SPECIAL TOOLS
7700 - Tester, Cooling System (Originally Shipped In Kit Number(s) 7700-A.) 8266B - End Play Socket Set (Originally Shipped In Kit Number(s) 8283, 8527, 8575, 8575CC.) 8286 - Refractometer
Scheme 19
Scheme 20
Scheme 21
Scheme 22
The accessory drive belt for all engines is a Poly-V type belt.
The accessory drive belt for the 2.0, 2.4L and 3.6L engines drive the generator, A/C compressor, and power steering pump.
Scheme 23
Accessory drive belt tension for all engines is maintained by a non-adjustable automatic drive belt tensioner.
Scheme 24
| 1 - NORMAL CRACKS BELT OK |
|---|
| 2 - NOT NORMAL CRACKS REPLACE BELT |
When diagnosing accessory drive belts, small cracks (1) that run across ribbed surface of belt from rib to rib, are considered normal. These are not a reason to replace belt. However, cracks running along a rib (not across) are not normal. Any belt with cracks running along a rib must be replaced. Also replace belt if it has excessive wear, frayed cords or severe glazing.
| CONDITION | POSSIBLE CAUSES | CORRECTION |
|---|---|---|
| RIB CHUNKING (ONE OR MORE RIBS HAS SEPARATED FROM BELT BODY) | 1. Foreign objects imbedded in pulley grooves. | 1. Remove foreign objects from pulley grooves. Replace belt. |
| 2. Installation damage. | 2. Replace belt. | |
| RIB OR BELT WEAR | 1. Pulley(s) misaligned. | 1. Align pulley(s). |
| 2. Abrasive environment. | 2. Clean pulley(s). Replace belt if necessary. | |
| 3. Rusted pulley(s). | 3. Clean rust from pulley(s). | |
| 4. Sharp or jagged pulley groove tips. | 4. Replace pulley. | |
| 5. Rubber deteriorated. | 5. Replace belt. | |
| LONGITUDINAL BELT CRACKING (CRACKS BETWEEN TWO RIBS) | 1. Belt has mis-tracked from pulley groove. | 1. Replace belt. |
| 2. Pulley groove tip has worn away rubber to tensile member. | 2. Replace belt. | |
| BELT SLIPS | 1. Belt slipping because of insufficient tension. | 1. Replace automatic belt tensioner. |
| 2. Belt routed incorrectly. | 2. Verify belt routing. | |
| 3. Incorrect belt. | 3. Replace belt. | |
| 4. Belt or pulley subjected to substance (belt dressing, oil ethylene glycol) that has reduced friction. | 4. Replace belt and clean pulleys. | |
| 5. Driven component bearing failure. | 5. Replace faulty component bearing. | |
| 6. Belt glazed and hardened from heat and excessive slippage. | 6. Replace belt. | |
| "GROOVE JUMPING" (BELT DOES NOT MAINTAIN CORRECT POSITION ON PULLEY) | 1. Belt tension either too high or too low. | 1. Replace automatic belt tensioner. |
| 2. Belt routed incorrectly. | 2. Verify belt routing. | |
| 3. Incorrect belt. | 3. Replace belt. | |
| 4. Pulley(s) not within design tolerance. | 4. Replace pulley(s). | |
| 5. Foreign object(s) in grooves. | 5. Remove foreign objects from grooves. | |
| 6. Pulley misalignment. | 6. Check and replace. | |
| 7. Belt cord line is broken. | 7. Replace belt. | |
| BELT BROKEN (NOTE: IDENTIFY AND CORRECT PROBLEM BEFORE NEW BELT IS INSTALLED) | 1. Excessive tension. | 1. Replace belt and automatic belt tensioner. |
| 2. Incorrect belt. | 2. Replace belt. | |
| 3. Tensile member damaged during belt installation. | 3. Replace belt. | |
| 4. Severe misalignment. | 4. Check and replace. | |
| 5. Bracket, pulley, or bearing failure. | 5. Replace defective component and belt. | |
| NOISE (OBJECTIONABLE SQUEAL, SQUEAK, OR RUMBLE IS HEARD OR FELT WHILE DRIVE BELT IS IN OPERATION) | 1. Belt slippage. | 1. Replace belt or automatic belt tensioner. |
| 2. Bearing noise. | 2. Locate and repair. | |
| 3. Belt misalignment. | 3. Replace belt. | |
| 4. Belt-to-pulley mismatch. | 4. Install correct belt. |
ACCESSORY DRIVE BELT DIAGNOSIS CHART
Scheme 25
| 1 - POWER STEERING PUMP |
|---|
| 2 - ACCESSORY DRIVE BELT |
| 3 - GENERATOR |
| 4 - CRANKSHAFT PULLEY |
| 5 - LOWER IDLER PULLEY |
| 6 - CRANKSHAFT PULLEY |
| 7 - WATER PUMP PULLEY |
| 8 - ACCESSORY DRIVE BELT TENSIONER |
| 9 - UPPER IDLER PULLEY |
- Using a wrench, rotate accessory drive belt tensioner (8) counterclockwise until accessory drive belt (2) can be removed from pulleys (5 and 9).
- Remove accessory drive belt (2).
Scheme 26
| CAUTION | Do not let tensioner arm snap back to the freearm position, severe damage may occur to the tensioner. |
- Disconnect negative battery cable from battery.
- Raise vehicle.
- Remove right front wheel.
- Remove the inner splash shield.
- Rotate belt tensioner (8) until it contacts its stop. Remove belt (7), then slowly rotate the tensioner into the freearm position.
Scheme 27
| 1 - POWER STEERING PUMP |
|---|
| 2 - ACCESSORY DRIVE BELT |
| 3 - GENERATOR |
| 4 - CRANKSHAFT PULLEY |
| 5 - LOWER IDLER PULLEY |
| 6 - CRANKSHAFT PULLEY |
| 7 - WATER PUMP PULLEY |
| 8 - ACCESSORY DRIVE BELT TENSIONER |
| 9 - UPPER IDLER PULLEY |
Note. When installing drive belt on the pulleys, make sure that belt is properly routed and all V-grooves make proper contact with pulley grooves.
- Install the accessory drive belt (2) around all the pulleys except for the generator pulley (3).
- Using a wrench, rotate accessory drive belt tensioner (8) counterclockwise until accessory drive belt (2) can be installed on the generator pulley (3). Release spring tension onto accessory drive belt (2).
Scheme 28
- Check condition of all pulleys. CAUTION: When installing the serpentine accessory drive belt, the belt MUST be routed correctly. If not, the engine may overheat due to the water pump rotating in the wrong direction.
- Install new belt (7). Route the belt around all pulleys except the idler pulley (2). Rotate the tensioner arm (8) until it contacts its stop position. Route the belt (7) around the idler (2) and slowly let the tensioner (8) rotate into the belt. Make sure the belt (7) is seated onto all pulleys.
- With the drive belt installed, inspect the belt wear indicator. The gap between the tang and the housing stop (measurement A) must not exceed 24 mm (.94 inches).
- Install the inner splash shield.
- Install the wheel.
- Lower vehicle.
- Connect the negative battery.
