Dtcs p0133 to p0153 Chrysler Crossfire I final

Scheme 103

1. When Monitored : Start and drive vehicle greater than 32 km/h (20 MPH) and less than 89 km/h (55 MPH). Throttle open for a minimum 120 seconds. Coolant Temp greater than 70°C (158°F) Catalytic Converter Temperature greater than 600°C (1112°F).
2. Set Condition : The O2 sensor voltage switches only 11 times or less from lean to rich within 20 seconds during monitoring. Two Trip Fault.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

Diagnostic Test

1. 1) CHECK FOR CURRENT DTC Turn the ignition on. With the scan tool, read PCM DTCs. Is this DTC present? Yes For complete diagnosis of this DTC, refer to «P0133-O2 SENSOR 1/1 SHORT DELAY TIME»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p0133-to-p0153__p0133-o2-sensor-11-short-delay-time) . No Go to 2) .
2. 2) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

P0133-O2 SENSOR 1/1 LONG PERFORMANCE

1. When Monitored : Start and drive vehicle greater than 32 km/h (20 MPH) and less than 89 km/h (55 MPH). Throttle open for a minimum 120 seconds. Coolant Temp greater than 70°C (158°F) Catalytic Converter Temperature greater than 600°C (1112°F).
2. Set Condition : The O2 sensor voltage switches only 11 times or less from lean to rich within 20 seconds during monitoring. Two Trip Fault.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

1. 1) CHECK FOR CURRENT DTC Turn the ignition on. With the scan tool, read PCM DTCs. Is this DTC present? Yes For complete diagnosis of this DTC, refer to «P0133-O2 SENSOR 1/1 SHORT DELAY TIME»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p0133-to-p0153__p0133-o2-sensor-11-short-delay-time) . No Go to 2) .
2. 2) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

P0133-O2 SENSOR 1/1 SHORT DELAY TIME

1. When Monitored : Start and drive vehicle greater than 32 km/h (20 MPH) and less than 89 km/h (55 MPH). Throttle open for a minimum 120 seconds. Coolant Temp greater than 70°C (158°F) Catalytic Converter Temperature greater than 600°C (1112°F).
2. Set Condition : The O2 sensor voltage switches only 11 times or less from lean to rich within 20 seconds during monitoring. Two Trip Fault.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

Scheme 104

Scheme 105

1. 1) PRE-DIAGNOSTIC CHECK OUT NOTE: Always perform diagnostics with a fully charged battery. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. NOTE: Check for applicable TSBs related to the problem. Turn the ignition on. With the scan tool, read PCM DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Repair as necessary. Perform this procedure prior to symptom diagnosis. Continue Go to 2) .
2. 2) CHECK FOR CURRENT DTC NOTE: It is important to perform the diagnostics on the O2 Sensor that set the DTC. NOTE: Check for contaminates that may have damaged the O2 Sensor: contaminated fuel, unapproved silicone, oil and coolant. NOTE: If the PCM detects and stores a DTC, the PCM also stores the engine/vehicle operating conditions under which the DTC was set. Some of these conditions are displayed on the scan tool at the same time the DTC is displayed. NOTE: Before erasing stored DTCs, record these conditions. Attempting to duplicate these conditions may assist when checking for a DTC. Turn the ignition on. With the scan tool, erase PCM DTCs. NOTE: It maybe necessary to road test the vehicle for this DTC to set. With the scan tool, read PCM DTCs. Did this DTC set again? Yes Go to 3) . No Go to 6) .
3. 3) EXHAUST LEAK Start the engine. Inspect the exhaust system for leaks between the engine and the O2 Sensors. Are there any exhaust leaks? Yes Repair or replace the leaking exhaust parts as necessary. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/exhaust/#exhaust-system__removal) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Go to 4) .
4. 4) O2 SENSOR SIGNAL CIRCUIT Turn the ignition off. Disconnect the O2 Sensor harness connector. NOTE: Check connectors - Clean/repair as necessary. Turn the ignition on. Measure the voltage on the O2 Sensor Signal circuit at the O2 Sensor harness connector. Is the voltage approximately 0.47 volt? Yes Go to 5) . No Check the O2 Sensor Signal circuit for damage, short to ground, open, or short to voltage. If OK, replace and program the Powertrain Control Module. See «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-service-information) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
5. 5) SENSOR GROUND CIRCUIT With the ignition on. Measure the voltage on the Sensor Ground circuit at the O2 Sensor harness connector. Is the voltage above 0.1 volt? Yes Check the Sensor Ground circuit for damage, short to ground, open, or short to voltage. If OK, replace and program the Powertrain Control Module. See «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-service-information) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Replace the Oxygen Sensor. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/fuel-system/#fuel-system) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
6. 6) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

P0133-O2 SENSOR 1/1 SHORT PERFORMANCE

1. When Monitored : Start and drive vehicle greater than 32 km/h (20 MPH) and less than 89 km/h (55 MPH). Throttle open for a minimum 120 seconds. Coolant Temp greater than 70°C (158°F) Catalytic Converter Temperature greater than 600°C (1112°F).
2. Set Condition : The O2 sensor voltage switches only 11 times or less from lean to rich within 20 seconds during monitoring. Two Trip Fault.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

1. 1) CHECK FOR CURRENT DTC Turn the ignition on. With the scan tool, read PCM DTCs. Is this DTC present? Yes For complete diagnosis of this DTC, refer to «P0133-O2 SENSOR 1/1 SHORT DELAY TIME»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p0133-to-p0153__p0133-o2-sensor-11-short-delay-time) . No Go to 2) .
2. 2) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

Scheme 106

1. When Monitored : With the engine running between 1000 and 2000 RPM, engine load between 15% to 50%, closed loop mode, the three way catalytic converter temperature is greater than 380°C (716°F), and the O2 sensor heater must be ON for at least 220 seconds to enable the signal inactive portion of the test.
2. Set Condition : O2 Sensor voltage is less than 0.15 volt for approximately 5 seconds. Signal stays at center: The O2 Sensor voltage stays between 0.4 and 0.6 volt for more than approximately 15 seconds after the O2 Sensor heater has been ON for at least 220 seconds.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

1. 1) CHECK FOR CURRENT DTC Turn the ignition on. With the scan tool, read PCM DTCs. Is this DTC present? Yes For complete diagnosis of this DTC, refer to «P0131-O2 SENSOR 1/1 CIRCUIT LOW»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p0033-to-p0132) . No Go to 2) .
2. 2) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

Scheme 107

1. When Monitored : Engine Running and Heater duty cycle greater than 0%.
2. Set Condition : O2 Heater Temperature does not reach 575°C (959°F) within 90 seconds during monitoring conditions. Two Trip Fault.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

Scheme 108

Scheme 109

Scheme 110

1. 1) PRE-DIAGNOSTIC CHECK OUT NOTE: Always perform diagnostics with a fully charged battery. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. NOTE: Check for applicable TSBs related to the problem. Turn the ignition on. With the scan tool, read PCM DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Repair as necessary. Perform this procedure prior to symptom diagnosis. Continue Go to 2) .
2. 2) CHECK FOR CURRENT DTC NOTE: If the PCM detects and stores a DTC, the PCM also stores the engine/vehicle operating conditions under which the DTC was set. Some of these conditions are displayed on the scan tool at the same time the DTC is displayed. NOTE: Before erasing stored DTCs, record these conditions. Attempting to duplicate these conditions may assist when checking for an active DTC. Turn the ignition on. With the scan tool, erase PCM DTCs. NOTE: It maybe necessary to road test the vehicle for this DTC to set. With the scan tool, read PCM DTCs. Did this DTC set again? Yes Go to 4) . No Go to 3) .
3. 3) O2 SENSOR HEATER OPERATION Turn the ignition off. NOTE: Allow the O2 Sensor to cool down before continuing the test. Raising the hood may help in reducing under hood temperatures. Connect a jumper wire between ground and the Oxygen Sensor Heater Control circuit at the PCM harness connector leaving the harness connector connected to the PCM. Turn the ignition on. With the scan tool, monitor O2 Sensor voltage for at least 2 minutes. CAUTION: Remove the jumper wire after this Step is complete. Does the voltage stay above 0.47 volt? Yes Go to 4) . No Go to 7) .
4. 4) O2 HEATER ELEMENT NOTE: Check the Engine Control Fuse 2 in the Relay Control Module. If it is open, multiple DTCs will be set in the PCM. Determine the cause of the open fuse before continuing using the wiring diagrams/schematics as a guide. Turn the ignition off. NOTE: Allow the O2 Sensor to cool down to room temperature. Raising the hood may help in reducing under hood temperatures. Disconnect the O2 Sensor harness connector. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance of the O2 Sensor Heater element. NOTE: O2 Sensor Heater Resistance Specification: 8.5 to 9.5 ohms. Is the resistance within specifications? Yes Go to 5) . No Replace the O2 Sensor. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/fuel-system/#fuel-system) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
5. 5) FUSED ENGINE CONTROL RELAY OUTPUT CIRCUIT OPEN Turn the ignition on. Measure the voltage of the O2 Heater Fused Engine Control Relay Output circuit at the O2 Sensor harness connector. Is the voltage above 10 volts? Yes Go to 6) . No Repair the O2 Heater Fused Engine Control Relay Output circuit for an open. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
6. 6) O2 HEATER CONTROL CIRCUIT OPEN Turn the ignition off. Disconnect the PCM harness connectors. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance of the O2 Heater Control circuit from the O2 Sensor harness connector to the PCM harness connector. Is the resistance below 5.0 ohms? Yes Replace and program the Powertrain Control Module. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-service-information) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Repair the O2 Heater Control circuit for an open. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
7. 7) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

P0135-O2 SENSOR 1/1 HEATER CIRCUIT LOW

1. When Monitored : Engine Running and Heater duty cycle greater than 0%
2. Set Condition : The PCM detects the O2 Heater voltage is out of acceptable range. Below 0.0926 volt.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

Scheme 111

1. 1) PRE-DIAGNOSTIC CHECK OUT NOTE: Always perform diagnostics with a fully charged battery. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. NOTE: Check for applicable TSBs related to the problem. Turn the ignition on. With the scan tool, read PCM DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Repair as necessary. Perform this procedure prior to symptom diagnosis. Continue Go to 2) .
2. 2) O2 HEATER ELEMENT NOTE: Check the Engine Control Fuse 2 in the Relay Control Module. If it is open, multiple DTCs will be set in the PCM. Determine the cause of the open fuse before continuing using the wiring diagrams/schematics as a guide. NOTE: Allow the O2 Sensor to cool down to room temperature. Turn the ignition off. Disconnect the O2 Sensor harness connector. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance of the O2 Sensor Heater element at the O2 Sensor harness connector. Is the O2 Sensor Heater element resistance between 8.5 and 9.5 ohms? Yes Go to 3) . No Replace the Oxygen Sensor. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/fuel-system/#fuel-system) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
3. 3) O2 HEATER CONTROL CIRCUIT SHORT TO GROUND With the ignition off. Disconnect the PCM harness connectors. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance between ground and the O2 Heater Control circuit. Is the resistance above 100 kohms? Yes Before continuing, check the PCM harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Replace and program the Powertrain Control Module. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-service-information) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Repair the O2 Heater Control circuit for a short to ground. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .

P0135-O2 SENSOR 1/1 HEATER CIRCUIT OPEN

1. When Monitored : Engine Running and Heater duty cycle greater than 0%.
2. Set Condition : O2 Heater Temperature does not reach 575°C (959°F) within 90 seconds during monitoring conditions. Two Trip Fault.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

1. 1) CHECK FOR CURRENT DTC Turn the ignition on. With the scan tool, read PCM DTCs. Is this DTC present? Yes For complete diagnosis of this DTC, refer to «P0135-O2 SENSOR 1/1 HEATER CIRCUIT HIGH»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p0133-to-p0153) No Go to 2) .
2. 2) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

P0135-O2 SENSOR 1/1 HEATER PERFORMANCE

1. When Monitored : Engine Running and Heater duty cycle greater than 0%.
2. Set Condition : O2 Heater Temperature does not reach 575°C (959°F) within 90 seconds during monitoring conditions. Two Trip Fault.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

Scheme 112

Scheme 113

Scheme 114

1. 1) PRE-DIAGNOSTIC CHECK OUT NOTE: Always perform diagnostics with a fully charged battery. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. NOTE: Check for applicable TSBs related to the problem. Turn the ignition on. With the scan tool, read PCM DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Repair as necessary. Perform this procedure prior to symptom diagnosis. Continue Go to 2) .
2. 2) CHECK FOR CURRENT DTC NOTE: If the PCM detects and stores a DTC, the PCM also stores the engine/vehicle operating conditions under which the DTC was set. Some of these conditions are displayed on the scan tool at the same time the DTC is displayed. NOTE: Before erasing stored DTCs, record these conditions. Attempting to duplicate these conditions may assist when checking for an active DTC. Turn the ignition on. With the scan tool, erase PCM DTCs. NOTE: It maybe necessary to road test the vehicle for this DTC to set. With the scan tool, read PCM DTCs. Did this DTC set again? Yes Go to 3) . No Go to 8) .
3. 3) PCM NOTE: Check the Engine Control Fuse 2 in the Relay Control Module. If it is open, multiple DTCs will be set in the PCM. Determine the cause of the open fuse before continuing using the wiring diagrams/schematics as a guide. Turn the ignition off. Disconnect the PCM harness connectors. NOTE: Check connectors - Clean/repair as necessary. Turn the ignition on. Measure the voltage of the O2 Sensor Heater Control circuit at the PCM harness connector. Is the voltage above 10 volts? Yes Replace and program the Powertrain Control Module. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-service-information) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Go to 4) .
4. 4) O2 SENSOR HEATER CONTROL CIRCUIT SHORT TO GROUND Turn the ignition off. Disconnect the O2 Sensor harness connector. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance between ground and the O2 Sensor Heater Control circuit. Is resistance above 100 kohms? Yes Go to 5) . No Repair the O2 Sensor Heater Control circuit for a short to ground. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
5. 5) O2 SENSOR HEATER CONTROL CIRCUIT SHORT TO VOLTAGE Turn the ignition on. Measure the voltage of the O2 Sensor Heater Control circuit at the O2 Sensor harness connector. Is the voltage below 1.0 volt? Yes Go to 6) . No Repair the O2 Sensor Heater Control circuit for a short to voltage. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
6. 6) O2 SENSOR HEATER CONTROL CIRCUIT OPEN Turn the ignition off. Measure the resistance of the O2 Sensor Heater Control circuit from the O2 Sensor harness connector to the PCM harness connector. Is the resistance below 5.0 ohms? Yes Go to 7) . No Repair the O2 Sensor Heater Control circuit for an open. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
7. 7) FUSED ENGINE CONTROL RELAY OUTPUT CIRCUIT OPEN Turn the ignition on. Measure the voltage of the Fused Engine Control Relay Output circuit at the O2 Sensor harness connector. Is the voltage above 10 volts? Yes Replace the O2 Sensor. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/fuel-system/#fuel-system) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Repair the Fused Engine Control Relay Output circuit for an open. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
8. 8) INTERMITTENT WIRING AND CONNECTORS The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. NOTE: Check for any Technical Service Bulletins that may apply. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

Scheme 115

1. When Monitored : Start and drive vehicle greater than 32 km/h (20 MPH) and less than 89 km/h (55 MPH). Throttle open for a minimum 120 seconds. Coolant Temp greater than 70°C (158°F) and Catalytic Converter Temperature greater than 600°C (1112°F).
2. Set Condition : The O2 sensor voltage switches only 11 times or less from lean to rich within 20 seconds during monitoring. Two Trip Fault.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

1. 1) CHECK FOR CURRENT DTC Turn the ignition on. With the scan tool, read PCM DTCs. Is this DTC present? Yes For complete diagnosis of this DTC, refer to «P0137-O2 SENSOR 2/2 ABOVE THRESHOLD»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p0133-to-p0153__p0137-o2-sensor-22-above-threshold) . No Go to 2) .
2. 2) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

P0137-O2 SENSOR 1/2 BELOW THRESHOLD

1. When Monitored : Start and drive vehicle greater than 32 km/h (20 MPH) and less than 89 km/h (55 MPH). Throttle open for a minimum 120 seconds. Coolant Temp greater than 70°C (158°F) and Catalytic Converter Temperature greater than 600°C (1112°F).
2. Set Condition : The O2 sensor voltage switches only 11 times or less from rich to lean within 20 seconds during monitoring. Two Trip Fault.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

1. 1) CHECK FOR CURRENT DTC Turn the ignition on. With the scan tool, read PCM DTCs. Is this DTC present? Yes For complete diagnosis of this DTC, refer to «P0137-O2 SENSOR 2/2 ABOVE THRESHOLD»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p0133-to-p0153__p0137-o2-sensor-22-above-threshold) . No Go to 2) .
2. 2) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

P0137-O2 SENSOR 2/2 ABOVE THRESHOLD

1. When Monitored : Start and drive vehicle greater than 32 km/h (20 MPH) and less than 89 km/h (55 MPH). Throttle open for a minimum 120 seconds. Coolant Temp greater than 70°C (158°F) and Catalytic Converter Temperature greater than 600°C (1112°F).
2. Set Condition : The O2 sensor voltage switches only 11 times or less from lean to rich within 20 seconds during monitoring. Two Trip Fault.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

Scheme 116

Scheme 117

1. 1) PRE-DIAGNOSTIC CHECK OUT NOTE: Always perform diagnostics with a fully charged battery. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. NOTE: Check for applicable TSBs related to the problem. Turn the ignition on. With the scan tool, read PCM DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Repair as necessary. Perform this procedure prior to symptom diagnosis. Continue Go to 2) .
2. 2) CHECK FOR CURRENT DTC NOTE: It is important to perform the diagnostics on the O2 Sensor that set the DTC. NOTE: Check for contaminates that may have damaged the O2 Sensor: contaminated fuel, unapproved silicone, oil and coolant. NOTE: If the PCM detects and stores a DTC, the PCM also stores the engine/vehicle operating conditions under which the DTC was set. Some of these conditions are displayed on the scan tool at the same time the DTC is displayed. NOTE: Before erasing stored DTCs, record these conditions. Attempting to duplicate these conditions may assist when checking for an active DTC. Turn the ignition on. With the scan tool, erase PCM DTCs. NOTE: It maybe necessary to road test the vehicle for this DTC to set. With the scan tool, read PCM DTCs. Did this DTC set again? Yes Go to 3) . No Go to 6) .
3. 3) EXHAUST LEAK Start the engine. Inspect the exhaust system for leaks between the engine and the O2 Sensors. Refer to «INSPECTION»(/chrysler/crossfire/i-final-2008-2008/remont/exhaust/#exhaust-system__inspection) . Are there any exhaust leaks? Yes Repair or replace the leaking exhaust parts as necessary. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/exhaust/#exhaust-system__removal) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Go to 4) .
4. 4) O2 SIGNAL CIRCUIT Turn the ignition off Disconnect the O2 Sensor harness connector. NOTE: Check connectors - Clean/repair as necessary. Turn the ignition on. Measure the voltage of the O2 Signal circuit at the O2 Sensor harness connector. Is the voltage approximately 0.47 volt? Yes Go to 5) . No Check the O2 Signal circuit for damage, short to ground, open, or short to voltage. If OK, replace and program the Powertrain Control Module. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-service-information) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
5. 5) SENSOR GROUND CIRCUIT Turn the ignition off. Disconnect the PCM harness connectors. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance of the Sensor Ground circuit from the O2 Sensor harness connector to the PCM harness connector. Is the resistance below 5.0 ohms? Yes Replace the Oxygen Sensor. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/fuel-system/#fuel-system) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Check the Sensor Ground circuit for damage, short to ground, open, or short to voltage. If OK, replace and program the Powertrain Control Module. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-service-information) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
6. 6) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

P0137-O2 SENSOR 2/2 BELOW THRESHOLD

1. When Monitored : Start and drive vehicle greater than 32 km/h (20 MPH) and less than 89 km/h (55 MPH). Throttle open for a minimum 120 seconds. Coolant Temp greater than 70°C (158°F) and Catalytic Converter Temperature greater than 600°C (1112°F).
2. Set Condition : The O2 sensor voltage switches only 11 times or less from rich to lean within 20 seconds during monitoring. Two Trip Fault.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

1. 1) CHECK FOR CURRENT DTC Turn the ignition on. With the scan tool, read PCM DTCs. Is this DTC present? Yes For complete diagnosis of this DTC, refer to «P0137-O2 SENSOR 2/2 ABOVE THRESHOLD»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p0133-to-p0153__p0137-o2-sensor-22-above-threshold) . No Go to 2) .
2. 2) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

P0138-O2 SENSOR 1/2 CIRCUIT HIGH

1. When Monitored : With the engine running between 1000 and 2000 RPM, engine load between 15% to 50%, closed loop mode, the three way catalytic converter temperature is greater than 380°C (716°F), and the O2 sensor heater must be ON for at least 220 seconds to enable the signal inactive portion of the test.
2. Set Condition : O2 Sensor voltage is greater than 1.5 volts for approximately 5 seconds.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

1. 1) CHECK FOR CURRENT DTC Turn the ignition on. With the scan tool, read PCM DTCs. Is this DTC present? Yes For complete diagnosis of this DTC, refer to «P0131-O2 SENSOR 1/1 CIRCUIT LOW»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p0033-to-p0132) . No Go to 2) .
2. 2) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

P0138-O2 SENSOR 1/2 CIRCUIT OPEN

1. When Monitored : With the engine running between 1000 and 2000 RPM, engine load between 15% to 50%, closed loop mode, the three way catalytic converter temperature is greater than 380°C (716°F), and the O2 sensor heater must be ON for at least 220 seconds to enable the signal inactive portion of the test.
2. Set Condition : O2 Sensor voltage is less than 0.15 volt for approximately 5 seconds. Signal stays at center: The O2 Sensor voltage stays between 0.4 and 0.6 volt for more than approximately 15 seconds after the O2 Sensor heater has been ON for at least 220 seconds.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

1. 1) CHECK FOR CURRENT DTC Turn the ignition on. With the scan tool, read PCM DTCs. Is this DTC present? Yes For complete diagnosis of this DTC, refer to «P0131-O2 SENSOR 1/1 CIRCUIT LOW»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p0033-to-p0132) . No Go to 2) .
2. 2) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

P0138-O2 SENSOR 2/2 CIRCUIT LOW

1. When Monitored : With the engine running between 1000 and 2000 RPM, engine load between 15% to 50%, closed loop mode, the three way catalytic converter temperature is greater than 380°C (716°F), and the O2 sensor heater must be ON for at least 220 seconds to enable the signal inactive portion of the test.
2. Set Condition : O2 Sensor voltage is less than 0.15 volt for approximately 5 seconds.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

1. 1) CHECK FOR CURRENT DTC Turn the ignition on. With the scan tool, read PCM DTCs. Is this DTC present? Yes For complete diagnosis of this DTC, refer to «P0131-O2 SENSOR 1/1 CIRCUIT LOW»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p0033-to-p0132) . No Go to 2) .
2. 2) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

P0138-O2 SENSOR 2/2 CIRCUIT OPEN

1. When Monitored : With the engine running between 1000 and 2000 RPM, engine load between 15% to 50%, closed loop mode, the three way catalytic converter temperature is greater than 380°C (716°F), and the O2 sensor heater must be ON for at least 220 seconds to enable the signal inactive portion of the test.
2. Set Condition : O2 Sensor voltage is less than 0.15 volt for approximately 5 seconds. Signal stays at center: The O2 Sensor voltage stays between 0.4 and 0.6 volt for more than approximately 15 seconds after the O2 Sensor heater has been ON for at least 220 seconds.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

1. 1) CHECK FOR CURRENT DTC Turn the ignition on. With the scan tool, read PCM DTCs. Is this DTC present? Yes For complete diagnosis of this DTC, refer to «P0131-O2 SENSOR 1/1 CIRCUIT LOW»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p0033-to-p0132) . No Go to 2) .
2. 2) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

P0140-O2 SENSOR 1/2 CIRCUIT LOW

1. When Monitored : With the engine running between 1000 and 2000 RPM, engine load between 15% to 50%, closed loop mode, the three way catalytic converter temperature is greater than 380°C (716°F), and the O2 sensor heater must be ON for at least 220 seconds to enable the signal inactive portion of the test.
2. Set Condition : O2 Sensor voltage is less than 0.15 volt for approximately 5 seconds. Signal stays at center: The O2 Sensor voltage stays between 0.4 and 0.6 volt for more than approximately 15 seconds after the O2 Sensor heater has been ON for at least 220 seconds.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

1. 1) CHECK FOR CURRENT DTC Turn the ignition on. With the scan tool, read PCM DTCs. Is this DTC present? Yes For complete diagnosis of this DTC, refer to «P0131-O2 SENSOR 1/1 CIRCUIT LOW»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p0033-to-p0132) . No Go to 2) .
2. 2) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

P0140-O2 SENSOR 2/2 CIRCUIT HIGH

1. When Monitored : With the engine running between 1000 and 2000 RPM, engine load between 15% to 50%, closed loop mode, the three way catalytic converter temperature is greater than 380°C (716°F), and the O2 sensor heater must be ON for at least 220 seconds to enable the signal inactive portion of the test.
2. Set Condition : The high limit: O2 Sensor voltage is greater than 1.5 volts for approximately 5 seconds.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

1. 1) CHECK FOR CURRENT DTC Turn the ignition on. With the scan tool, read PCM DTCs. Is this DTC present? Yes For complete diagnosis of this DTC, refer to «P0131-O2 SENSOR 1/1 CIRCUIT LOW»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p0033-to-p0132) . No Go to 2) .
2. 2) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

P0141-O2 SENSOR 1/2 HEATER CIRCUIT HIGH

1. When Monitored : Engine Running and Heater duty cycle greater than 0%.
2. Set Condition : O2 Heater Temperature does not reach 575°C (959°F) within 90 seconds during monitoring conditions. Two Trip Fault.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

1. 1) CHECK FOR CURRENT DTC Turn the ignition on. With the scan tool, read PCM DTCs. Is this DTC present? Yes For complete diagnosis of this DTC, refer to «P0135-O2 SENSOR 1/1 HEATER CIRCUIT HIGH»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p0133-to-p0153) . No Go to 2) .
2. 2) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

P0141-O2 SENSOR 1/2 HEATER CIRCUIT LOW

1. When Monitored : Engine Running and Heater duty cycle greater than 0%
2. Set Condition : The PCM detects the O2 Heater voltage is out of acceptable range. Below 0.0926 volt.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

1. 1) CHECK FOR CURRENT DTC Turn the ignition on. With the scan tool, read PCM DTCs. Is this DTC present? Yes For complete diagnosis of this DTC, refer to «P0135-O2 SENSOR 1/1 HEATER CIRCUIT LOW»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p0133-to-p0153__p0135-o2-sensor-11-heater-circuit-low) . No Go to 2) .
2. 2) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

P0141-O2 SENSOR 1/2 HEATER CIRCUIT OPEN

1. When Monitored : Engine Running and Heater duty cycle greater than 0%.
2. Set Condition : O2 Heater Temperature does not reach 575°C (959°F) within 90 seconds during monitoring conditions. Two Trip Fault.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

1. 1) CHECK FOR CURRENT DTC Turn the ignition on. With the scan tool, read PCM DTCs. Is this DTC present? Yes For complete diagnosis of this DTC, refer to «P0135-O2 SENSOR 1/1 HEATER CIRCUIT HIGH»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p0133-to-p0153) . No Go to 2) .
2. 2) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

P0141-O2 SENSOR 1/2 HEATER PERFORMANCE

1. When Monitored : Engine Running and Heater duty cycle greater than 0%.
2. Set Condition : O2 Heater Temperature does not reach 575°C (959°F) within 90 seconds during monitoring conditions. Two Trip Fault.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

1. 1) CHECK FOR CURRENT DTC Turn the ignition on. With the scan tool, read PCM DTCs. Is this DTC present? Yes For complete diagnosis of this DTC, refer to «P0135-O2 SENSOR 1/1 HEATER PERFORMANCE»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p0133-to-p0153__p0135-o2-sensor-11-heater-performance) . No Go to 2) .
2. 2) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

P0151-O2 SENSOR 2/1 CIRCUIT LOW

1. When Monitored : With the engine running between 1000 and 2000 RPM, engine load between 15% to 50%, closed loop mode, the three way catalytic converter temperature is greater than 380°C (716°F), and the O2 sensor heater must be ON for at least 220 seconds to enable the signal inactive portion of the test.
2. Set Condition : O2 Sensor voltage is less than 0.15 volt for approximately 5 seconds. Signal stays at center: The O2 Sensor voltage stays between 0.4 and 0.6 volt for more than approximately 15 seconds after the O2 Sensor heater has been ON for at least 220 seconds.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

Scheme 118

Scheme 119

Scheme 120

1. 1) PRE-DIAGNOSTIC CHECK OUT NOTE: Always perform diagnostics with a fully charged battery. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. NOTE: Check for applicable TSBs related to the problem. Turn the ignition on. With the scan tool, read PCM DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Repair as necessary. Perform this procedure prior to symptom diagnosis. Continue Go to 2) .
2. 2) MONITOR THE O2 SENSOR VOLTAGE With the scan tool, monitor the 2/1 O2 Sensor Signal voltage. Is the O2 Sensor voltage above 1.4 volts or below 0.15 volt? Voltage is above 1.4 volts. Go to 4) . Voltage is less than 0.15 of a volt. Go to 6) . Voltage is between 1.4 volts and 0.15 of a volt. Go to 3) .
3. 3) O2 SENSOR VOLTAGE Start the engine. Operate the engine above 1200 RPM for 3 minutes and 40 seconds. With the scan tool, monitor the 2/1 O2 Sensor Signal voltage. Does the O2 Sensor voltage stay between 0.4 and 0.6 volt? Yes Go to 12) . No Go to 8) .
4. 4) 2/1 O2 SENSOR Turn the ignition off. Disconnect the 2/1 O2 Sensor harness connector. NOTE: Check connectors - Clean/repair as necessary. Turn the ignition on. With the scan tool, monitor the 2/1 O2 Sensor Signal voltage. Is the O2 Sensor voltage below 1.4 volts? Yes Replace the 2/1 O2 Sensor. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/fuel-system/#fuel-system) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Go to 5) .
5. 5) 2/1 O2 SENSOR SIGNAL CIRCUIT SHORTED TO VOLTAGE With the ignition on. With the scan tool, monitor the 2/1 O2 Sensor Signal voltage. Is the O2 Sensor voltage above 2.0 volts? Yes Repair the 2/1 O2 Sensor Signal circuit for a short to voltage. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Replace and program the Powertrain Control Module. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-service-information) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
6. 6) DISCONNECT THE 2/1 O2 SENSOR Turn the ignition off. Disconnect the 2/1 O2 Sensor harness connector. NOTE: Check connectors - Clean/repair as necessary. Turn the ignition on. With the scan tool, monitor the 2/1 O2 Sensor Signal voltage. Is the 2/1 O2 Sensor voltage above 0.15 volt? Yes NOTE: Determine the cause of any contamination before replacing the sensor. Inspect for the following before replacing the 2/1 O2 Sensor. Fuel contamination. Engine oil or coolant consumption. Use of improper RTV sealant. Replace the 2/1 O2 Sensor if none of the above conditions are present. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/fuel-system/#fuel-system) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Go to 7) .
7. 7) 2/1 O2 SENSOR SIGNAL CIRCUIT SHORT TO GROUND Turn the ignition off. Disconnect the PCM harness connectors. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance between ground or any ground circuit in the PCM harness connector and the 2/1 O2 Sensor Signal circuit. Is the resistance above 100 kohms for all measurements? Yes Replace and program the Powertrain Control Module. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-service-information) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Repair the 2/1 O2 Sensor Signal circuit for a short to ground or any ground circuit in the PCM harness connector. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
8. 8) 2/1 O2 SENSOR SYSTEM INSPECTION Turn the ignition off. Inspect for the following conditions. Exhaust leak. Refer to «INSPECTION»(/chrysler/crossfire/i-final-2008-2008/remont/exhaust/#exhaust-system__inspection) . Incorrectly installed 2/1 O2 Sensor. Damaged wiring. Were any of the above conditions found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Go to 9) .
9. 9) JUMPER THE 2/1 O2 SENSOR With the ignition off. Disconnect the 2/1 O2 Sensor harness connector of the affected 2/1 O2 Sensor. NOTE: Check connectors - Clean/repair as necessary. Turn the ignition on. Connect a jumper wire between ground and the 2/1 O2 Sensor Signal circuit. With the scan tool, monitor the 2/1 O2 Sensor Signal voltage. Does the O2 Sensor voltage stay between 0.4 and 0.6 volt? Yes Go to 10) . No Go to 11) .
10. 10) 2/1 O2 SENSOR SIGNAL CIRCUIT OPEN Turn the ignition off. Remove the jumper wire. Disconnect the PCM harness connectors. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance of the 2/1 O2 Sensor Signal circuit from the O2 Sensor harness connector to the PCM harness connector. Is the resistance below 5.0 ohms? Yes Replace and program the Powertrain Control Module. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-service-information) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Repair the 2/1 O2 Sensor Signal circuit for an open. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
11. 11) SENSOR GROUND CIRCUIT OPEN Turn the ignition off. Remove the jumper wire. Disconnect the PCM harness connectors. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance of the Sensor Ground circuit from the O2 Sensor harness connector to the PCM harness connector. Is the resistance below 5.0 ohms? Yes NOTE: Determine the cause of any contamination before replacing the sensor. Inspect for the following before replacing the O2 Sensor. Fuel contamination. Engine oil or coolant consumption. Use of improper RTV sealant. Replace the Oxygen Sensor if none of the above conditions are present. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/fuel-system/#fuel-system) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Repair the Sensor Ground circuit for an open. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
12. 12) INTERMITTENT WIRING AND CONNECTORS The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

P0152-O2 SENSOR 2/1 CIRCUIT HIGH

1. When Monitored : With the engine running between 1000 and 2000 RPM, engine load between 15% to 50%, closed loop mode, the three way catalytic converter temperature is greater than 380°C (716°F), and the O2 sensor heater must be ON for at least 220 seconds to enable the signal inactive portion of the test.
2. Set Condition : O2 Sensor voltage is greater than 1.5 volts for approximately 5 seconds.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

1. 1) CHECK FOR CURRENT DTC Turn the ignition on. With the scan tool, read PCM DTCs. Is this DTC present? Yes Go to 3) . No Go to 2) .
2. 2) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.
3. 3) JUMPER THE 2/1 O2 SENSOR Turn the ignition off. Disconnect the 2/1 O2 Sensor harness connector. NOTE: Check connectors - Clean/repair as necessary. Turn the ignition on. Connect a jumper wire between ground and the 2/1 O2 Sensor Signal circuit. With the scan tool, monitor the 2/1 O2 Sensor Signal voltage. Does the O2 Sensor voltage drop to 0 volts? Yes Go to 5) . No Go to 4) .
4. 4) SENSOR GROUND CIRCUIT OPEN Turn the ignition off. Remove the jumper wire. Disconnect the PCM harness connectors. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance of the Sensor Ground circuit from the O2 Sensor harness connector to the PCM harness connector. Is the resistance below 5.0 ohms? Yes Inspect for the following before replacing the O2 Sensor. Fuel contamination. Engine oil or coolant consumption. Use of improper RTV sealant. Replace the Oxygen Sensor if none of the above conditions are present. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/fuel-system/#fuel-system) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Repair the excessive resistance in the Sensor Ground circuit. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
5. 5) O2 SENSOR SIGNAL CIRCUIT SHORT TO VOLTAGE Remove the jumper wire. With the scan tool, monitor the 2/1 O2 Sensor Signal voltage. Is the O2 Sensor voltage above 5.0 volts? Yes Repair the short to voltage in the 2/1 O2 Sensor Signal circuit. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Replace and program the Powertrain Control Module. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-service-information) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .

P0153-O2 SENSOR 2/1 LONG DELAY TIME

1. When Monitored : Start and drive vehicle greater than 32 km/h (20 MPH) and less than 89 km/h (55 MPH). Throttle open for a minimum 120 seconds. Coolant Temp greater than 70°C (158°F) Catalytic Converter Temperature greater than 600°C (1112°F).
2. Set Condition : The O2 sensor voltage switches only 11 times or less from lean to rich within 20 seconds during monitoring. Two Trip Fault.

For a complete Powertrain Control Module Circuit Diagram, refer to SCHEMATICS AND DIAGRAMS .

1. 1) PRE-DIAGNOSTIC CHECK OUT NOTE: Always perform diagnostics with a fully charged battery. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. NOTE: Check for applicable TSBs related to the problem. Turn the ignition on. With the scan tool, read PCM DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Repair as necessary. Perform this procedure prior to symptom diagnosis. Continue Go to 2) .
2. 2) CHECK FOR CURRENT DTC NOTE: It is important to perform the diagnostics on the O2 Sensor that set the DTC. NOTE: Check for contaminates that may have damaged the O2 Sensor: contaminated fuel, unapproved silicone, oil and coolant. NOTE: If the PCM detects and stores a DTC, the PCM also stores the engine/vehicle operating conditions under which the DTC was set. Some of these conditions are displayed on the scan tool at the same time the DTC is displayed. NOTE: Before erasing stored DTCs, record these conditions. Attempting to duplicate these conditions may assist when checking for a DTC. Turn the ignition on. With the scan tool, erase PCM DTCs. NOTE: It maybe necessary to road test the vehicle for this DTC to set. With the scan tool, read PCM DTCs. Did this DTC set again? Yes Go to 3) . No Go to 6) .
3. 3) EXHAUST LEAK Start the engine. Inspect the exhaust system for leaks between the engine and the O2 Sensors. Are there any exhaust leaks? Yes Repair or replace the leaking exhaust parts as necessary. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/exhaust/#exhaust-system__removal) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Go to 4) .
4. 4) 2/1 O2 SENSOR SIGNAL CIRCUIT Turn the ignition off. Disconnect the 2/1 O2 Sensor harness connector. NOTE: Check connectors - Clean/repair as necessary. Turn the ignition on. Measure the voltage on the 2/1 O2 Sensor Signal circuit at the 2/1 O2 Sensor harness connector. Is the voltage approximately 0.47 volt? Yes Go to 5) . No Check the 2/1 O2 Sensor Signal circuit for damage, short to ground, open, or short to voltage. If OK, replace and program the Powertrain Control Module. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-service-information) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
5. 5) SENSOR GROUND CIRCUIT With the ignition on. Measure the voltage on the Sensor Ground circuit at the 2/1 O2 Sensor harness connector. Is the voltage above 0.1 volt? Yes Check the Sensor Ground circuit for damage, short to ground, open, or short to voltage. If OK, replace and program the Powertrain Control Module. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-service-information) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Replace the Oxygen Sensor. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/fuel-system/#fuel-system) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
6. 6) INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits. NOTE: Check for any Technical Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.

See also:
• SCHEMATICS AND DIAGRAMS
• POWERTRAIN VERIFICATION TEST - VER 2
• REMOVAL
• REMOVAL
• REMOVAL
• P0131-O2 SENSOR 1/1 CIRCUIT LOW
• INSPECTION
• P0133-O2 SENSOR 1/1 SHORT DELAY TIME
• P0135-O2 SENSOR 1/1 HEATER CIRCUIT HIGH
• P0137-O2 SENSOR 2/2 ABOVE THRESHOLD
• P0135-O2 SENSOR 1/1 HEATER CIRCUIT LOW
• P0135-O2 SENSOR 1/1 HEATER PERFORMANCE
