Monitor Conditions

1. When Monitored: With the engine running.

Set Conditions

1. Set Condition: The PCM detects that the secondary ignition burn time is incorrect or not present. One Trip Fault.

Possible Causes

Scheme 486

Scheme 487

Scheme 488

Scheme 489

1. DTC IS ACTIVE Start the engine and allow it to reach operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts, or fan. Do not wear loose clothing. Failure to follow these instructions can result in personal injury or death. With the scan tool, select View DTCs. Is the status Active for this DTC? Yes Go to 2 . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure.
2. IGNITION COIL OPERATION CAUTION: Do not allow the ignition coil to fire with the secondary circuit open. PCM driver failure may result. Install a spark tester whenever testing for spark or a cylinder misfire. Turn the ignition off. Remove the ignition coil. NOTE: Inspect the ignition coil and the spark plug insulator for damage or carbon tracking. If any problems are found, replace the ignition coil. NOTE: If the ignition coil is on a 6.1 L engine, the spark tester must be installed on both sides of the coil. Each side of the coil should output a crisp blue spark that jumps the gap of the spark tester during the test. Attach the spark tester to the ignition coil. Crank the engine and observe the spark tester. NOTE: A crisp blue spark that jumps the gap of the spark tester should be generated. Is a good spark generated? Yes Go to 8 . Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 3 .
3. (F343) ASD RELAY OUTPUT CIRCUIT OPEN OR HIGH RESISTANCE Turn the ignition off. Disconnect the Ignition Coil 1 harness connector. Turn the ignition on. With the scan tool, actuate the Auto Shutdown (ASD) Relay Control State. Using a 12 volt test light connected to ground, check the (F343) ASD Relay Output circuit in the Ignition Coil 1 harness connector. NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. Is the test light illuminated and bright? Yes Go to 4 . No Repair the (F343) ASD Relay Output circuit for an open circuit or high resistance. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
4. IGNITION COIL Turn the ignition off. Using a 12 volt test light connected to 12 volts, check the (K19) Coil 1 Control circuit. Crank the engine for 5 second while observing the test light. Does the test light blink/flicker? Yes Replace the Ignition Coil. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 5 .
5. (K19) COIL 1 CONTROL CIRCUIT SHORTED TO GROUND Turn the ignition off. Measure the resistance between ground and the (K19) Coil 1 Control circuit in the Ignition Coil 1 harness connector. Is the resistance above 100 ohms? Yes Go to 6 . No Repair the (K19) Coil 1 Control circuit for a short to ground. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
6. (K19) COIL 1 CONTROL CIRCUIT OPEN OR HIGH RESISTANCE CAUTION: Do not probe the PCM harness connectors. Probing the PCM harness connectors will damage the PCM terminals, resulting in poor terminal to pin connection. Install Miller Special Tool #8815 to perform diagnosis. Measure the resistance of the (K19) Coil 1 Control circuit between the Ignition Coil 1 harness connector and the appropriate terminal of special tool #8815. Is the resistance below 5.0 ohms? Yes Go to 7 . No Repair the (K19) Coil 1 Control circuit for an open circuit or high resistance. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
7. POWERTRAIN CONTROL MODULE (PCM) Using the wiring diagram/schematic as a guide, inspect the wiring and connectors between the Ignition Coil 1 and the Powertrain Control Module (PCM). Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Refer to any Technical Service Bulletins that may apply. Were any problems found? Yes Repair as necessary. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Replace and program the Powertrain Control Module (PCM) in accordance with the Service Information. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
8. ENGINE MECHANICAL CONDITION Turn the ignition off. Remove the spark plug. Inspect the spark plug for the contamination, fouling, or evidence of oil or coolant. Were any problems found? Yes Repair the engine mechanical condition and replace the spark plug. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 9 .
9. SPARK PLUG Inspect the spark plug for the following conditions. - Cracks - Carbon Tracking - Gap size out of specifications - Loose or broken electrode NOTE: Lightly tap the bottom of the spark plug on a solid surface. The spark plug electrode should not move. Were any problems found? Yes Replace the spark plug. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure.

Scheme 490

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the engine running.

1. Set Condition: The PCM detects that the secondary ignition burn time is incorrect or not present. One Trip Fault.

Scheme 491

Scheme 492

Scheme 493

Scheme 494

1. DTC IS ACTIVE Start the engine and allow it to reach operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts, or fan. Do not wear loose clothing. Failure to follow these instructions can result in personal injury or death. With the scan tool, select View DTCs. Is the status Active for this DTC? Yes Go to 2 . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure.
2. IGNITION COIL OPERATION CAUTION: Do not allow the ignition coil to fire with the secondary circuit open. PCM driver failure may result. Install a spark tester whenever testing for spark or a cylinder misfire. NOTE: The spark test must be repeated for the adjacent ignition wire. Turn the ignition off. Disconnect the ignition wire from the spark plug. NOTE: Inspect the ignition wire and the spark plug insulator for damage or carbon tracking. If any problems are found, replace the ignition wire. Attach the spark tester to the ignition wire. Crank the engine and observe the spark tester. NOTE: A crisp blue spark that jumps the gap of the spark tester should be generated. Is a good spark generated? Yes Go to 9 . Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 3 .
3. IGNITION WIRE NOTE: This test must be repeated for the adjacent ignition wire. Turn the ignition off. Remove the ignition wire. Measure the resistance of the ignition wire. Is the resistance below 10K ohms? Yes Go to 4 . No Replace the ignition wire. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
4. (K344) ASD RELAY OUTPUT CIRCUIT OPEN OR HIGH RESISTANCE Turn the ignition off. Disconnect the Ignition Coil harness connector. Turn the ignition on. With the scan tool, actuate the Auto Shutdown (ASD) Relay Control State. Using a 12 volt test light connected to ground, check the (K344) ASD Relay Output circuit in the Ignition Coil harness connector. NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. Is the test light illuminated and bright? Yes Go to 5 . No Repair the (K344) ASD Relay Output circuit for an open circuit or high resistance. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
5. IGNITION COIL Turn the ignition off. Using a 12 volt test light connected to 12 volts, check the (K17) Coil 2 Control circuit. Crank the engine for 5 second while observing the test light. Does the test light blink/flicker? Yes Replace the Ignition Coil. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 6 .
6. (K17) COIL 2 CONTROL CIRCUIT SHORTED TO GROUND Turn the ignition off. Measure the resistance between ground and the (K17) Coil 2 Control circuit in the Ignition Coil harness connector. Is the resistance above 100 ohms? Yes Go to 7 . No Repair the (K17) Coil 2 Control circuit for a short to ground. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
7. (K17) COIL 2 CONTROL CIRCUIT OPEN OR HIGH RESISTANCE CAUTION: Do not probe the PCM harness connectors. Probing the PCM harness connectors will damage the PCM terminals, resulting in poor terminal to pin connection. Install Miller Special Tool #8815 to perform diagnosis. Measure the resistance of the (K17) Coil 2 Control circuit between the Ignition Coil harness connector and the appropriate terminal of special tool #8815. Is the resistance below 5.0 ohms? Yes Go to 8 . No Repair the (K17) Coil 2 Control circuit for an open circuit or high resistance. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
8. POWERTRAIN CONTROL MODULE (PCM) Using the wiring diagram/schematic as a guide, inspect the wiring and connectors between the Ignition Coil and the Powertrain Control Module (PCM). Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Refer to any Technical Service Bulletins that may apply. Were any problems found? Yes Repair as necessary. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Replace and program the Powertrain Control Module (PCM) in accordance with the Service Information. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
9. ENGINE MECHANICAL CONDITION Turn the ignition off. Remove the spark plug. Inspect the spark plug for the contamination, fouling, or evidence of oil or coolant. Were any problems found? Yes Repair the engine mechanical condition and replace the spark plug. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 10 .
10. SPARK PLUG Inspect the spark plug for the following conditions. - Cracks - Carbon Tracking - Gap size out of specifications - Loose or broken electrode NOTE: Lightly tap the bottom of the spark plug on a solid surface. The spark plug electrode should not move. Were any problems found? Yes Replace the spark plug. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure.

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the engine running.

1. Set Condition: The PCM detects that the secondary ignition burn time is incorrect or not present. One Trip Fault.

Scheme 495

1. DTC IS ACTIVE Start the engine and allow it to reach operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts, or fan. Do not wear loose clothing. Failure to follow these instructions can result in personal injury or death. With the scan tool, select View DTCs. Is the status Active for this DTC? Yes Go to 2 . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure.
2. IGNITION COIL OPERATION CAUTION: Do not allow the ignition coil to fire with the secondary circuit open. PCM driver failure may result. Install a spark tester whenever testing for spark or a cylinder misfire. Turn the ignition off. Remove the ignition coil. NOTE: Inspect the ignition coil and the spark plug insulator for damage or carbon tracking. If any problems are found, replace the ignition coil. NOTE: If the ignition coil is on a 6.1 L engine, the spark tester must be installed on both sides of the coil. Each side of the coil should output a crisp blue spark that jumps the gap of the spark tester during the test. Attach the spark tester to the ignition coil. Crank the engine and observe the spark tester. NOTE: A crisp blue spark that jumps the gap of the spark tester should be generated. Is a good spark generated? Yes Go to 8 . Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 3 .
3. (F343) ASD RELAY OUTPUT CIRCUIT OPEN OR HIGH RESISTANCE Turn the ignition off. Disconnect the Ignition Coil 2 harness connector. Turn the ignition on. With the scan tool, actuate the Auto Shutdown (ASD) Relay Control State. Using a 12 volt test light connected to ground, check the (F343) ASD Relay Output circuit in the Ignition Coil 2 harness connector. NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. Is the test light illuminated and bright? Yes Go to 4 . No Repair the (F343) ASD Relay Output circuit for an open circuit or high resistance. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
4. IGNITION COIL Turn the ignition off. Using a 12 volt test light connected to 12 volts, check the (K17) Coil 2 Control circuit. Crank the engine for 5 second while observing the test light. Does the test light blink/flicker? Yes Replace the Ignition Coil. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 5 .
5. (K17) COIL 2 CONTROL CIRCUIT SHORTED TO GROUND Turn the ignition off. Measure the resistance between ground and the (K17) Coil 2 Control circuit in the Ignition Coil 2 harness connector. Is the resistance above 100 ohms? Yes Go to 6 . No Repair the (K17) Coil 2 Control circuit for a short to ground. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
6. (K17) COIL 2 CONTROL CIRCUIT OPEN OR HIGH RESISTANCE CAUTION: Do not probe the PCM harness connectors. Probing the PCM harness connectors will damage the PCM terminals, resulting in poor terminal to pin connection. Install Miller Special Tool #8815 to perform diagnosis. Measure the resistance of the (K17) Coil 2 Control circuit between the Ignition Coil 2 harness connector and the appropriate terminal of special tool #8815. Is the resistance below 5.0 ohms? Yes Go to 7 . No Repair the (K17) Coil 2 Control circuit for an open circuit or high resistance. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
7. POWERTRAIN CONTROL MODULE (PCM) Using the wiring diagram/schematic as a guide, inspect the wiring and connectors between the Ignition Coil 2 and the Powertrain Control Module (PCM). Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Refer to any Technical Service Bulletins that may apply. Were any problems found? Yes Repair as necessary. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Replace and program the Powertrain Control Module (PCM) in accordance with the Service Information. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
8. ENGINE MECHANICAL CONDITION Turn the ignition off. Remove the spark plug. Inspect the spark plug for the contamination, fouling, or evidence of oil or coolant. Were any problems found? Yes Repair the engine mechanical condition and replace the spark plug. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 9 .
9. SPARK PLUG Inspect the spark plug for the following conditions. - Cracks - Carbon Tracking - Gap size out of specifications - Loose or broken electrode NOTE: Lightly tap the bottom of the spark plug on a solid surface. The spark plug electrode should not move. Were any problems found? Yes Replace the spark plug. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure.

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the engine running.

1. Set Condition: The PCM detects that the secondary ignition burn time is incorrect or not present. One Trip Fault.

Scheme 496

Scheme 497

Scheme 498

1. DTC IS ACTIVE Start the engine and allow it to reach operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts, or fan. Do not wear loose clothing. Failure to follow these instructions can result in personal injury or death. With the scan tool, select View DTCs. Is the status Active for this DTC? Yes Go to 2 . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure.
2. IGNITION COIL OPERATION CAUTION: Do not allow the ignition coil to fire with the secondary circuit open. PCM driver failure may result. Install a spark tester whenever testing for spark or a cylinder misfire. NOTE: The spark test must be repeated for the adjacent ignition wire. Turn the ignition off. Disconnect the ignition wire from the spark plug. NOTE: Inspect the ignition wire and the spark plug insulator for damage or carbon tracking. If any problems are found, replace the ignition wire. Attach the spark tester to the ignition wire. Crank the engine and observe the spark tester. NOTE: A crisp blue spark that jumps the gap of the spark tester should be generated. Is a good spark generated? Yes Go to 9 . Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 3 .
3. IGNITION WIRE NOTE: This test must be repeated for the adjacent ignition wire. Turn the ignition off. Remove the ignition wire. Measure the resistance of the ignition wire. Is the resistance below 10K ohms? Yes Go to 4 . No Replace the ignition wire. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
4. (K344) ASD RELAY OUTPUT CIRCUIT OPEN OR HIGH RESISTANCE Turn the ignition off. Disconnect the Ignition Coil harness connector. Turn the ignition on. With the scan tool, actuate the Auto Shutdown (ASD) Relay Control State. Using a 12 volt test light connected to ground, check the (K344) ASD Relay Output circuit in the Ignition Coil harness connector. NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. Is the test light illuminated and bright? Yes Go to 5 . No Repair the (K344) ASD Relay Output circuit for an open circuit or high resistance. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
5. IGNITION COIL Turn the ignition off. Using a 12 volt test light connected to 12 volts, check the (K18) Coil 3 Control circuit. Crank the engine for 5 second while observing the test light. Does the test light blink/flicker? Yes Replace the Ignition Coil. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 6 .
6. (K18) COIL 3 CONTROL CIRCUIT SHORTED TO GROUND Turn the ignition off. Measure the resistance between ground and the (K18) Coil 3 Control circuit in the Ignition Coil harness connector. Is the resistance above 100 ohms? Yes Go to 7 . No Repair the (K18) Coil 3 Control circuit for a short to ground. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
7. (K18) COIL 3 CONTROL CIRCUIT OPEN OR HIGH RESISTANCE CAUTION: Do not probe the PCM harness connectors. Probing the PCM harness connectors will damage the PCM terminals, resulting in poor terminal to pin connection. Install Miller Special Tool #8815 to perform diagnosis. Measure the resistance of the (K18) Coil 3 Control circuit between the Ignition Coil harness connector and the appropriate terminal of special tool #8815. Is the resistance below 5.0 ohms? Yes Go to 8 . No Repair the (K18) Coil 3 Control circuit for an open circuit or high resistance. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
8. POWERTRAIN CONTROL MODULE (PCM) Using the wiring diagram/schematic as a guide, inspect the wiring and connectors between the Ignition Coil and the Powertrain Control Module (PCM). Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Refer to any Technical Service Bulletins that may apply. Were any problems found? Yes Repair as necessary. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Replace and program the Powertrain Control Module (PCM) in accordance with the Service Information. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
9. ENGINE MECHANICAL CONDITION Turn the ignition off. Remove the spark plug. Inspect the spark plug for the contamination, fouling, or evidence of oil or coolant. Were any problems found? Yes Repair the engine mechanical condition and replace the spark plug. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 10 .
10. SPARK PLUG Inspect the spark plug for the following conditions. - Cracks - Carbon Tracking - Gap size out of specifications - Loose or broken electrode NOTE: Lightly tap the bottom of the spark plug on a solid surface. The spark plug electrode should not move. Were any problems found? Yes Replace the spark plug. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure.

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the engine running.

1. Set Condition: The PCM detects that the secondary ignition burn time is incorrect or not present. One Trip Fault.

Scheme 499

1. DTC IS ACTIVE Start the engine and allow it to reach operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts, or fan. Do not wear loose clothing. Failure to follow these instructions can result in personal injury or death. With the scan tool, select View DTCs. Is the status Active for this DTC? Yes Go to 2 . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure.
2. IGNITION COIL OPERATION CAUTION: Do not allow the ignition coil to fire with the secondary circuit open. PCM driver failure may result. Install a spark tester whenever testing for spark or a cylinder misfire. Turn the ignition off. Remove the ignition coil. NOTE: Inspect the ignition coil and the spark plug insulator for damage or carbon tracking. If any problems are found, replace the ignition coil. NOTE: If the ignition coil is on a 6.1 L engine, the spark tester must be installed on both sides of the coil. Each side of the coil should output a crisp blue spark that jumps the gap of the spark tester during the test. Attach the spark tester to the ignition coil. Crank the engine and observe the spark tester. NOTE: A crisp blue spark that jumps the gap of the spark tester should be generated. Is a good spark generated? Yes Go to 8 . Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 3 .
3. (F343) ASD RELAY OUTPUT CIRCUIT OPEN OR HIGH RESISTANCE Turn the ignition off. Disconnect the Ignition Coil 3 harness connector. Turn the ignition on. With the scan tool, actuate the Auto Shutdown (ASD) Relay Control State. Using a 12 volt test light connected to ground, check the (F343) ASD Relay Output circuit in the Ignition Coil 3 harness connector. NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. Is the test light illuminated and bright? Yes Go to 4 . No Repair the (F343) ASD Relay Output circuit for an open circuit or high resistance. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
4. IGNITION COIL Turn the ignition off. Using a 12 volt test light connected to 12 volts, check the (K18) Coil 3 Control circuit. Crank the engine for 5 second while observing the test light. Does the test light blink/flicker? Yes Replace the Ignition Coil. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 5 .
5. (K18) COIL 3 CONTROL CIRCUIT SHORTED TO GROUND Turn the ignition off. Measure the resistance between ground and the (K18) Coil 3 Control circuit in the Ignition Coil 3 harness connector. Is the resistance above 100 ohms? Yes Go to 6 . No Repair the (K18) Coil 3 Control circuit for a short to ground. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
6. (K18) COIL 3 CONTROL CIRCUIT OPEN OR HIGH RESISTANCE CAUTION: Do not probe the PCM harness connectors. Probing the PCM harness connectors will damage the PCM terminals, resulting in poor terminal to pin connection. Install Miller Special Tool #8815 to perform diagnosis. Measure the resistance of the (K18) Coil 3 Control circuit between the Ignition Coil 3 harness connector and the appropriate terminal of special tool #8815. Is the resistance below 5.0 ohms? Yes Go to 7 . No Repair the (K18) Coil 3 Control circuit for an open circuit or high resistance. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
7. POWERTRAIN CONTROL MODULE (PCM) Using the wiring diagram/schematic as a guide, inspect the wiring and connectors between the Ignition Coil 3 and the Powertrain Control Module (PCM). Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Refer to any Technical Service Bulletins that may apply. Were any problems found? Yes Repair as necessary. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Replace and program the Powertrain Control Module (PCM) in accordance with the Service Information. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
8. ENGINE MECHANICAL CONDITION Turn the ignition off. Remove the spark plug. Inspect the spark plug for the contamination, fouling, or evidence of oil or coolant. Were any problems found? Yes Repair the engine mechanical condition and replace the spark plug. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 9 .
9. SPARK PLUG Inspect the spark plug for the following conditions. - Cracks - Carbon Tracking - Gap size out of specifications - Loose or broken electrode NOTE: Lightly tap the bottom of the spark plug on a solid surface. The spark plug electrode should not move. Were any problems found? Yes Replace the spark plug. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure.

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the engine running.

1. Set Condition: The PCM detects that the secondary ignition burn time is incorrect or not present. One Trip Fault.

Scheme 500

1. DTC IS ACTIVE Start the engine and allow it to reach operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts, or fan. Do not wear loose clothing. Failure to follow these instructions can result in personal injury or death. With the scan tool, select View DTCs. Is the status Active for this DTC? Yes Go to 2 . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure.
2. IGNITION COIL OPERATION CAUTION: Do not allow the ignition coil to fire with the secondary circuit open. PCM driver failure may result. Install a spark tester whenever testing for spark or a cylinder misfire. Turn the ignition off. Remove the ignition coil. NOTE: Inspect the ignition coil and the spark plug insulator for damage or carbon tracking. If any problems are found, replace the ignition coil. NOTE: If the ignition coil is on a 6.1 L engine, the spark tester must be installed on both sides of the coil. Each side of the coil should output a crisp blue spark that jumps the gap of the spark tester during the test. Attach the spark tester to the ignition coil. Crank the engine and observe the spark tester. NOTE: A crisp blue spark that jumps the gap of the spark tester should be generated. Is a good spark generated? Yes Go to 8 . Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 3 .
3. (F343) ASD RELAY OUTPUT CIRCUIT OPEN OR HIGH RESISTANCE Turn the ignition off. Disconnect the Ignition Coil 4 harness connector. Turn the ignition on. With the scan tool, actuate the Auto Shutdown (ASD) Relay Control State. Using a 12 volt test light connected to ground, check the (F343) ASD Relay Output circuit in the Ignition Coil 4 harness connector. NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. Is the test light illuminated and bright? Yes Go to 4 . No Repair the (F343) ASD Relay Output circuit for an open circuit or high resistance. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
4. IGNITION COIL Turn the ignition off. Using a 12 volt test light connected to 12 volts, check the (K15) Coil 4 Control circuit. Crank the engine for 5 second while observing the test light. Does the test light blink/flicker? Yes Replace the Ignition Coil. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 5 .
5. (K15) COIL 4 CONTROL CIRCUIT SHORTED TO GROUND Turn the ignition off. Measure the resistance between ground and the (K15) Coil 4 Control circuit in the Ignition Coil 4 harness connector. Is the resistance above 100 ohms? Yes Go to 6 . No Repair the (K15) Coil 4 Control circuit for a short to ground. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
6. (K15) COIL 4 CONTROL CIRCUIT OPEN OR HIGH RESISTANCE CAUTION: Do not probe the PCM harness connectors. Probing the PCM harness connectors will damage the PCM terminals, resulting in poor terminal to pin connection. Install Miller Special Tool #8815 to perform diagnosis. Measure the resistance of the (K15) Coil 4 Control circuit between the Ignition Coil 4 harness connector and the appropriate terminal of special tool #8815. Is the resistance below 5.0 ohms? Yes Go to 7 . No Repair the (K15) Coil 4 Control circuit for an open circuit or high resistance. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
7. POWERTRAIN CONTROL MODULE (PCM) Using the wiring diagram/schematic as a guide, inspect the wiring and connectors between the Ignition Coil 4 and the Powertrain Control Module (PCM). Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Refer to any Technical Service Bulletins that may apply. Were any problems found? Yes Repair as necessary. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Replace and program the Powertrain Control Module (PCM) in accordance with the Service Information. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
8. ENGINE MECHANICAL CONDITION Turn the ignition off. Remove the spark plug. Inspect the spark plug for the contamination, fouling, or evidence of oil or coolant. Were any problems found? Yes Repair the engine mechanical condition and replace the spark plug. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 9 .
9. SPARK PLUG Inspect the spark plug for the following conditions. - Cracks - Carbon Tracking - Gap size out of specifications - Loose or broken electrode NOTE: Lightly tap the bottom of the spark plug on a solid surface. The spark plug electrode should not move. Were any problems found? Yes Replace the spark plug. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure.

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the engine running.

1. Set Condition: The PCM detects that the secondary ignition burn time is incorrect or not present. One Trip Fault.

Scheme 501

1. DTC IS ACTIVE Start the engine and allow it to reach operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts, or fan. Do not wear loose clothing. Failure to follow these instructions can result in personal injury or death. With the scan tool, select View DTCs. Is the status Active for this DTC? Yes Go to 2 . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure.
2. IGNITION COIL OPERATION CAUTION: Do not allow the ignition coil to fire with the secondary circuit open. PCM driver failure may result. Install a spark tester whenever testing for spark or a cylinder misfire. Turn the ignition off. Remove the ignition coil. NOTE: Inspect the ignition coil and the spark plug insulator for damage or carbon tracking. If any problems are found, replace the ignition coil. NOTE: If the ignition coil is on a 6.1 L engine, the spark tester must be installed on both sides of the coil. Each side of the coil should output a crisp blue spark that jumps the gap of the spark tester during the test. Attach the spark tester to the ignition coil. Crank the engine and observe the spark tester. NOTE: A crisp blue spark that jumps the gap of the spark tester should be generated. Is a good spark generated? Yes Go to 8 . Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 3 .
3. (F343) ASD RELAY OUTPUT CIRCUIT OPEN OR HIGH RESISTANCE Turn the ignition off. Disconnect the Ignition Coil 5 harness connector. Turn the ignition on. With the scan tool, actuate the Auto Shutdown (ASD) Relay Control State. Using a 12 volt test light connected to ground, check the (F343) ASD Relay Output circuit in the Ignition Coil 5 harness connector. NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. Is the test light illuminated and bright? Yes Go to 4 . No Repair the (F343) ASD Relay Output circuit for an open circuit or high resistance. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
4. IGNITION COIL Turn the ignition off. Using a 12 volt test light connected to 12 volts, check the (K16) Coil 5 Control circuit. Crank the engine for 5 second while observing the test light. Does the test light blink/flicker? Yes Replace the Ignition Coil. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 5 .
5. (K16) COIL 5 CONTROL CIRCUIT SHORTED TO GROUND Turn the ignition off. Measure the resistance between ground and the (K16) Coil 5 Control circuit in the Ignition Coil 5 harness connector. Is the resistance above 100 ohms? Yes Go to 6 . No Repair the (K16) Coil 5 Control circuit for a short to ground. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
6. (K16) COIL 5 CONTROL CIRCUIT OPEN OR HIGH RESISTANCE CAUTION: Do not probe the PCM harness connectors. Probing the PCM harness connectors will damage the PCM terminals, resulting in poor terminal to pin connection. Install Miller Special Tool #8815 to perform diagnosis. Measure the resistance of the (K16) Coil 5 Control circuit between the Ignition Coil 5 harness connector and the appropriate terminal of special tool #8815. Is the resistance below 5.0 ohms? Yes Go to 7 . No Repair the (K16) Coil 5 Control circuit for an open circuit or high resistance. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
7. POWERTRAIN CONTROL MODULE (PCM) Using the wiring diagram/schematic as a guide, inspect the wiring and connectors between the Ignition Coil 5 and the Powertrain Control Module (PCM). Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Refer to any Technical Service Bulletins that may apply. Were any problems found? Yes Repair as necessary. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Replace and program the Powertrain Control Module (PCM) in accordance with the Service Information. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
8. ENGINE MECHANICAL CONDITION Turn the ignition off. Remove the spark plug. Inspect the spark plug for the contamination, fouling, or evidence of oil or coolant. Were any problems found? Yes Repair the engine mechanical condition and replace the spark plug. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 9 .
9. SPARK PLUG Inspect the spark plug for the following conditions. - Cracks - Carbon Tracking - Gap size out of specifications - Loose or broken electrode NOTE: Lightly tap the bottom of the spark plug on a solid surface. The spark plug electrode should not move. Were any problems? Yes Replace the spark plug. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure.

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the engine running.

1. Set Condition: The PCM detects that the secondary ignition burn time is incorrect or not present. One Trip Fault.

Scheme 502

1. DTC IS ACTIVE Start the engine and allow it to reach operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts, or fan. Do not wear loose clothing. Failure to follow these instructions can result in personal injury or death. With the scan tool, select View DTCs. Is the status Active for this DTC? Yes Go to 2 . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure.
2. IGNITION COIL OPERATION CAUTION: Do not allow the ignition coil to fire with the secondary circuit open. PCM driver failure may result. Install a spark tester whenever testing for spark or a cylinder misfire. Turn the ignition off. Remove the ignition coil. NOTE: Inspect the ignition coil and the spark plug insulator for damage or carbon tracking. If any problems are found, replace the ignition coil. NOTE: If the ignition coil is on a 6.1 L engine, the spark tester must be installed on both sides of the coil. Each side of the coil should output a crisp blue spark that jumps the gap of the spark tester during the test. Attach the spark tester to the ignition coil. Crank the engine and observe the spark tester. NOTE: A crisp blue spark that jumps the gap of the spark tester should be generated. Is a good spark generated? Yes Go to 8 . Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 3 .
3. (F343) ASD RELAY OUTPUT CIRCUIT OPEN OR HIGH RESISTANCE Turn the ignition off. Disconnect the Ignition Coil 6 harness connector. Turn the ignition on. With the scan tool, actuate the Auto Shutdown (ASD) Relay Control State. Using a 12 volt test light connected to ground, check the (F343) ASD Relay Output circuit in the Ignition Coil 6 harness connector. NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. Is the test light illuminated and bright? Yes Go to 4 . No Repair the (F343) ASD Relay Output circuit for an open circuit or high resistance. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
4. IGNITION COIL Turn the ignition off. Using a 12 volt test light connected to 12 volts, check the (K10) Coil 6 Control circuit. Crank the engine for 5 second while observing the test light. Does the test light blink/flicker? Yes Replace the Ignition Coil. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 5 .
5. (K10) COIL 6 CONTROL CIRCUIT SHORTED TO GROUND Turn the ignition off. Measure the resistance between ground and the (K10) Coil 6 Control circuit in the Ignition Coil 6 harness connector. Is the resistance above 100 ohms? Yes Go to 6 . No Repair the (K10) Coil 6 Control circuit for a short to ground. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
6. (K10) COIL 6 CONTROL CIRCUIT OPEN OR HIGH RESISTANCE CAUTION: Do not probe the PCM harness connectors. Probing the PCM harness connectors will damage the PCM terminals, resulting in poor terminal to pin connection. Install Miller Special Tool #8815 to perform diagnosis. Measure the resistance of the (K10) Coil 6 Control circuit between the Ignition Coil 6 harness connector and the appropriate terminal of special tool #8815. Is the resistance below 5.0 ohms? Yes Go to 7 . No Repair the (K10) Coil 6 Control circuit for an open circuit or high resistance. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
7. POWERTRAIN CONTROL MODULE (PCM) Using the wiring diagram/schematic as a guide, inspect the wiring and connectors between the Ignition Coil 6 and the Powertrain Control Module (PCM). Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Refer to any Technical Service Bulletins that may apply. Were any problems found? Yes Repair as necessary. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Replace and program the Powertrain Control Module (PCM) in accordance with the Service Information. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
8. ENGINE MECHANICAL CONDITION Turn the ignition off. Remove the spark plug. Inspect the spark plug for the contamination, fouling, or evidence of oil or coolant. Were any problems found? Yes Repair the engine mechanical condition and replace the spark plug. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 9 .
9. SPARK PLUG Inspect the spark plug for the following conditions. - Cracks - Carbon Tracking - Gap size out of specifications - Loose or broken electrode NOTE: Lightly tap the bottom of the spark plug on a solid surface. The spark plug electrode should not move. Were any problems found? Yes Replace the spark plug. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure.

Scheme 503

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the ignition on. Engine RPM greater than 1000 RPM. With no other charging system codes set.

1. Set Condition: Battery voltage is 1 volt less than desired voltage for more than 10 seconds. One Trip Fault. Three good trips to turn off the MIL.

Always perform the PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding.

Diagnostic Test

1. DTC IS ACTIVE Start the engine and allow it to reach operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts, or fan. Do not wear loose clothing. Failure to follow these instructions can result in personal injury or death. With the scan tool, select View DTCs. Is the status Active for this DTC? Yes Go to 2 . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure.
2. CHECKING THE CHARGING SYSTEM OPERATION Perform the diagnostic procedure for «*CHECKING THE CHARGING SYSTEM OPERATION»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) . Were any problems found? Yes Repair as necessary in accordance with the Service Information. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure.

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the ignition on. Engine RPM greater than 1000 RPM. With no other charging system codes set.

1. Set Condition: Battery voltage is 1 volt greater than desired voltage for more than 10 seconds. Battery voltage greater than 15.75 volts. One Trip Fault. Three good trips to turn off the MIL.

Always perform the PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding.

1. DTC IS ACTIVE Start the engine and allow it to reach operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts, or fan. Do not wear loose clothing. Failure to follow these instructions can result in personal injury or death. With the scan tool, select View DTCs. Is the status Active for this DTC? Yes Go to 2 . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure.
2. CHECKING THE CHARGING SYSTEM OPERATION Perform the diagnostic procedure for «*CHECKING THE CHARGING SYSTEM OPERATION»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) . Were any problems found? Yes Repair as necessary in accordance with the Service Information. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure.

Scheme 504

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

The PCM compares actual shutdown time to a calculated value, which is based on the amount the ECT should drop after a completely warmed up engine is shut down. If the difference is greater than a maximum value, a pending DTC will set.

1. When Monitored: After a complete engine warm up then ignition off time of greater than 1 hour with a minimum ECT drop of 10 C (50 C), with the engine running, the difference between ECT and AAT above 10 C (50 F) and battery voltage above 10 volts

1. Set Condition: If the measured shutdown time is significantly greater than an expected shutdown time based on how much the ECT has dropped, a one trip failure sets. If this happens again after another warm up and 1 hour engine off period, the MIL will set

Always perform the PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE before proceeding.

1. ENGINE COOLANT INSPECTION NOTE: This DTC will set if the engine cools quicker than it should compared to engine off times. If a hot engine is washed with the ignition off, a pending DTC may set. If the vehicle is parked in a highly ventilated area or has a large fan blowing on it which might cause the engine to cool quicker than expected, a pending DTC may set. WARNING: Do not remove or loosen the radiator cap with the system hot and under pressure. Serious burns from coolant can occur. Turn the ignition off. Allow the engine to cool enough to allow the pressure in the coolant system to drop enough to safely remove the radiator cap. Check the coolant level and condition. Is the engine coolant level filled to the proper level? Yes Go to 2 . No Add the appropriate type and amount of engine coolant in accordance with the Service Information and retest. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .
2. IGNITION OFF TIMER Turn the ignition on. With the scan tool under PCM/NGC Data Display, locate the Ignition Off Time value. While monitoring a stop watch, turn the Ignition off for 10 minutes, watch the stop watch for those 10 minutes, and then turn the Ignition on. With the scan tool under Data Functions, check the Ignition Off Time value again. Does the Ignition Time Off value on the scan tool match the actual time you had the Ignition off on the stop watch? Yes The conditions that set the DTC are not active at this time. Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure. No Go to 3 .
3. CHECKING THE PCM POWER AND GROUND CIRCUITS Perform the diagnostic procedure for «*CHECKING THE PCM POWER AND GROUND CIRCUITS»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) . Were any problems found? Yes Repair the PCM power and ground circuit(s) as necessary and retest. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Go to 4 .
4. POWERTRAIN CONTROL MODULE (PCM) Verify that the PCM is operating at the latest software version available. Refer to any Technical Service Bulletins that may apply. Were any problems found? Yes Repair as necessary and retest. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) . No Replace and program the Powertrain Control Module (PCM) in accordance with the Service Information. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the ignition on, battery voltage between 9 and 16 volts, and engine run time greater than 3 seconds.

1. Set Condition: The PCM doesn't receive any Can C bus messages for a specific amount of time.

Refer to DIAGNOSIS AND TESTING for diagnostic procedures and for further possible causes.

1. ACTIVE DTC NOTE: For vehicle communication problems, use the scan tool to refer to the Network Review Screen. The screen depicts a high level view of the vehicle network. Fault and problem areas appear in red. Selecting any of the network components allows access to the source of the problem. Turn the ignition on. With a scan tool, select View DTCs. Is the status Active for this DTC? Yes Refer to «DIAGNOSIS AND TESTING»(/chrysler/town-country/v-2007-2010/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) for diagnostic procedures and for further possible causes. No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the ignition on, battery voltage between 9 and 16 volts, and engine run time greater than 3 seconds.

1. Set Condition: The PCM doesn't receive any Can C bus messages for a specific amount of time.

Refer to DIAGNOSIS AND TESTING for diagnostic procedures and for further possible causes.

1. ACTIVE DTC NOTE: For vehicle communication problems, use the scan tool to refer to the Network Review Screen. The screen depicts a high level view of the vehicle network. Fault and problem areas appear in red. Selecting any of the network components allows access to the source of the problem. Turn the ignition on. With a scan tool, select View DTCs. Is the status Active for this DTC? Yes Refer to «DIAGNOSIS AND TESTING»(/chrysler/town-country/v-2007-2010/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) for diagnostic procedures and for further possible causes. No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the ignition on, battery voltage between 9 and 16 volts, and engine run time greater than 3 seconds.

1. Set Condition: An expected bus message is not received for a specific amount of time.

Refer to DIAGNOSIS AND TESTING for diagnostic procedures and for further possible causes.

1. ACTIVE DTC NOTE: For vehicle communication problems, use the scan tool to refer to the Network Review Screen. The screen depicts a high level view of the vehicle network. Fault and problem areas appear in red. Selecting any of the network components allows access to the source of the problem. Turn the ignition on. With a scan tool, select View DTCs. Is the status Active for this DTC? Yes Refer to «DIAGNOSIS AND TESTING»(/chrysler/town-country/v-2007-2010/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) for diagnostic procedures and for further possible causes. No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the ignition on, battery voltage between 9 and 16 volts, and engine run time greater than 3 seconds.

1. Set Condition: The PCM doesn't receive a bus message from the indicated module for a specific amount of time.

Refer to DIAGNOSIS AND TESTING for diagnostic procedures and for further possible causes.

1. ACTIVE DTC NOTE: For vehicle communication problems, use the scan tool to refer to the Network Review Screen. The screen depicts a high level view of the vehicle network. Fault and problem areas appear in red. Selecting any of the network components allows access to the source of the problem. Turn the ignition on. With a scan tool, select View DTCs. Is the status Active for this DTC? Yes Refer to «DIAGNOSIS AND TESTING»(/chrysler/town-country/v-2007-2010/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) for diagnostic procedures and for further possible causes. No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the ignition on, battery voltage between 9 and 16 volts, and engine run time greater than 3 seconds.

1. Set Condition: The PCM doesn't receive a bus message from the Anti-Lock Brake Module for a specific amount of time.

Refer to DIAGNOSIS AND TESTING for diagnostic procedures and for further possible causes.

1. ACTIVE DTC NOTE: For vehicle communication problems, use the scan tool to refer to the Network Review Screen. The screen depicts a high level view of the vehicle network. Fault and problem areas appear in red. Selecting any of the network components allows access to the source of the problem. Turn the ignition on. With a scan tool, select View DTCs. Is the status Active for this DTC? Yes Refer to «DIAGNOSIS AND TESTING»(/chrysler/town-country/v-2007-2010/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) for diagnostic procedures and for further possible causes. No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the ignition on, battery voltage between 9 and 16 volts, and engine run time greater than 3 seconds.

1. Set Condition: The PCM doesn't receive a bus message from the TIPM for a specific amount of time.

Refer to DIAGNOSIS AND TESTING for diagnostic procedures and for further possible causes.

1. ACTIVE DTC NOTE: For vehicle communication problems, use the scan tool to refer to the Network Review Screen. The screen depicts a high level view of the vehicle network. Fault and problem areas appear in red. Selecting any of the network components allows access to the source of the problem. Turn the ignition on. With a scan tool, select View DTCs. Is the status Active for this DTC? Yes Refer to «DIAGNOSIS AND TESTING»(/chrysler/town-country/v-2007-2010/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) for diagnostic procedures and for further possible causes. No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the ignition on, battery voltage between 9 and 16 volts, and engine run time greater than 3 seconds.

1. Set Condition: The PCM doesn't receive a bus message from the Vehicle Security Control Module (WIN) for a specific amount of time.

Refer to DIAGNOSIS AND TESTING for diagnostic procedures and for further possible causes.

1. ACTIVE DTC NOTE: For vehicle communication problems, use the scan tool to refer to the Network Review Screen. The screen depicts a high level view of the vehicle network. Fault and problem areas appear in red. Selecting any of the network components allows access to the source of the problem. NOTE: Check the IOD fuse before continuing. If the fuse is open, check the circuit for a short to ground. Turn the ignition on. With a scan tool, select View DTCs. Is the status Active for this DTC? Yes Refer to «DIAGNOSIS AND TESTING»(/chrysler/town-country/v-2007-2010/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) for diagnostic procedures and for further possible causes. No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the ignition on, battery voltage between 9 and 16 volts, and engine run time greater than 3 seconds.

1. Set Condition: The PCM either doesn't receive a bus message or receives an implausible bus message from the TIPM.

Refer to DIAGNOSIS AND TESTING for diagnostic procedures and for further possible causes.

1. ACTIVE DTC NOTE: For vehicle communication problems, use the scan tool to refer to the Network Review Screen. The screen depicts a high level view of the vehicle network. Fault and problem areas appear in red. Selecting any of the network components allows access to the source of the problem. NOTE: Diagnose and repair any related sensor or communication DTCs in the TIPM before continuing with this test. Start the engine and allow it to reach operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts, or fan. Do not wear loose clothing. Failure to follow these instructions can result in personal injury or death. With a scan tool, select View DTCs. Is the status Active for this DTC? Yes Refer to «DIAGNOSIS AND TESTING»(/chrysler/town-country/v-2007-2010/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) for diagnostic procedures and for further possible causes. No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the ignition on, battery voltage between 9 and 16 volts, and engine run time greater than 3 seconds.

1. Set Condition: The PCM either doesn't receive a bus message or receives an implausible bus message from the TIPM.

Refer to DIAGNOSIS AND TESTING for diagnostic procedures and for further possible causes.

1. ACTIVE DTC NOTE: For vehicle communication problems, use the scan tool to refer to the Network Review Screen. The screen depicts a high level view of the vehicle network. Fault and problem areas appear in red. Selecting any of the network components allows access to the source of the problem. NOTE: Diagnose and repair any related sensor or communication DTCs in the TIPM before continuing with this test. Start the engine and allow it to reach operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts, or fan. Do not wear loose clothing. Failure to follow these instructions can result in personal injury or death. With a scan tool, select View DTCs. Is the status Active for this DTC? Yes Refer to «DIAGNOSIS AND TESTING»(/chrysler/town-country/v-2007-2010/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) for diagnostic procedures and for further possible causes. No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the ignition on, battery voltage between 9 and 16 volts, and engine run time greater than 3 seconds.

1. Set Condition: The PCM either doesn't receive a bus message or receives an implausible bus message from the TIPM.

Refer to DIAGNOSIS AND TESTING for diagnostic procedures and for further possible causes.

1. ACTIVE DTC NOTE: For vehicle communication problems, use the scan tool to refer to the Network Review Screen. The screen depicts a high level view of the vehicle network. Fault and problem areas appear in red. Selecting any of the network components allows access to the source of the problem. NOTE: Diagnose and repair any related sensor or communication DTCs in the TIPM before continuing with this test. Start the engine and allow it to reach operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts, or fan. Do not wear loose clothing. Failure to follow these instructions can result in personal injury or death. With a scan tool, select View DTCs. Is the status Active for this DTC? Yes Refer to «DIAGNOSIS AND TESTING»(/chrysler/town-country/v-2007-2010/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) for diagnostic procedures and for further possible causes. No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the ignition on, battery voltage between 9 and 16 volts, and engine run time greater than 3 seconds.

1. Set Condition: The PCM either doesn't receive a bus message or receives an implausible bus message from the Anti-Lock Brake Module.

Refer to DIAGNOSIS AND TESTING for diagnostic procedures and for further possible causes.

1. ACTIVE DTC NOTE: For vehicle communication problems, use the scan tool to refer to the Network Review Screen. The screen depicts a high level view of the vehicle network. Fault and problem areas appear in red. Selecting any of the network components allows access to the source of the problem. NOTE: Diagnose and repair any related sensor or communication DTCs in the Anti-Lock Brake Module before continuing with this test. Start the engine and allow it to reach operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts, or fan. Do not wear loose clothing. Failure to follow these instructions can result in personal injury or death. With a scan tool, select View DTCs. Is the status Active for this DTC? Yes Refer to «DIAGNOSIS AND TESTING»(/chrysler/town-country/v-2007-2010/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) for diagnostic procedures and for further possible causes. No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the ignition on, battery voltage between 9 and 16 volts, and engine run time greater than 3 seconds.

1. Set Condition: The PCM either doesn't receive a bus message or receives an implausible bus message from the TIPM.

Refer to DIAGNOSIS AND TESTING for diagnostic procedures and for further possible causes.

1. ACTIVE DTC NOTE: For vehicle communication problems, use the scan tool to refer to the Network Review Screen. The screen depicts a high level view of the vehicle network. Fault and problem areas appear in red. Selecting any of the network components allows access to the source of the problem. NOTE: Diagnose and repair any related sensor or communication DTCs in the TIPM before continuing with this test. Start the engine and allow it to reach operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts, or fan. Do not wear loose clothing. Failure to follow these instructions can result in personal injury or death. With a scan tool, select View DTCs. Is the status Active for this DTC? Yes Refer to «DIAGNOSIS AND TESTING»(/chrysler/town-country/v-2007-2010/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) for diagnostic procedures and for further possible causes. No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the ignition on, battery voltage between 9 and 16 volts, and engine run time greater than 3 seconds.

1. Set Condition: The PCM either doesn't receive a bus message or receives an implausible bus message from the Anti-Lock Brake Module.

Refer to DIAGNOSIS AND TESTING for diagnostic procedures and for further possible causes.

1. ACTIVE DTC NOTE: For vehicle communication problems, use the scan tool to refer to the Network Review Screen. The screen depicts a high level view of the vehicle network. Fault and problem areas appear in red. Selecting any of the network components allows access to the source of the problem. NOTE: Diagnose and repair any related sensor or communication DTCs in the Anti-Lock Brake Module before continuing with this test. Start the engine and allow it to reach operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts, or fan. Do not wear loose clothing. Failure to follow these instructions can result in personal injury or death. With a scan tool, select View DTCs. Is the status Active for this DTC? Yes Refer to «DIAGNOSIS AND TESTING»(/chrysler/town-country/v-2007-2010/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) for diagnostic procedures and for further possible causes. No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the ignition on, battery voltage between 9 and 16 volts, and engine run time greater than 3 seconds.

1. Set Condition: The PCM either doesn't receive a bus message or receives an implausible bus message from the TIPM.

Refer to DIAGNOSIS AND TESTING for diagnostic procedures and for further possible causes.

1. ACTIVE DTC NOTE: For vehicle communication problems, use the scan tool to refer to the Network Review Screen. The screen depicts a high level view of the vehicle network. Fault and problem areas appear in red. Selecting any of the network components allows access to the source of the problem. NOTE: Diagnose and repair any related sensor or communication DTCs in the TIPM before continuing with this test. Start the engine and allow it to reach operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts, or fan. Do not wear loose clothing. Failure to follow these instructions can result in personal injury or death. With a scan tool, select View DTCs. Is the status Active for this DTC? Yes Refer to «DIAGNOSIS AND TESTING»(/chrysler/town-country/v-2007-2010/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) for diagnostic procedures and for further possible causes. No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .

For complete wiring diagrams refer to

SYSTEM WIRING DIAGRAMS for Grand Caravan.

SYSTEM WIRING DIAGRAMS for Town & Country.

1. When Monitored: With the ignition on, battery voltage between 9 and 16 volts, and engine run time greater than 3 seconds.

1. Set Condition: The PCM either doesn't receive a bus message or receives an implausible bus message from the Anti-Lock Brake Module.

Refer to DIAGNOSIS AND TESTING for diagnostic procedures and for further possible causes.

The PCM receives

Wheel speed and wheel distance CAN bus messages from the Anti-lock Brake module.

A/C Pressure, Ambient Air Temperature and Fuel Level CAN bus messages from the Body Control Module.

1. ACTIVE DTC NOTE: For vehicle communication problems, use the scan tool to refer to the Network Review Screen. The screen depicts a high level view of the vehicle network. Fault and problem areas appear in red. Selecting any of the network components allows access to the source of the problem. NOTE: Diagnose and repair any related sensor or communication DTCs in the Anti-Lock Brake Module before continuing with this test. Start the engine and allow it to reach operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts, or fan. Do not wear loose clothing. Failure to follow these instructions can result in personal injury or death. With a scan tool, select View DTCs. Is the status Active for this DTC? Yes Refer to «DIAGNOSIS AND TESTING»(/chrysler/town-country/v-2007-2010/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) for diagnostic procedures and Perform the «*NO RESPONSE FROM ABS (ANTILOCK BRAKE MODULE)»(/chrysler/town-country/v-2007-2010/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) . No Refer to the «*CHECKING FOR AN INTERMITTENT DTC»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#dtcs-u1417-to-u1418-checking-no-crank-and-no-start-condition-intermittent-dtc-component-checks-system-checks-checking-po) Diagnostic Procedure. Perform «PCM VERIFICATION TEST»(/chrysler/town-country/v-2007-2010/remont/testing-diagnostics/#powertrain-control-modules-pcm-electrical-diagnosis__pcm-verification-test) .

See also:
• *CHECKING FOR AN INTERMITTENT DTC
• PCM VERIFICATION TEST
• PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE
• DIAGNOSIS AND TESTING
