Electrical Component Locator — Chrysler Crossfire I final (2008-2008)

BUZZERS, RELAYS & TIMERS

Component	Location
Air Pump Relay	In relay control module.
Brake Lamp Relay	Rear of underhood accessory fuse block. (Scheme 5)
Engine Control Relay	In relay control module.
Fuel Pump Relay	In control module.
Horn Relay	In relay control module.
Power Seat Relay	Behind left side of dash.
Remote Keyless Entry Relay	Rear of underhood accessory fuse block. (Scheme 5)
Traction System Relay	In relay control module.

BUZZERS, RELAYS & TIMERS LOCATION

CIRCUIT PROTECTION DEVICES

Component	Location
Control Module Box	At right rear of engine compartment. (Scheme 10)
Engine Fuse Block	At right rear of engine compartment. (Scheme 10)
Underhood Accessory Fuse Block	At left rear of engine compartment. (Scheme 2)

CIRCUIT PROTECTION DEVICES LOCATION

CONTROL UNITS

Component	Location
A/C Heater Control Module	Behind center of dash. (Scheme 17)
Body Control Module	In control module box. (Scheme 9)
Central Locking Pump/Security System Module	At right rear of trunk. (Scheme 4)
Controller Antilock Brake	At left rear of engine compartment. (Scheme 2)
Heated Seat Module	Center of dash.
Illumination Control Module	Behind left side of dash.
Occupant Restraint Controller	Under center console. (Scheme 8)
Power Top Control Module	At rear of trunk. (Scheme 18)
Powertrain Control Module	In control module box. (Scheme 9)
Pulse Module	Side of underhood accessory fuse block. (Scheme 5)
Radiator Fan Control Module	At left front of engine compartment. (Scheme 10)
Relay Control Module	In control module box. (Scheme 9)
Sentry Key Remote Entry Module	Behind left side of dash. (Scheme 1)
Transmission Control Module	Behind passenger footwell. (Scheme 3)

CONTROL UNITS LOCATION

MOTORS

Component	Location
Air Pump	At top of engine. (Scheme 13)
Blower Motor	Behind right side of dash.
Coolant Circulation Pump	Below right headlight.
Engine Starter Motor	Lower right side of engine.
Left Front Power Window Motor	Inside center of left door.
Passenger Power Window Motor	In passenger door. (Scheme 6)
Radiator Fan Motor	At front of engine compartment.
Rear Spoiler Motor	Below rear spoiler.
Right Front Power Window Motor	Inside center of right door.
Trunk Latch Assembly	Center rear of trunk lid. (Scheme 25)
Washer Pump Motor	Behind right front wheelwell splash shield.

MOTORS LOCATION

SENDING UNITS & SENSORS

Component	Location
Accelerator Pedal Position Sensor	At top of accelerator pedal.
A/C Pressure Sensor	Behind left headlight.
Ambient Temperature Sensor	At lower left grille.
Anti-Theft Tow Sensor	At right side of trunk. (Scheme 4)
Camshaft Position Sensor	At right front of engine. (Scheme 12)
Coolant Level Sensor	Below coolant recovery reservoir.
Crankshaft Position Sensor	At left rear of engine. (Scheme 12)
Engine Coolant Temperature Sensor	At front of engine. (Scheme 13)
ESP Brake Pressure Sensor 1	Left rear of engine compartment.
ESP Lateral Acceleration Sensor	Under center console. (Scheme 8)
ESP Yaw Rate Sensor	Under rear of center console. (Scheme 8)
Evaporator Temperature Sensor	Behind lower center of dash.
Fuel Level Sensor	At top of fuel tank.
Fuel Tank Pressure Sensor	At top of fuel tank.
Heater Core Temperature Sensor	Behind center of dash.
Left Front WSS/Brake Pad Wear Sensor	At left front brake caliper.
Left Knock Sensor	Under intake manifold.
Left Rear Wheel Speed Sensor	On left brake backing plate.
Left Side Impact Sensor	On floor, under driver seat. (Scheme 8)
MAF/IAT Sensor	At rear of engine.
Manifold Absolute Pressure Sensor	At front of engine. (Scheme 13)
Oil Sensor	At lower right side of engine oil pan.
Oxygen Sensor 1/1 Upstream	At rear of left exhaust manifold.
Oxygen Sensor 1/2 Downstream	On exhaust, downstream of catalytic converter.
Oxygen Sensor 2/1 Upstream	At rear of right exhaust manifold.
Oxygen Sensor 2/2 Downstream	On exhaust, downstream of catalytic converter.
Right Front WSS/Brake Pad Wear Sensor	On right front brake caliper.
Right Knock Sensor	Under intake manifold.
Right Rear Wheel Speed Sensor	On right brake backing plate.
Right Side Impact Sensor	On floor, under right seat.
Steering Angle Sensor	At lower left side of steering column.
Throttle Position Sensor	On throttle body. (Scheme 14)
Tire Pressure Monitor	At top center of windshield. (Scheme 1)

SENDING UNITS & SENSORS LOCATION

SOLENOIDS & SOLENOID VALVES

Component	Location
Air Pump Switchover Solenoid	At front of engine. (Scheme 13)
Air Pump Switchover Valve	At top of engine. (Scheme 13)
Charcoal Canister Shutoff Valve	Under right rear of vehicle.
Coolant Circulation Valve	At right side of engine compartment. (Scheme 10)
EGR Solenoid	At right rear of engine. (Scheme 14)
EVAP Purge Solenoid	At left rear of engine compartment. (Scheme 2)
Fuel Injector 1	At right side of intake manifold.
Fuel Injector 2	At right side of intake manifold.
Fuel Injector 3	At right side of intake manifold.
Fuel Injector 4	At left side of intake manifold. (Scheme 12)
Fuel Injector 5	At left side of intake manifold. (Scheme 12)
Fuel Injector 6	At left side of intake manifold. (Scheme 12)
Recirculated Air Switchover Valve	Behind lower right side of dash.
Short Runner Valve Solenoid	At front of engine.
Transmission Solenoid Assembly (A/T)	At bottom of transmission.
Transmission Solenoid Assembly Connector	Right side of transmission. (Scheme 16)

SOLENOIDS & SOLENOID VALVES LOCATION

SWITCHES

Component	Location
Back-Up Lamp Switch (M/T)	At right rear of transmission. (Scheme 15)
Brake Fluid Level Switch	On master brake cylinder reservoir. (Scheme 2)
Brake Lamp Switch A (A/T)	At top of brake pedal.
Brake Lamp Switch A (M/T)	At top of brake pedal.
Brake Lamp Switch B (A/T)	At top of brake pedal.
Brake Lamp Switch B (M/T)	At top of brake pedal.
Clutch Interlock Switch (M/T)	At top of clutch pedal.
Clutch Pedal Position Switch (M/T)	At top of clutch pedal.
D-Handle Lock Switch (Convertible)	On front header. (Scheme 21)
Driver Cylinder Lock Switch	In driver door.
Driver Seat Belt Switch	In driver side seat belt buckle.
Hood Ajar Switch	Part of hood latch.
Key In Ignition Switch	Under ignition key cylinder.
Kickdown Switch	Under acceleration pedal.
Left Door Ajar Switch	Rear of left door.
Liftgate Lock Switch	Below liftgate hinge. (Scheme 20)
Passenger Seat Belt Switch	In passenger seat belt tensioner.
Rear Spoiler Limit Switch	Below rear spoiler.
Right Door Ajar Switch	Rear of right door.
Tonneau Cover Switch	Behind rear seat. (Scheme 24)
Washer Fluid Level Switch	Behind right front wheelwell splash shield.

SWITCHES LOCATION

MISCELLANEOUS

Component	Location
A/C Compressor Clutch	At lower left front of engine. (Scheme 12)
Antenna C1 (Convertible)	At left rear quarterpanel.
Antenna C1 (Coupe)	At underside of lower liftgate. (Scheme 19)
Antenna C2	At underside of lower liftgate. (Scheme 19)
BAS Brake Booster C1	At left rear of engine compartment.
BAS Brake Booster C2	At left rear of engine compartment.
Battery	At right rear of engine compartment. (Scheme 10)
Clockspring	Top of steering column.
Coil On Plug 1	On right valve cover.
Coil On Plug 2	On right valve cover.
Coil On Plug 3	On right valve cover.
Coil On Plug 4	On left valve cover. (Scheme 12)
Coil On Plug 5	On left valve cover. (Scheme 12)
Coil On Plug 6	On left valve cover. (Scheme 12)
Data Link Connector	Under left side of dash.
Driver Seat Belt Tensioner Squib	In driver seat belt tensioner.
Generator	At lower right front of engine. (Scheme 12)
Left Side Air Bag Squib	Rear of left door.
Passenger Air Bag Squib	Behind right side of dash.
Passenger Seat Belt Tensioner Squib	In passenger seat belt tensioner.
Passenger Seat Occupant Simulator	Behind passenger footwell. (Scheme 3)
Power Amplifier	Behind passenger footwell. (Scheme 3)
Right Side Air Bag Squib	Rear of right door.
Sentry Key Antenna Ring	On ignition key cylinder.
Siren	At base of windshield, under grille.
Supercharger Clutch (SRT)	On front of engine.

MISCELLANEOUS LOCATION

CONNECTORS

Component	Location
C100 (Natural, 8 Pin)	Behind left side of dash.
C105 (Black, 4 Pin)	At left side of engine compartment. (Scheme 5)
C106 (Black, 8 Pin)	In control module box. (Scheme 9)
C200 (Black, 8 Pin)	Behind left side of dash.
C201 (Black, 18 Pin)	Behind passenger footwell. (Scheme 3)
C206 (Black 8, Pin)	Behind passenger footwell. (Scheme 3)
C207 (Black, 4 Pin)	Behind passenger footwell. (Scheme 3)
C208 (Yellow, 5 Pin)	Behind left side of dash.
C210 (Yellow, 5 Pin)	Behind passenger footwell. (Scheme 3)
C211 (Natural, 8 Pin)	Behind passenger footwell. (Scheme 3)
C219 (Blue, 8 Pin)	Behind passenger footwell. (Scheme 3)
C223 (Black/Yellow, 2 Pin)	At left kick panel.
C224 (Black/Yellow, 2 Pin)	At right kick panel. (Scheme 7)
C226 (18 Pin)	Behind left side of dash.
C227 (Blue, 8 Pin)	Behind left side of dash.
C228 (Black, 8 Pin)	At left kick panel.
C229 (Black, 5 Pin)	At left kick panel.
C230 (Black, 8 Pin)	At right kick panel. (Scheme 7)
C231 (Black, 5 Pin)	At right kick panel. (Scheme 7)
C240 (Black, 8 Pin)	Behind left side of dash.
C300 (Natural, 8 Pin)	Left side of luggage compartment.
C301 (Black, 8 Pin)	Left side of luggage compartment.
C302 (Black, 8 Pin)	Left side of luggage compartment.

CONNECTORS LOCATION

GROUNDS

Component	Location
G100	At left side of engine compartment. (Scheme 10)
G101	At right side of engine compartment. (Scheme 9)
G104	At top front of engine.
G107	At right side of engine compartment. (Scheme 9)
G200	Behind upper left side of dash.
G201	At left kick panel. (Scheme 22)
G202	Under center console. (Scheme 8)
G203	Under center console. (Scheme 8)
G204	At right kick panel. (Scheme 7)
G205	At upper left rear of passenger compartment. (Scheme 23)
G206	At right kick panel. (Scheme 7)
G300	Left side of trunk, behind trim panel. (Scheme 23)
G301	At right side of trunk. (Scheme 4)
G302	Top of liftgate. (Scheme 19)

GROUNDS LOCATION

SPLICES

Component	Location
Splice Block 100	At left side of engine compartment. (Scheme 5)
Splice Block 101	At left side of engine compartment. (Scheme 5)
Splice Block 102	At left side of engine compartment. (Scheme 5)
Splice Block 200	Under center console. (Scheme 8)
S101	At top left of intake manifold.
S103	In control module box. (Scheme 11)
S104	At top left of intake manifold.
S105	At front of intake manifold.
S106	At rear of engine compartment.
S107	At top left of intake manifold.
S108	At rear of engine compartment.
S113	At rear of engine compartment.
S114	In control module box. (Scheme 11)
S116	Behind left side of dash.
S117	Behind left side of dash.
S118	In control module box. (Scheme 11)
S119	At right side of engine compartment. (Scheme 11)
S121	At front of intake manifold.
S122	At rear of engine compartment.
S123	At rear of engine compartment.
S124 (A/T)	At rear of engine compartment.
S125 (A/T)	At rear of engine compartment.
S211	Behind instrument cluster.
S212	Behind instrument cluster.
S213	Behind instrument cluster.
S215	Behind upper side of dash.
S216	Behind upper side of dash.
S217	Behind upper side of dash.
S218	At end of sentry key remote entry module antenna.
S219	Behind lower side of dash.
S220	Behind lower side of dash.
S221	Behind lower side of dash.
S224	Behind lower side of dash.
S225	Behind passenger footwell.
S226	Behind passenger footwell.
S232	Under center console. (Scheme 8)
S233	At right kick panel.
S235	Behind passenger footwell.
S236	Behind passenger footwell.
S239	Behind passenger footwell.
S240	Behind lower side of dash.
S241	In left seat assembly.
S242	In left seat assembly.
S243	In right seat assembly.
S244	In right seat assembly.
S246	Behind passenger footwell.
S305	At right rear of passenger compartment, behind headliner.
