
| Component | Months | Miles |
|---|
| Air Filter |
| 5.9L |
| Normal Service | 24 | 24,000 |
| Severe Service | (3) | (4) 12,000 |
| 8.0L | 12 | 12,000 |
| Air Injection Pump Filter |
| Normal Service | 24 | 24,000 |
| Severe Service | (3) | (4) 12,000 |
| Coolant | (5) | (5) |
| EGR Valve (5.9L Only) (6) |
| Normal Service | 60 | 60,000 |
| Severe Service | (3) | 60,000 |
| Engine Oil |
| Normal Service | 6 | 6000 |
| Severe Service | (3) | 3000 |
| Engine Oil Filter |
| 5.9L |
| Normal Service | 12 | 12,000 |
| Severe Service | (3) | 6000 |
| 8.0L |
| Normal Service | 6 | 6000 |
| Severe Service | (3) | 3000 |
| PCV Valve (5.9L Only) |
| Normal Service | 60 | 60,000 |
| Severe Service (7) | (3) | 30,000 |
| Distributor Cap & Rotor (5.9L Only) |
| Normal Service | 60 | 60,000 |
| Severe Service | (3) | 60,000 |
| Spark Plugs |
| Normal Service | 30 | 30,000 |
| Severe Service | (3) | 30,000 |
| Spark Plug Wires |
| Normal Service | 60 | 60,000 |
| Severe Service | (3) | 60,000 |
| Oxygen Sensor (5.9L Only) |
| Normal Service | 82 | 82,500 |
| Severe Service | (3) | 82,500 |
| Automatic Transmission Fluid, Filter & Band Adjustment |
| Normal Service | 24 | 24,000 |
| Severe Service | (3) | 12,000 |
| Manual Transmission Fluid | (8) | (8) |
| Transfer Case Fluid (4WD) |
| Normal Service | 36 | 36,000 |
| Severe Service | (3) | 18,000 |
| Front Differential Fluid (4WD) (9) |
| Severe Service | (3) | 12,000 |
| Rear Differential Fluid (9) | (3) | 12,000 |
| Repack Front Wheel Bearings |
| 2WD |
| Normal Service | 24 | 24,000 |
| Severe Service | (3) | 9000 |
| 4WD |
| Normal Service | 18 | 18,000 |
| Severe Service | (3) | 6000 |
| (1) Heavy-duty vehicles apply to 2500 and 3500 Federal models with 8.0L engine and all 3500 models with 5.9L gasoline engine. (2) Different interval may be required for normal and severe service. Severe service is described as long periods of engine idling, frequent short trip operation of less than 5 miles, trailer towing, off-highway operation, snow removal operation, or operating in dusty or excessively hot conditions. (3) Monthly interval is not available from manufacturer. (4) Inspect filter every 12,000 miles and replace as necessary. Replace at 24,000 miles unless previously replaced during inspection. (5) Replace coolant at 36,000 miles or 36 months whichever occurs first. Replace coolant at 36 months regardless of mileage. After first coolant change, replace coolant every 24 months or 30,000 miles thereafter. (6) If equipped with EGR valve, clean EGR passages when replacing EGR valve. (7) Inspect and replace as necessary. Replace PCV valve at 60,000 miles. (8) Service interval is not available from manufacturer. (9) Normal service interval is not available from manufacturer. Manufacturer lists service schedule only under severe service conditions. |
| (1) | Heavy-duty vehicles apply to 2500 and 3500 Federal models with 8.0L engine and all 3500 models with 5.9L gasoline engine. |
| (2) | Different interval may be required for normal and severe service. Severe service is described as long periods of engine idling, frequent short trip operation of less than 5 miles, trailer towing, off-highway operation, snow removal operation, or operating in dusty or excessively hot conditions. |
| (3) | Monthly interval is not available from manufacturer. |
| (4) | Inspect filter every 12,000 miles and replace as necessary. Replace at 24,000 miles unless previously replaced during inspection. |
| (5) | Replace coolant at 36,000 miles or 36 months whichever occurs first. Replace coolant at 36 months regardless of mileage. After first coolant change, replace coolant every 24 months or 30,000 miles thereafter. |
| (6) | If equipped with EGR valve, clean EGR passages when replacing EGR valve. |
| (7) | Inspect and replace as necessary. Replace PCV valve at 60,000 miles. |
| (8) | Service interval is not available from manufacturer. |
| (9) | Normal service interval is not available from manufacturer. Manufacturer lists service schedule only under severe service conditions. |
REPLACEMENT INTERVALS (RAM PICKUP - HEAVY-DUTY - GASOLINE) (1) (2)
REPLACEMENT INTERVALS (RAM PICKUP - MEDIMUM & HEAVY DUTY - 5.9L DIESEL)
| Component | Months | Miles |
|---|
| Air Filter | (2) | (2) |
| Coolant | (3) | (3) |
| Engine Oil & Filter |
| Normal Service | 6 | 7500 |
| Severe Service | (4) | 3750 |
| Fuel Filter |
| Normal Service | 12 | 15,000 |
| Severe Service | (4) | 7500 |
| Valve Clearance Adjustment | (5) | (5) |
| Automatic Transmission Fluid, Filter & Band Adjustment |
| Normal Service | 24 | 30,000 |
| Severe Service | (4) | 15,000 |
| Manual Transmission Fluid | (6) | (6) |
| Transfer Case Fluid (4WD) |
| Normal Service | 36 | 45,000 |
| Severe Service | (4) | 36,000 |
| Front Differential Fluid (4WD) (7) |
| Severe Service | (4) | 15,000 |
| Rear Differential Fluid (7) |
| Severe Service | (4) | 15,000 |
| Repack Front Wheel Bearings (2WD) |
| Normal Service | 24 | 30,000 |
| Severe Service | (4) | 30,000 |
| Normal Service | 48 | 48,000 |
| Severe Service | (4) | 48,000 |
| (1) Different interval may be required for normal and severe service. Severe service is described as long periods of engine idling, frequent short trip operation of less than 5 miles, trailer towing, off-highway operation, snow removal operation, or operating in dusty or excessively hot conditions. (2) Service interval is not available from manufacturer. Use filter- minder on top of air cleaner housing to determine condition of air filter. If filter-minder is in the Red zone, replace air filter. Reset filter-minder by depressing button on top of filter-minder. (3) Replace coolant at 30,000 miles or 24 months whichever occurs first. Replace coolant at 24 months regardless of mileage. After first coolant change, replace coolant every 24 months or 30,000 miles thereafter. (4) Monthly interval is not available from manufacturer. (5) Does not require routine adjustments. (6) Service interval is not available from manufacturer. (7) Normal service interval is not available from manufacturer. Manufacturer lists service schedule only under severe service conditions. |
| (1) | Different interval may be required for normal and severe service. Severe service is described as long periods of engine idling, frequent short trip operation of less than 5 miles, trailer towing, off-highway operation, snow removal operation, or operating in dusty or excessively hot conditions. |
| (2) | Service interval is not available from manufacturer. Use filter- minder on top of air cleaner housing to determine condition of air filter. If filter-minder is in the Red zone, replace air filter. Reset filter-minder by depressing button on top of filter-minder. |
| (3) | Replace coolant at 30,000 miles or 24 months whichever occurs first. Replace coolant at 24 months regardless of mileage. After first coolant change, replace coolant every 24 months or 30,000 miles thereafter. |
| (4) | Monthly interval is not available from manufacturer. |
| (5) | Does not require routine adjustments. |
| (6) | Service interval is not available from manufacturer. |
| (7) | Normal service interval is not available from manufacturer. Manufacturer lists service schedule only under severe service conditions. |
REPLACEMENT INTERVALS (RAM PICKUP - MEDIMUM & HEAVY DUTY - 5.9L DIESEL) (1)
REPLACEMENT INTERVALS (RAM VAN & RAM WAGON)
| Component | Months | Miles |
|---|
| Air Filter |
| Normal Service | 24 | 30,000 |
| Severe Service | (2) | (3) 15,000 |
| Coolant | (4) | (4) |
| Engine Oil |
| Normal Service | 6 | 7500 |
| Severe Service | (2) | 3000 |
| Engine Oil Filter |
| Normal Service | 12 | 15,000 |
| Severe Service | (2) | 6000 |
| PCV Valve (5) |
| Normal Service | 48 | 60,000 |
| Severe Service | (2) | 30,000 |
| Spark Plugs |
| Normal Service | 24 | 30,000 |
| Severe Service | (2) | 30,000 |
| Spark Plug Wires |
| Normal Service | 48 | 60,000 |
| Severe Service | (2) | 60,000 |
| Automatic Transaxle Fluid, Filter & Band Adjustment | (6) | (6) |
| Rear Differential Fluid (7) |
| Severe Service | (2) | 12,000 |
| Repack Front Wheel Bearings |
| Normal Service | 18 | 22,500 |
| Severe Service | (2) | 21,000 |
| (1) Different interval may be required for normal and severe service. Severe service is described as long periods of engine idling, frequent short trip operation of less than 5 miles, trailer towing, or operating in dusty or excessively hot conditions. (2) Monthly interval is not available from manufacturer. (3) Inspect air filter every 15,000 miles and replace as necessary. Replace at 30,000 miles unless previously replaced during inspection. (4) Replace coolant at 45,000 miles or 36 months whichever occurs first. Replace coolant at 36 months regardless of mileage. After first coolant change, replace coolant every 24 months or 30,000 miles thereafter. (5) Inspect at scheduled interval and replace as necessary. (6) Normal service interval is not available from manufacturer. Under severe service, change fluid, filter and adjust bands every 12,000 miles. (7) Normal service interval is not available from manufacturer. Manufacturer lists service schedule only under severe service conditions. |
| (1) | Different interval may be required for normal and severe service. Severe service is described as long periods of engine idling, frequent short trip operation of less than 5 miles, trailer towing, or operating in dusty or excessively hot conditions. |
| (2) | Monthly interval is not available from manufacturer. |
| (3) | Inspect air filter every 15,000 miles and replace as necessary. Replace at 30,000 miles unless previously replaced during inspection. |
| (4) | Replace coolant at 45,000 miles or 36 months whichever occurs first. Replace coolant at 36 months regardless of mileage. After first coolant change, replace coolant every 24 months or 30,000 miles thereafter. |
| (5) | Inspect at scheduled interval and replace as necessary. |
| (6) | Normal service interval is not available from manufacturer. Under severe service, change fluid, filter and adjust bands every 12,000 miles. |
| (7) | Normal service interval is not available from manufacturer. Manufacturer lists service schedule only under severe service conditions. |
REPLACEMENT INTERVALS (RAM VAN & RAM WAGON) (1)
DRIVE BELT ADJUSTMENT
| Application | New Belt | (1) Used Belt |
|---|
| Caravan |
| 2.4L |
| A/C & Generator | 190 (86) | 115 (52) |
| Power Steering | 140 (64) | 90 (41) |
| 3.0L |
| A/C | 150 (68) | 80 (36) |
| Generator & Power Steering | (2) | (2) |
| 3.3L & 3.8L | (2) | (2) |
| Dakota |
| 2.5L | 200 (91) | 160 (73) |
| 3.9L, 5.2L & 5.9L | (2) | (2) |
| Durango |
| 3.9L, 5.2L & 5.9L | (2) | (2) |
| Ram Pickup, Ram Van & Ram Wagon | (2) | (2) |
| Town & Country |
| 3.3L & 3.8L | (2) | (2) |
| Voyager |
| 2.4L |
| A/C & Generator | 190 (86) | 115 (52) |
| Power Steering | 140 (64) | 90 (41) |
| 3.0L |
| A/C | 150 (68) | 80 (36) |
| Generator & Power Steering | (2) | (2) |
| 3.3L | (2) | (2) |
| (1) Used belt is a belt that has been in service for more than 15 minutes. (2) Automatic belt tensioner is used. Belt tension adjustment is not required. |
| (1) | Used belt is a belt that has been in service for more than 15 minutes. |
| (2) | Automatic belt tensioner is used. Belt tension adjustment is not required. |
BELT ADJUSTMENT (TENSION IN LBS. (KG) USING BELT TENSION GAUGE)
ENGINE COMPRESSION
Ensure battery is fully charged. Warm engine to normal operating temperature. Disconnect wire at ignition coil to prevent engine from starting. Check engine compression with all spark plugs removed and throttle wide open.
| Application | Specification |
|---|
| Compression Ratio |
| Caravan |
| 2.4L | 9.4:1 |
| 3.0L | 8.9:1 |
| 3.3L | 8.9:1 |
| 3.8L | 9.6:1 |
| Dakota & Durango | 9.1:1 |
| Ram Pickup |
| 3.9L, 5.2L & 5.9L (Gasoline) | 9.1:1 |
| 5.9L (Diesel) | 17.5:1 |
| 8.0L | 8.4:1 |
| Ram Van & Ram Wagon | 9.1:1 |
| Town & Country |
| 3.3L | 8.9:1 |
| 3.8L | 9.6:1 |
| Voyager |
| 2.4L | 9.4:1 |
| 3.0L | 8.9:1 |
| 3.3L | 8.9:1 |
| Normal Compression Pressure |
| Caravan |
| 2.4L | 170-225 psi (11.9-15.7 kg/cm 2 ) |
| 3.0L | 178 psi (12.5 kg/cm 2 ) |
| 3.3L & 3.8L | (1) |
| Dakota |
| 2.5L | 120-150 psi (8.4-10.5 kg/cm 2 ) |
| 3.9L, 5.2L & 5.9L | (1) |
| Durango | (1) |
| Ram Pickup, Ram Van & Ram Wagon | (1) |
| Town & Country | (1) |
| Voyager |
| 2.4L | 170-225 psi (11.9-15.7 kg/cm 2 ) |
| 3.0L | 178 psi (12.5 kg/cm 2 ) |
| 3.3L | (1) |
| Minimum Compression Pressure |
| Caravan, Town & Country, & Voyager | 100 psi (7.0 kg/cm 2 ) |
| Dakota |
| 2.5L | (1) |
| 3.9L, 5.2L & 5.9L | 100 psi (7.0 kg/cm 2 ) |
| Durango | 100 psi (7.0 kg/cm 2 ) |
| Ram Pickup |
| 3.9L, 5.2L & 5.9L (Gasoline) & 8.0L | 100 psi (7.0 kg/cm 2 ) |
| 5.9L (Diesel) | (1) |
| Ram Van & Ram Wagon | 100 psi (7.0 kg/cm 2 ) |
| Maximum Variation Between Cylinders |
| Caravan, Town & Country, & Voyager | 25 Percent |
| Dakota |
| 2.5L | 30 psi (2.1 kg/cm 2 ) |
| 3.9L, 5.2L & 5.9L | (1) |
| Durango, Ram Pickup, Ram Van & Ram Wagon | (1) |
| (1) Information is not available from manufacturer. |
| (1) | Information is not available from manufacturer. |
COMPRESSION SPECIFICATIONS
Gasoline Models
All engines are equipped with hydraulic lifters. No adjustments are required.
5.9L Diesel (Ram Pickup)
Valve adjustment is recommended every 150 months or 150,000 miles during normal service, every 135,000 miles during severe service. Severe service is described as frequent short trip operation of less than 5 miles, long periods of engine idling, trailer towing, police, taxi, local delivery service, or operating in dusty or excessively hot conditions. See VALVE CLEARANCE SPECIFICATIONS (DIESEL) table.
| Application | In. (mm) |
|---|
| Intake Valve | .010 (.25) |
| Exhaust Valve | .020 (.51) |
| (1) Adjust valves with engine temperature less than 140°F (60°C). |
| (1) | Adjust valves with engine temperature less than 140°F (60°C). |
VALVE CLEARANCE SPECIFICATIONS (DIESEL) (1)
IGNITION COIL
| Application | Primary | Secondary |
|---|
| Caravan & Grand Caravan |
| 2.4L |
| Diamond (1) (2) | .53-.65 | 11,500-13,500 |
| Weastec (1) | .45-.65 | 10,900-14,700 |
| 3.0L | (3) | (3) |
| 3.3L & 3.8L | .45-.65 | 7000-15,800 |
| Dakota & Durango |
| Diamond (1) (2) | .97-1.18 | 11,300-15,300 |
| Toyodenso (1) | .95-1.20 | 11,300-13,300 |
| Ram Pickup |
| Except 8.0L |
| Diamond (1) (2) | .97-1.18 | 11,300-15,300 |
| Toyodenso (1) | .95-1.20 | 11,300-13,300 |
| 8.0L | .53-.65 | 10,900-14,700 |
| Ram Van & Ram Wagon |
| Diamond (1) (2) | .97-1.18 | 11,300-15,300 |
| Toyodenso (1) | .95-1.20 | 11,300-13,300 |
| Town & Country | .45-.65 | 7000-15,800 |
| Voyager & Grand Voyager |
| 2.4L |
| Diamond (1) (2) | .53-.65 | 11,500-13,500 |
| Weastec (1) | .45-.65 | 10,900-14,700 |
| 3.0L | (3) | (3) |
| 3.3L | .45-.65 | 7000-15,800 |
| (1) This is the manufacturer of ignition coil. (2) Brass terminals. (3) Information is not available from manufacturer. |
| (1) | This is the manufacturer of ignition coil. |
| (3) | Information is not available from manufacturer. |
IGNITION COIL RESISTANCE - Ohms @ 70-80°F (21-27°C)
HIGH TENSION WIRE RESISTANCE
| Application | Ohms |
|---|
| Caravan & Grand Caravan (As Applicable) (1) |
| 2.4L |
| Cylinder No. 1 Or 4 | 4200 |
| Cylinder No. 2 Or 3 | 3200 |
| 3.0L |
| Cylinder No. 1 | 14,000 |
| Cylinder No. 2 | 10,400 |
| Cylinder No. 3 | 14,900 |
| Cylinder No. 4 | 11,500 |
| Cylinder No. 5 | 17,500 |
| Cylinder No. 6 | 10,300 |
| Ignition Coil Wire | 11,100 |
| 3.3L & 3.8L |
| Cylinder No. 1 | 18,500 |
| Cylinder No. 2 | 15,500 |
| Cylinder No. 3 | 20,400 |
| Cylinder No. 4 | 21,200 |
| Cylinder No. 5 | 27,700 |
| Cylinder No. 6 | 26,700 |
| Dakota & Durango |
| All High Tension Wires | (2) |
| Ram Pickup, Ram Van & Ram Wagon |
| All High Tension Wires | (2) |
| Town & Country (1) |
| Cylinder No. 1 | 18,500 |
| Cylinder No. 2 | 15,500 |
| Cylinder No. 3 | 20,400 |
| Cylinder No. 4 | 21,200 |
| Cylinder No. 5 | 27,700 |
| Cylinder No. 6 | 26,700 |
| Voyager & Grand Voyager (As Applicable) (1) |
| 2.4L |
| Cylinder No. 1 Or 4 | 4200 |
| Cylinder No. 2 Or 3 | 3200 |
| 3.0L |
| Cylinder No. 1 | 14,000 |
| Cylinder No. 2 | 10,400 |
| Cylinder No. 3 | 14,900 |
| Cylinder No. 4 | 11,500 |
| Cylinder No. 5 | 17,500 |
| Cylinder No. 6 | 10,300 |
| Ignition Coil Wire | 11,100 |
| 3.3L |
| Cylinder No. 1 | 18,500 |
| Cylinder No. 2 | 15,500 |
| Cylinder No. 3 | 20,400 |
| Cylinder No. 4 | 21,200 |
| Cylinder No. 5 | 27,700 |
| Cylinder No. 6 | 26,700 |
| (1) Maximum wire resistance is listed according to high tension wire application. For cylinder identification, see FIRING ORDER & TIMING MARKS. (2) Resistance should be 250-1000 ohms per one inch or 3000-12,000 ohms per 12 inches. |
| (1) | Maximum wire resistance is listed according to high tension wire application. For cylinder identification, see FIRING ORDER & TIMING MARKS. |
| (2) | Resistance should be 250-1000 ohms per one inch or 3000-12,000 ohms per 12 inches. |
HIGH TENSION WIRE RESISTANCE
SPARK PLUGS
| Application | Champion No. |
|---|
| Caravan & Grand Caravan |
| 2.4L | RC12YC5 |
| 3.0L | RN11YC4 |
| 3.3L & 3.8L | RN14PMP5 |
| Dakota |
| 2.5L | RC12ECC |
| 3.9L, 5.2L & 5.9L | RC12LC4 |
| Durango | RC12LC4 |
| Ram Pickup |
| 3.9L, 5.2L & 5.9L | RC12LC4 |
| 8.0L | QC9MC4 |
| Ram Van & Ram Wagon | RC12LC4 |
| Town & Country | RN14PMP5 |
| Voyager & Grand Voyager |
| 2.4L | RC12YC5 |
| 3.0L | RN11YC4 |
| 3.3L | RN14PMP5 |
| (1) Check spark plug application on underhood vehicle emission control label. If application differs from application listed, use application on underhood vehicle emission control label. |
| (1) | Check spark plug application on underhood vehicle emission control label. If application differs from application listed, use application on underhood vehicle emission control label. |
| Application | Gap In. (mm) | Torque Ft. Lbs. (N.m) |
|---|
| Caravan & Grand Caravan |
| 2.4L | .048-.053 (1.22-1.35) | 20 (27) |
| 3.0L | .039-.044 (1.00-1.12) | 20 (27) |
| 3.3L & 3.8L | .048-.053 (1.22-1.35) | 20 (27) |
| Dakota |
| 2.5L | .035 (.89) | 30 (41) |
| 3.9L, 5.2L & 5.9L | .040 (1.01) | 30 (41) |
| Durango | .040 (1.01) | 30 (41) |
| Ram Pickup |
| 3.9L, 5.2L & 5.9L | .040 (1.01) | 30 (41) |
| 8.0L | .045 (1.14) | 30 (41) |
| Ram Van & Ram Wagon | .040 (1.01) | 30 (41) |
| Town & Country | .048-.053 (1.22-1.35) | 20 (27) |
| Voyager & Grand Voyager |
| 2.4L | .048-.053 (1.22-1.35) | 20 (27) |
| 3.0L | .039-.044 (1.00-1.12) | 20 (27) |
| 3.3L | .048-.053 (1.22-1.35) | 20 (27) |
| (1) Check spark plug gap specification on underhood vehicle emission control label. If specification differs from that listed above, use specification on underhood vehicle emission control label. |
| (1) | Check spark plug gap specification on underhood vehicle emission control label. If specification differs from that listed above, use specification on underhood vehicle emission control label. |
SPARK PLUG SPECIFICATIONS (1)
Firing Order 2.4L 4-Cyl. (Caravan & Voyager). Scheme 1
Scheme 1: Firing Order 2.4L 4-Cyl. (Caravan & Voyager)
Firing Order & Distributor Rotation 2.5L 4-Cyl. (Dakota). Scheme 2
Scheme 2: Firing Order & Distributor Rotation 2.5L 4-Cyl. (Dakota)
Firing Order & Distributor Rotation 3.0L V6 (Caravan & Voyager). Scheme 3
Scheme 3: Firing Order & Distributor Rotation 3.0L V6 (Caravan & Voyager)
Firing Order 3.3L & 3.8L V6 (Caravan, Town & Country, & Voyager). Scheme 4
Scheme 4: Firing Order 3.3L & 3.8L V6 (Caravan, Town & Country, & Voyager)
Firing Order & Distributor Rotation 3.9L V6 (Dakota, Durango, Ram Pickup, Ram Van & Ram Wagon). Scheme 5
Scheme 5: Firing Order & Distributor Rotation 3.9L V6 (Dakota, Durango, Ram Pickup, Ram Van & Ram Wagon)
Firing Order & Distributor Rotation 5.2L & 5.9L Gasoline V8 (Dakota, Durango, Ram Pickup, Ram Van & Ram Wagon). Scheme 6
Scheme 6: Firing Order & Distributor Rotation 5.2L & 5.9L Gasoline V8 (Dakota, Durango, Ram Pickup, Ram Van & Ram Wagon)
Firing Order 5.9L Diesel 6-Cyl. (Ram Pickup). Scheme 7
Scheme 7: Firing Order 5.9L Diesel 6-Cyl. (Ram Pickup)
Firing Order 8.0L V10 (Ram Pickup). Scheme 8
Scheme 8: Firing Order 8.0L V10 (Ram Pickup)
IGNITION TIMING
Note. On all models, ignition timing is controlled by Powertrain Control Module (PCM). Ignition timing is non-adjustable. DO NOT attempt to adjust ignition timing.
Note. On Dakota 3.9L, 5.2L and 5.9L, Durango, Ram Pickup 3.9L, 5.2L and 5.9L (gasoline), Ram Van and Ram Wagon, the distributor can be checked for proper location. See FUEL SYSTEM SYNCHRONIZATION under FUEL SYSTEM in ON-VEHICLE ADJUSTMENTS.
FUEL PUMP (GASOLINE)
| Application | Pressure psi (kg/cm 2 ) | Min. Vol. In 7 Sec. Pts. (L) |
|---|
| Caravan |
| 2.4L & 3.0L | (1) 43-53 (3.0-3.7) | (2) |
| 3.3L |
| Flex-Fuel | (1) 50-60 (3.5-4.2) | (2) |
| Except Flex-Fuel | (1) 43-53 (3.0-3.7) | (2) |
| 3.8L | (1) 43-53 (3.0-3.7) | (2) |
| Dakota & Durango | (3) 44-54 (3.0-3.8) | .5 (24) |
| Ram Pickup, Ram Van & Ram Wagon | (3) 44-54 (3.0-3.8) | .5 (24) |
| Town & Country |
| 3.3L |
| Flex-Fuel | (1) 50-60 (3.5-4.2) | (2) |
| Except Flex-Fuel | (1) 43-53 (3.0-3.7) | (2) |
| 3.8L | (1) 43-53 (3.0-3.7) | (2) |
| Voyager |
| 2.4L & 3.0L | (1) 43-53 (3.0-3.7) | (2) |
| 3.3L |
| Flex-Fuel | (1) 50-60 (3.5-4.2) | (2) |
| Except Flex-Fuel | (1) 43-53 (3.0-3.7) | (2) |
| (1) Manufacturer lists fuel pressure with engine off, ignition on and using scan tool to activate fuel pump. (2) Information is not available from manufacturer. (3) Manufacturer lists fuel pressure with engine idling. |
| (1) | Manufacturer lists fuel pressure with engine off, ignition on and using scan tool to activate fuel pump. |
| (2) | Information is not available from manufacturer. |
| (3) | Manufacturer lists fuel pressure with engine idling. |
FUEL INJECTION PUMP & FUEL TRANSFER PUMP (DIESEL)
Note. For fuel injection pump timing, see ON-VEHICLE ADJUSTMENTS article.
| Application | Output Pressure psi (kg/cm 2 ) |
|---|
| Ram Pickup 5.9L | (1) |
| (1) Pressure testing procedure and output pressure is not available from manufacturer. |
| (1) | Pressure testing procedure and output pressure is not available from manufacturer. |
FUEL INJECTION PUMP PERFORMANCE (DIESEL)
Note. For testing of fuel transfer pump, see BASIC DIAGNOSTIC PROCEDURES article.
FUEL INJECTOR OPENING PRESSURE (DIESEL)
| Application | Psi (kg/cm 2 ) |
|---|
| Ram Pickup 5.9L | 4500 (316) |
FUEL INJECTOR OPENING PRESSURE (DIESEL)
FUEL INJECTOR RESISTANCE
| Application | Ohms @ 68°F (20°C) |
|---|
| All Models | 10-16 |
IDLE SPEED & MIXTURE
Note. On all except diesel models, idle speed and mixture are controlled by Powertrain Control Module (PCM). No adjustment is required.
| Application | RPM |
|---|
| Gasoline Models | (1) |
| Diesel Models | (2) |
| (1) Idle speed is controlled by Powertrain Control Module PCM) and idle air control motor. Idle speed is nonadjustable. (2) Idle speed is controlled by PCM. Idle speed is nonadjustable. |
| (1) | Idle speed is controlled by Powertrain Control Module PCM) and idle air control motor. Idle speed is nonadjustable. |
| (2) | Idle speed is controlled by PCM. Idle speed is nonadjustable. |
IDLE SPEED SPECIFICATIONS
THROTTLE BODY MINIMUM AIRFLOW IDLE SPEED
| Application | RPM |
|---|
| Caravan |
| 2.4L (1) |
| 1000 Miles Or Less | (2) 500-875 |
| More Than 1000 Miles | (2) 550-875 |
| 3.0L (1) |
| 1000 Miles Or Less | (2) 560-910 |
| More Than 1000 Miles | (2) 610-910 |
| 3.3L & 3.8L (1) |
| 1000 Miles Or Less | (2) 525-875 |
| More Than 1000 Miles | (2) 575-875 |
| Dakota |
| 2.5L | (3) 500-900 |
| 3.9L, 5.2L & 5.9L | (3) 500-900 |
| Durango | (3) 500-900 |
| Ram Pickup |
| 3.9L, 5.2L & 5.9L (Gasoline) | (3) 500-900 |
| 8.0L | (4) |
| Ram Van & Ram Wagon | (3) 500-900 |
| Town & Country (1) |
| 1000 Miles Or Less | (2) 525-875 |
| More Than 1000 Miles | (2) 575-875 |
| Voyager |
| 2.4L (1) |
| 1000 Miles Or Less | (2) 500-875 |
| More Than 1000 Miles | (2) 550-875 |
| 3.0L (1) |
| 1000 Miles Or Less | (2) 560-910 |
| More Than 1000 Miles | (2) 610-910 |
| 3.3L (1) |
| 1000 Miles Or Less | (2) 525-875 |
| More Than 1000 Miles | (2) 575-875 |
| (1) Specification listed in accordance with vehicle mileage. (2) Specification listed with Air Metering Fitting (6457) installed. (3) Specification listed with Air Metering Fitting (6714) installed. (4) Does not apply to this application. |
| (1) | Specification listed in accordance with vehicle mileage. |
| (2) | Specification listed with Air Metering Fitting (6457) installed. |
| (3) | Specification listed with Air Metering Fitting (6714) installed. |
| (4) | Does not apply to this application. |
THROTTLE BODY MINIMUM AIRFLOW IDLE SPEED SPECIFICATIONS
THROTTLE POSITION SENSOR
| Throttle Opening | Volts |
|---|
| Caravan, Town & Country, & Voyager (1) (2) |
| At Idle | .38-1.20 |
| At Full Throttle | 3.10-4.40 |
| Dakota & Durango (1) (2) |
| At Idle | .26-.90 |
| At Full Throttle | Less Than 4.50 |
| Ram Pickup |
| 3.9L, 5.2L, 5.9L (Gasoline) & 8.0L (1) (2) |
| At Idle | .35-.90 |
| At Full Throttle | Less Than 4.50 |
| 5.9L (Diesel) | (3) |
| Ram Van & Ram Wagon (1) (2) |
| At Idle | .35-.90 |
| At Full Throttle | Less Than 4.50 |
| (1) Measure voltage at center terminal on throttle position sensor with ignition on. (2) Voltage should increase smoothly when moving throttle from idle to full throttle. (3) Diesel Accelerator Pedal Position Sensor (APPS) is not adjustable. Voltage should be less than one volt at idle and more than 3 volts at full throttle. |
| (1) | Measure voltage at center terminal on throttle position sensor with ignition on. |
| (2) | Voltage should increase smoothly when moving throttle from idle to full throttle. |
| (3) | Diesel Accelerator Pedal Position Sensor (APPS) is not adjustable. Voltage should be less than one volt at idle and more than 3 volts at full throttle. |
THROTTLE POSITION SENSOR VOLTAGE SPECIFICATIONS
