ENGINE MOUNTS
| 1 - BOLT - VERTICAL 102 N.m (75 ft. lbs.) |
|---|
| 2 - BRACKET - REAR MOUNT |
| 3 - BOLT - HORIZONTAL 102 N.m (75 ft. lbs.) |
- Install rear mount bracket (2), if removed. 1 - BOLT 54 N.m (40 ft. lbs.) 2 - REAR MOUNT BRACKET 3 - THRU-BOLT 54 N.m (40 ft. lbs.) 4 - REAR MOUNT
- Install the rear mount (4) and bolts (1). Tighten bolts to 54 N.m (40 ft. lbs.).
- Install the mount thru bolt (3) to the mount and bracket (2). Tighten through bolt (3) to 54 N.m (40 ft. lbs.). 1 - BOLT - HEAT SHIELD 11 N.m (100 in. lbs.) 2 - HEAT SHIELD 3 - CLIP 4 - REAR MOUNT
- Install the rear mount heat shield (2).
- Lower vehicle on hoist.
Scheme 127
| 1 - RIGHT ENGINE MOUNT |
|---|
| 2 - BOLT - MOUNT TO FRAME RAIL |
| 3 - BOLT - MOUNT TO ENGINE |
| 4 - ENGINE MOUNT BRACKET |
| 5 - RIGHT FRAME RAIL |
- Remove air cleaner housing lid and clean air hose from throttle body.
- Remove air cleaner element and housing.
- Disconnect make-up air hose from cylinder head cover.
- Remove the load on the right engine mount (1) by carefully supporting the engine assembly with a floor jack.
- Disconnect electrical harness support clips from engine mount bracket.
- Remove the bolts (2,3) attaching the engine mount (1) to the frame rail.
- Remove the three bolts attaching the engine mount to the engine bracket (4).
- Remove the right engine mount (1).
