STARTER SPECIFICATIONS
| Application | Specification |
|---|
| Number Of Teeth | 8 |
| Rated Output At 12 Volts | .95 Kw |
STARTER SPECIFICATIONS - DIRECT DRIVE
| Application | Specification |
|---|
| Carbon Brush |
| Minimum Length | (1) |
| Commutator |
| Diameter |
| Standard | 1.158" (29.4 mm) |
| Minimum | 1.118" (28.4 mm) |
| Mica Undercut Depth | .020" (0.5 mm) |
| Runout |
| Standard | .002" (.05 mm) |
| Maximum | .004" (.10 mm) |
| No-Load Test At 11 Volts |
| Maximum Amps | 90 |
| Minimum RPM | 3000 |
| Number Of Teeth | 10 |
| Pinion Gap | .020-.079" (0.5-2.0 mm) |
| Rated Output At 12 Volts |
| Canada | 1.4 Kw |
| US | 1.2 Kw |
| (1) Replace brushes when worn to limit line. |
| (1) | Replace brushes when worn to limit line. |
STARTER SPECIFICATIONS - REDUCTION GEAR
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Air Injection Valve | 25 (34) |
| Starter Mounting Bolts | 40 (54) |
Starting System Wiring Diagram (A/T With Anti-Theft). Scheme 1
Scheme 1: Starting System Wiring Diagram (A/T With Anti-Theft)
Starting System Wiring Diagram (M/T With Anti-Theft). Scheme 2
Scheme 2: Starting System Wiring Diagram (M/T With Anti-Theft)
Starting System Wiring Diagram (Without Anti-Theft). Scheme 3
Scheme 3: Starting System Wiring Diagram (Without Anti-Theft)
