GENERATOR SPECIFICATIONS
| Application | Rated Amps | Minimum Amps |
|---|
| DOHC | 90 | 63 |
| SOHC | 110 | 77 |
| (1) At 2500 RPM. |
GENERATOR SPECIFICATIONS (1)
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Battery Hold-Down Bolt | 10 (13.5) |
| Exhaust Gas Recirculation Valve System Fasteners | 17 (23) |
| Generator Mounting Bolts & Nuts (8 mm) | 30 (41) |
| Generator Mounting Bolts & Nuts (10 mm) | 40 (54.0) |
| Intake Manifold Plenum Bolts | 14 (19) |
| INCH Lbs. (N.m) |
| Generator BAT Terminal Nut | 75 (8.5) |
| Negative Battery Terminal Nut | 90 (10) |
Charging System Wiring Diagram. Scheme 1
Scheme 1: Charging System Wiring Diagram
