Heating & Air Conditioning (Atc) - Electrical Diagnostics: Other Dodge Avenger II facelift

WHEN MONITORED

With the ignition on.

SET CONDITION

If the A/C On/Off Control Switch is stuck in an On position for more than two minutes. This DTC has a de-maturing time of one second. If the DTCs status changes from active to stored, the DTC will stay in memory for 100 ignition cycles.

POSSIBLE CAUSES

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

With the ignition on.

If the Panel Mode switch is stuck in the On position for more than two minutes. This DTC has a de-maturing time of one second. If the DTCs status changes from active to stored, the DTC will stay in memory for 100 ignition cycles.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

With the ignition on.

If the Bi-level Mode Switch is stuck in the On position for more than two minutes. This DTC has a de-maturing time of one second. If the DTCs status changes from active to stored, the DTC will stay in memory for 100 ignition cycles.

With the ignition on.

If the Recirculation mode switch is stuck in a On position for more than two minutes. This DTC has a de-maturing time of one second. If the DTCs status changes from active to stored, the DTC will stay in memory for 100 ignition cycles.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

B100C-FLOOR MODE SWITCH REQUEST INPUT CIRCUIT/PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

If the Floor Mode Switch is stuck in the On position for more than two minutes. This DTC has a de-maturing time of one second. If the DTCs status changes from active to stored, the DTC will stay in memory for 100 ignition cycles.

B100F-MIX SWITCH REQUEST INPUT CIRCUIT/PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

If the Mix Mode Switch is stuck in the On position for more than two minutes. This DTC has a de-maturing time of one second. If the DTCs status changes from active to stored, the DTC will stay in memory for 100 ignition cycles.

With the ignition on.

If the Defrost Mode Switch is stuck in an On position for more than two minutes. This DTC has a de-maturing time of one second. If the DTCs status changes from active to stored, the DTC will stay in memory for 100 ignition cycles.

With the ignition on.

If the Electric Back light (EBL) Electronic Rear Defrost switch is stuck in an On position for more than two minutes. This DTC has a de-maturing time of one second. If the DTCs status changes from active to stored, the DTC will stay in memory for 100 ignition cycles.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

With the ignition on.

The Evaporator Temperature Sensor voltage input to the A/C Heater Control is equal to or below 0.01 volts for a continuous period of five seconds. If the A/C Heater Control detects a valid voltage, the Diagnostic Trouble Code (DTC) will change from active to stored and will stay stored for 100 ignition cycles.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 2

Scheme 3

1. CHECK IF THE DTC IS ACTIVE Ignition on, engine not running. Using the scan tool, read HVAC DTCs. Is this DTC active? Yes Go To 2 . No Go To 5 .
2. CHECK (C21) EVAPORATOR TEMPERATURE SENSOR SIGNAL CIRCUIT FOR A SHORT TO GROUND Turn the ignition off to the lock position. Disconnect the A/C Heater Control C1 harness connector. Disconnect the Evaporator Temperature Sensor harness connector. Measure the resistance between ground and the (C21) Evaporator Temperature Sensor Signal circuit. Is the resistance below 100k Ohms? Yes Repair the (C21) Evaporator Temperature Sensor Signal circuit for a short to ground. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 3 .
3. CHECK (C21) EVAPORATOR TEMPERATURE SENSOR SIGNAL CIRCUIT FOR A SHORT TO THE (C121) SENSOR GROUND CIRCUIT Measure the resistance between the (C21) Evaporator Temperature Sensor Signal circuit and the (C121) Sensor Ground circuit. Is the resistance below 100k Ohms? Yes Repair the (C21) Evaporator Temperature Sensor Signal circuit for a short to (C121) Sensor Ground circuit. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 4 .
4. CHECK THE EVAPORATOR TEMPERATURE SENSOR Replace the Evaporator Temperature Sensor in Accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . Cycle the ignition off for 30 seconds then back on and wait a minimum of 5 seconds. With the scan tool read HVAC DTCs. Does this DTC reset? Yes Replace and program the A/C Heater Control in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete.
5. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the scan tool, check the Environmental Data to help identify the conditions in which the DTC was set. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Wiggle the wiring and connectors while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete.

With the ignition on.

The Evaporator Temperature Sensor voltage input to the A/C Heater Control is equal to or above 4.95 volts for a continuous period of five seconds. If the A/C Heater Control detects a valid voltage, the DTC will change from Active to Stored and will stay in the controllers memory for 100 ignition cycles.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 4

Scheme 5

Scheme 6

Scheme 7

1. CHECK (C21) EVAPORATOR TEMPERATURE SENSOR SIGNAL CIRCUIT VOLTAGE Ignition on, engine not running. Using the scan tool, read HVAC DTCs. Is this DTC active? Yes Go To 2 . No Go To 7 .
2. CHECK THE (C21) EVAPORATOR TEMPERATURE SENSOR SIGNAL CIRCUIT VOLTAGE Turn the ignition off to the lock position. Disconnect the Evaporator Temperature Sensor harness connector. NOTE: Due to the small terminal and pin size of the Evaporator Temperature Sensor and harness connector, make sure to not damage the terminals in this process. Connect a jumper wire between the (C21) Evaporator Temperature Sensor Signal circuit and the (C121) Sensor Ground circuit in the Evaporator Temperature Sensor harness connector. Ignition on, engine not running. Using the scan tool, read the Evaporator Temperature Sensor voltage. Is the voltage below 0.1 of a volt? Yes Replace the Evaporator Temperature Sensor in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 3 .
3. CHECK THE (C21) EVAPORATOR TEMPERATURE SENSOR SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off to the lock position. Disconnect the jumper wire from the Evaporator Temperature Sensor harness connector. Disconnect the A/C Heater Control C1 harness connector. Ignition on, engine not running. Measure the voltage of the (C21) Evaporator Temperature Sensor Signal circuit Is there any voltage present? Yes Repair the (C21) Evaporator Temperature Sensor Signal circuit for a short to voltage. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 4 .
4. CHECK THE (C21) EVAPORATOR TEMPERATURE SENSOR SIGNAL CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Measure the resistance of the (C21) Evaporator Temperature Sensor Signal circuit between the A/C Heater Control C1 harness connector and the Evaporator Temperature Sensor harness connector. Is the resistance above 1.0 Ohm? Yes Repair the (C21) Evaporator Temperature Sensor Signal circuit for an open or high resistance. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 5 .
5. CHECK THE (C121) SENSOR GROUND CIRCUIT FOR AN OPEN Measure the resistance of the (C121) Sensor Ground circuit between the A/C Heater Control C1 harness connector and the Evaporator Temperature Sensor harness connector. Is the resistance above 1.0 Ohm? Yes Repair the (C121) Sensor Ground circuit for an open. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 6 .
6. CHECK THE EVAPORATOR TEMPERATURE SENSOR Replace the Evaporator Temperature Sensor in Accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . Cycle the ignition off for 30 seconds then back on and wait a minimum of 5 seconds. With the scan tool read HVAC DTCs. Does this DTC reset? Yes Replace and program the A/C Heater Control in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete.
7. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the scan tool, check the Environmental Data to help identify the conditions in which the DTC was set. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Wiggle the wiring and connectors while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete.

With the ignition on.

When the Infrared (IR) Temperature Sensor Pulse Width Modulated (PWM) signal to the A/C Heater Control is less than 9.5% for a continuous period of 123 msec. If the A/C Heater Control detects a valid PWM signal, the DTC will change from active to stored and will stay stored for 100 ignition cycles.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

1. CHECK IF DTC IS ACTIVE Ignition on, engine not running. With the scan tool, read HVAC DTCs. Is this DTC active? Yes Go To 2 . No Go To 10 .
2. IDENTIFY THE VEHICLE Pick below what best describes the vehicle you are working on. JS27 Two Door Go To 3 . JS41 Four Door Go To 6 .
3. CHECK THE (F202) IGNITION SWITCH OUTPUT (RUN-START) CIRCUIT FOR AN OPEN (JS27) Turn the ignition off to the lock position. Disconnect the Infrared Sensor harness connector. Ignition on, engine not running. With a test light connected to ground, check the (F202) Ignition Switch Output (Run-Start) circuit. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Go To 4 . No Repair the (F202) Ignition Switch Output (Run-Start) circuit for an open. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) .
4. CHECK THE (C83) IR SENSOR SIGNAL CIRCUIT FOR A SHORT TO GROUND (JS27) Turn the ignition off to the lock position. Disconnect the A/C Heater Control harness connector. Measure the resistance between ground and the (C83) IR Sensor Signal circuit. Is the resistance below 100k Ohms? Yes Repair the (C83) IR Sensor Signal circuit for a short to ground. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 5 .
5. CHECK THE (C83) IR SENSOR SIGNAL CIRCUIT FOR AN OPEN (JS27) Measure the resistance of the (C83) IR Sensor Signal circuit between the A/C Heater Control harness connector. Is the resistance below 100k Ohms? Yes Repair the (C83) IR Sensor Signal circuit for an open. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 9 .
6. CHECK THE (F202) IGNITION SWITCH OUTPUT (RUN-START) CIRCUIT FOR AN OPEN (JS41) Turn the ignition off to the lock position. Disconnect the Infrared Sensor harness connector. Ignition on, engine not running. With a test light connected to ground, check the (F202) Ignition Switch Output (Run-Start) circuit. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Go To 7 . No Repair the (F202) Ignition Switch Output (Run-Start) circuit for an open. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) .
7. CHECK THE (C83) IR SENSOR SIGNAL CIRCUIT FOR A SHORT TO GROUND (JS41) Turn the ignition off to the lock position. Disconnect the A/C Heater Control harness connector. Measure the resistance between ground and the (C83) IR Sensor Signal circuit. Is the resistance below 100k Ohms? Yes Repair the (C83) IR Sensor Signal circuit for a short to ground. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 8 .
8. CHECK THE (C83) IR SENSOR SIGNAL CIRCUIT FOR AN OPEN (JS41) Measure the resistance of the (C83) IR Sensor Signal circuit between the A/C Heater Control harness connector. Is the resistance below 100k Ohms? Yes Repair the (C83) IR Sensor Signal circuit for an open. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 9 .
9. CHECK THE INFRARED SENSOR Replace the Infrared Sensor in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . Did the DTC reset performing the HVAC Verification Test? Yes Replace and program the A/C Heater Control in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete.
10. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. With the scan tool, check the Environmental Data to help identify the conditions in which the DTC was set. Were there any problems found? Yes Repair as necessary. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete.

With the ignition on.

When the Infrared (IR) Temperature Sensor Pulse Width Modulated (PWM) signal to the A/C Heater Control is greater than 84.3% for a continuous period of 123 msec. or more. If the A/C Heater Control detects a valid PWM signal, the DTC will change from active to stored and will stay stored for 100 ignition cycles.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

1. CHECK IF DTC IS ACTIVE Ignition on, engine not running. With the scan tool, read HVAC DTCs. Is this DTC active? Yes Go To 3 . No Go To 10 .
2. IDENTIFY THE VEHICLE Pick below what best describes the vehicle you are working on. JS27 Two Door Go To 3 . JS41 Four Door Go To 6 .
3. CHECK THE (C83) IR SENSOR SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE (JS27) Turn the ignition off to the lock position. Disconnect the A/C Heater Control harness connector. Disconnect the Infrared Sensor harness connector. Ignition on, engine not running. Measure the voltage of the (C83) IR Sensor Signal circuit. Is there any voltage present? Yes Repair the (C83) IR Sensor Signal circuit for a short to voltage. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 4 .
4. CHECK THE (C830) IR SENSOR RETURN CIRCUIT FOR A SHORT TO VOLTAGE (JS27) Measure the voltage of the (C830) IR Sensor Return circuit. Is there any voltage present? Yes Repair the (C830) IR Sensor Return circuit for a short to voltage. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 5 .
5. CHECK THE (C830) IR SENSOR RETURN CIRCUIT FOR AN OPEN (JS27) Turn the ignition off to the lock position. Measure the resistance of the (C830) IR Sensor Return circuit between the A/C Heater Control harness connector and the Infrared Sensor harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (C830) IR Sensor Return circuit for an open. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 9 .
6. CHECK THE (C83) IR SENSOR SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE (JS41) Turn the ignition off to the lock position. Disconnect the A/C Heater Control harness connector. Disconnect the Infrared Sensor harness connector. Ignition on, engine not running. Measure the voltage of the (C83) IR Sensor Signal circuit. Is there any voltage present? Yes Repair the (C83) IR Sensor Signal circuit for a short to voltage. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 7 .
7. CHECK THE (C830) IR SENSOR RETURN CIRCUIT FOR A SHORT TO VOLTAGE (JS41) Measure the voltage of the (C830) IR Sensor Return circuit. Is there any voltage present? Yes Repair the (C830) IR Sensor Return circuit for a short to voltage. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 8 .
8. CHECK THE (C830) IR SENSOR RETURN CIRCUIT FOR AN OPEN (JS41) Turn the ignition off to the lock position. Measure the resistance of the (C830) IR Sensor Return circuit between the A/C Heater Control harness connector and the Infrared Sensor harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (C830) IR Sensor Return circuit for an open. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 9 .
9. CHECK THE INFRARED SENSOR Replace the Infrared Sensor in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . Did the DTC reset performing the HVAC Verification Test? Yes Replace and program the A/C Heater Control in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete.
10. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. With the scan tool, check the Environmental Data to help identify the conditions in which the DTC was set. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Wiggle the wiring and connectors while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete.

Scheme 20

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on and an actuator movement is commanded by the A/C Heater Control or during an HVAC Actuator Calibration Test.

If an actuator move is commanded by A/C Heater Control and an overcurrent condition is detected in either clockwise or counterclockwise movement for the period of five seconds. If the A/C Heater Control detects valid current draw for ten seconds, the DTC will change from Active to Stored and will stay in the controllers memory for 100 ignition cycles.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 21

Scheme 22

Scheme 23

Scheme 24

1. CHECK IF DTC IS ACTIVE Ignition on, engine not running. With the scan tool, read HVAC DTCs. Is this DTC active? Yes Go To 3 . No Go To 2 .
2. PERFORM HVAC ACTUATOR CALIBRATION TEST With the scan tool, perform the HVAC Actuator Calibration Test. Did this DTC change from Stored to Active while performing the HVAC Actuator Calibration Test? Yes Go To 3 . No Go To 9 .
3. CHECK THE (C35) MODE DOOR DRIVER CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off to the lock position. Disconnect the A/C Heater Control C1 harness connector. Disconnect the Mode Door Actuator harness connector. Ignition on, engine not running. Measure the voltage of the (C35) Mode Door Driver circuit. Is there any voltage present? Yes Repair the (C35) Mode Door Driver circuit for a short to voltage. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 4 .
4. CHECK THE (C34) COMMON DOOR DRIVER CIRCUIT FOR A SHORT TO VOLTAGE Measure the voltage of the (C34) Common Door Driver circuit. Is there any voltage present? Yes Repair the (C34) Common Door Driver circuit for a short to voltage. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 5 .
5. CHECK THE (C35) MODE DOOR DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off to the lock position. Measure the resistance between ground and the (C35) Mode Door Driver circuit. Is the resistance below 100k Ohms? Yes Repair the (C35) Mode Door Driver circuit for a short to ground. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 6 .
6. CHECK THE (C34) COMMON DOOR DRIVER CIRCUIT FOR A SHORT TO GROUND Measure the resistance between ground and the (C34) Common Door Driver circuit. Is the resistance below 100k Ohms? Yes Repair the (C34) Common Door Driver circuit for a short to ground. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 7 .
7. CHECK THE MODE DOOR Remove the Mode Door Actuator and check the Mode Door for binding and full travel. Were there any problems found? Yes Repair or replace the Mode Door as necessary in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 8 .
8. CHECK THE MODE DOOR ACTUATOR Replace the Mode Door Actuator in accordance with the Service Information. With the scan tool, erase HVAC DTCs and perform the HVAC System Test. Did this DTC reset? Yes Replace and program the A/C Heater Control in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) .
9. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the scan tool, check the Environmental Data to help identify the conditions in which the DTC was set. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Wiggle the wiring and connectors while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete.

With the ignition on and when a HVAC Actuator Calibration Test is performed.

If an HVAC Actuator Calibration Test is performed the A/C Heater Control detects there are no feedback pulses detected in that direction, the controller commands the actuator in the opposite direction. If no feedback pulses are detected in either direction this DTC will set. If the A/C Heater Control detects a valid pulse feedback in both directions, the DTC will change from Active to Stored and will stay in the controllers memory for 100 ignition cycles.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 25

Scheme 26

Scheme 27

1. CHECK FOR OTHER DTCS Ignition on, engine not running. With the scan tool, read HVAC DTCs. Is there more than one Door Control Circuit Open DTC present? Yes Repair the (C34) Common Door Driver circuit for an open. NOTE: Due to the common shared driver circuit, probable area of concern is the splice, or from the splice to the A/C Heater Control harness connector. Make sure to check all inline connectors. No Go To 2 .
2. CHECK IF DTC IS ACTIVE Ignition on, engine not running. With the scan tool, read HVAC DTCs. Is this DTC active? Yes Go To 4 . No Go To 3 .
3. PERFORM HVAC ACTUATOR CALIBRATION TEST With the scan tool, perform the HVAC Actuator Calibration Test. Did this DTC change from Stored to Active while performing the HVAC Actuator Calibration Test? Yes Go To 4 . No Go To 7 .
4. CHECK THE MODE DOOR ACTUATOR Turn the ignition off to the lock position. Disconnect the A/C Heater Control C1 harness connector. Measure the resistance between the (C35) Mode Door Driver circuit and the (C34) Common Door Driver circuit. Is the resistance 38.0 Ohms (± 5.0 Ohms)? Yes Replace and program the A/C Heater Control in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 5 .
5. CHECK THE (C35) MODE DOOR DRIVER CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the Mode Door Actuator harness connector. Measure the resistance of the (C35) Mode Door Driver circuit between the A/C Heater Control C1 harness connector and the Mode Door Actuator harness connector. Is the resistance above 1.0 Ohm? Yes Repair the (C35) Mode Door Driver circuit for an open or high resistance. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 6 .
6. CHECK THE (C34) COMMON DOOR DRIVER CIRCUIT FOR AN OPEN Measure the resistance of the (C34) Common Door Driver circuit between the A/C Heater Control C1 harness connector and the Mode Door Actuator harness connector. Is the resistance above 1.0 Ohm? Yes Repair the (C34) Common Door Driver circuit for an open or high resistance. NOTE: Probable location is the wiring harness splice or the wiring between the splice and the door actuator. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Replace the Mode Door Actuator in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) .
7. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the scan tool, check the Environmental Data to help identify the conditions in which the DTC was set. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Wiggle the wiring and connectors while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete.

When ever an Actuator Calibration Test is performed.

The A/C Heater Control uses a pulse feedback to the controller to detect the total door movement range. If the amount of pulses required to move the door completely in both directions is less than what the controller has stored in its memory, this DTC will set. If an Actuator Calibration Test is performed and the A/C Heater Control detects a valid range of the door movement span in both directions, the DTC will change from Active to Stored and will stay in the controllers memory for 100 ignition cycles.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

During normal operation or when ever an Actuator Calibration Test is performed.

The A/C Heater Control uses a pulse feedback to the controller to detect the total door movement range. If the amount of pulses required to move the door completely in both directions is greater than what the controller has stored in its memory, this DTC will set. If an Actuator Calibration Test is performed or during normal operation and the A/C Heater Control detects a valid range of the door movement span in both directions, the DTC will change from Active to Stored and will stay in the controllers memory for 100 ignition cycles.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

With the ignition on and an actuator movement is commanded by the A/C Heater Control or during an HVAC Actuator Calibration Test.

If an actuator move is commanded by A/C Heater Control and an overcurrent condition is detected in either clockwise or counterclockwise movement for the period of five seconds. If the A/C Heater Control detects valid current draw for ten seconds, the DTC will change from Active to Stored and will stay in the controllers memory for 100 ignition cycles.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 28

Scheme 29

Scheme 30

Scheme 31

1. CHECK IF DTC IS ACTIVE Ignition on, engine not running. With the scan tool, read HVAC DTCs. Is this DTC active? Yes Go To 3 . No Go To 2 .
2. PERFORM HVAC ACTUATOR CALIBRATION TEST With the scan tool, perform the HVAC Actuator Calibration Test. Did this DTC change from Stored to Active while performing the HVAC Actuator Calibration Test? Yes Go To 3 . No Go To 9 .
3. CHECK THE (C32) RECIRCULATION DOOR DRIVER CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off to the lock position. Disconnect the A/C Heater Control C1 harness connector. Disconnect the Recirculation Door Actuator harness connector. Ignition on, engine not running. Measure the voltage of the (C32) Recirculation Door Driver circuit. Is there any voltage present? Yes Repair the (C32) Recirculation Door Driver circuit for a short to voltage. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 4 .
4. CHECK THE (C34) COMMON DOOR DRIVER CIRCUIT FOR A SHORT TO VOLTAGE Measure the voltage of the (C34) Common Door Driver circuit. Is there any voltage present? Yes Repair the (C34) Common Door Driver circuit for a short to voltage. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 5 .
5. CHECK THE (C32) RECIRCULATION DOOR DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off to the lock position. Measure the resistance between ground and the (C32) Recirculation Door Driver circuit. Is the resistance below 100k Ohms? Yes Repair the (C32) Recirculation Door Driver circuit for a short to ground. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 6 .
6. CHECK THE (C34) COMMON DOOR DRIVER CIRCUIT FOR A SHORT TO GROUND Measure the resistance between ground and the (C34) Common Door Driver circuit. Is the resistance below 100k Ohms? Yes Repair the (C34) Common Door Driver circuit for a short to ground. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 7 .
7. CHECK THE RECIRCULATION DOOR Remove the Recirculation Door Actuator and check the Recirculation Door for binding and full travel. Were there any problems found? Yes Repair or replace the Recirculation Door as necessary in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 8 .
8. CHECK THE RECIRCULATION DOOR ACTUATOR Replace the Recirculation Door Actuator in accordance with the Service Information. With the scan tool, erase HVAC DTCs and perform the HVAC Actuator Calibration Test. Did this DTC reset? Yes Replace and program the A/C Heater Control in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) .
9. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the scan tool, check the Environmental Data to help identify the conditions in which the DTC was set. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Wiggle the wiring and connectors while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete.

B105B-RECIRCULATION DOOR CONTROL CIRCUIT OPEN

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on and when a HVAC Actuator Calibration Test is performed.

If an HVAC Actuator Calibration Test is performed the A/C Heater Control detects there are no feedback pulses detected in that direction, the controller commands the actuator in the opposite direction. If no feedback pulses are detected in either direction this DTC will set. If the A/C Heater Control detects a valid pulse feedback in both directions, the DTC will change from Active to Stored and will stay in the controllers memory for 100 ignition cycles.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 32

Scheme 33

Scheme 34

1. CHECK FOR OTHER DTCS Ignition on, engine not running. With the scan tool, read HVAC DTCs. Is there more than one Door Control Circuit Open DTC present? Yes Repair the (C34) Common Door Driver circuit for an open. NOTE: Due to the common shared driver circuit, probable area of concern is the splice, or from the splice to the A/C Heater Control harness connector. Make sure to check all inline connectors. No Go To 2 .
2. CHECK IF DTC IS ACTIVE Ignition on, engine not running. With the scan tool, read HVAC DTCs. Is this DTC active? Yes Go To 4 . No Go To 3 .
3. PERFORM HVAC ACTUATOR CALIBRATION TEST With the scan tool, perform the HVAC Actuator Calibration Test. Did this DTC change from Stored to Active while performing the HVAC Actuator Calibration Test? Yes Go To 4 . No Go To 7 .
4. CHECK THE RECIRCULATION DOOR ACTUATOR Turn the ignition off to the lock position. Disconnect the A/C Heater Control C1 harness connector. Measure the resistance between the (C32) Recirculation Door Driver circuit and the (C34) Common Door Driver circuit. Is the resistance 38.0 Ohms (± 5.0 Ohms)? Yes Replace and program the A/C Heater Control in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 5 .
5. CHECK THE (C32) RECIRCULATION DOOR DRIVER CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the Recirculation Door Actuator harness connector. Measure the resistance of the (C32) Recirculation Door Driver circuit between the A/C Heater Control C1 harness connector and the Recirculation Door Actuator harness connector. Is the resistance above 1.0 Ohm? Yes Repair the (C32) Recirculation Door Driver circuit for an open or high resistance. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 6 .
6. CHECK THE (C34) COMMON DOOR DRIVER CIRCUIT FOR AN OPEN Measure the resistance of the (C34) Common Door Driver circuit between the A/C Heater Control C1 harness connector and the Recirculation Door Actuator harness connector. Is the resistance above 1.0 Ohm? Yes Repair the (C34) Common Door Driver circuit for an open or high resistance. NOTE: Probable location is the wiring harness splice or the wiring between the splice and the door actuator. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Replace the Recirculation Door Actuator in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) .
7. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the scan tool, check the Environmental Data to help identify the conditions in which the DTC was set. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Wiggle the wiring and connectors while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete.

B105C-RECIRCULATION DOOR TRAVEL RANGE TOO SMALL

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

When ever an Actuator Calibration Test is performed.

The A/C Heater Control uses a pulse feedback to the controller to detect the total door movement range. If the amount of pulses required to move the door completely in both directions is less than what the controller has stored in its memory, this DTC will set. If an Actuator Calibration Test is performed and the A/C Heater Control detects a valid range of the door movement span in both directions, the DTC will change from Active to Stored and will stay in the controllers memory for 100 ignition cycles.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

B105D-RECIRCULATION DOOR TRAVEL RANGE TOO LARGE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During normal operation or when ever an Actuator Calibration Test is performed.

The A/C Heater Control uses a pulse feedback to the controller to detect the total door movement range. If the amount of pulses required to move the door completely in both directions is greater than what the controller has stored in its memory, this DTC will set. If an Actuator Calibration Test is performed or during normal operation and the A/C Heater Control detects a valid range of the door movement span in both directions, the DTC will change from Active to Stored and will stay in the controllers memory for 100 ignition cycles.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

B10A2-LEFT BLEND DOOR 1 CONTROL CIRCUIT/PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on and an actuator movement is commanded by the A/C Heater Control or during an HVAC Actuator Calibration Test.

If an actuator move is commanded by A/C Heater Control and an overcurrent condition is detected in either clockwise or counterclockwise movement for the period of five seconds. If the A/C Heater Control detects valid current draw for ten seconds, the DTC will change from Active to Stored and will stay in the controllers memory for 100 ignition cycles.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 35

Scheme 36

Scheme 37

Scheme 38

1. CHECK IF DTC IS ACTIVE Ignition on, engine not running. Using the scan tool, read HVAC DTCs. Is this DTC active? Yes Go To 3 . No Go To 2 .
2. PERFORM HVAC ACTUATOR CALIBRATION TEST Using the scan tool, perform the HVAC Actuator Calibration Test. Did this DTC change from Stored to Active while performing the HVAC Actuator Calibration Test? Yes Go To 3 . No Go To 9 .
3. CHECK THE (C61) BLEND DOOR DRIVER CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off to the lock position. Disconnect the A/C Heater Control C1 harness connector. Disconnect the Blend Door Actuator harness connector. Ignition on, engine not running. Measure the voltage of the (C61) Blend Door Driver circuit. Is there any voltage present? Yes Repair the (C61) Blend Door Driver circuit for a short to voltage. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 4 .
4. CHECK THE (C34) COMMON DOOR DRIVER CIRCUIT FOR A SHORT TO VOLTAGE Measure the voltage of the (C34) Common Door Driver circuit. Is there any voltage present? Yes Repair the (C34) Common Door Driver circuit for a short to voltage. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 5 .
5. CHECK THE (C61) BLEND DOOR DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off to the lock position. Measure the resistance between ground and the (C61) Blend Door Driver circuit. Is the resistance below 100k Ohms? Yes Repair the (C61) Blend Door Driver circuit for a short to ground. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 6 .
6. CHECK THE (C34) COMMON DOOR DRIVER CIRCUIT FOR A SHORT TO GROUND Measure the resistance between ground and the (C34) Common Door Driver circuit. Is the resistance below 100k Ohms? Yes Repair the (C34) Common Door Driver circuit for a short to ground. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 7 .
7. CHECK THE BLEND DOOR Remove the Blend Door Actuator and check the Blend Door for binding and full travel. Were there any problems found? Yes Repair or replace the Blend Door as necessary in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 8 .
8. CHECK THE BLEND DOOR ACTUATOR Replace the Blend Door Actuator in accordance with the Service Information. Using the scan tool, erase HVAC DTCs and perform the HVAC Actuator Calibration Test. Did this DTC reset? Yes Replace and program the A/C Heater Control in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) .
9. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the scan tool, check the Environmental Data to help identify the conditions in which the DTC was set. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Wiggle the wiring and connectors while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete.

B10A5-LEFT BLEND DOOR CONTROL CIRCUIT OPEN

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on and when a HVAC Actuator Calibration Test is performed.

If an HVAC Actuator Calibration Test is performed the A/C Heater Control detects there are no feedback pulses detected in that direction, the controller commands the actuator in the opposite direction. If no feedback pulses are detected in either direction this DTC will set. If the A/C Heater Control detects a valid pulse feedback in both directions, the DTC will change from Active to Stored and will stay in the controllers memory for 100 ignition cycles.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 39

Scheme 40

Scheme 41

1. CHECK FOR OTHER DTCS Ignition on, engine not running. Using the scan tool, read HVAC DTCs. Is there more than one Door Control Circuit Open DTC present? Yes Repair the (C34) Common Door Driver circuit for an open. NOTE: Due to the common shared driver circuit, probable area of concern is the splice, or from the splice to the A/C Heater Control harness connector. Make sure to check all inline connectors. No Go To 2 .
2. CHECK IF DTC IS ACTIVE Ignition on, engine not running. Using the scan tool, read HVAC DTCs. Is this DTC active? Yes Go To 4 . No Go To 3 .
3. PERFORM HVAC ACTUATOR CALIBRATION TEST Using the scan tool, perform the HVAC Actuator Calibration Test. Did this DTC change from Stored to Active while performing the HVAC Actuator Calibration Test? Yes Go To 4 . No Go To 7 .
4. CHECK THE BLEND DOOR ACTUATOR Turn the ignition off to the lock position. Disconnect the A/C Heater Control C1 harness connector. Measure the resistance between the (C61) Blend Door Driver circuit and the (C34) Common Door Driver circuit. Is the resistance 38.0 Ohms (± 5.0 Ohms)? Yes Replace and program the A/C Heater Control in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 5 .
5. CHECK THE (C61) BLEND DOOR DRIVER CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the Blend Door Actuator harness connector. Measure the resistance of the (C61) Blend Door Driver circuit between the A/C Heater Control C1 harness connector and the Blend Door Actuator harness connector. Is the resistance above 1.0 Ohm? Yes Repair the (C61) Blend Door Driver circuit for an open or high resistance. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 6 .
6. CHECK THE (C34) COMMON DOOR DRIVER CIRCUIT FOR AN OPEN Measure the resistance of the (C34) Common Door Driver circuit between the A/C Heater Control C1 harness connector and the Blend Door Actuator harness connector. Is the resistance above 1.0 Ohm? Yes Repair the (C34) Common Door Driver circuit for an open or high resistance. NOTE: Probable location is the wiring harness splice or the wiring between the splice and the door actuator. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Replace the Blend Door Actuator in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) .
7. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the scan tool, check the Environmental Data to help identify the conditions in which the DTC was set. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Wiggle the wiring and connectors while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete.

B10A6-LEFT BLEND DOOR 1 TRAVEL TOO SMALL

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

When ever an Actuator Calibration Test is performed.

The A/C Heater Control uses a pulse feedback to the controller to detect the total door movement range. If the amount of pulses required to move the door completely in both directions is less than what the controller has stored in its memory, this DTC will set. If an Actuator Calibration Test is performed and the A/C Heater Control detects a valid range of the door movement span in both directions, the DTC will change from Active to Stored and will stay in the controllers memory for 100 ignition cycles.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

B10A7-LEFT BLEND DOOR TRAVEL TOO LARGE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

During normal operation or when ever an Actuator Calibration Test is performed.

The A/C Heater Control uses a pulse feedback to the controller to detect the total door movement range. If the amount of pulses required to move the door completely in both directions is greater than what the controller has stored in its memory, this DTC will set. If an Actuator Calibration Test is performed or during normal operation and the A/C Heater Control detects a valid range of the door movement span in both directions, the DTC will change from Active to Stored and will stay in the controllers memory for 100 ignition cycles.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

With ever an A/C Cooldown Test is performed.

This DTC is set whenever the A/C Cooldown Test is performed and the desired temperature drop is not achieved by the system. The DTC will go to stored after a successful A/C Cooldown Test.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

B160F-TWILIGHT/AMBIENT LIGHT SENSOR 1 INPUT CIRCUIT/PERFORMANCE

For a complete wiring diagram, refer to the appropriate SYSTEM WIRING DIAGRAMS article .

Continuously with the ignition on.

If the Auto Headlamps Signal input voltage is less than 1.9 volts and greater than 0.5 of a volt for period of five seconds. This DTC has a de-maturing time of 10 seconds. If the DTCs status changes from active to stored, the DTC will stay in memory for 100 ignition cycles.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 42

1. CHECK IF THE DTC IS ACTIVE Ignition on, engine not running. Using the scan tool, read HVAC DTCs. Is this DTC active? Yes Go To 2 . No Go To 4 .
2. CHECK (L24) AUTO HEADLAMPS SIGNAL CIRCUIT FOR A SHORT TO GROUND Turn the ignition off to the lock position. Disconnect the A/C Heater Control C1 harness connector. Disconnect the Sun Sensor harness connector. Measure the resistance between ground and the (L24) Auto Headlamps Signal circuit. Is the resistance below 100k Ohms? Yes Repair the (L24) Auto Headlamps Signal circuit for a short to ground. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 3 .
3. CHECK THE A/C HEATER CONTROL Replace the Sun Sensor in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . Did this DTC reset while performing the HVAC Verification Test? Yes Replace and program the A/C Heater Control in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete.
4. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the scan tool, check the Environmental Data to help identify the conditions in which the DTC was set. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Wiggle the wiring and connectors while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete.

With the ignition on.

If the Twilight or Ambient Light Sensor input voltage is less than 0.5 of a volt for the period of five seconds.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

With the ignition on.

If the Twilight or Ambient Light Sensor input voltage is greater than 4.5 volts for period of five seconds.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 43

Scheme 44

Scheme 45

1. CHECK IF THE DTC IS ACTIVE Ignition on, engine not running. Using the scan tool, read HVAC DTCs. Is this DTC active? Yes Go To 2 . No Go To 6 .
2. CHECK THE (L24) AUTO HEADLAMPS SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off. Disconnect the A/C Heater Control C1 harness connector. Ignition on, engine not running. Measure the voltage of the (L24) Auto Headlamps Signal circuit. Is there any voltage present? Yes Repair the (L24) Auto Headlamps Signal circuit for a short to voltage. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 3 .
3. CHECK THE (L24) AUTO HEADLAMPS SIGNAL CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the Sun Sensor harness connector. Measure the resistance of the (L24) Auto Headlamps Signal circuit between the A/C Heater Control C1 harness connector and the Sun Sensor harness connector. Is the resistance below 5.0 Ohms? Yes Go To 4 . No Repair the (L24) Auto Headlamps Signal circuit for an open. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) .
4. CHECK THE (G939) SUN SENSOR RETURN CIRCUIT FOR AN OPEN Measure the resistance of the (G939) Sun Sensor Return circuit between the A/C Heater Control C1 harness connector and the Sun Sensor harness connector. Is the resistance below 5.0 Ohms? Yes Go To 5 . No Repair the (G939) Sun Sensor Return circuit for an open. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) .
5. CHECK THE SUN SENSOR AND A/C HEATER CONTROL Replace the Sun Sensor in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . Did this DTC reset while performing the HVAC Verification Test? Yes Replace and program the A/C Heater Control in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete.
6. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the scan tool, check the Environmental Data to help identify the conditions in which the DTC was set. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Wiggle the wiring and connectors while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete.

Scheme 46

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

If the controller battery voltage is less than or equal to 10.0 volts for period of 5.0 seconds.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 47

Scheme 48

Scheme 49

1. CHECK FOR CHARGING SYSTEM DTCS Using the scan tool, read PCM DTCs. Are there any charging system DTCs present in the Powertrain Control Module (PCM)? Yes Refer to «2.4L - DIAGNOSTIC CODE INDEX»(ref-485540) or «3.6L - DIAGNOSTIC CODE INDEX»(ref-485548) and perform the appropriate diagnostic procedure . No Go To 2 .
2. CHECK FOR TOTALLY INTEGRATED POWER MODULE DTCS Using the scan tool, read TIPM DTCs. Are there any TIPM DTCS present? Yes Refer to «TIPM - DIAGNOSIS AND TESTING»(ref-485529-S21413626642012071300000) and perform the appropriate diagnostic procedure. No Go To 3 .
3. CHECK IF THE DTC IS ACTIVE Using the scan tool, read HVAC DTCs. Is this DTC active? Yes Go To 4 . No Go To 7 .
4. CHECK THE (F921) FUSED RUN RELAY OUTPUT CIRCUIT FOR AN OPEN Ignition on, engine not running. While back probing, measure the voltage of the (F921) Fused Run Relay Output circuit in the A/C Heater Control C1 harness connector. Is the voltage 10.0 volts or below? Yes Repair the (F921) Fused Run Relay Output circuit for an open or high resistance. NOTE: If the fuse is open, make sure to check for a short to ground on the (F921) Fused Run Relay Output circuit. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 5 .
5. CHECK THE (A417) FUSED B(+) CIRCUIT FOR AN OPEN Ignition on, engine not running. While back probing, measure the voltage of the (A417) Fused B(+) circuit in the A/C Heater Control C1 harness connector. Is the voltage 10.0 volts or below? Yes Repair the (A417) Fused B(+) circuit for an open or high resistance. NOTE: If the fuse is open, make sure to check for a short to ground on the (A417) Fused B(+) circuit. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Go To 6 .
6. CHECK THE (Z912) GROUND CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the A/C Heater Control C1 harness connector. Using a 12-volt test light connected to 12-volts, check the (Z912) Ground circuit. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Replace and program the A/C Heater Control in accordance with the Service Information. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Repair the (Z912) Ground circuit for an open. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) .
7. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the scan tool, check the Environmental Data to help identify the conditions in which the DTC was set. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Wiggle the wiring and connectors while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform the HVAC VERIFICATION TEST. Refer to «HVAC VERIFICATION TEST»(ref-485533-S34738617912012071300000) . No Test complete.

B210B-SYSTEM VOLTAGE HIGH

For a complete wiring diagram, refer to the appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

If the controller battery voltage is higher than 16.0 volts for period of 5.0 seconds.

Always perform the HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding. Refer to HVAC PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

With the ignition on.

If the A/C Heater Control has an internal fault. This DTC has a maturing time of 5 seconds and a de-maturing time of 10 seconds. If the DTC's status changes from active to stored it will stay in memory for 100 ignition cycles.

B222A-VEHICLE LINE MISMATCH

For a complete wiring diagram refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

The A/C Heater Control will receive and monitor the vehicle line message from the PCM and record the vehicle line if different from the last vehicle line.

Continuously

If the CAN Interior Bus (+) or CAN Interior Bus (-) circuit is open, shorted to voltage, or shorted to ground.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the TIPM for approximately two to five seconds.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the ORC for approximately two to five seconds.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Cluster for approximately two to five seconds.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Intrusion Transceiver Control Module (ITM) for approximately two to five seconds.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the WCM for approximately two to five seconds.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Radio for approximately two to five seconds.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the AMP for approximately two to five seconds.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Vehicle Entertainment Control Module (VES3) for approximately two to five seconds.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Hands Free Phone Module (HFM) for approximately two to five seconds.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Driver Door Module (DDM) for approximately two to five seconds.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Passenger Door Module (PDM) for approximately two to five seconds.

Continuously when the ignition is on.

Battery voltage between 10 and 16 volts.

Ignition Off Draw (IOD) fused installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Power Top Control Module (PTCM) for approximately two to five seconds.
