Active bodyworks — Pedestrian alert circuit Chrysler Pacifica RU facelift
All systems — 36 systems
- Active bodyworks 2
- Air conditioning
- Anti-lock brakes
- Anti-theft 2
- Body control modules
- Cabin accessories
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering 2
- Engine performance 3.6l
- Engine performance 3.6l hybrid 2
- Exterior lights 4
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster 2
- Interior lights 2
- Memory systems 3
- Navigation 8
- Power distribution
- Power door locks
- Power mirrors 3
- Power seats 7
- Power top/sunroof
- Power windows 2
- Radio 5
- Shift interlock 2
- Starting/charging 3
- Supplemental restraints
- Transmission 3.6l 2
- Transmission 3.6l hybrid 2
- Trunk, tailgate, fuel door 3
- Warning systems
- Wiper/washer
Components on these wiring diagrams 7
Click a component to highlight it on every diagram it appears on.
