INSTALLATION - IGNITION LOCK CABLE
- Install the ignition lock cable (1) to the ignition/starter switch by sliding it into the retaining slot until the tabs click.
- Install the ignition lock cable (1) to the shift lever assembly by inserting it into the mounting hole and then turning it 90° to the right.
- Turn the ignition switch to the OFF/LOCK position. It should only be possible to move the shift lever out of the Park position when the ignition switch is in the ON/RUN position and the brake pedal is depressed. It should only be possible to remove the ignition key when the shift lever is in the Park position and the ignition switch is in the OFF/LOCK position.
- Install the lower instrument panel (2). Refer to «INSTALLATION»(/chrysler/crossfire/i-final-2008-2008/remont/gauges-instrument-panels/#body-interior-exterior-service-information) .
- Install the ash tray (2) in the front center console.
- Install the shifter cover (1). Refer to «INSTALLATION»(/chrysler/crossfire/i-final-2008-2008/remont/gauges-instrument-panels/#body-interior-exterior-service-information) .
Scheme 36
Scheme 36: REMOVAL - IGNITION SWITCH
| 1 - IGNITION SWITCH CONNECTOR |
|---|
| 2 - IGNITION SWITCH |
| 3 - WASHER |
| 4 - PARKING LOCK VALVE |
| 5 - CAM |
| 6 - STEERING LOCK |
| 7 - PARK/BRAKE INTERLOCK CABLE |
| 8 - BUZZER |
| 9 - LOCKING PIN |
| 10 - RELEASE CLAMP |
- Remove the lower instrument panel cover. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/gauges-instrument-panels/#body-interior-exterior-service-information) .
- Remove the transponder coil from the ignition lock cylinder by Inserting a plastic wedge directly between the lock cylinder cover sleeve and the transponder coil. Once the plastic wedge is in position apply slight pressure to the transponder coil to remove it from the ignition lock cylinder. Once the transponder coil in removed from the ignition lock cylinder, reposition the coil out of the way. CAUTION: The steering lock and lock cylinder can only be fitted in lock cylinder position "1". NEVER turn the steering lock when the ignition/starter switch is not fitted.
- Remove the key cylinder. See «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/manual-power-steering/#rack-pinion-power-steering-system) .
- Disconnect the connector (8) from the warning buzzer contact.
- Remove the parking lock interlock cable (7). NOTE: Vehicles with automatic transmission
- Release the clamp (10), press in locking pin (9) and pull the steering lock (6) out of the steering column.
- Disconnect the connector (1) from the ignition/starter switch. NOTE: The ignition switch must not be turned out of position "1" when the ignition/starter switch is not fitted, otherwise the steering lock is locked permanently
- Remove the ignition switch (2) from the steering lock (6).
- Remove the washer (3) and parking lock valve (4).
- Remove the warning buzzer (8) contact and switch.
