Lighting Systems- Interior: Removal & Installation Chrysler Pacifica CS

INSTALLATION

1. Place lamp over retaining clips in door courtesy lamp unit retaining clips and firmly snap into place. see scheme 2
2. Place the door courtesy lamp lens over the retaining pins making sure that they are lined up and them firmly snap into place. see scheme 1
3. Close door.
4. Connect the battery negative cable.
5. Verify vehicle and system operation.

Scheme 3

1. Disconnect and isolate the battery negative cable.
2. Remove the front door trim panel «(Refer to BODY/DOOR - FRONT/TRIM PANEL - REMOVAL)»(ref-245423-S16680146352006110200000). (Scheme 3) 1 - FRONT DOOR TRIM PANEL 3 - DOOR COURTESY LAMP UNIT CONNECTOR 2 - FRONT DOOR PANEL 4 - DOOR COURTESY LAMP UNIT
3. With the trim panel on the bench, push in on the side retaining clips of the door courtesy lamp unit and push through trim panel to remove. (Scheme 4)

Scheme 4

1. Align the door courtesy lamp unit in the door trim panel opening and firmly snap into place. (Scheme 4)
2. Install the front door trim panel «(Refer to BODY/DOOR - FRONT/TRIM PANEL - INSTALLATION)»(ref-245423-S26865939162006110200000). (Scheme 3)
3. Connect the battery negative cable.
4. Verify vehicle and system operation.

Scheme 5

1. Open hood, disconnect and isolate the battery negative cable.
2. Open right door.
3. Open glove box.
4. Reach up behind instrument panel and disconnect the glove box lamp switch electrical connector.
5. Using a trim stick (special tool #C-4755) or equivalent, gently pry out glove box lamp switch from glove box opening surround. (Scheme 5) 1 - GLOVE BOX LAMP SWITCH 2 - GLOVE BOX LAMP SWITCH CONNECTOR 3 - INSTRUMENT PANEL 4 - GLOVE BOX OPENING
6. If replacing the lamp, pull straight out of glove box lamp switch.

1. If replacing the lamp, push straight into glove box lamp switch.
2. Position lamp switch over retaining hole and firmly snap into place. (Scheme 5)
3. Reach up behind instrument panel, and connect the electrical connector.
4. Close glove box.
5. Close right door.
6. Connect the battery negative cable.
7. Close hood.
8. Verify vehicle and system operation.

REMOVAL

The Instrument Panel Switch Pod has two illumination lamps. (Scheme 6) If found to be faulty, the entire cluster bezel must be removed. The Light Emitting Diodes (LED's) are serviceable by turning 1/4 turn counterclockwise to remove. The cluster bezel must first be removed to service the LED's (Refer to BODY/INSTRUMENT PANEL/CLUSTER BEZEL - REMOVAL).

Scheme 6

1. Place Light Emitting Diode (LED) into lamp opening in instrument panel switch pod.
2. Turn 1/4 turn clockwise.
3. Install Cluster bezel «(Refer to BODY/INSTRUMENT PANEL/CLUSTER BEZEL - INSTALLATION)»(ref-245423-S01917880992006110200000) .
4. Verify vehicle and system operation.

Scheme 7

1. Open hood, disconnect and isolate the battery negative cable.
2. Open liftgate.
3. Using a trim stick (special tool #C-4755) or equivalent, gently pry out on door courtesy lamp lens and remove from trim panel. (Scheme 7) 1 - LIFTGATE TRIM PANEL 2 - LIFTGATE LAMP UNIT LENS 3 - TRIM STICK (SPECIAL TOOL #C-4755)
4. Gently pry up on the edge of the lamp and pull out of the liftgate lamp unit to remove. (Scheme 8)

Scheme 8

1. Place lamp over retaining clips in liftgate lamp unit retaining clips and firmly snap into place. (Scheme 8)
2. Place the liftgate lamp lens over the retaining pins making sure that they are lined up and them firmly snap into place. (Scheme 7)
3. Close liftgate.
4. Connect the battery negative cable.
5. Close hood.
6. Verify vehicle and system operation.

Scheme 9

1. Disconnect and isolate the battery negative cable.
2. Remove the liftgate trim panel (Refer to «TRIM PANEL»(ref-245423-S15280559772006110200000) ). (Scheme 9) 1 - LIFTGATE LAMP UNIT 2 - LIFTGATE TRIM PANEL 3 - LIFTGATE PANEL 4 - LIFTGATE LAMP UNIT CONNECTOR
3. With the trim panel on the bench, push in on the side retaining clips of the liftgate lamp unit and push through trim panel to remove. (Scheme 10)

Scheme 10

1. Align the liftgate lamp unit in the liftgate door trim panel opening and firmly snap into place. (Scheme 10)
2. Install the liftgate trim panel (Refer to «TRIM PANEL»(ref-245423-S15280559772006110200000) ). (Scheme 9)
3. Connect the battery negative cable.
4. Verify vehicle and system operation.

Scheme 11

1. Open hood, disconnect and isolate the battery negative cable.
2. Open door.
3. Using a trim stick (special tool #4755) or equivalent, gently pry out from the bottom of the lamp lens to remove. (Scheme 11) 1 - POWER LIFTGATE, SUN ROOF CONTROLS (IF EQUIPPED) 2 - OVERHEAD CONSOLE 3 - FRONT READING LAMP LENS 4 - TRIM STICK (SPECIAL TOOL #C-4755) 5 - UNIVERSAL TRANSMITTER
4. Gently pry up on the edge of the lamp and pull out of the overhead console to remove.

Scheme 12

Scheme 13

1. Open hood, disconnect and isolate the battery negative cable.
2. Open door.
3. Using a trim stick (special tool #4755) or equivalent, gently pry out from the side or bottom of the lamp lens to remove. (Scheme 12) 1 - COAT HOOK 2 - REAR READING LAMP LENS 3 - TRIM STICK (SPECIAL TOOL #C-4755)
4. Gently pry up on the edge of the lamp and pull out of the overhead console to remove. (Scheme 13)

1. Place lamp over retaining clips in vanity unit retaining clips and firmly snap into place. see scheme 15
2. Place the vanity lamp lens over the retaining slots making sure that they are lined up and them firmly snap into place. see scheme 14
3. Connect the battery negative cable.
4. Close hood.
5. Verify vehicle and system operation.
6. Close door.
