Power Window System - Electrical Diagnostics: Diagnosis Dodge Avenger II

Windows 3 illustrations ~839 words

DIAGNOSTIC CODE INDEX

DTCDescription
B1852DRIVER WINDOW SWITCH CIRCUIT STUCK - DDM
B1854DRIVER WINDOW CONTROL CIRCUIT LOW - DDM
B1858DRIVER WINDOW POSITION SENSOR POWER SUPPLY LOW - PDM
B185ADRIVER WINDOW POSITION SENSOR CIRCUIT PERFORMANCE - DDM
B185DPASSENGER WINDOW SWITCH CIRCUIT STUCK - PDM
B185FPASSENGER WINDOW CONTROL CIRCUIT LOW - PDM
B1863WINDOW POSITION SENSOR POWER SUPPLY LOW - PDM
B1865PASSENGER WINDOW POSITION SENSOR CIRCUIT PERFORMANCE - PDM
B1868DRIVER PASSENGER WINDOW SWITCH CIRCUIT STUCK - DDM
B18BBWINDOW CONTROL CIRCUIT LOW
B18D5DRIVER DOOR PAWL SWITCH STUCK - DDM - JS27
B18DBPASSENGER DOOR PAWL SWITCH STUCK - PDM - JS27
B190EDRIVER WINDOW SWITCH CIRCUIT LOW
B190FDRIVER WINDOW SWITCH CIRCUIT HIGH
B1911PASSENGER WINDOW SWITCH CIRCUIT LOW
B1912PASSENGER WINDOW SWITCH CIRCUIT HIGH
B1914DRIVER WINDOW CONTROL 2 CIRCUIT LOW - DDM
B1918PASSENGER WINDOW CONTROL 2 CIRCUIT LOW - PDM
B191DWINDOW CONTROL CIRCUIT OVERCURRENT
B1929LEFT REAR WINDOW MOTOR CNTRL CKT OPEN OR THERMO PROTECTION ACT - PTCM
B192DRIGHT REAR WINDOW MOTOR CNTRL CKT OPEN OR THERMO PROTECTION ACT - PTCM
B19F9LEFT REAR WINDOW SWITCH CIRCUIT STUCK - DDM - JS27
B19FDRIGHT REAR WINDOW SWITCH CIRCUIT STUCK - DDM - JS27
B1DA7SWITCH POWER SUPPLY CIRCUIT LOW
B210DBATTERY VOLTAGE LOW - DDM/PDM
B210EBATTERY VOLTAGE HIGH - DDM/PDM
B2218,B2219DRIVER/PASSENGER DOOR MODULE INTERNAL
B2515REAR WIN POS SEN SUP LOW - PTM - JS27
B2517LEFT REAR WINDOW POSITION SENSOR 1 CIRCUIT PERFORMANCE - PTCM - JS27
B2518LEFT REAR WINDOW POSITION SENSOR 2 CIRCUIT PERFORMANCE - PTCM - JS27
B2519RT RR WIN POS SEN 1 PERFORMANCE - PTCM - JS27
B251ARIGHT REAR WINDOW POSITION SENSOR 2 CIRCUIT PERFORMANCE - PTCM - JS27
B251BLEFT REAR MOTOR - INCORRECT DIRECTION - PTCM - JS27
B251CRIGHT REAR MOTOR - INCORRECT DIRECTION - PTCM - JS27
U0141LOST COMMUNICATION WITH FRONT CONTROL MODULE
U0151LOST COMMUNICATION WITH OCCUPANT RESTRAINT CONTROLLER
U0154LOST COMMUNICATION WITH OCCUPANT CLASSIFICATION MODULE
U0155LOST COMMUNICATION WITH CLUSTER/CCN
U0156LOST COMMUNICATION WITH EOM
U0159LOST COMMUNICATION WITH PARKING ASSIST CONTROL MODULE
U0164LOST COMMUNICATION WITH HVAC CONTROL MODULE
U0167LOST COMMUNICATION WITH INTRUSION TRANSCEIVING CONTROL MODULE
U0168LOST COMMUNICATION WITH VEHICLE SECURITY CONTROL MODULE (SKREEM/WCM)
U0169LOST COMMUNICATION WITH SUNROOF CONTROL MODULE
U0181LOST COMMUNICATION WITH HEADLAMP LEVELING TRANSLATOR
U0184LOST COMMUNICATION WITH RADIO
U0186LOST COMMUNICATION WITH AUDIO AMPLIFIER
U0195LOST COMMUNICATION WITH SDARS
U0196LOST COMMUNICATION WITH VEHICLE ENTERTAINMENT CONTROL MODULE
U0197LOST COMMUNICATION WITH HANDS FREE PHONE MODULE
U0199LOST COMMUNICATION WITH DRIVER DOOR MODULE
U0200LOST COMMUNICATION WITH PASSENGER DOOR MODULE
U0208LOST COMMUNICATION WITH HEATED SEAT CONTROL MODULE
U0212LOST COMMUNICATION WITH SCM - CAN B
U0231LOST COMMUNICATION WITH RAIN SENSING MODULE
U0241LOST COMMUNICATION WITH AUTO HIGHBEAM HEADLAMP CONTROL MODULE
U1000CAN B BUS (+) CIRCUIT
U1001CAN B BUS (-) CIRCUIT

DIAGNOSTIC CODE INDEX

Scheme 1

Scheme 1: Circuit Schematic

Diagnostic Test

  1. Replace the Door Module NOTE: Anytime this code is logged, the module must be replaced. Repair Replace the appropriate Door Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  1. CHECK ENGINE DTC's With the scan tool, read ENGINE DTC's Are there any ENGINE DTC's present? No Go to 2 . Yes Refer to symptom list for problems related to ENGINE.
  2. TEST FOR INTERMITTENT CONDITION With the scan tool, record and erase DTC's Start the engine and run for 2 minutes. With the scan tool, read DTC's. Does the scan tool display B210E-BATTERY VOLTAGE HIGH? Yes Replace the appropriate Door Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  1. Replace the Door Module NOTE: Anytime this code is logged, the module must be replaced. Repair Replace the appropriate Door Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .

Scheme 2

Scheme 2: B2515-REAR WIN POS SEN SUP LOW - PTM - JS27

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING . Refer to U0126-LOST COMMUNICATION WITH STEERING ANGLE SENSOR (SAS) for diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Refer to DIAGNOSIS AND TESTING for the diagnostic test procedure.

Scheme 3

Scheme 3: Circuit Schematic
  1. WINDOW MOTOR NOT CALIBRATED Move the window part way down. Run the window to the full up position and continue to hold the switch for an additional 2 seconds. Run the window to the full down position and continue to hold the switch for an additional 2 seconds. Press and release the switch to the express up position. Did the window move to the full up position? No Go To step 2 . Yes Test complete.
  2. EXPRESS WINDOW SWITCH Turn the ignition off. Move the Driver Express Switch from the idle position to the up position and then to the express up position. Is there two definite detent positions felt? Yes Replace the Driver Door Module in accordance with service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) . No Replace the Driver Express Window Switch assembly. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  1. TEST FOR DIAGNOSTIC TROUBLE CODES Turn the ignition on. With the scan tool, read DTC's. Does the scan tool display any Power Window related DTC's? No Go To step 2 . Yes Refer to symptom list for problems related to POWER WINDOWS. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  2. WINDOW HALL SENSOR A AND SENSOR B SIGNAL CIRCUIT OPEN Disconnect the appropriate Door Module C2 connector. Disconnect the appropriate Window Motor connector. Measure the resistance of the Window Hall Sensor A Signal circuit between the Motor connector and the Module C2 connector. Measure the resistance of the Window Hall Sensor B Signal circuit between the Motor connector and the Module C2 connector. Is the resistance below 2.0 ohms on both Signal circuits? No Repair the Window Hall Sensor Signal circuit(s) for opens. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) . Yes Replace the Window Motor. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
  1. WINDOW MOTOR NOT CALIBRATED Move the window part way down. Run the window to the full up position and continue to hold the switch for an additional 2 seconds. Run the window to the full down position and continue to hold the switch for an additional 2 seconds. Press and release the switch to the express up position. Did the window move to the full up position? No Go To step 2 . Yes Test complete.
  2. EXPRESS SWITCH Is the express feature inoperative from both front door switches? Yes Replace the Passenger Door Module. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) . No Replace the defective Express Window Switch assembly. Perform «BODY VERIFICATION TEST - VER 1»(ref-305767-S12156571892008120200000) .
