FASTENER TORQUE SPECIFICATIONS
| Description | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| All Screws NOT Listed Below | 2 | 17 | |
| A/C Accumulator Bracket Bolts | 9 | 80 | |
| A/C Accumulator Retaining Band Bolt | 8 | 71 | |
| A/C Compressor to Engine Bolts | 25 | 18 | |
| Air Distribution Housing Halves Screws | 1.2 | 10 | |
| Air Distribution Housing to HVAC Housing Screws | 1.2 | 10 | |
| Air Inlet Housing to HVAC Housing Screws | 1.2 | 10 | |
| Blend Door Lever Screw | 0.6 | 5 | |
| Blower Motor Screws | 1.2 | 10 | |
| Blower Motor Power Module Screws | 1.2 | 10 | |
| Blower Motor Resistor Screws | 1.2 | 10 | |
| Defroster Duct Screws | 2.2 | 20 | |
| Demister Duct Screws | 2.2 | 20 | |
| Discharge Jumper Line To Condenser Nut | 18 | 13 | |
| Discharge Line To Jumper Line Nut | 18 | 13 | |
| Flange to HVAC Housing Screw | 1.2 | 10 | |
| Heater Core Tube Retaining Bracket Screw | 1.2 | 10 | |
| Heat Shield to Dash Panel Nuts | 1.2 | 10 | |
| HVAC Housing Halves Screws | 1.2 | 10 | |
| HVAC Housing to Dash Panel Nut | 4.5 | 40 | |
| Infrared Sensor Screw | 1.2 | 10 | |
| Instrument Panel Duct Screws | 2.2 | 20 | |
| Liquid Line to A/C Condenser Nut | 25 | 18 | |
| Lower Condenser Bracket to Radiator Bolts | 4.5 | 40 | |
| Mode Door Cam Screw | 0.6 | 5 | |
| Rear Seat Floor Duct Screw | 2.2 | 20 | |
| Refrigerant Lines to A/C Evaporator Bolt | 25 | 18 | |
| Refrigerant Lines to Compressor Nuts | 20 | 15 | |
| Refrigerant Line Bracket to Strut Tower Nut | 20 | 15 | |
| Suction Lines to Accumulator Nuts | 25 | 18 |
SPECIFICATIONS
| Application | Capacity |
|---|---|
| All models | 0.454 kg (1.0 lbs.) |
REFRIGERANT CHARGE CAPACITY
Scheme 1
The A/C orifice tube establishes the pressure differential between the high and low pressure sides of the A/C system by providing a restriction between the A/C condenser and the A/C evaporator. The A/C orifice tube in this vehicle is installed in the A/C liquid line and is of a variable orifice valve (VOV) design.
The variable A/C orifice tube consists of the inlet filter screen (5), the bi-metal coil (4), the fixed port (3), the variable port (6), metering orifices (1), a nylon mesh diffuser screen (7) and two rubber O-rings (2) which seal the tube to the inside of the A/C liquid line to prevent refrigerant from bypassing the metering orifices.
