Power Distribution: Removal & Installation Chrysler Pacifica CS

REMOVAL

Note. When a replacement IPM is installed in the vehicle, the IOD fuse must be rotated to the "customer" position.

Scheme 216

1. Disconnect and isolate the battery negative cable.
2. Remove the hood cable retaining clip near the Integrated Power Module (IPM).
3. Using a flat bladed tool, depress the four locking tabs on the side of the IPM. (Scheme 216)
4. Lift the IPM from the bracket.
5. Disconnect the electrical harness connectors from the IPM.
6. Disconnect the battery connection to the IPM by removing the nut attaching the connection to the bolt.

INSTALLATION

Note. When a replacement IPM is installed in the vehicle, the IOD fuse must be rotated to the "customer" position.

1. Install battery connection and retaining nut. Tighten nut to 28 N.m (250 in. lbs.)
2. Connect the electrical harness connectors to the Integrated Power Module (IPM).
3. Position IPM into place, and lock into position.
4. Install the hood cable retaining clip.
5. Connect battery negative cable.

1. Install base mount ring.
2. Connect the base wires.
3. Firmly snap base into position inside of instrument panel.
4. Connect the battery negative cable.
