B210B-SYSTEM VOLTAGE HIGH
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With the ignition switch on.
The Power Top Control Module (PTCM) has detected the system voltage above 16 volts for over 15 seconds.
| Possible Causes |
|---|
| GENERATOR FIELD CONTROL CIRCUIT SHORTED TO BATTERY VOLTAGE |
| POWERTRAIN CONTROL MODULE (PCM) |
| GENERATOR |
With the ignition on.
When battery voltage at the Power Top Control Module (PTCM) is less than 10 volts for over one minute.
| Possible Causes |
|---|
| RESISTANCE IN THE BATTERY POSITIVE CIRCUIT |
| RESISTANCE IN THE GENERATOR CASE GROUND |
| GENERATOR OPERATION |
| GENERATOR FIELD CONTROL CIRCUIT OPEN |
| GENERATOR FIELD CONTROL CIRCUIT SHORTED TO GROUND |
| BOTH (Z916) AND (Z908) GROUND CIRCUITS OPEN |
| BOTH THE (A926) AND (A927) FUSED B(+) CIRCUITS OPEN |
| POWERTRAIN CONTROL MODULE (PCM) |
| POWER TOP CONTROL MODULE (PTCM) |
Scheme 63
Scheme 64
Scheme 65
- DETERMINING IF DTC IS CURRENT NOTE: Diagnose any related Powertrain DTC(s) before continuing. With a scan tool, read and record PTCM DTCs. With the scan tool, erase the DTCs. Perform five ignition cycles, leaving the ignition switch on for a minimum of 90 seconds per cycle. Using the scan tool, read the PTCM DTCs. Does the scan tool display this DTC as Active? Yes Go To 3 . No Go To 2 .
- INTERMITTENT CONDITION NOTE: Check for any of the follow conditions: Poor wire to terminal connection Corroded terminals Backed out or loose terminals Broken wire internal to the insulation Dirty (partial) module ground With the ignition on, wiggle the related wires. Using a scan tool, read the DTCs. Does the DTC reset? Yes Repair the wiring as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No DTC is not active at this time. Test complete.
- CHECK FOR MULTIPLE BATTERY VOLTAGE LOW DTCS With a scan tool, read and record DTCs. With the scan tool, clear DTCs. Perform five ignition cycles, leaving the ignition switch on for a minimum of 90 seconds per cycle. Using the scan tool, read DTCs. Are multiple other modules reporting this DTC? Yes Check the possible causes table above for conditions that can cause a system low voltage condition. Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Go To 4 .
- (A926) AND (A927) FUSED B(+) CIRCUITS OPEN NOTE: Check the related fuses to the Fused B(+) circuits. If the fuses are found to be open, repair the circuits for a shorted condition. Turn the ignition off. Disconnect the PTCM C2 harness connector. Turn the ignition on. Using a 12 volt test light connected to ground, check the (A926) and (A927) Fused B(+) circuits in the PTCM C2 harness connector. Does the test light illuminate brightly? Yes Go To 5 . No Repair the Fused B(+) circuits for an open. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
- (Z916) AND (Z908) GROUND CIRCUITS OPEN Turn the ignition off. Using a 12-volt test light connected to battery, check the (Z908) and (Z916) Ground circuits in the PTCM C2 harness connector. Does the test light illuminate brightly in both Ground circuits? Yes Go To 6 . No Repair the (Z916) and (Z908) Ground circuits for an open. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
- CHECK SYSTEM VOLTAGE AT THE PTCM Turn the ignition off. Reconnect the PTCM C2 connector. Start the engine. Using the scan tool, view battery voltage under Data Display in the Engine category. NOTE: The graphic shows the terminal end of the connector for reference only, back probe the wire end. Using a voltmeter, back probe the (A926) and then the (A927) Fused B(+) circuits. Compare the voltage on the scan tool to the voltage readings on the voltmeter. NOTE: If charging system voltage readings are acceptable on both the scan tool and at the (A926 and A927) Fused (B+) circuits at the Power Top Control Module and no other modules are reporting this DTC then replacing the Power Top Control Module is the most likely course of action. Is the voltage on the scan tool equal to the voltmeter readings (+/- 0.5 volt) back probed at the connector? Yes Replace and program the Power Top Control Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No Repair the Fused (B+) circuits for high resistances. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.
