Lighting Systems - Interior - Service Information Chrysler Crossfire I final

INTERIOR LAMPS/LIGHTING TESTING

If a vehicle experiences problems with the interior lighting system, verify the following are in proper operating condition

1. Battery connections
2. Charging system
3. Interior lamp bulbs
4. Illumination Control Module/Headlamp switch
5. Wiring harness connectors

For complete interior lamp system schematics and diagrams, see SCHEMATICS AND DIAGRAMS .

Each vehicle is equipped with various lamp assemblies. A good ground is necessary for proper lighting operation. Grounding is provided by the lamp socket when it comes in contact with the metal body, or through a separate ground wire.

When diagnosing the interior lighting circuits, remember that high generator output can burn out bulbs rapidly, and that dim or flickering bulbs can be caused by low generator output or a poor battery condition.

When changing lamp bulbs, check the socket for loose pin connections and/or evidence of corrosion. Repair as necessary.

When it is necessary to remove a component to service another, it should not be necessary to apply excessive force to bend a component to remove it. Before damaging a trim component, verify hidden fasteners or captured edges are not holding the component in place.

For additional interior lamp diagnosis, refer to LAMPS/LIGHTING - INTERIOR - ELECTRICAL DIAGNOSTICS .

SPECIFICATIONS - BULB APPLICATION

BULB APPLICATION TABLE

Scheme 17

Scheme 18

1. Disconnect the negative battery cable.
2. Remove the cargo lamp unit (1) from the interior trim panel. See «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/interiorillumination-lights/#lighting-systems-interior-service-information) .
3. Remove the bulb (1) from the cargo lamp unit (2).

Scheme 19

1. Insert the bulb (1) into the cargo lamp unit (2).
2. Install the cargo lamp unit (2) to the cargo area interior trim panel (3). See «INSTALLATION»(/chrysler/crossfire/i-final-2008-2008/remont/interiorillumination-lights/#lighting-systems-interior-service-information) .
3. Connect the negative battery cable.

Scheme 20

1. Disconnect the negative battery cable.
2. Gently pry the cargo lamp unit (1) away from the cargo area interior trim panel (2).
3. Disconnect the cargo lamp unit harness connector (1) and remove from the vehicle.

INSTALLATION - CARGO LAMP UNIT

1. Connect the harness connector (1) to the cargo lamp unit.
2. Install the cargo lamp unit to the cargo area interior trim panel (2).
3. Connect the negative battery cable.

Scheme 21

1. Remove the courtesy lamp switch/unit from the roof frame. See «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/interiorillumination-lights/#lighting-systems-interior-service-information) .
2. Rotate the lamp socket (1) counterclockwise in the courtesy lamp switch/unit and remove.
3. Remove the bulb from the lamp socket.

Scheme 22

1. Insert the bulb into the lamp socket.
2. Install the lamp socket into the courtesy lamp switch/unit by rotating clockwise.
3. Install the courtesy lamp switch/unit to the roof frame. See «INSTALLATION»(/chrysler/crossfire/i-final-2008-2008/remont/interiorillumination-lights/#lighting-systems-interior-service-information) .

Scheme 23

With the courtesy lamp defeat switch in the "O" position (1), the courtesy lamps are prevented from illuminating when the doors are opened. With the courtesy lamp defeat switch in the "-" position, the courtesy lamps illuminate when the doors are opened, then fade to off approximately 8 seconds after the last door is closed (unless the courtesy lamp switch is depressed). If a door remains unclosed, the lamps will remain on for approximately 5 minutes. At this time the Body Control Module will interrupt the ground path to conserve battery power. The courtesy lamp defeat switch is an integrated part of the courtesy lamp unit assembly and cannot be adjusted or repaired. If faulty, worn, or damaged, the entire assembly must be replaced. For complete courtesy lamp unit removal procedures, refer to REMOVAL .

Scheme 24

The courtesy lamps (1) provide overhead interior illumination when the doors are opened and the courtesy lamp defeat switch (3) is in the "-" position, or when the courtesy lamp switch (2) is pressed. The courtesy lamp defeat switch (3) can prevent the courtesy lamps operation when the doors are opened if the "O" position is selected. The courtesy lamp switch/unit cannot be adjusted or repaired. If faulty, worn, or damaged, the entire assembly must be replaced. For complete courtesy lamp switch/unit removal procedures, refer to REMOVAL .

OPERATION - COURTESY LAMP SWITCH/UNIT

Non-switched power is supplied through Fuse 9 in the Underhood Accessory Fuse Block, and ground is provided by the Body Control Module. Regardless of the ignition switch position, the courtesy lamps illuminate when either door is opened if the courtesy lamp defeat switch is in the "-" position; or the courtesy lamp switch is pressed. The courtesy lamps will fade off approximately 8 seconds after the last door is closed. If a door remains unclosed, the lamps will remain on for approximately 5 minutes. At this time the Body Control Module will interrupt the ground path to conserve battery power.

When the courtesy lamp switch is pressed, the courtesy lamps are provided a direct path to ground and will remain illuminated until the switch is pressed again.

Scheme 25

Scheme 26

1. Disconnect the negative battery cable.
2. Using a trim stick (1), gently pry down and away from the courtesy lamp switch/unit body (2) to release the lens cover.
3. Remove the retaining screws.
4. Using a trim stick, gently pry and lower the courtesy lamp switch/unit from the headliner opening.
5. Disconnect the courtesy lamp switch/unit harness connector and remove from the vehicle.

Scheme 27

1. Connect the courtesy lamp switch/unit harness connector (1) and align into the headliner opening.
2. Install the retaining screws and secure.
3. Install the lens cover into the courtesy lamp switch/unit body.
4. Connect the negative battery cable.

Scheme 28

The dimmer switch (3) is an integrated part of the Instrument Cluster and is located at the left side of the speedometer. It controls the brightness of the adjustable interior illumination when rotated to the left or right. The dimmer switch cannot be repaired. If it is found faulty or damaged, the entire Instrument Cluster must be replaced. For complete Instrument Cluster removal procedures, refer to REMOVAL .

DESCRIPTION - DOOR/LIFTGATE AJAR SWITCH

There are three door ajar switches, one at each door and one in the liftgate latch. The door switches are located in the B-pillar directly below the latch striker plate, and the liftgate switch is integral to the liftgate latch assembly. A door or body harness connector with a service loop connects each switch to the vehicle electrical system. The door ajar switches cannot be adjusted or repaired, and if faulty or damaged, the switch itself or the liftgate latch must be replaced as an assembly. For complete door ajar switch removal procedures, see the appropriate removal procedure.

OPERATION - DOOR/LIFTGATE AJAR SWITCH

The door ajar switches are actuated by either door, or the liftgate being opened. When either door or the liftgate is closed and properly latched, its ajar switch is open. When either door or the liftgate is partially latched, its ajar switch is closed. The ajar switches are connected via a harness connector to a body ground and the Central Locking Pump/Security System Module.

Scheme 29

The liftgate ajar switch (1) is an integral part of the liftgate handle assembly and cannot be adjusted or repaired. If faulty, worn, or damaged, the entire liftgate handle assembly must be replaced. For complete liftgate handle removal procedures, see REMOVAL .

Scheme 30

1. Disconnect the negative battery cable.
2. Using a trim stick, press and release the retaining tab (1) at the top of the door ajar switch.
3. Pull the top of the door ajar switch out and downward away from the B-pillar (2), then disconnect the door ajar switch harness connector.

Scheme 31

1. Connect the door ajar switch harness connector (1).
2. Install the lower edge of the door ajar switch into the B-pillar opening (2) first, then rotate upward until fully seated.
3. Connect the negative battery cable.

INSTALLATION - LIFTGATE AJAR SWITCH

The liftgate ajar switch is an integral part of the liftgate handle assembly. For complete liftgate handle installation procedures, see INSTALLATION .

REMOVAL - GLOVE BOX LAMP

Scheme 32

1. Remove the glove box lamp/switch assembly. See «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/interiorillumination-lights/#lighting-systems-interior-service-information) .
2. Press the bulb retaining arm aside and remove the bulb (1) from the glove box lamp/switch (2).

INSTALLATION - GLOVE BOX LAMP

Scheme 33

1. Press the bulb retaining arm (2) aside and install the bulb (1) into the glove box lamp/switch assembly.
2. Install the glove box lamp/switch assembly. See «INSTALLATION»(/chrysler/crossfire/i-final-2008-2008/remont/interiorillumination-lights/#lighting-systems-interior-service-information) .

Scheme 34

The glove box lamp/switch (1) is a self-contained set of switches, lamp, and housing assembly that provides illumination into the glove box compartment whenever the glove box door is opened. It is located behind the glove box door at the top of the liner, just to the left of the latch striker.

OPERATION - GLOVE BOX LAMP/SWITCH

The Glove Box Lamp/Switch contains two separate switches; one for control of the illumination, and the other to sense the glove box door position. Power is supplied through Fuse 31 in the Underhood Accessory Fuse Block for the lamp illumination switch. The Central Locking Pump/Security System Module receives a ground signal from the second switch when the glove box is opened. Neither of these switches can be adjusted or repaired. If faulty, worn, or damaged, the entire Glove Box Lamp/Switch assembly must be replaced. For complete Glove Box Lamp/Switch removal procedures, refer to REMOVAL .

REMOVAL - GLOVE BOX LAMP/SWITCH

Scheme 35

1. Disconnect the negative battery cable.
2. Open the glove box door and depress the lens retaining clips with a trim stick (1). Gently pry the glove box lamp/switch (2) from the glove box liner (3).
3. Disconnect the glove box lamp/switch harness connector and remove the glove box lamp/switch (2) from the vehicle.

INSTALLATION - GLOVE BOX LAMP/SWITCH

Scheme 36

1. Connect the glove box lamp/switch harness connector (1).
2. Insert the glove box lamp/switch (2) into the opening in the glove box liner and close the glove box door.
3. Connect the negative battery cable.

Scheme 37

The Heater Switch (3) is illuminated with LEDs whenever the headlamps or marker lamps are on. The lamp brightness is adjustable with the dimmer switch located in the Instrument Cluster. The heater switch LEDs cannot be adjusted or repaired. If faulty or damaged, the entire Heater Switch Assembly must be replaced as a unit. For complete Heater Switch removal procedures, refer to REMOVAL .

Scheme 38

The transmission range indicator is illuminated with LEDs whenever the headlamps or marker lamps are on. The lamp brightness is adjustable with the dimmer switch located in the instrument cluster. The transmission range indicator LEDs cannot be adjusted or repaired. If faulty or damaged, the entire transmission range indicator assembly must be replaced as a unit. For complete transmission range indicator removal procedures, see REMOVAL .

Scheme 39

Scheme 40

Scheme 41

Scheme 42

1. Remove the cover on the center console. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/gauges-instrument-panels/#body-interior-exterior-service-information) .
2. Remove the screws (1-3) attaching the ashtray (2) to the center console.
3. Press the ashtray housing (1) to the left and remove it toward the right (arrows).
4. Disconnect the ashtray harness connector for the courtesy lamp on the back of the ashtray (1).
5. Remove the ashtray lamp from the ashtray harness connector.

INSTALLATION - ASH RECEIVER LAMP

1. Install the ashtray lamp into the ashtray lamp harness connector.
2. Connect the ashtray lamp harness connector to the ashtray (1).
3. Install the ashtray housing (1) to the right and push it toward the left.
4. Install the screws (1-3) attaching the ashtray (2) to the center console.
5. Install the cover (1) on the center console. Refer to «INSTALLATION»(/chrysler/crossfire/i-final-2008-2008/remont/gauges-instrument-panels/#body-interior-exterior-service-information) .
