Suspension System: Specifications Dodge Avenger II

Suspension Front 9 illustrations ~239 words

TORQUE SPECIFICATIONS

DESCRIPTIONN.mFt. Lbs.In. Lbs.
Brake Shield10789
Crossmember Mounting Bolts135100
Crossmember Reinforcement Bracket Mounting Screws5037
Hub And Bearing Mounting Bolts8260
Hub Nut13297
Lower Ball Joint Stud Nut9570
Lower Control Arm Front Pivot Bolt145107
Lower Control Arm Rear Pivot Bolt Nut145107
Stabilizer Bar Cushion Retainer Screws6044
Stabilizer Bar Link Nuts4835
Strut Clevis-to-Knuckle Nuts140103
Strut Rod Nut6044
Strut-to-Tower Nuts5541
Tie Rod Adjuster Jam Nut7555
Tie Rod End Knuckle Nut8563
Wheel Mounting (Lug) Nuts135100

TORQUE SPECIFICATIONS

Scheme 1

Scheme 1: SPECIAL TOOLS
Scheme 1: SPECIAL TOOLS

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6: DESCRIPTION
Scheme 6: DESCRIPTION

The front wheel bearing and wheel hub of this vehicle are a one piece sealed unit or hub and bearing unit type assembly.

The hub and bearing (1) is mounted to the knuckle using four mounting bolts (2) and to the axle half shaft using a retaining nut. The center of the hub and bearing is splined to match the outer joint of the axle half shaft.

Each front hub and bearing has five wheel mounting studs on the hub flange for mounting the wheel to the vehicle. The wheel mounting studs are the only replaceable components of the hub and bearing. Otherwise, the hub and bearing is serviced as a complete assembly.

DESCRIPTIONN.mFt. Lbs.In. Lbs.
Brake Tube Bracket Knuckle Mounting Screw1511133
Brake Flex Hose Trailing Link Mounting Screw2317
Hub And Bearing Mounting Bolts10577
Hub Nut245181
Lower Control Arm Knuckle Mounting Bolt Nut10577
Lower Control Arm Crossmember Mounting Bolt Nut10577
Shock Assembly Lower Mounting Bolt Nut9973
Shock Assembly Upper Mounting Nuts5541
Shock Rod Nut4130
Stabilizer Bar Retainer Screws2518
Stabilizer Link Mounting Nuts4835
Toe Link Knuckle Mounting Bolt Nut10577
Toe Link Cam Bolt Nut3526
Trailing Link Body Mounting Bolts11081
Trailing Link Knuckle Mounting Bolts6044
Upper Control Arm Knuckle Mounting Bolt Nut10577
Upper Control Arm Crossmember Mounting Bolt Nut10577
Wheel Mounting (Lug) Nuts135100

TORQUE SPECIFICATIONS

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9
  1. Raise and support the vehicle. Refer to «STANDARD PROCEDURE»(ref-305753-S01950477782008120200000) .
  2. Remove the wheel mounting nuts (3), then the tire and wheel assembly (1).
  3. If equipped, while holding the stabilizer bar link lower stud stationary, remove the nut (3) securing the link (2) to the lower control arm (4).
  4. Remove the lower shock mounting nut (1) and bolt (4).
  5. Remove the nut (2) and bolt (7) securing the lower control arm (3) to the knuckle (1).
  6. Remove the nut (4) and bolt (6) securing the lower control arm (3) to the rear crossmember (5).
  7. Remove the lower control arm (3).
