Engine Controls - Self-Diagnostics: Diagnosis Daewoo Nubira II

Testing & Diagnostics 254 illustrations ~910 words

DIAGNOSTICS AIDS

Note. If an intermittent problem is evident, follow guidelines below.

Diagnostic Trouble Code Tables

Do not use Diagnostic Trouble Code (DTC) tables to try to correct an intermittent fault. The fault must be present to locate problem. Incorrect use of DTC tables may result in unnecessary replacement of parts.

Road Test

If a visual inspection does not find cause of problem, vehicle can be driven with a voltmeter or a scan tool connected to a suspected circuit. An abnormal voltage or scan tool reading will indicate that problem is in that circuit.

If there are no wiring or connector problems found and a DTC was stored for a circuit having a sensor, except for DTC P0171 and DTC P0172, replace sensor.

CLEARING TROUBLE CODES

Note. To prevent PCM/ECM damage, key must be OFF when disconnecting or reconnecting power to PCM/ECM (for example battery cable, PCM/ECM pigtail connector, PCM/ECM fuse, jumper cables, etc.).

When PCM/ECM sets a diagnostic trouble code (DTC), Malfunction Indicator Lamp (MIL) will be turned on only for type A and B, and a DTC will be stored in PCM/ECM's memory.

The MIL operates differently on OBD II compliant vehicles. OBD II guidelines require that MIL (CHECK ENGINE or SERVICE ENGINE SOON) illuminate only for DTCs that will impact vehicle emissions (type A and B). The Diagnostic Executive will turn on MIL if test fails or emissions exceed FTP by 1-1/2 times.

If vehicle is experiencing a misfire malfunction that may cause damage to Three-Way Catalytic Converter (TWC), MIL will flash once per-second. Flashing of MIL will continue until vehicle is out of engine speed and load conditions that could cause possible catalyst damage. The MIL will remain illuminated after flashing stops.

When MIL is on, Diagnostic Executive will turn off MIL after three consecutive trips in which a "test passed" has been reported for diagnostic test that originally caused MIL to illuminate. For fuel trim or misfire DTCs, tests must also pass during same operating conditions that DTC is set under (within 375 rpm, within 10% of engine load) and similar engine temperature when DTC set.

DTCs should be cleared after repairs have been completed. Some diagnostic tables will tell you to clear codes before using chart. This allows PCM/ECM to set DTC while going through chart, which will help to find cause of problem more quickly.

DIAGNOSTIC TROUBLE CODES

DTCDescription
DTC P0106MANIFOLD ABSOLUTE PRESSURE RATIONALITY
DTC P0107MANIFOLD ABSOLUTE PRESSURE LOW VOLTAGE
DTC P0108MANIFOLD ABSOLUTE PRESSURE HIGH VOLTAGE
DTC P0112INTAKE AIR TEMPERATURE LOW VOLTAGE
DTC P0113INTAKE AIR TEMPERATURE HIGH VOLTAGE
DTC P0117ENGINE COOLANT TEMPERATURE LOW VOLTAGE
DTC P0118ENGINE COOLANT TEMPERATURE HIGH VOLTAGE
DTC P0121THROTTLE POSITION SENSOR RATIONALITY
DTC P0122THROTTLE POSITION SENSOR LOW VOLTAGE
DTC P0123THROTTLE POSITION SENSOR HIGH VOLTAGE
DTC P0125ENGINE COOLANT TEMPERATURE INSUFFICIENT FOR CLOSED LOOP FUEL CONTROL
DTC P0128STUCK OPEN THERMOSTAT
DTC P0131O2 BANK 1 SENSOR 1 LOW VOLTAGE
DTC P0132O2 BANK 1 SENSOR 1 HIGH VOLTAGE
DTC P0133O2 BANK 1 SENSOR 1 SLOW RESPONSE
DTC P0134O2 BANK 1 SENSOR 1 NO ACTIVITY
DTC P0137O2 BANK 1 SENSOR 2 LOW VOLTAGE
DTC P0138O2 BANK 1 SENSOR 2 HIGH VOLTAGE
DTC P0140O2 BANK 1 SENSOR 2 NO ACTIVITY
DTC P0141O2 BANK 1 SENSOR 2 HEATER
DTC P0171BANK 1 SYSTEM TOO LEAN
DTC P0172BANK 1 SYSTEM TOO RICH
DTC P0201INJECTOR 1 CIRCUIT FAULT
DTC P0202INJECTOR 2 CIRCUIT FAULT
DTC P0203INJECTOR 3 CIRCUIT FAULT
DTC P0204INJECTOR 4 CIRCUIT FAULT
DTC P0300MULTIPLE CYLINDER MISFIRE DETECTED
DTC P0301CYLINDER 1 MISFIRE
DTC P0302CYLINDER 2 MISFIRE
DTC P0303CYLINDER 3 MISFIRE
DTC P0304CYLINDER 4 MISFIRE
DTC P0325KNOCK SENSOR DSNEF INTERNAL MALFUNCTION
DTC P0327KNOCK SENSOR CIRCUIT FAULT
DTC P033658X CRANK POSITION EXTRA/MISSING PULSES
DTC P033758X CRANK POSITION NO SIGNAL
DTC P0341CAM RATIONALITY
DTC P0342CAM POSITION NO SIGNAL
DTC P0351IGNITION CONTROL A CIRCUIT FAULT
DTC P0352IGNITION CONTROL B CIRCUIT FAULT
DTC P0401EXHAUST GAS RECIRCULATION INSUFFICIENT FLOW
DTC P0402EXHAUST GAS RECIRCULATION EXCESSIVE FLOW
DTC P0404EXHAUST GAS RECIRCULATION OPEN VALVE POSITION ERROR
DTC P0405EXHAUST GAS RECIRCULATION PINTLE POSITION LOW VOLTAGE
DTC P0406EXHAUST GAS RECIRCULATION PINTLE POSITION HIGH VOLTAGE
DTC P0420CATALYST BANK 1 LOW EFFICIENCY
DTC P0440EVAPORATIVE EMISSION SYSTEM LARGE LEAK/LOW TANK VACUUM
DTC P0442EVAPORATIVE EMISSION SYSTEM SMALL LEAK
DTC P0446EVAPORATIVE EMISSION SYSTEM VENT CONTROL MALFUNCTION
DTC P0449EVAPORATIVE EMISSION SYSTEM VENT SOLENOID CIRCUIT FAULT
DTC P0452FUEL TANK PRESSURE SENSOR LOW VOLTAGE
DTC P0453FUEL TANK PRESSURE SENSOR HIGH VOLTAGE
DTC P0461FUEL LEVEL STUCK
DTC P0462FUEL LEVEL LOW VOLTAGE
DTC P0463FUEL LEVEL HIGH VOLTAGE
DTC P0464FUEL LEVEL RATIONALITY
DTC P0480COOLING FAN RELAY A FAN CONTROL CIRCUIT FAULT (WITH A/C)
DTC P0481COOLING FAN RELAY B FAN CONTROL CIRCUIT FAULT (WITH A/C)
DTC P0502VEHICLE SPEED (ENGINE SIDE) NO SIGNAL
DTC P0506IDLE SPEED RPM LOWER THAN DESIRED IDLE SPEED
DTC P0507IDLE SPEED RPM HIGHER THAN DESIRED IDLE SPEED
DTC P0562SYSTEM VOLTAGE (ENGINE SIDE) TOO LOW
DTC P0563SYSTEM VOLTAGE (ENGINE SIDE) TOO HIGH
DTC P0601PCM/ECM (ENGINE SIDE) CHECKSUM FAULT
DTC P1106MANIFOLD ABSOLUTE PRESSURE INTERMITTENT HIGH VOLTAGE
DTC P1107MANIFOLD ABSOLUTE PRESSURE INTERMITTENT LOW VOLTAGE
DTC P1111INTAKE AIR TEMPERATURE INTERMITTENT HIGH VOLTAGE
DTC P1112INTAKE AIR TEMPERATURE INTERMITTENT LOW VOLTAGE
DTC P1114ENGINE COOLANT TEMPERATURE INTERMITTENT LOW VOLTAGE
DTC P1115ENGINE COOLANT TEMPERATURE INTERMITTENT HIGH VOLTAGE
DTC P1121THROTTLE POSITION SENSOR INTERMITTENT HIGH VOLTAGE
DTC P1122THROTTLE POSITION SENSOR INTERMITTENT LOW VOLTAGE
DTC P1130O2 BANK 1 SENSOR 1 LOW SIGNAL VARIANCE
DTC P1133O2 BANK 1 SENSOR 1 TOO FEW TRANSITIONS
DTC P1134O2 BANK 1 SENSOR 1 TRANSITION RATIO
DTC P1171FUEL SUPPLY SYSTEM LEAN DURING POWER ENRICH
DTC P133658X CRANK POSITION TOOTH ERROR NOT LEARNED
DTC P1380ABS ROUGH ROAD DATA INVALID
DTC P1381ABS ROUGH ROAD SERIAL DATA FAULT
DTC P1391G SENSOR ROUGH ROAD RATIONALITY
DTC P1392G SENSOR ROUGH ROAD LOW VOLTAGE
DTC P1393G SENSOR ROUGH ROAD HIGH VOLTAGE
DTC P1404EXHAUST GAS RECIRCULATION CLOSED VALVE PINTLE ERROR
DTC P1441EVAPORATIVE EMISSION CONTINUOUS PURGE FLOW
DTC P1546A/C CLUTCH OUTPUT CIRCUIT FAULT
DTC P1618PCM/ECM INTERNAL SPI COMMUNICATION
DTC P1627PCM/ECM A/D CONVERSION ERROR
DTC P1635PCM/ECM 5 VOLT REFERENCE LINE LOW
DTC P1640ODM INTERNAL SPI COMMUNICATION

DTC INDEX

Scheme 18

Scheme 18

Scheme 19

Scheme 19

Scheme 20

Scheme 20

Scheme 21

Scheme 21: DTC P0106: MANIFOLD ABSOLUTE PRESSURE RATIONALITY

Scheme 22

Scheme 22

Scheme 23

Scheme 23: DTC P0107: MANIFOLD ABSOLUTE PRESSURE LOW VOLTAGE

Scheme 24

Scheme 24

Scheme 25

Scheme 25

Scheme 26

Scheme 26: DTC P0108: MANIFOLD ABSOLUTE PRESSURE HIGH VOLTAGE

Scheme 27

Scheme 27

Scheme 28

Scheme 28

Scheme 29

Scheme 29: DTC P0112: INTAKE AIR TEMPERATURE LOW VOLTAGE

Scheme 30

Scheme 30

Scheme 31

Scheme 31: DTC P0113: INTAKE AIR TEMPERATURE HIGH VOLTAGE

Scheme 32

Scheme 32

Scheme 33

Scheme 33

Scheme 34

Scheme 34: DTC P0117: ENGINE COOLANT TEMPERATURE LOW VOLTAGE

Scheme 35

Scheme 35

Scheme 36

Scheme 36: DTC P0118: ENGINE COOLANT TEMPERATURE HIGH VOLTAGE

Scheme 37

Scheme 37

Scheme 38

Scheme 38

Scheme 39

Scheme 39: DTC P0121: THROTTLE POSITION SENSOR RATIONALITY

Scheme 40

Scheme 40

Scheme 41

Scheme 41

Scheme 42

Scheme 42: DTC P0122: THROTTLE POSITION SENSOR LOW VOLTAGE

Scheme 43

Scheme 43

Scheme 44

Scheme 44

Scheme 45

Scheme 45: DTC P0123: THROTTLE POSITION SENSOR HIGH VOLTAGE

Scheme 46

Scheme 46

Scheme 47

Scheme 47

Scheme 48

Scheme 48: DTC P0125: ENGINE COOLANT TEMPERATURE INSUFFICIENT FOR CLOSED LOOP FUEL CONTROL

Scheme 49

Scheme 49

Scheme 50

Scheme 50

Scheme 51

Scheme 51: DTC P0128: STUCK OPEN THERMOSTAT

Scheme 52

Scheme 52

Scheme 53

Scheme 53

Scheme 54

Scheme 54: DTC P0131: O2 BANK 1 SENSOR 1 LOW VOLTAGE

Scheme 55

Scheme 55

Scheme 56

Scheme 56

Scheme 57

Scheme 57: DTC P0132: O2 BANK 1 SENSOR 1 HIGH VOLTAGE

Scheme 58

Scheme 58

Scheme 59

Scheme 59

Scheme 60

Scheme 60: DTC P0133: O2 BANK 1 SENSOR 1 SLOW RESPONSE

Scheme 61

Scheme 61

Scheme 62

Scheme 62

Scheme 63

Scheme 63: DTC P0134: O2 BANK 1 SENSOR 1 NO ACTIVITY

Scheme 64

Scheme 64

Scheme 65

Scheme 65

Scheme 66

Scheme 66: DTC P0137: O2 BANK 1 SENSOR 2 LOW VOLTAGE

Scheme 67

Scheme 67

Scheme 68

Scheme 68

Scheme 69

Scheme 69: DTC P0138: O2 BANK 1 SENSOR 2 HIGH VOLTAGE

Scheme 70

Scheme 70

Scheme 71

Scheme 71

Scheme 72

Scheme 72: DTC P0140: O2 BANK 1 SENSOR 2 NO ACTIVITY

Scheme 73

Scheme 73

Scheme 74

Scheme 74

Scheme 75

Scheme 75: DTC P0141: O2 BANK 1 SENSOR 2 HEATER

Scheme 76

Scheme 76

Scheme 77

Scheme 77

Scheme 78

Scheme 78: DTC P0171: BANK 1 SYSTEM TOO LEAN

Scheme 79

Scheme 79

Scheme 80

Scheme 80

Scheme 81

Scheme 81

Scheme 82

Scheme 82: DTC P0172: BANK 1 SYSTEM TOO RICH

Scheme 83

Scheme 83

Scheme 84

Scheme 84

Scheme 85

Scheme 85

Scheme 86

Scheme 86: DTC P0201: INJECTOR 1 CIRCUIT FAULT

Scheme 87

Scheme 87

Scheme 88

Scheme 88

Scheme 89

Scheme 89: DTC P0202: INJECTOR 2 CIRCUIT FAULT

Scheme 90

Scheme 90

Scheme 91

Scheme 91

Scheme 92

Scheme 92: DTC P0203: INJECTOR 3 CIRCUIT FAULT

Scheme 93

Scheme 93

Scheme 94

Scheme 94

Scheme 95

Scheme 95: DTC P0204: INJECTOR 4 CIRCUIT FAULT

Scheme 96

Scheme 96

Scheme 97

Scheme 97

Scheme 98

Scheme 98: DTC P0300: MULTIPLE CYLINDER MISFIRE DETECTED

Scheme 99

Scheme 99

Scheme 100

Scheme 100

Scheme 101

Scheme 101

Scheme 102

Scheme 102: DTC P0301: CYLINDER 1 MISFIRE

Scheme 103

Scheme 103

Scheme 104

Scheme 104

Scheme 105

Scheme 105

Scheme 106

Scheme 106: DTC P0302: CYLINDER 2 MISFIRE

Scheme 107

Scheme 107

Scheme 108

Scheme 108

Scheme 109

Scheme 109

Scheme 110

Scheme 110: DTC P0303: CYLINDER 3 MISFIRE

Scheme 111

Scheme 111

Scheme 112

Scheme 112

Scheme 113

Scheme 113

Scheme 114

Scheme 114: DTC P0304: CYLINDER 4 MISFIRE

Scheme 115

Scheme 115

Scheme 116

Scheme 116

Scheme 117

Scheme 117

Scheme 118

Scheme 118: DTC P0325: KNOCK SENSOR DSNEF INTERNAL MALFUNCTION

Scheme 119

Scheme 119: DTC P0327: KNOCK SENSOR CIRCUIT FAULT

Scheme 120

Scheme 120

Scheme 121

Scheme 121

Scheme 122

Scheme 122: DTC P0336: 58X CRANK POSITION EXTRA/MISSING PULSES

Scheme 123

Scheme 123

Scheme 124

Scheme 124: DTC P0337: 58X CRANK POSITION NO SIGNAL

Scheme 125

Scheme 125

Scheme 126

Scheme 126

Scheme 127

Scheme 127: DTC P0341: CAM RATIONALITY

Scheme 128

Scheme 128

Scheme 129

Scheme 129

Scheme 130

Scheme 130: DTC P0342: CAM POSITION NO SIGNAL

Scheme 131

Scheme 131

Scheme 132

Scheme 132

Scheme 133

Scheme 133: DTC P0351: IGNITION CONTROL A CIRCUIT FAULT

Scheme 134

Scheme 134

Scheme 135

Scheme 135: DTC P0352: IGNITION CONTROL B CIRCUIT FAULT

Scheme 136

Scheme 136

Scheme 137

Scheme 137: DTC P0401: EXHAUST GAS RECIRCULATION INSUFFICIENT FLOW

Scheme 138

Scheme 138

Scheme 139

Scheme 139

Scheme 140

Scheme 140: DTC P0402: EXHAUST GAS RECIRCULATION EXCESSIVE FLOW

Scheme 141

Scheme 141

Scheme 142

Scheme 142

Scheme 143

Scheme 143

Scheme 144

Scheme 144: DTC P0404: EXHAUST GAS RECIRCULATION OPEN VALVE POSITION ERROR

Scheme 145

Scheme 145

Scheme 146

Scheme 146

Scheme 147

Scheme 147

Scheme 148

Scheme 148: DTC P0405: EXHAUST GAS RECIRCULATION PINTLE POSITION LOW VOLTAGE

Scheme 149

Scheme 149

Scheme 150

Scheme 150

Scheme 151

Scheme 151

Scheme 152

Scheme 152: DTC P0406: EXHAUST GAS RECIRCULATION PINTLE POSITION HIGH VOLTAGE

Scheme 153

Scheme 153

Scheme 154

Scheme 154

Scheme 155

Scheme 155: DTC P0420: CATALYST BANK 1 LOW EFFICIENCY

Scheme 156

Scheme 156

Scheme 157

Scheme 157: DTC P0440: EVAPORATIVE EMISSION SYSTEM LARGE LEAK/LOW TANK VACUUM

Scheme 158

Scheme 158

Scheme 159

Scheme 159

Scheme 160

Scheme 160

Scheme 161

Scheme 161

Scheme 162

Scheme 162: DTC P0442: EVAPORATIVE EMISSION SYSTEM SMALL LEAK

Scheme 163

Scheme 163

Scheme 164

Scheme 164

Scheme 165

Scheme 165

Scheme 166

Scheme 166: DTC P0446: EVAPORATIVE EMISSION SYSTEM VENT CONTROL MALFUNCTION

Scheme 167

Scheme 167

Scheme 168

Scheme 168

Scheme 169

Scheme 169: DTC P0449: EVAPORATIVE EMISSION SYSTEM VENT SOLENOID CIRCUIT FAULT

Scheme 170

Scheme 170

Scheme 171

Scheme 171

Scheme 172

Scheme 172: DTC P0452: FUEL TANK PRESSURE SENSOR LOW VOLTAGE

Scheme 173

Scheme 173

Scheme 174

Scheme 174

Scheme 175

Scheme 175: DTC P0453: FUEL TANK PRESSURE SENSOR HIGH VOLTAGE

Scheme 176

Scheme 176

Scheme 177

Scheme 177

Scheme 178

Scheme 178: DTC P0461: FUEL LEVEL STUCK

Scheme 179

Scheme 179

Scheme 180

Scheme 180

Scheme 181

Scheme 181: DTC P0462: FUEL LEVEL LOW VOLTAGE

Scheme 182

Scheme 182

Scheme 183

Scheme 183

Scheme 184

Scheme 184: DTC P0463: FUEL LEVEL HIGH VOLTAGE

Scheme 185

Scheme 185

Scheme 186

Scheme 186

Scheme 187

Scheme 187: DTC P0464: FUEL LEVEL RATIONALITY

Scheme 188

Scheme 188

Scheme 189

Scheme 189

Scheme 190

Scheme 190: DTC P0480: COOLING FAN RELAY A FAN CONTROL CIRCUIT FAULT (WITH A/C)

Scheme 191

Scheme 191

Scheme 192

Scheme 192

Scheme 193

Scheme 193: DTC P0481: COOLING FAN RELAY B FAN CONTROL CIRCUIT FAULT (WITH A/C)

Scheme 194

Scheme 194

Scheme 195

Scheme 195

Scheme 196

Scheme 196: DTC P0502: VEHICLE SPEED (ENGINE SIDE) NO SIGNAL

Scheme 197

Scheme 197

Scheme 198

Scheme 198

Scheme 199

Scheme 199: DTC P0506: IDLE SPEED RPM LOWER THAN DESIRED IDLE SPEED

Scheme 200

Scheme 200

Scheme 201

Scheme 201

Scheme 202

Scheme 202

Scheme 203

Scheme 203: DTC P0507: IDLE SPEED RPM HIGHER THAN DESIRED IDLE SPEED

Scheme 204

Scheme 204

Scheme 205

Scheme 205: DTC P0562: SYSTEM VOLTAGE (ENGINE SIDE) TOO LOW

Scheme 206

Scheme 206

Scheme 207

Scheme 207: DTC P0563: SYSTEM VOLTAGE (ENGINE SIDE) TOO HIGH

Scheme 208

Scheme 208

Scheme 209

Scheme 209: DTC P0601: PCM/ECM (ENGINE SIDE) CHECKSUM FAULT

Scheme 210

Scheme 210: DTC P1106: MANIFOLD ABSOLUTE PRESSURE INTERMITTENT HIGH VOLTAGE

Scheme 211

Scheme 211

Scheme 212

Scheme 212: DTC P1107: MANIFOLD ABSOLUTE PRESSURE INTERMITTENT LOW VOLTAGE

Scheme 213

Scheme 213

Scheme 214

Scheme 214: DTC P1111: INTAKE AIR TEMPERATURE INTERMITTENT HIGH VOLTAGE

Scheme 215

Scheme 215

Scheme 216

Scheme 216

Scheme 217

Scheme 217: DTC P1112: INTAKE AIR TEMPERATURE INTERMITTENT LOW VOLTAGE

Scheme 218

Scheme 218

Scheme 219

Scheme 219: DTC P1114: ENGINE COOLANT TEMPERATURE INTERMITTENT LOW VOLTAGE

Scheme 220

Scheme 220

Scheme 221

Scheme 221: DTC P1115: ENGINE COOLANT TEMPERATURE INTERMITTENT HIGH VOLTAGE

Scheme 222

Scheme 222

Scheme 223

Scheme 223

Scheme 224

Scheme 224: DTC P1121: THROTTLE POSITION SENSOR INTERMITTENT HIGH VOLTAGE

Scheme 225

Scheme 225

Scheme 226

Scheme 226: DTC P1122: THROTTLE POSITION SENSOR INTERMITTENT LOW VOLTAGE

Scheme 227

Scheme 227

Scheme 228

Scheme 228: DTC P1130: O2 BANK 1 SENSOR 1 LOW SIGNAL VARIANCE

Scheme 229

Scheme 229

Scheme 230

Scheme 230

Scheme 231

Scheme 231: DTC P1133: O2 BANK 1 SENSOR 1 TOO FEW TRANSITIONS

Scheme 232

Scheme 232

Scheme 233

Scheme 233

Scheme 234

Scheme 234

Scheme 235

Scheme 235: DTC P1134: O2 BANK 1 SENSOR 1 TRANSITION RATIO

Scheme 236

Scheme 236

Scheme 237

Scheme 237

Scheme 238

Scheme 238: DTC P1171: FUEL SUPPLY SYSTEM LEAN DURING POWER ENRICH

Scheme 239

Scheme 239

Scheme 240

Scheme 240: DTC P1336: 58X CRANK POSITION TOOTH ERROR NOT LEARNED

Scheme 241

Scheme 241

Scheme 242

Scheme 242: DTC P1380: ABS ROUGH ROAD DATA INVALID

Scheme 243

Scheme 243

Scheme 244

Scheme 244: DTC P1381: ABS ROUGH ROAD SERIAL DATA FAULT

Scheme 245

Scheme 245

Scheme 246

Scheme 246: DTC P1391: G SENSOR ROUGH ROAD RATIONALITY

Scheme 247

Scheme 247

Scheme 248

Scheme 248

Scheme 249

Scheme 249: DTC P1392: G SENSOR ROUGH ROAD LOW VOLTAGE

Scheme 250

Scheme 250

Scheme 251

Scheme 251

Scheme 252

Scheme 252: DTC P1393: G SENSOR ROUGH ROAD HIGH VOLTAGE

Scheme 253

Scheme 253

Scheme 254

Scheme 254

Scheme 255

Scheme 255: DTC P1404: EXHAUST GAS RECIRCULATION CLOSED VALVE PINTLE ERROR

Scheme 256

Scheme 256

Scheme 257

Scheme 257

Scheme 258

Scheme 258: DTC P1441: EVAPORATIVE EMISSION CONTINUOUS PURGE FLOW

Scheme 259

Scheme 259

Scheme 260

Scheme 260

Scheme 261

Scheme 261: DTC P1546: A/C CLUTCH OUTPUT CIRCUIT FAULT

Scheme 262

Scheme 262

Scheme 263

Scheme 263

Scheme 264

Scheme 264: DTC P1618: PCM/ECM INTERNAL SPI COMMUNICATION

Scheme 265

Scheme 265: DTC P1627: PCM/ECM A/D CONVERSION ERROR

Scheme 266

Scheme 266: DTC P1635: PCM/ECM 5 VOLT REFERENCE LINE LOW

Scheme 267

Scheme 267

Scheme 268

Scheme 268

Scheme 269

Scheme 269: DTC P1640: ODM INTERNAL SPI COMMUNICATION

Scheme 270

Scheme 270

Scheme 271

Scheme 271
