FUSE PANEL IDENTIFICATION
To gain access to fuse box, place hands under fuse access panel, one on each side of steering column, and pull panel outward. Considerable effort is required to overcome retaining latches. When panel is free of the latches, swing it away from tabs that hold top in place. With panel out of the way, fuse block can be removed by sliding it off the retaining bracket, to the left.
Note. On all 1983-84 models, headlight and washer/wiper switches have integral circuit breakers. On all 1985-89 models, only the headlight switch has an integral circuit breaker.
Scheme 2
1 - 20 Amp
Hazard Flashers.
2 - 20 Amp
Back-Up Lights, Cornering Lights, Trip Navigator, Fan Relay Coil, A/C Fan & Clutch Relay Coil, Overhead Console, ATC Control, Transmission Pressure Switch, Convertible Top Relay Coil, Air Bag Module, Rear Window Defroster, Auto. Load Leveling.
3 - 30 Amp (Circuit Breaker)
Power Window Motors, Convertible Power Top.
4 - 30 Amp
A/C Blower Motor, Heater Blower, ATC Power Module.
5 - 20 Amp
Park & Taillights, License & Side Marker Lights, Display Intensity, Cavity 12, Rear A/C Unit Light, Taillight Outage.
6 - 20 Amp
Stoplights & Stoplight Outage, Illuminated Entry, Dome & Map Light, Trunk/Cargo & Underhood Lights, Ignition Switch Time Delay Relay, Power Mirrors, Vanity Mirrors, Overhead & Rear Consoles, Chimes.
7 - 20 Amp
Horn, Horn Relay, Cigarette Lighter, Glove Box & Key In Lights, Radio & Clock Memory, Navigator/Traveler, Electronic Cluster, Power Antenna, Air Bag Module, Electronic Chime, Speaker Amplifier, Voice Alert, Door Open Light, Trip Computer, Clock.
8 - 30 Amp (Circuit Breaker)
Power Seat Motors, Power Door Lock Motors, Horns & Horn Relay (1989), Concealed Headlight Motors (1988).
9 - 5 Amp (1983-84); 10 Amp (1985-89)
Radio & Clock Display, Pre-Speaker Electronics Relay Sense, Trip Computer (1983-84); Radio & Clock Power (1985-89).
10 - 20 Amp
Turn Signal Lights, Heated Rear Window Relay, Console Bin Light, A/C Clutch, Idle-Up (2.2L With A/C), A/C Fan Relay Coil, Premium Speakers, Illuminated Entry, Convertible Top Relay.
11 - 20 Amp
Front Windshield Wipers & Washers, Intermittent Wiper Module.
12 - 4 Amp
Cluster, A/C & Heater Control, Heated Rear Window, Ashtray, Console Radio, Navigator/Traveler, Rear Heater Switch, Rear A/C Light, Trip Computer Switch, Clock & Radio Display Dimming, Message Center Illumination.
13 - 5 Amp
Fuel Gauge, BRAKE Warning Light, CHECK ENGINE Warning & Seat Belt, Voltage & Message Center Warnings, Seat Belt Chimes, Speed Control, Temperature Gauge, Temperature Lights, Illuminated Entry, Air Bag Module, Cluster Printed Circuit Board Gauges, Voice Alert, Fuel Pacer, CHECK ENGINE Lights.
14 - 6 Amp Circuit Breaker (1983-88); 20 Amp (1989)
Electric Deck Lid Release, Rear Washer/Wiper & Liftgate Solenoid Relay (1983-88); Optional Horn, High Beam Indicator, Concealed Headlight Module, Rear Washer/Wiper & Liftgate Relay (1989).
15 - Blank (1983 & 1985-87); 20 Amp (1984 & 1988); 10 Amp (1989)
Not Used (1983). Heated Rear Window Sensor (1984); Not Used (1985-87); Dome & Map Light, Trunk/Cargo Light, Ignition Switch Key Light Time Delay, Power Mirrors, Load Leveling Solenoid, Illuminated Entry (1988); Heated Mirrors (1989).
16 - Blank (1983 & 1985-87 Town & Country); 20 Amp (1984 & 1988); 25 Amp (1989)
Not Used (1983). EFI Fuel Pump Motors, Injectors & Ignition Coil (1984); Not Used (1985-87); Right & Left Spotlight (1988); Concealed Headlight Motors (1989).
17 - Turn Signal Flasher
No additional description.
18 - Time Delay Relay
No additional description.
19 - Horn Relay
No additional description.
20 - Circuit Breaker
No additional description.
21 - Circuit Breaker
No additional description.
