Amplifier (Amp) - Electrical Diagnostics: Diagnosis Dodge Avenger II facelift

Entertainment Systems 4 illustrations ~1716 words

DIAGNOSTIC CODE INDEX

DTCDescription
B1460CHANNEL 1 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B1461CHANNEL 1 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B1462CHANNEL 1 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B1463CHANNEL 1 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B1464CHANNEL 1 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B1465CHANNEL 2 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B1466CHANNEL 2 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B1467CHANNEL 2 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B1468CHANNEL 2 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B1469CHANNEL 2 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B146ACHANNEL 3 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B146BCHANNEL 3 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B146CCHANNEL 3 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B146DCHANNEL 3 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B146ECHANNEL 3 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B146FCHANNEL 4 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B1470CHANNEL 4 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B1471CHANNEL 4 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B1472CHANNEL 4 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B1473CHANNEL 4 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B1474CHANNEL 5 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B1475CHANNEL 5 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B1476CHANNEL 5 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B1477CHANNEL 5 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B1478CHANNEL 5 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B1479CHANNEL 6 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B147ACHANNEL 6 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B147BCHANNEL 6 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B147CCHANNEL 6 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B147DCHANNEL 6 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B221FAMPLIFIER INTERNAL
U0019CAN B BUS
U0020CAN B BUS OFF PERFORMANCE
U0141LOST COMMUNICATION WITH IPM (FCM/TIPM)
U0155LOST COMMUNICATION WITH CLUSTER/CCN
U0184LOST COMMUNICATION WITH RADIO
U0196LOST COMMUNICATION WITH VEHICLE ENTERTAINMENT CONTROL MODULE
U0197LOST COMMUNICATION WITH HANDS FREE PHONE MODULE
U0199LOST COMMUNICATION WITH DRIVER DOOR MODULE
U0200LOST COMMUNICATION WITH PASSENGER DOOR MODULE

DIAGNOSTIC CODE INDEX

DIAGNOSTIC TEST

  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on and open one of the front doors. NOTE: A front door must remain open whenever checking or erasing Amplifier DTCs. Using the scan tool, record and erase the Amplifier DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the Radio on and set the volume to 25. Adjust the speakers to the front and center. Using the scan tool, read the active Amplifier DTCs. Does the scan tool display active: B1460-CHANNEL 1 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-485529-S24369246162012071300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-485529-S24369246162012071300000) .

Scheme 20

Scheme 20: B1461-CHANNEL 1 AUDIO SPEAKER OUTPUT CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on and open one of the front doors. NOTE: A front door must remain open whenever checking or erasing Amplifier DTCs. Using the scan tool, record and erase the Amplifier DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the Radio on and set the volume to 25. Adjust the speakers to the front and center. Using the scan tool, read the active Amplifier DTCs. Does the scan tool display active: B1465-CHANNEL 2 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-485529-S24369246162012071300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

Scheme 21

Scheme 21: B1466-CHANNEL 2 AUDIO SPEAKER OUTPUT CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on and open one of the front doors. NOTE: A front door must remain open whenever checking or erasing Amplifier DTCs. Using the scan tool, record and erase the Amplifier DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the Radio on and set the volume to 25. Adjust the speakers to the front and center. Using the scan tool, read the active Amplifier DTCs. Does the scan tool display active: B146A-CHANNEL 3 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-485529-S24369246162012071300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-485529-S24369246162012071300000) .

Scheme 22

Scheme 22: B146B-CHANNEL 3 AUDIO SPEAKER OUTPUT CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on and open one of the front doors. NOTE: A front door must remain open whenever checking or erasing Amplifier DTCs. Using the scan tool, record and erase the Amplifier DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the Radio on and set the volume to 25. Adjust the speakers to the front and center. Using the scan tool, read the active Amplifier DTCs. Does the scan tool display active: B146F-CHANNEL 4 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-485529-S24369246162012071300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-485529-S24369246162012071300000) .
  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on and open one of the front doors. NOTE: A front door must remain open whenever checking or erasing Amplifier DTCs. Using the scan tool, record and erase the Amplifier DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the Radio on and set the volume to 25. Adjust the speakers to the front and center. Using the scan tool, read the active Amplifier DTCs. Does the scan tool display active: B1474-CHANNEL 5 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-485529-S24369246162012071300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .

Scheme 23

Scheme 23: B1475-CHANNEL 5 AUDIO SPEAKER OUTPUT CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on and open one of the front doors. NOTE: A front door must remain open whenever checking or erasing Amplifier DTCs. Using the scan tool, record and erase the Amplifier DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the Radio on and set the volume to 25. Adjust the speakers to the front and center. Using the scan tool, read the active Amplifier DTCs. Does the scan tool display active: B1479-CHANNEL 6 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-485529-S24369246162012071300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) .
  1. REPLACE THE AMPLIFIER IF DTC IS ACTIVE With the scan tool, read the active DTCs. Cycle the ignition switch from off to on. With the scan tool, read the active DTCs. Does the scan tool display this DTC as active? Yes Replace the Amplifier in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) . No If the DTC is stored, check for an intermittent condition. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals.
  1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «U0141-LOST COMMUNICATION WITH IPM (FCM/TIPM)»(ref-485529-S32074441492012071300000) and perform the U0141-Lost Communication with IPM (FCM/TIPM) diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.
  1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «U0155-LOST COMMUNICATION WITH CLUSTER/CCN»(ref-485529-S17191963192012071300000) and perform the U0155-Lost Communication with Cluster/CCN diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.
  1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «U0184-LOST COMMUNICATION WITH RADIO»(ref-485529-S40159287352012071300000) and perform the U0184-Lost Communication with Radio diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.
  1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «U0196-LOST COMMUNICATION WITH VEHICLE ENTERTAINMENT CONTROL MODULE»(ref-485493-S14790328002012071300000) and perform the U0196-Lost Communication with Vehicle Entertainment Control Module diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.
  1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «U0197-LOST COMMUNICATION WITH HANDS FREE PHONE MODULE (HFM)»(ref-485529-S41525900412012071300000) and perform the U0197-Lost Communication with Hands Free Phone Module diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.
  1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «U0199-LOST COMMUNICATION WITH DRIVER DOOR MODULE»(ref-485529-S39271847462012071300000) and perform the U0199-Lost Communication with Drive Door Module diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.
  1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «U0200-LOST COMMUNICATION WITH PASSENGER DOOR MODULE»(ref-485529-S19544055862012071300000) and perform the U0200-Lost Communication with Passenger Door Module diagnostic procedure. No Refer to «COMMUNICATION - DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.
