Maintenance Reminder Light Reset Procedures: Maintenance Dodge Cab & Chassis Dakota

Reset Procedures 8 illustrations ~3572 words

ASSYST MAINTENANCE COMPUTER

Note. To determine the appropriate reset procedure, refer to ASSYST MAINTENANCE COMPUTER RESET INDEX . Only vehicles listed in this index have an ASSYST Maintenance Computer reset.

Model & YearReset Procedure
Sprinter
2003-09Assyst Maintenance Computer Reset - Procedure 1

ASSYST MAINTENANCE COMPUTER RESET INDEX

ASSYST MAINTENANCE COMPUTER RESET - PROCEDURE 1

When a service as been performed, the ASSYST maintenance computer can be reset as follow

  1. Turn the key to position 2 in the ignition lock and immediately press the "mi" ("km") button twice and hold. Keep the "mi" ("km") button pressed.
  2. Within 10 seconds, return the key to position 0 in the ignition lock.
  3. Continue to press and hold the "mi" ("km") button. Turn the key to position 2 in the ignition lock. Keep the "mi" ("km") button pressed.
  4. The maintenance indicator with the current remaining time/distance is shown.
  5. After about 10 seconds, an acoustic signal will sound and the maintenance indicator is displayed with the new remaining time/distance.
  6. Release the "mi" ("km") button.

EGR/MAINTENANCE REQUIRED WARNING LIGHT

Note. To determine the appropriate reset procedure, refer to EGR/MAINTENANCE REQUIRED WARNING LIGHT RESET INDEX . Only vehicles listed in this index have an EGR/Maintenance Required Warning Light reset.

Model & YearReset Procedure
Colt & Colt Vista
1978-94EGR/Maintenance Required Warning Light Reset - Procedure 1
Ram-50
1985-93EGR/Maintenance Required Warning Light Reset - Procedure 1

EGR/MAINTENANCE REQUIRED WARNING LIGHT RESET INDEX

EGR/MAINTENANCE REQUIRED WARNING LIGHT RESET - PROCEDURE 1

  1. On some models, an EGR or MAINTENANCE REQUIRED warning light in dash will come on as a reminder to have EGR system serviced (each 50,000 miles), oxygen sensor replaced (each 80,000 miles), or evaporative carbon canister replaced (100,000 miles).
  2. After servicing or replacing components, reset mileage counter. Reset switch is located on back of instrument cluster. (Scheme 1), (Scheme 2) and (Scheme 3). Slide switch to opposite side to reset indicator light.
  3. Remove light bulb after 120,000 mile service on Ram-50.

Scheme 1

Scheme 1

Scheme 2

Scheme 2

Scheme 3

Scheme 3

EMR MILEAGE RESET

Note. To determine the appropriate reset procedure, refer to EMR MILEAGE RESET INDEX . Only vehicles listed in this index have a EMR mileage reset.

Model & YearReset Procedure
Light Duty Trucks & Vans
1989-92EMR Mileage Reset - Procedure 1

EMR MILEAGE RESET INDEX

EMR MILEAGE RESET - PROCEDURE 1

  1. Using DRB-II tester, select EMR MEMORY CHECK. DRB-II display will read, EMR MEMORY CHECK ARE YOU SURE? Press YES key.
  2. Display will read, WRITE TEST. Display will read, IS INSTRUMENT PANEL MILEAGE BETWEEN XXXXXX AND XXXXXX? If odometer mileage on vehicle is within specification, press YES key. DRB-II will display EMR MEMORY CHECK TEST COMPLETE. NOTE: DRB-II may display EMR MEMORY WRITE FAILURE or EMR MEMORY CHECK WRITE REFUSED if there is a problem with SMEC/SBEC.
  3. If odometer mileage on vehicle is not within specification shown on DRB-II, press NO key. DRB-II will read DO YOU WANT TO CORRECT EMR MILEAGE? Press YES key on DRB-II. DRB-II will display ENTER MILEAGE SHOWN ON INSTRUMENT PANEL.
  4. Enter mileage shown on instrument panel. DO NOT enter tenths. Press ENTER key on DRB-II. DRB-II will ask for verification of entry. If mileage entry was correct, DRB-II will display SETTING ENGINE DATA and EMR MEMORY CHECK TEST COMPLETE. Vehicle must be driven for at least 8 miles for mileage reset to be accepted.

MAINT REQD OR CHECK EGR INDICATOR LIGHT RESET - PROCEDURE 1

The Service Reminder Indicator (SRI) module is not an emissions warning system. It is only a reminder to perform emissions servicing. Components to be serviced include the EGR system, PCV valve, oxygen sensor, delay valves, and bi-level purge valve.

The SRI module will illuminate the MAINT REQD or CHECK EGR light after a predetermined time. The light will remain on until the SRI module is reset by inserting a small screwdriver into the hole in the module (RWD only) and/or depressing the reset switch (FWD and RWD). Replace 9-volt battery (if equipped).

The SRI module is located on steering column, behind instrument panel on RWD vans and in instrument cluster, under fuel gauge, on FWD vans. (Scheme 4)or (Scheme 5). On light trucks except Dakota, SRI module is located behind the far right side of dash panel next to glove box. (Scheme 6) On Dakota models, module is located on bracket below headlight switch, on rear of instrument panel. (Scheme 7)

Scheme 4

Scheme 4: MAINT REQD OR CHECK EGR INDICATOR LIGHT RESET - PROCEDURE 1

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Scheme 7

Scheme 7

MAINT REQD OR CHECK EGR INDICATOR LIGHT RESET - PROCEDURE 2

Note. If any other scan tool is used, use scan tool manufacturer's instructions.

Attach DRB-II tester to diagnostic connector. Turn ignition on but do not start engine. Access SELECT SYSTEMS function of DRB-II tester. Select appropriate engine. Select with or without A/C. Select FUEL & IGNITION. Select ADJUSTMENTS. Select RESET EMR LIGHT. Reset EMR light. When DRB-II is finished resetting light, DRB-II display will read EMR LIGHT IS RESET.

Note. If Single Module Engine Controller (SMEC) or Single Board Engine Controller (SBEC) is replaced, vehicle mileage must be programmed back into the SMEC/SBEC. DRB-II tester MUST be used for this procedure. If the following procedure is not performed, EMR light will not turn on at the proper mileage intervals.

MAINT REQD OR SRI LIGHT RESET - PROCEDURE 1

  1. Attach DRB tester to diagnostic connector. Turn ignition on, but do not start engine. Using DRB, perform Service Reminder Indicator (SRI) memory test. If DRB displays WRITE FAILURE, replace Powertrain Control Module (PCM).
  2. If DRB displays WRITE REFUSED, go to step 4 . If DRB displays SRI MILEAGE INVALID, update mileage and retest SRI memory. If DRB does not display SRI MILEAGE INVALID, compare SRI mileage stored with instrument panel odometer.
  3. If mileage is same, retest SRI memory. If mileage is not same, update mileage and retest SRI memory.
  4. PCM was busy. Using DRB, perform SRI memory test. Retest SRI memory 2 or more times, if necessary. If WRITE REFUSED trouble code returns, replace PCM. If WRITE REFUSED does not return, procedure is complete.

MAINT REQD OR SRI LIGHT RESET - PROCEDURE 2

The components to be serviced include the EGR system, PCV valve, and oxygen sensor. The SRI or Maintenance Required will illuminate after a predetermined mileage. To reset the light, a Chrysler Diagnostic Readout Box (DRB) Tester or suitable scan tool is required. Follow scan tool manufacturer's information to reset SRI.

OIL CHANGE REQUIRED MESSAGE RESET - PROCEDURE 1

Note. The message can be temporarily turned off by pressing and releasing the Trip Odometer button in instrument cluster.

To reset oil change indicator after performing scheduled maintenance

  1. Turn ignition on, with engine off. NOTE: On vehicles with keyless START, without pressing the brake pedal, push the ENGINE START/STOP button and cycle the ignition to the ON/RUN position (Do not start the engine).
  2. Fully depress accelerator pedal slowly 3 times within 10 seconds.
  3. Turn ignition off. NOTE: On vehicles with keyless START, without pressing the brake pedal, push the ENGINE START/STOP button once to return the ignition to the OFF/LOCK position.
  4. Start engine. If indicator message illuminates when engine is started, repeat reset procedure.

PERFORM SERVICE MESSAGE RESET - PROCEDURE 1

The PERFORM SERVICE message is a warning message delivered from the Electronic Vehicle Information Center (EVIC). This indicates that regular maintenance is due. After regular required maintenance is performed, the counter is reset by pressing and holding the reset button for 3 seconds.

PERFORM SERVICE MESSAGE RESET - PROCEDURE 2

  1. The Electronic Vehicle Information Center (EVIC) displays a PERFORM SERVICE message when distance to service interval has been reached, indicating that regular service and maintenance is due. After performing necessary services, reset service distance by selecting a distance to service interval.
  2. To program EVIC, turn ignition switch to ON position. Depress and release MENU push button until SERVICE INTV. = is displayed. Press and release STEP button to step through available options. The last selected distance option displayed becomes the service interval at which the PERFORM SERVICE message will be displayed.
  3. If a new distance interval is selected, RESET SERVICE DISTANCE? with a yes or no option. When YES is selected, the accumulated distance since the last previous PERFORM SERVICE message will be reset to zero because the service interval has been changed. When NO is selected, the distance until the next PERFORM SERVICE message is reduced by the accumulated distance since the last pervious message.
  4. EVIC exits programming mode and returns to its normal operation mode when the C/T button is depressed or when the end of the programmable feature menu list is reached, whichever occurs first.

PERFORM SERVICE MESSAGE RESET - PROCEDURE 3

The Vehicle Information Center (VIC) displays a PERFORM SERVICE message. PERFORM SERVICE message is displayed when "miles/kms" to service is zero, indicating that regular service and maintenance is due. After performing necessary services, reset service distance by pressing the STEP button when in this display will select "Yes" or "No".

PERFORM SERVICE MESSAGE RESET - PROCEDURE 4

  1. The Electronic Vehicle Information Center (EVIC) displays a PERFORM SERVICE message when distance to service interval has been reached, indicating that regular service and maintenance is due. After performing necessary services, reset service distance by selecting a distance to service interval.
  2. To program EVIC, turn ignition switch to ON position. Depress and release MENU push button until SERVICE INTV. = is displayed. Press and release STEP button to step through available options. The last selected distance option displayed becomes the service interval at which the PERFORM SERVICE message will be displayed.
  3. If a new distance interval is selected, RESET SERVICE DISTANCE? with a yes or no option. When YES is selected, the accumulated distance since the last previous PERFORM SERVICE message will be reset to zero because the service interval has been changed. When NO is selected, the distance until the next PERFORM SERVICE message is reduced by the accumulated distance since the last pervious message.
  4. EVIC exits programming mode and returns to its normal operation mode when the C/T button is depressed or when the end of the programmable feature menu list is reached, whichever occurs first.

SERVICE REMINDER INDICATOR LIGHT RESET - PROCEDURE 1

A mileage counter activates the service reminder indicator between 12,000 and 30,000 mile intervals, depending on whether mechanical or electronic type is used. On 1987 Dakota models, mileage counter in the odometer will illuminate reminder light at 52,500, 82,500 and 105,000 miles.

The electronic type uses a 9-volt battery which supplies power to the electronic counter, preventing memory loss when vehicle battery is disconnected.

Note. Vehicle battery must be connected during resetting procedure to prevent power loss to memory.

To reset electronic type, locate Green, Red, White or Tan plastic case behind instrument panel in lower left cluster area. Slide case from bracket and open cover. Remove 9-volt battery, and insert a small rod or screwdriver into hole in switch, closing contacts. Replace battery with a new 9-volt alkaline type. Close case. Slide case back into bracket. (Scheme 8)

Note. Some models use a non-resettable mileage counter. Replace it with a resettable type.

Scheme 8

Scheme 8: SERVICE REMINDER INDICATOR LIGHT RESET - PROCEDURE 1

SERVICE REMINDER INDICATOR LIGHT RESET - PROCEDURE 2

Every 7500 miles, a Vehicle Maintenance Monitor (VMM) will illuminate a SERVICE interval reminder indicator light. This indicates regular maintenance is due. After required service is performed, press RESET button on dash below VMM display. Hold button until a beep is heard. VMM display will now be clear.

SERVICE REMINDER MESSAGE RESET - PROCEDURE 1

Every 7500 miles or 12 months which ever comes first, a service reminder message on Electronic Vehicle Information Center (EVIC) display will illuminate, indicating an oil change is due. The EVIC is an optional accessory located in the overhead console.

Pressing INFO button with the ignition on will activate a MONITORED SYSTEMS OK message on the display if all systems are operating properly. If service is required, SERVICE REMINDER message will be displayed. Pressing the RESET button after message has been displayed will clear the message.

SERVICE REMINDER MESSAGE RESET - PROCEDURE 2

Every 7500 miles or 12 months which ever comes first, a service reminder message on Electronic Vehicle Information Center (EVIC) display will illuminate, indicating an oil change is due. The EVIC is an optional accessory located in the overhead console.

Pressing INFO button with the ignition on will activate a MONITORED SYSTEMS OK message on the display if all systems are operating properly. If service is required, SERVICE REMINDER message will be displayed. To clear message, press INFO button and within 5 seconds, press SET button.

TPMS RESET - PROCEDURE 1

Note. In a low tire pressure siuation, the TPMS indicator light (and message) will turn OFF only after the tires are inflated to the vehicles recommended cold placard pressure value. The vehicle may need to be driven for up to 20 minutes above 20 mph (32 km/h) in order for the TPMS to determine that the inflation pressures are correct.

Once a sensor has been replaced and vehicle has remained stationary for more than 20 minutes, drive vehicle for a minimum of 20 minutes while maintaining a continuous speed above 20 mph (32 km/h). During this time, the system will learn the new sensor ID code and will clear any DTCs automatically. If a sensor cannot be trained, see appropriate manufacturer service information.

Note. The sensor IDs can also be programmed using the TPM-RKE Analyzer Tool. Scan each TPM sensor at each road wheel, and store each Sensor ID in the correct location (Left Front, Left Rear, Right Front, and Right Rear). Connect the TPM-RKE Analyzer Tool to the Scan Tool. Then follow the programming steps outlined in the diagnostic Scan Tool for "Program Tire Pressure Sensor ID w/ TPM Tool".

TPMS Indicator Reset

Once a sensor has been replaced and vehicle has remained stationary for more than 20 minutes, drive vehicle for a minimum of 10 minutes while maintaining a continuous speed above 20 mph (32 km/h). During this time, the system will learn the new sensor ID code and will clear any DTCs automatically. If a sensor cannot be trained, see appropriate manufacturer service information.

TPMS RESET - PROCEDURE 3

Note. If a tire is changed (tire rotation), one or more tire pressure sensors fail, or if TPM module is replaced, the TPM system needs to relearn tire pressure sensor IDs. The procedure is similar to Tire Sensors Programming in TPMS RESET - PROCEDURE 2.

When tire pressure is low, the "Low Tire" Pressure Indicator Lamp signal circuit will be pulsed to ground by the TPM module for two seconds on and then two seconds off, over and over. The BCM will then illuminate the "Low Tire" Pressure Indicator Lamp at the same rate and sound the audible chime as one single long tone.

When tire pressure is critical, the low tire pressure warning lamp signal circuit will be pulsed to ground by the low tire pressure warning module for one second on and then one second off, over and over. The BCM will then illuminate the "Low Tire" Pressure Indicator Lamp and sound the audible chime at the rate of one second on and one second off.

In either case, the TPM module will continue to pulse to ground the "Low Tire" Pressure Indicator Lamp signal circuit until the sensor/transmitter(s) transmits a pressure above the calibrated thresholds (and car is then driven above 20 mph (32 km/h)) or the ignition is turned off. If the conditions has not been corrected when the ignition is turned off, the indicator lamp will remain off when the ignition is turned on again until the vehicle reaches a speed of approximately 20 mph (32 km/h).

Note. In the event a diagnostic trouble code (DTC) is set, the "Low Tire" Pressure Indicator Lamp will illuminate continuously until the ignition is turned off. A low tire pressure condition cannot set a diagnostic trouble code (DTC).

TPMS RESET - PROCEDURE 4

The TPMS will not turn off the indicator lamp until the tire pressure is at or above the Low Pressure (lamp) OFF threshold. The system will automatically update and the TPM indicator lamp will extinguish once the updated tire pressures have been received.

Note. If a tire pressure sensor has been replaced, the TPM system needs to relearn tire pressure sensor IDs.

Wireless Control Module (WCM): The WCM automatically learns and stores new sensor IDs while driving "within 10-20 minutes continuously above 15 mph (24 km/h)" after a sensor has been replaced. The learning sequence will initiate when the vehicle has been stopped for more then 20 minutes.

A new sensor ID can also be programmed directly into the WCM by using an RKE-TPM Analyzer in conjunction with a Scan Tool. Scan each TPM sensor at each road wheel, and store each Sensor ID in the correct location. (Left Front, Left Rear, Right Front, and Right Rear) Connect the TPM-RKE Analyzer Tool to the Scan Tool. Then follow the programming steps outlined in the diagnostic Scan Tool for "Program Tire Pressure Sensor ID w/ TPM Tool"

For further information, refer to the Owners Manual or the Appropriate Diagnostic Information.

TPMS RESET - PROCEDURE 5

There are two tire pressure monitoring systems available, a base system and a premium system. The base system does not specify how many tires are low or where they are located. The premium system does indicate which tire is low. Sensor types are the Tire Pressure Monitoring (TPM) module for the 2500/3500 series, or the Wireless Ignition Node (WIN) for the 1500 series.

Base Tire Pressure Monitoring System

The TPMS will not turn off the indicator lamp until the tire pressure is at or above specified tire pressure. The system will automatically update and the TPM indicator lamp will extinguish once the updated tire pressures have been received.

Premium Tire Pressure Monitoring System

If the TPMS detects that the tire pressure in any road tire is going low, a chime will sound and the indicator lamp will turn on. In addition to the chime and lamp, a graphic display of the pressure value(s) and position of the low tire(s) will flash in the Electronic Vehicle Information Center (EVIC). Once pressure in the suspect tire(s) raises above the specified tire pressure, and the TPM module receives a valid transmission from the sensor the lamp will go out. If a system fault is detected due to a missing sensor signal, in addition to a chime and a indicator lamp flashing, a "Check TPM System" text message will be displayed in the instrument cluster, and the tire pressure graphic display will display "- -" in place of the pressure value. After the flash sequence the TPM indicator lamp will remain illuminated. The system will return to normal once the TPM module receives a valid transmission from that sensor location. If a system fault is detected, the indicator lamp will flash on/off for 75 seconds and then remain on solid.

Base and Premium Systems

Note. If a tire pressure sensor has been replaced, the TPM system needs to relearn tire pressure sensor IDs.

The WIN or TPM automatically learns and stores the sensor IDs while driving "within 10-20 minutes continuously above 15 mph (24 km/h)" after a sensor has been replaced. The learning sequence will initiate after the vehicle has been stopped for more than 20 minutes.

A new sensor ID can also be programmed directly into the WIN or TPM module by using a RKE-TPM Analyzer in conjunction with a Scan Tool. Once the new sensor ID has been programmed, the vehicle will need to be driven above 15 mph until the fault is no longer active (lamp extinguishes) and display is updated (for up to 20 minutes).

Note. The matching full size spare wheel and tire assembly (if equipped) has a TPM sensor. The spare can be used in place of any of the four road tires. The TPMS will only monitor the pressure in the full size spare when it is used in place of a road tire. Otherwise, a spare with pressure below the low-pressure limit will not cause the TPMS indicator light to illuminate or the chime to sound.

TPMS RESET - PROCEDURE 6

Note. If tires have been rotated or a tire pressure sensor has been replaced, the tire pressure sensors must be retrained. Refer to the following procedure to program the module for identification of one new or all tire pressure sensor/transmitters.

Note. The vehicle's tires must not have been rotated above 5 mph (8 km/h) in the last two minutes prior to programming.

  1. Connect a DRBIII® scan tool to the vehicle's diagnostic connector beneath the instrument panel, to the right of the steering column.
  2. Access the Chassis System using the DRBIII.
  3. Once in the Chassis System, select Tire Pressure Monitor, followed by Miscellaneous.
  4. Select the appropriate function from the next screen displaying the following options: Program LF Pressure Sensor Program RF Pressure Sensor Program RR Pressure Sensor Program LR Pressure Sensor Program Module (4 Sensors) Monitor
  5. Place a magnet (or special tool 8821), at the valve stem for that wheel as directed by the DRBIII. If the Program Module function has been chosen, the DRBIII will direct you to the left front wheel pressure sensor/transmitter first.
  6. When that wheels pressure sensor/transmitter has been programmed, the DRBIII will display Program Transmitter Complete or will automatically direct you to the next wheel sensor/transmitter to be programmed.
  7. Remove the magnet and if programming the entire module, move the magnet to each of the remaining wheels as directed by the DRBIII. Each sensor/transmitter will automatically sense the presence of the magnet and begin programming.
  8. Once Program Transmitter Complete is displayed, exit the program function screen.
  9. Verify that the module programming is complete by looking at the tire pressure sensor/transmitter ID's in the Sensor Display using the DRBIII.
