POWER WINDOW RELAY
- Remove power window relay from fuse/relay block located under left side of instrument panel. see scheme 2 Check continuity between power window relay terminals No. 1 and 3. If continuity exists, go to next step. If continuity does not exist, replace relay.
- Using jumper wires and a 12-volt power source, apply battery positive to relay terminal No. 1 and battery negative to relay terminal No. 3. (Scheme 10) Continuity should exist between relay terminals No. 4 and 5. If continuity does not exist, replace relay.
Scheme 10
POWER WINDOW MOTOR
- Remove appropriate door trim panel. See «DOOR TRIM PANEL & WATERSHIELD»(ref-123836-S19401364132001092700000) under REMOVAL & INSTALLATION. Disconnect window motor connector. Using jumper wires, apply battery voltage to window motor terminals. Motor should operate, unless it is already at maximum travel. Reverse jumper wires. Motor should operate in opposite direction.
- If window does not move in either direction, replace window motor. If motor operates in one direction only, remove motor. See «POWER WINDOW MOTOR»(ref-123836-S27363333912001092700000) under REMOVAL & INSTALLATION. Check window/regulator for freedom of movement.
- Remove screws holding glass lift plate to regulator. Slide window up and down by hand to ensure it moves freely in glass channels. If window slides freely, check regulator assembly. Repair window/regulator as necessary.
POWER WINDOW SWITCH
Remove window switch from trim panel. Using ohmmeter, check window switch continuity. See appropriate WINDOW SWITCH CONTINUITY table. see scheme 6or see scheme 7. Replace window switch as necessary.
| Switch Position | Continuity Between Terminals No. | |
|---|---|---|
| Driver's Side Switch | ||
| Off | 2, 6 & 9 | |
| Up | 2 & 6; 8 & 9 | |
| Down Or Auto Down | 6 & 8; 2 & 9 | |
| Passenger's Side Switch | ||
| Off | 3 & 7 | |
| Up | 3 & 8 | |
| Down | 7 & 8 | |
| Window Lock Switch | ||
| Normal | 2 & 3; 2 & 7 | |
| Lock | (1) | |
| (1) Continuity should not exist between terminal No. 2 and terminals No. 3 and 7. | ||
| (1) | Continuity should not exist between terminal No. 2 and terminals No. 3 and 7. |
DRIVER'S WINDOW SWITCH CONTINUITY
| Switch Position | Continuity Between Terminals No. |
|---|---|
| Off | 1 & 4; 2 & 3 |
| Up | 1 & 4; 3 & 6 |
| Down | 1 & 6; 2 & 3 |
PASSENGER'S WINDOW SWITCH CONTINUITY
