Engine Controls - Tests W/o Codes - Bcc Chrysler New Yorker XIII

DIAGNOSTIC TEST PROCEDURE

Diagnostic test procedures are designed to detect system faults as quickly as possible. Body fault codes are accessed through Chrysler Collision Detection (CCD) bus diagnostic connector. On Dynasty and New Yorker, CCD bus diagnostic connector is located under middle of dashboard. On Fifth Avenue and Imperial, CCD bus diagnostic connector is located under left side of dash. (Scheme 120) Chrysler's Diagnostic Readout Box II (DRB-II) tester is used to access information from CCD bus diagnostic connector.

Scheme 120

DRB-II tester, jumper wires, analog volt/ohmmeter and circuit tester will be needed for testing. Proceed to TEST 1: IDENTIFYING VEHICLE EQUIPMENT & SYSTEM PROBLEMS in this article. When system problem is identified according to customer's complaint, perform diagnostic test indicated in flow chart. Information for using the DRB-II during testing is given in diagnostic charts. Once problem has been determined, perform test procedures using these guidelines

1. Always start at the first test in each category or incorrect results may occur.
2. Only perform test steps indicated. It is NOT necessary to perform all steps in a test.
3. At the end of each test step, reconnect all wires and install any components removed for testing.
4. Vehicle battery must be fully charged.
5. Use extreme care when connecting or disconnecting wiring during testing to prevent accidental grounding or shorting.
6. DO NOT use a test light in place of a voltmeter. Damage to electronic components may occur.

CCD BUS TESTING

Using DRB-II tester, a bus problem will show up in one of 3 ways. Despite passing automatic bus test, a NO RESPONSE message may be displayed rather than an expected value on the DRB-II. It is impossible to use DRB-II until reason for NO RESPONSE message is found and corrected. A NO RESPONSE message can be caused by

1. a bus wire open or poorly connected at a module
2. ground or power supply is missing at certain modules
3. ignition is turned off and body controller has timed out

A major bus failure can cause anything from an ENGINE NO START CONDITION to a blank message screen on Electronic Vehicle Information Center (EVIC) head. The automatic bus test will not complete or allow access to further system tests at this point and Red light on DRB-II will come on. A major bus failure can be caused by

1. Short To Ground
2. Short To Battery Voltage
3. Short To 5 Volts
4. Bus "+" & Bus "-" Shorted Together

Critical bus messages preventing bus from operating properly are

1. NO TERMINATION
2. BIAS LEVEL TOO HIGH
3. BIAS LEVEL TOO LOW
4. NO BUS BIAS
5. BUS - OPEN
6. BUS + OPEN
7. BUS + & BUS - OPEN
8. NOT RECEIVING BUS MESSAGES CORRECTLY

DRB-II will display any of these messages on display screen and then go to the next level of testing with no Red light. The only interference will come when trying to access a module directly related to or causing bus failure. A NO RESPONSE message will then appear.

Scheme 121

Scheme 122

Scheme 123

Scheme 124

Note. The following trouble shooting charts and illustrations are Courtesy of Chrysler Motors.

Test 1: Flow Chart (1 of 3). Scheme 125

Test 1: Flow Chart (2 of 3). Scheme 126

Test 1: Flow Chart (3 of 3). Scheme 127

Test 2: Circuit Diagram. Scheme 128

Test 2: Flow Chart (1 of 3). Scheme 129

Test 2: Flow Chart (2 of 3). Scheme 130

Test 2: Flow Chart (3 of 3). Scheme 131

Test 3: Flow Chart (1 of 2). Scheme 132

Test 3: Flow Chart (2 of 2). Scheme 133

Test 4: Circuit Diagram. Scheme 134

Test 4: Flow Chart. Scheme 135

Test 5: Circuit Diagram. Scheme 136

Test 5: Flow Chart. Scheme 137

Test 6: Circuit Diagram. Scheme 138

Test 6: Flow Chart. Scheme 139

Test 7: Circuit Diagram. Scheme 140

Test 7: Flow Chart. Scheme 141

Test 8: Circuit Diagram. Scheme 142

Test 8: Flow Chart. Scheme 143

Test 9: Circuit Diagram. Scheme 144

Test 9: Flow Chart. Scheme 145

Test 10: Circuit Diagram. Scheme 146

Test 10: Flow Chart. Scheme 147

Test 11: Circuit Diagram. Scheme 148

Test 11: Flow Chart. Scheme 149

Test 12: Circuit Diagram. Scheme 150

Test 12: Flow Chart (1 of 2). Scheme 151

Test 12: Flow Chart (2 of 2). Scheme 152

Test 13: Circuit Diagram. Scheme 153

Test 13: Flow Chart. Scheme 154

Test 14: Circuit Diagram. Scheme 155

Test 14: Flow Chart. Scheme 156

Test 15: Circuit Diagram (For 1 of 2). Scheme 157

Test 15: Flow Chart (1 of 2). Scheme 158

Test 15: Circuit Diagram (For 2 of 2). Scheme 159

Test 15: Flow Chart (2 of 2). Scheme 160

Test 16: Circuit Diagram (For 1 of 2). Scheme 161

Test 16: Flow Chart (1 of 2). Scheme 162

Test 16: Flow Chart (2 of 2). Scheme 163

Test 17: Circuit Diagram. Scheme 164

Test 17: Flow Chart. Scheme 165

Test 18: Circuit Diagram. Scheme 166

Test 18: Flow Chart. Scheme 167

Test 19: Circuit Diagram. Scheme 168

Test 19: Flow Chart. Scheme 169

Test 20: Circuit Diagram. Scheme 170

Test 20: Flow Chart. Scheme 171

Test 21: Circuit Diagram & Flow Chart. Scheme 172

Test 22: Circuit Diagram. Scheme 173

Test 22: Flow Chart. Scheme 174

Test 23: Circuit Diagram. Scheme 175

Test 23: Flow Chart. Scheme 176

Test 24: Circuit Diagram. Scheme 177

Test 24: Flow Chart. Scheme 178

Test 25: Flow Chart. Scheme 179

Test 26: Circuit Diagram. Scheme 180

Test 26: Flow Chart. Scheme 181

Test 27: Circuit Diagram. Scheme 182

Test 27: Flow Chart. Scheme 183

Test 28: Circuit Diagram. Scheme 184

Test 28: Flow Chart. Scheme 185

Test 29: Circuit Diagram. Scheme 186

Test 29: Flow Chart. Scheme 187

Test 30: Flow Chart. Scheme 188

Test 31: Circuit Diagram. Scheme 189

Test 31: Flow Chart. Scheme 190

Test 32: Circuit Diagram. Scheme 191

Test 32: Flow Chart (1 of 2). Scheme 192

Test 32: Flow Chart (2 of 2). Scheme 193

Test 33: Circuit Diagram & Flow Chart. Scheme 194

Test 34: Circuit Diagram (For 1 of 2). Scheme 195

Test 34: Flow Chart (1 of 2). Scheme 196

Test 34: Circuit Diagram & Flow Chart (2 of 2). Scheme 197

Test 35: Circuit Diagram. Scheme 198

Test 35: FLow Chart. Scheme 199

Test 36: Circuit Diagram. Scheme 200

Test 36: Flow Chart (1 of 2). Scheme 201

Test 36: Circuit Diagram & Flow Chart (2 of 2). Scheme 202

Test 37: Circuit Diagram. Scheme 203

Test 37: Flow Chart. Scheme 204

Test 38: Flow Chart. Scheme 205

Test 39: Flow Chart (1 of 4). Scheme 206

Test 39: Circuit Diagram (For 2 of 4). Scheme 207

Test 39: Flow Chart (2 of 4). Scheme 208

Test 39: Flow Chart (3 of 4). Scheme 209

Test 39: Flow Chart (4 of 4). Scheme 210

Test 40: Flow Chart (1 of 3). Scheme 211

Test 40: Circuit Diagram (For 2 of 3). Scheme 212

Test 40: Flow Chart (2 of 3). Scheme 213

Test 40: Circuit Diagram (For 3 of 3). Scheme 214

Test 40: Flow Chart (3 of 3). Scheme 215

Test 41: Flow Chart. Scheme 216

Test 42: Flow Chart. Scheme 217

Test 43: Flow Chart. Scheme 218

Test 44: Circuit Diagram. Scheme 219

Test 44: Flow Chart (1 of 2). Scheme 220

Test 44: Flow Chart (2 of 2). Scheme 221

Test 45: Circuit Diagram. Scheme 222

Test 45: Flow Chart (1 of 2). Scheme 223

Test 45: Flow Chart (2 of 2). Scheme 224

Test 46: Flow Chart (1 of 3). Scheme 225

Test 46: Circuit Diagram. Scheme 226

Test 46: Flow Chart (2 of 3). Scheme 227

Test 46: Flow Chart (3 of 3). Scheme 228

Test 47: Flow Chart. Scheme 229

Test 48: Flow Chart. Scheme 230

Test 49: Circuit Diagram. Scheme 231

Test 49: Flow Chart (1 of 2). Scheme 232

Test 49: Flow Chart (2 of 2). Scheme 233

Test 50: Circuit Diagram (For 1 & 2 of 6). Scheme 234

Test 50: Flow Chart (1 of 6). Scheme 235

Test 50: Flow Chart (2 of 6). Scheme 236

Test 50: Circuit Diagram (For 3 of 6). Scheme 237

Test 50: Flow Chart (3 of 6). Scheme 238

Test 50: Circuit Diagram (For 4 of 6). Scheme 239

Test 50: Flow Chart (4 of 6). Scheme 240

Test 50: Circuit Diagram (For 5 & 6 of 6). Scheme 241

Test 50: Flow Chart (5 of 6). Scheme 242

Test 50: Flow Chart (6 of 6). Scheme 243

Test 51: Flow Chart. Scheme 244

Test 52: Circuit Diagram. Scheme 245

Test 52: Flow Chart (1 of 2). Scheme 246

Test 52: Flow Chart (2 of 2). Scheme 247

Test 53: Flow Chart. Scheme 248

Test 54: Circuit Diagram. Scheme 249

Test 54: FLow Chart (1 of 2). Scheme 250

Test 54: Flow Chart (2 of 2). Scheme 251

Test 55: Circuit Diagram. Scheme 252

Test 55: Flow Chart (1 of 2). Scheme 253

Test 55: Flow Chart (2 of 2). Scheme 254

Test 56: Flow Chart (1 of 4). Scheme 255

Test 56: Flow Chart (2 of 4). Scheme 256

Test 56: Flow Chart (3 of 4). Scheme 257

Test 56: Flow Chart (4 of 4). Scheme 258

Test 57: Circuit Diagram. Scheme 259

Test 57: Flow Chart. Scheme 260

Test 58: Circuit Diagram. Scheme 261

Test 58: Flow Chart. Scheme 262

Test 59: Circuit Diagram. Scheme 263

Test 59: Flow Chart. Scheme 264

Test 60A: Flow Chart. Scheme 265

Test 60B: Circuit Diagram & Flow Chart. Scheme 266

Test 61: Circuit Diagram & Flow Chart. Scheme 267

Test 62: Circuit Diagram & Flow Chart. Scheme 268

Test 63: Circuit Diagram & Flow Chart. Scheme 269

Test 64: Circuit Diagram & Flow Chart. Scheme 270

Test 65: Flow Chart. Scheme 271

Test 66: Circuit Diagram & Flow Chart (1 of 2). Scheme 272

Test 66: Circuit Diagram & Flow Chart (2 of 2). Scheme 273

Test 67: Circuit Diagram & Flow Chart. Scheme 274

Test 68: Circuit Diagram & Flow Chart. Scheme 275

Test 69: Circuit Diagram & Flow Chart. Scheme 276

Test 70: Circuit Diagram & Flow Chart. Scheme 277

Test 71: Circuit Diagram & Flow Chart. Scheme 278

Test 72: Circuit Diagram & Flow Chart. Scheme 279

Test 73: Circuit Diagram & Flow Chart. Scheme 280

Test 74: Circuit Diagram & Flow Chart. Scheme 281

Test 75: Circuit Diagram & Flow Chart. Scheme 282

Test 76: Circuit Diagram & Flow Chart. Scheme 283

Test 77: Circuit Diagram & Flow Chart. Scheme 284

Test 78: Circuit Diagram & Flow Chart. Scheme 285

Test 79: Circuit Diagram & Flow Chart. Scheme 286

Test 80: Circuit Diagram. Scheme 287

Test 80: Flow Chart (1 of 2). Scheme 288

Test 80: Flow Chart (2 of 2). Scheme 289

Test 81: Circuit Diagram & Flow Chart. Scheme 290

Test 82: Circuit Diagram & Flow Chart. Scheme 291

Test 83: Circuit Diagram (For 1 of 3). Scheme 292

Test 83: Flow Chart (1 of 3). Scheme 293

Test 46: Circuit Diagram (For 2 & 3 of 3). Scheme 294

Test 83: Flow Chart (2 of 3). Scheme 295

Test 83: Flow Chart (3 of 3). Scheme 296

Test 84: Flow Chart (1 of 3). Scheme 297

Test 84: Flow Chart (2 of 3). Scheme 298

Test 84: Flow Chart (3 of 3). Scheme 299

Test 85: Circuit Diagram & Flow Chart (1 of 2). Scheme 300

Test 85: Circuit Diagram & Flow Chart (2 of 2). Scheme 301

Test 86: Circuit Diagram & Flow Chart. Scheme 302

Test 87: Circuit Diagram. Scheme 303

Test 87: Flow Chart. Scheme 304

Test 88: Flow Chart (1 of 2). Scheme 305

Test 88: Circuit Diagram & Flow Chart (2 of 2). Scheme 306

Test 89: Flow Chart. Scheme 307

Test 90: Circuit Diagram. Scheme 308

Test 90: Flow Chart. Scheme 309

Test 91: Circuit Diagram. Scheme 310

Test 91: Flow Chart. Scheme 311

Test 92: Circuit Diagram. Scheme 312

Test 92: Flow Chart. Scheme 313

Test 93: Flow Chart (1 of 3). Scheme 314

Test 93: Flow Chart (2 of 3). Scheme 315

Test 93: Circuit Diagram & Flow Chart (3 of 3). Scheme 316

Test 94: Circuit Diagram & Flow Chart. Scheme 317

Test 95: Circuit Diagram & Flow Chart. Scheme 318

Test 96: Circuit Diagram & Flwo Chart. Scheme 319

Test 97: Circuit Diagram & Flow Chart. Scheme 320

Test 98: Circuit Diagram (For 1 of 2). Scheme 321

Test 98: FLow Chart (1 of 2). Scheme 322

Test 98: Circuit Diagram (For 2 of 2). Scheme 323

Test 98: Flow Chart (2 of 2). Scheme 324

Test 99: Circuit Diagram & Flow Chart. Scheme 325

Test 100: Circuit Diagram & Flow Chart. Scheme 326

Test 101: Flow Chart (1 of 4). Scheme 327

Test 101: Circuit Diagram & Flow Chart (2 of 4). Scheme 328

Test 101: Circuit Diagram & Flow Chart (3 of 4). Scheme 329

Test 101: Circuit Diagram & Flow Chart (4 of 4). Scheme 330

Test 102: Circuit Diagram. Scheme 331

Test 102: Flow Chart. Scheme 332

Test 103: Flow Chart (1 of 2). Scheme 333

Test 103: Circiut Diagram & Flow Chart (2 of 2). Scheme 334

Test 104: Circuit Diagram & Flow Chart. Scheme 335

Test 105: Circuit Diagram & Flow Chart. Scheme 336

Test 106: Circuit Diagram & Flow Chart. Scheme 337

Test 107: Circuit Diagram & Flow Chart. Scheme 338

Test 108: Flow Chart. Scheme 339

Test 109: Flow Chart (1 of 2). Scheme 340

Test 109: Circuit Diagram & Flow Chart (2 of 2). Scheme 341

Test 110: Flow Chart (1 of 2). Scheme 342

Test 110: Flow Chart (2 of 2). Scheme 343

Test 111: Circuit Diagram & Flow Chart (1 of 4). Scheme 344

Test 111: Flow Chart (2 of 4). Scheme 345

Test 111: Flow Chart (3 of 4). Scheme 346

Test 111: Flow Chart (4 of 4). Scheme 347

Test 112: Flow Chart (1 of 2). Scheme 348

Test 112: Flow Chart (2 of 2). Scheme 349

Test 113: Flow Chart (1 of 3). Scheme 350

Test 113: Flow Chart (2 of 3). Scheme 351

Test 113: Flow Chart (3 of 3). Scheme 352

Test 114: Flow Chart (1 of 3). Scheme 353

Test 114: Flow Chart (2 of 3). Scheme 354

Test 114: Flow Chart (3 of 3). Scheme 355

Test 115: Flow Chart (1 of 3). Scheme 356

Test 115: Flow Chart (2 of 3). Scheme 357

Test 115: Flow Chart (3 of 3). Scheme 358

Test 116: Circuit Diagram & Flow Chart. Scheme 359

Test 117: Circuit Diagram & Flow Chart. Scheme 360

Test 118: Circuit Diagram & Flow Chart. Scheme 361

Test 119: Circuit Diagram & Flow Chart. Scheme 362

Test 120: Circuit Diagram & Flow Chart. Scheme 363

Test 121: Circuit Diagram. Scheme 364

Test 121: Flow Chart. Scheme 365

Test 122: Flow Chart (1 of 2). Scheme 366

Test 122: Flow Chart (2 of 2). Scheme 367

Test 123: Circuit Diagram & Flow Chart. Scheme 368

Test 124: Flow Chart (1 of 2). Scheme 369

Test 124: Flow Chart (2 of 2). Scheme 370

Test 125: Flow Chart (1 of 2). Scheme 371

Test 125: Flow Chart (2 of 2). Scheme 372

Test 126: Flow Chart (1 of 2). Scheme 373

Test 126: Flow Chart (2 of 2). Scheme 374

Test 127: Circuit Diagram & Flow Chart. Scheme 375
