Electronic Control Modules - Electrical Diagnostics Chrysler Crossfire I final

Scheme 28

For a complete Data Link Connector Circuit Diagram, see SCHEMATICS AND DIAGRAMS .

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

1. 1) CHECK COMMUNICATION WITH OTHER MODULES Turn the ignition on. Using the scan tool, attempt to communicate with the PCM. Is the scan tool able to communicate with the PCM? Yes Go to step 2) . No Perform «*NO RESPONSE FROM ALL MODULES»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) .
2. 2) CHECK COMMUNICATION WITH OTHER MODULES ON SCI TRANSMIT CIRCUIT With the ignition on. Using the scan tool, attempt to communicate with either the Instrument Cluster, Universal Garage Door Opener/Tire Pressure Monitor, or Power Top Control Module (if equipped). Is the scan tool able to communicate with the module selected? Yes Go to step 3) . No Go to step 7) .
3. 3) FUSED B+ CIRCUIT OPEN Turn the ignition off. Disconnect the A/C Heater Control Module harness connector. NOTE: Check connector - Clean/repair as necessary. Turn the ignition on. Measure the voltage of the Fused B+ circuit at the A/C Heater Control Module harness connector. Is the voltage above 10 volts? Yes Go to step 4) . No Repair the Fused B+ circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
4. 4) FUSED IGNITION SWITCH OUTPUT CIRCUIT(S) OPEN With the ignition on. Measure the voltage of the Fused Ignition Switch Output circuits at the A/C Heater Control Module harness connector. Is the voltage above 10 volts? Yes Go to step 5) . No Repair the Fused Ignition Switch Output circuit(s) for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
5. 5) GROUND CIRCUIT OPEN Turn the ignition off. Measure the resistance of the Ground circuit from the A/C Heater Control Module harness connector to ground. Is the resistance below 5.0 ohms? Yes Go to step 6) . No Repair the Ground circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
6. 6) SCI TRANSMIT CIRCUIT OPEN With the ignition off. Measure the resistance of the SCI Transmit circuit from the A/C Heater Control Module harness connector to the DLC. Is the resistance below 5.0 ohms? Yes Replace the A/C Heater Control Module. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/ac-compressor/#hvac-systems-service-information) . Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Repair the SCI Transmit circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
7. 7) DISCONNECT MODULES NOTE: The Instrument Cluster, Universal Garage Door Opener/Tire Pressure Monitor, A/C Heater Control Module, and Power Top Control Module (if equipped) all use the SCI Transmit circuit at DLC cavity 15 to communicate with the scan tool. If one of these modules keeps the SCI Transmit circuit artificially high or low, the scan tool will not be able to communicate with any of the four modules. NOTE: Perform the following steps for each of the modules until communication is restored with the other modules or until each of the modules has been eliminated as the cause of the fault. Turn the ignition off. Disconnect each of the modules noted above, one at a time. Turn the ignition on. Using the scan tool, attempt to communicate with any of the three modules still connected. Is the scan tool able to communicate with the module selected? Yes Replace the module that was disconnected when communication was restored to the other two modules. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Go to step 8) .
8. 8) SCI TRANSMIT CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Disconnect the harness connectors for the IC, UGDO/TPM, A/C Heater Control Module, and Power Top Control Module (if equipped). Turn the ignition on. Measure the voltage of the SCI Transmit circuit at the A/C Heater Control Module harness connector. Is the voltage below 0.5 volt? Yes Go to step 9) . No Repair the SCI Transmit circuit for a short to voltage. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
9. 9) SCI TRANSMIT CIRCUIT SHORTED TO GROUND OR OPEN Turn the ignition off. Measure the resistance between ground and the SCI Transmit circuit. Is the resistance above 100 kohms? Yes Repair the SCI Transmit circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Repair the SCI Transmit circuit for a short to ground. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .

Scheme 35

For a complete Data Link Connector Circuit Diagram, see SCHEMATICS AND DIAGRAMS .

Scheme 36

Scheme 37

1. 1) CHECK PCM C4 HARNESS CONNECTOR CONNECTION Turn the ignition off. Disconnect the PCM C4 harness connector. NOTE: Check connector - Clean/repair as necessary. Reconnect the PCM C4 harness connector. Turn the ignition on. Attempt to communicate with any module with the scan tool. Does the scan tool communicate with the module selected? Yes The repair is complete. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Go to step 2) .
2. 2) DISCONNECT THE FUEL TANK PRESSURE SENSOR Turn the ignition off. Disconnect the Fuel Tank Pressure Sensor harness connector. Attempt to communicate with any module with the scan tool. Does the scan tool communicate with the module selected? Yes Replace the Fuel Tank Pressure Sensor. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/fuel-system/#fuel-system) . No Go to step 3) .
3. 3) MEASURE THE PCM SENSOR GROUND CIRCUIT VOLTAGE With the ignition on. Measure the voltage of the Sensor Ground circuit at DLC cavity 5. Is the voltage below 0.5 volts? Yes Go to step 4) . No Go to step 5) .
4. 4) MEASURE THE PCM SENSOR GROUND CIRCUIT Turn the ignition off. Disconnect the PCM C4 harness connector. NOTE: Check connector - Clean/repair as necessary. Measure the resistance of the Sensor Ground circuit from PCM C4 harness connector cavity 10 to DLC cavity 5. Is the resistance below 5.0 ohms? Yes Replace the Powertrain Control Module. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-service-information) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Repair the Sensor Ground circuit for an open. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
5. 5) MEASURE THE PCM SENSOR GROUND CIRCUIT VOLTAGE WITH THE PCM DISCONNECTED Turn the ignition off. Disconnect the PCM C4 harness connector. NOTE: Check connector - Clean/repair as necessary. Turn the ignition on. Measure the voltage of the Sensor Ground circuit at DLC cavity 5. Is the voltage below 0.5 volt? Yes Replace the Powertrain Control Module. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-service-information) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Repair the Sensor Ground circuit for a short to voltage. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .

Scheme 38

For a complete Data Link Connector Circuit Diagram, see SCHEMATICS AND DIAGRAMS .

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

1. 1) CHECK COMMUNICATION WITH OTHER MODULES Turn the ignition on. Using the scan tool, attempt to communicate with the PCM. Is the scan tool able to communicate with the PCM? Yes Go to step 2) . No Perform «*NO RESPONSE FROM ALL MODULES»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) .
2. 2) CHECK COMMUNICATION WITH OTHER MODULES ON SCI TRANSMIT CIRCUIT With the ignition on. Using the scan tool, attempt to communicate with the Sentry Key Remote Entry Module. Is the scan tool able to communicate with the Sentry Key Remote Entry Module? Yes Go to step 3) . No Go to step 7) .
3. 3) FUSED B+ CIRCUIT(S) OPEN Turn the ignition off. Disconnect the BCM harness connectors. NOTE: Check connector - Clean/repair as necessary. Turn the ignition on. Measure the voltage of the Fused B+ circuits at the BCM C4 harness connector. Is the voltage above 10 volts? Yes Go to step 4) . No Repair the Fused B+ circuit(s) for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
4. 4) FUSED IGNITION SWITCH OUTPUT CIRCUIT(S) OPEN With the ignition on. Measure the voltage of the Fused Ignition Switch Output circuits at the BCM C4 harness connector. Is the voltage above 10 volts? Yes Go to step 5) . No Repair the Fused Ignition Switch Output circuit(s) for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
5. 5) GROUND CIRCUIT(S) OPEN Turn the ignition off. Measure the resistance of the Ground circuits from the BCM C4 harness connector to ground. Is the resistance below 5.0 ohms? Yes Go to step 6) . No Repair the Ground circuit(s) for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
6. 6) SCI TRANSMIT CIRCUIT OPEN With the ignition off. Measure the resistance of the SCI Transmit circuit from the BCM C4 harness connector to the DLC. Is the resistance below 5.0 ohms? Yes Replace the Body Control Module. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-service-information) . Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Repair the SCI Transmit circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
7. 7) DISCONNECT MODULES NOTE: The Body Control Module and Sentry Key Remote Entry Module both use the SCI Transmit circuit at DLC cavity 1 to communicate with the scan tool. If one of these modules keeps the SCI Transmit circuit artificially high or low, the scan tool will not be able to communicate with either of the modules. NOTE: Perform the following steps for each of the modules until communication is restored with the other module or until each of the modules has been eliminated as the cause of the fault. Turn the ignition off. Disconnect each of the modules noted above, one at a time. Turn the ignition on. Using the scan tool, attempt to communicate with the other module still connected. Is the scan tool able to communicate with the other module? Yes Replace the module that was disconnected when communication was restored to the other module. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Go to step 8) .
8. 8) SCI TRANSMIT CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Disconnect the harness connectors for the Body Control Module and Sentry Key Remote Entry Module. Turn the ignition on. Measure the voltage of the SCI Transmit circuit at DLC cavity 1. Is the voltage below 0.5 volt? Yes Go to step 9) . No Repair the SCI Transmit circuit for a short to voltage. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
9. 9) SCI TRANSMIT CIRCUIT SHORTED TO GROUND OR OPEN Turn the ignition off. Measure the resistance between ground and the SCI Transmit circuit. Is the resistance above 100 kohms? Yes Repair the SCI Transmit circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Repair the SCI Transmit circuit for a short to ground. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .

Scheme 45

For a complete Data Link Connector Circuit Diagram, see SCHEMATICS AND DIAGRAMS .

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

1. 1) CHECK COMMUNICATION WITH OTHER MODULES Turn the ignition on. Using the scan tool, attempt to communicate with the PCM. Is the scan tool able to communicate with the PCM? Yes Go to step 2) . No Perform «*NO RESPONSE FROM ALL MODULES»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) .
2. 2) CHECK COMMUNICATION WITH OTHER MODULES ON SCI TRANSMIT CIRCUIT With the ignition on. Using the scan tool, attempt to communicate with the Shift Lever Assembly. Is the scan tool able to communicate with the Shift Lever Assembly? Yes Go to step 3) . No Go to step 7) .
3. 3) FUSED B+ CIRCUIT(S) OPEN Turn the ignition off. Disconnect the CAB harness connector. NOTE: Check connector - Clean/repair as necessary. Turn the ignition on. Measure the voltage of the Fused B+ circuits at the CAB harness connector. Is the voltage above 10 volts? Yes Go to step 4) . No Repair the Fused B+ circuit(s) for an open. Perform «ABS VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/anti-locktraction-control/#anti-lock-brake-system-electrical-diagnostics) .
4. 4) TRACTION SYSTEM RELAY OUTPUT CIRCUIT OPEN With the ignition on. Measure the voltage of the Traction System Relay Output circuit at the CAB harness connector. Is the voltage above 10 volts? Yes Go to step 5) . No Repair the Traction System Relay Output circuit for an open. Perform «ABS VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/anti-locktraction-control/#anti-lock-brake-system-electrical-diagnostics) .
5. 5) GROUND CIRCUIT(S) OPEN Turn the ignition off. Measure the resistance of the Ground circuits from the CAB harness connector to ground. Is the resistance below 5.0 ohms? Yes Go to step 6) . No Repair the Ground circuit(s) for an open. Perform «ABS VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/anti-locktraction-control/#anti-lock-brake-system-electrical-diagnostics) .
6. 6) SCI TRANSMIT CIRCUIT OPEN With the ignition off. Measure the resistance of the SCI Transmit circuit from the CAB harness connector to the DLC. Is the resistance below 5.0 ohms? Yes Replace the Controller Antilock Brake. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-service-information) . Perform «ABS VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/anti-locktraction-control/#anti-lock-brake-system-electrical-diagnostics) . No Repair the SCI Transmit circuit for an open. Perform «ABS VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/anti-locktraction-control/#anti-lock-brake-system-electrical-diagnostics) .
7. 7) DISCONNECT MODULES NOTE: The Controller Antilock Brake and Shift Lever Assembly both use the SCI Transmit circuit at DLC cavity 9 to communicate with the scan tool. If one of these modules keeps the SCI Transmit circuit artificially high or low, the scan tool will not be able to communicate with either of the modules. NOTE: Perform the following steps for each of the modules until communication is restored with the other module or until each of the modules has been eliminated as the cause of the fault. Turn the ignition off. Disconnect each of the modules noted above, one at a time. Turn the ignition on. Using the scan tool, attempt to communicate with the other module still connected. Is the scan tool able to communicate with the other module? Yes Replace the module that was disconnected when communication was restored to the other module. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Go to step 8) .
8. 8) SCI TRANSMIT CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Disconnect the harness connectors for the Controller Antilock Brake and Shift Lever Assembly. Turn the ignition on. Measure the voltage of the SCI Transmit circuit at DLC cavity 9. Is the voltage below 0.5 volt? Yes Go to step 9) . No Repair the SCI Transmit circuit for a short to voltage. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
9. 9) SCI TRANSMIT CIRCUIT SHORTED TO GROUND OR OPEN Turn the ignition off. Measure the resistance between ground and the SCI Transmit circuit. Is the resistance above 100 kohms? Yes Repair the SCI Transmit circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Repair the SCI Transmit circuit for a short to ground. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .

Scheme 52

For a complete Data Link Connector Circuit Diagram, see SCHEMATICS AND DIAGRAMS .

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

1. 1) CHECK COMMUNICATION WITH OTHER MODULES Turn the ignition on. Using the scan tool, attempt to communicate with the PCM. Is the scan tool able to communicate with the PCM? Yes Go to step 2) . No Perform «*NO RESPONSE FROM ALL MODULES»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) .
2. 2) CHECK COMMUNICATION WITH OTHER MODULES ON SCI TRANSMIT CIRCUIT With the ignition on. Using the scan tool, attempt to communicate with either the Universal Garage Door Opener/Tire Pressure Monitor, A/C Heater Control Module, or Power Top Control Module (if equipped). Is the scan tool able to communicate with the module selected? Yes Go to step 3) . No Go to step 7) .
3. 3) FUSED B+ CIRCUIT OPEN Turn the ignition off. Disconnect the IC C1 harness connector. NOTE: Check connector - Clean/repair as necessary. Turn the ignition on. Measure the voltage of the Fused B+ circuit at the IC C1 harness connector. Is the voltage above 10 volts? Yes Go to step 4) . No Repair the Fused B+ circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
4. 4) FUSED IGNITION SWITCH OUTPUT CIRCUIT(S) OPEN Turn the ignition off. Disconnect the IC C2 harness connector. NOTE: Check connector - Clean/repair as necessary. Turn the ignition on. Measure the voltage of the Fused Ignition Switch Output circuits at the IC C1 and C2 harness connectors. Is the voltage above 10 volts? Yes Go to step 5) . No Repair the Fused Ignition Switch Output circuit(s) for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
5. 5) GROUND CIRCUIT(S) OPEN Turn the ignition off. Measure the resistance of the Ground circuits from the IC C1 harness connector to ground. Is the resistance below 5.0 ohms? Yes Go to step 6) . No Repair the Ground circuit(s) for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
6. 6) SCI TRANSMIT CIRCUIT OPEN With the ignition off. Measure the resistance of the SCI Transmit circuit from the IC C1 harness connector to the DLC. Is the resistance below 5.0 ohms? Yes Replace the Instrument Cluster. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/gauges-instrument-panels/#instrument-cluster-service-information) . Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Repair the SCI Transmit circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
7. 7) DISCONNECT MODULES NOTE: The Instrument Cluster, Universal Garage Door Opener/Tire Pressure Monitor, A/C Heater Control Module and Power Top Control Module (if equipped) all use the SCI Transmit circuit at DLC cavity 15 to communicate with the scan tool. If one of these modules keeps the SCI Transmit circuit artificially high or low, the scan tool will not be able to communicate with any of the four modules. NOTE: Perform the following steps for each of the modules until communication is restored with the other modules or until each of the modules has been eliminated as the cause of the fault. Turn the ignition off. Disconnect each of the modules noted above, one at a time. Turn the ignition on. Using the scan tool, attempt to communicate with any of the three modules still connected. Is the scan tool able to communicate with the module selected? Yes Replace the module that was disconnected when communication was restored to the other two modules. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Go to step 8) .
8. 8) SCI TRANSMIT CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Disconnect the harness connectors for the IC, UGDO/TPM, A/C Heater Control Module, and Power Top Control Module (if equipped). Turn the ignition on. Measure the voltage of the SCI Transmit circuit at the IC C1 harness connector. Is the voltage below 0.5 volt? Yes Go to step 9) . No Repair the SCI Transmit circuit for a short to voltage. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
9. 9) SCI TRANSMIT CIRCUIT SHORTED TO GROUND OR OPEN Turn the ignition off. Measure the resistance between ground and the SCI Transmit circuit. Is the resistance above 100 kohms? Yes Repair the SCI Transmit circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Repair the SCI Transmit circuit for a short to ground. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .

*NO RESPONSE FROM OCCUPANT CLASSIFICATION MODULE (PASS SEAT OCCUPANT DETECTION)

Diagnostic Test

1. 1) CHECK COMMUNICATION WITH ORC Turn the ignition on. Using the scan tool, attempt to communicate with the ORC. Is the scan tool able to communicate with the ORC? Yes Go to step 2) . No Check the CAN Interior Bus circuits for an open (between the DLC and the spice), short to ground or short to voltage.
2. 2) FUSED B+ CIRCUIT OPEN WARNING: To avoid serious or fatal injury, turn the ignition off, disconnect the battery and wait two minutes before proceeding. Turn the ignition off. Disconnect the Occupant Classification Module (Pass Seat Occupant Detection) harness connector. NOTE: Check connector - Clean/repair as necessary. WARNING: To avoid serious or fatal injury, turn the ignition on, then reconnect the battery. Measure the voltage Fused B+ circuit at the OCM harness connector. Is the voltage above 10 volts? Yes Go to step 3) . No WARNING: To avoid serious or fatal injury, turn the ignition off, disconnect the battery and wait two minutes before proceeding. Repair the Fused B+ circuit for an open. Perform «*AIRBAG VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/airbag/#dtcs-b1e64-to-u0151-airbag-verification-test) .
3. 3) GROUND CIRCUIT OPEN WARNING: To avoid serious or fatal injury, turn the ignition off, disconnect the battery and wait two minutes before proceeding. Measure the resistance of the Ground circuit from the OCM harness connector to ground. Is the resistance below 5.0 ohms? Yes Go to step 4) . No Repair the Ground circuit for an open. Perform «*AIRBAG VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/airbag/#dtcs-b1e64-to-u0151-airbag-verification-test) .
4. 4) CAN INTERIOR BUS CIRCUITS OPEN Measure the resistance of the CAN Interior Bus circuits from the OCM harness connector to the DLC. Is the resistance below 5.0 ohms for both circuits? Yes If the Occupant Classification Module (OCM) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental airbag deployment and serious or fatal injury. Replace the Occupant Classification Module (Pass Seat Occupant Detection). Perform «*AIRBAG VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/airbag/#dtcs-b1e64-to-u0151-airbag-verification-test) . No Repair the CAN Interior Bus circuit for an open. Perform «*AIRBAG VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/airbag/#dtcs-b1e64-to-u0151-airbag-verification-test) .

*NO RESPONSE FROM OCCUPANT RESTRAINT CONTROLLER

1. 1) CHECK COMMUNICATION WITH OCM Turn the ignition on. Using the scan tool, attempt to communicate with the OCM. Is the scan tool able to communicate with the OCM? Yes Go to step 2) . No Check the CAN Interior Bus circuits for an open (between the DLC and the spice), short to ground or short to voltage.
2. 2) FUSED IGNITION SWITCH OUTPUT CIRCUIT OPEN WARNING: TURN THE IGNITION OFF, DISCONNECT THE BATTERY AND WAIT TWO MINUTES BEFORE PROCEEDING. Turn the ignition off. Disconnect the Occupant Restraint Controller (ORC) harness connector. NOTE: Check connector - Clean/repair as necessary. Reconnect the battery. Turn the ignition on. Measure the voltage of both Fused Ignition Switch Output circuits at the ORC harness connector. Is the voltage above 10 volts? Yes Go to step 3) . No Repair the Fused Ignition Switch Output circuit for an open. WARNING: WHEN RECONNECTING AIRBAG SYSTEM COMPONENTS, THE IGNITION MUST BE TURNED OFF AND THE BATTERY MUST BE DISCONNECTED FOR TWO MINUTES. Perform «*AIRBAG VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/airbag/#dtcs-b1e64-to-u0151-airbag-verification-test) .
3. 3) ORC GROUND CIRCUIT OPEN Turn the ignition off. Measure the resistance of the Ground circuits from the ORC harness connector to ground. Is the resistance below 5.0 ohms? Yes Go to step 4) . No Repair the Ground circuit for an open. WARNING: WHEN RECONNECTING AIRBAG SYSTEM COMPONENTS, THE IGNITION MUST BE TURNED OFF AND THE BATTERY MUST BE DISCONNECTED FOR TWO MINUTES. Perform «*AIRBAG VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/airbag/#dtcs-b1e64-to-u0151-airbag-verification-test) .
4. 4) CAN INTERIOR BUS CIRCUITS OPEN With the ignition off. Measure the resistance of the CAN Interior Bus circuits from the ORC harness connector to the DLC. Is the resistance below 5.0 ohms for both circuits? Yes Replace the Occupant Restraint Controller. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/airbag/#restraints-service-information) . WARNING: IF THE OCCUPANT RESTRAINT CONTROLLER IS DROPPED AT ANY TIME, IT MUST BE REPLACED. WARNING: WHEN RECONNECTING AIRBAG SYSTEM COMPONENTS, THE IGNITION MUST BE TURNED OFF AND THE BATTERY MUST BE DISCONNECTED FOR TWO MINUTES. Perform «*AIRBAG VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/airbag/#dtcs-b1e64-to-u0151-airbag-verification-test) . No Repair the CAN Interior Bus circuit for an open. Perform «*AIRBAG VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/airbag/#dtcs-b1e64-to-u0151-airbag-verification-test) .

Scheme 59

For a complete Data Link Connector Circuit Diagram, see SCHEMATICS AND DIAGRAMS .

Scheme 60

Scheme 61

Scheme 62

Scheme 63

1. 1) CHECK COMMUNICATION WITH OTHER MODULES Turn the ignition on. Using the scan tool, attempt to communicate with the PCM. Is the scan tool able to communicate with the PCM? Yes Go to step 2) . No Perform «*NO RESPONSE FROM ALL MODULES»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) .
2. 2) CHECK COMMUNICATION WITH OTHER MODULES ON SCI TRANSMIT CIRCUIT With the ignition on. Using the scan tool, attempt to communicate with either the Instrument Cluster, A/C Heater Control Module, or Universal Garage Door Opener/Tire Pressure Monitor. Is the scan tool able to communicate with the module selected? Yes Go to step 3) . No Go to step 6) .
3. 3) FUSED IGNITION SWITCH OUTPUT CIRCUIT OPEN Turn the ignition off. Disconnect the Power Top Control Module harness connector. NOTE: Check connector - Clean/repair as necessary. Turn the ignition on. Measure the voltage of the Fused Ignition Switch Output circuit at the Power Top Control Module harness connector. Is the voltage above 10 volts? Yes Go to step 4) . No Repair the Fused Ignition Switch Output circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
4. 4) GROUND CIRCUIT OPEN Turn the ignition off. Measure the resistance of the Ground circuit from the Power Top Control Module harness connector to ground. Is the resistance below 5.0 ohms? Yes Go to step 5) . No Repair the Ground circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
5. 5) SCI TRANSMIT CIRCUIT OPEN With the ignition off. Measure the resistance of the SCI Transmit circuit from the Power Top Control Module harness connector to the DLC. Is the resistance below 5.0 ohms? Yes Replace the Power Top Control Module. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Repair the SCI Transmit circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
6. 6) SCI TRANSMIT CIRCUIT SHORTED TO GROUND OR OPEN Turn the ignition off. Measure the resistance between ground and the SCI Transmit circuit. Is the resistance above 100 kohms? Yes Repair the SCI Transmit circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Repair the SCI Transmit circuit for a short to ground. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .

Scheme 64

For a complete Data Link Connector Circuit Diagram, see SCHEMATICS AND DIAGRAMS .

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

1. 1) CHECK COMMUNICATION WITH OTHER MODULES Turn the ignition on. Using the scan tool, attempt to communicate with any other module. Is the scan tool able to communicate with the module selected? Yes Go to step 2) . No Perform «*NO RESPONSE FROM ALL MODULES»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) .
2. 2) FUSED B(+) CIRCUIT OPEN Turn the ignition off. Disconnect the PCM C5 harness connector. NOTE: Check connector - Clean/repair as necessary. Turn the ignition on. Measure the voltage of the Fused B(+) circuit at the PCM C5 harness connector. Is the voltage above 10 volts? Yes Go to step 3) . No Repair the Fused B(+) circuit for an open. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
3. 3) FUSED ENGINE CONTROL RELAY OUTPUT CIRCUIT OPEN With the ignition on. Measure the voltage of the Fused Engine Control Relay Output circuit at the PCM C5 harness connector. Is the voltage above 10 volts? Yes Go to step 4) . No Repair the Fused Engine Control Relay Output circuit for an open. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
4. 4) PCM GROUND CIRCUITS OPEN Turn the ignition off. Measure the resistance of the Ground circuits from the PCM C5 harness connector to ground. Is the resistance below 5.0 ohms on each ground circuit? Yes Go to step 5) . No Repair the Ground circuit(s) for an open. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
5. 5) SCI RECEIVE CIRCUIT OPEN With the ignition off. Disconnect the PCM C4 harness connector. NOTE: Check connector - Clean/repair as necessary. Measure the resistance of the PCM SCI Receive circuit from the PCM C4 harness connector to the DLC. Is the resistance below 5.0 ohms? Yes Go to step 6) . No Repair the PCM SCI Receive circuit for an open. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
6. 6) SCI RECEIVE CIRCUIT SHORTED TO GROUND With the ignition off. Measure the resistance between ground and the PCM SCI Receive circuit. Is the resistance above 100 kohms? Yes Go to step 7) . No Repair the PCM SCI Receive circuit for a short to ground. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
7. 7) SCI RECEIVE CIRCUIT SHORTED TO VOLTAGE Turn the ignition on. Measure the voltage of the PCM SCI Receive circuit at the DLC. Is the voltage below 0.5 volt? Yes Go to step 8) . No Repair the PCM SCI Receive circuit for a short to voltage. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
8. 8) SCI TRANSMIT CIRCUIT OPEN Turn the ignition off. Measure the resistance of the PCM SCI Transmit circuit from the PCM harness connector to the DLC. Is the resistance below 5.0 ohms? Yes Go to step 9) . No Repair the PCM SCI Transmit circuit for an open. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
9. 9) SCI TRANSMIT CIRCUIT SHORTED TO GROUND With the ignition off. Measure the resistance between ground and the PCM SCI Transmit circuit. Is the resistance above 100 kohms? Yes Go to step 10) . No Repair the PCM SCI Transmit circuit for a short to ground. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .
10. 10) SCI TRANSMIT CIRCUIT SHORTED TO VOLTAGE Turn the ignition on. Measure the voltage of the PCM SCI Transmit circuit at the DLC. Is the voltage below 0.5 volt? Yes Replace the Powertrain Control Module. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-service-information) . Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) . No Repair the PCM SCI Transmit circuit for a short to voltage. Perform «POWERTRAIN VERIFICATION TEST - VER 2»(/chrysler/crossfire/i-final-2008-2008/remont/testing-diagnostics/#dtcs-p1999-to-p2561-checking-fuel-delivery-hard-start-engine-cranks-but-does-not-start-powertrain-verification-tests__powertrain-verification-test-ver-2) .

Scheme 74

For a complete Data Link Connector Circuit Diagram, see SCHEMATICS AND DIAGRAMS .

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

1. 1) CHECK COMMUNICATION WITH OTHER MODULES Turn the ignition on. Using the scan tool, attempt to communicate with the PCM. Is the scan tool able to communicate with the PCM? Yes Go to step 2) . No Perform «*NO RESPONSE FROM ALL MODULES»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) .
2. 2) CHECK COMMUNICATION WITH OTHER MODULES ON SCI TRANSMIT CIRCUIT With the ignition on. Using the scan tool, attempt to communicate with the Body Control Module. Is the scan tool able to communicate with the Body Control Module? Yes Go to step 3) . No Go to step 7) .
3. 3) FUSED B+ CIRCUIT OPEN Turn the ignition off. Disconnect the SKREEM C1 harness connector. NOTE: Check connector - Clean/repair as necessary. Turn the ignition on. Measure the voltage of the Fused B+ circuit at the SKREEM C1 harness connector. Is the voltage above 10 volts? Yes Go to step 4) . No Repair the Fused B+ circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
4. 4) FUSED IGNITION SWITCH OUTPUT CIRCUIT OPEN With the ignition on. Measure the voltage of the Fused Ignition Switch Output circuit at the SKREEM C1 harness connector. Is the voltage above 10 volts? Yes Go to step 5) . No Repair the Fused Ignition Switch Output circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
5. 5) GROUND CIRCUIT OPEN Turn the ignition off. Measure the resistance of the Ground circuit from the SKREEM C1 harness connector. Is the resistance below 5.0 ohms? Yes Go to step 6) . No Repair the Ground circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
6. 6) SCI TRANSMIT CIRCUIT OPEN With the ignition off. Measure the resistance of the SCI Transmit circuit from the SKREEM C1 harness connector to the DLC. Is the resistance below 5.0 ohms? Yes Replace the Sentry Key Remote Entry Module. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-service-information) . Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Repair the SCI Transmit circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
7. 7) DISCONNECT MODULES NOTE: The Body Control Module and Sentry Key Remote Entry Module both use the SCI Transmit circuit at DLC cavity 1 to communicate with the scan tool. If one of these modules keeps the SCI Transmit circuit artificially high or low, the scan tool will not be able to communicate with either of the modules. NOTE: Perform the following steps for each of the modules until communication is restored with the other module or until each of the modules has been eliminated as the cause of the fault. Turn the ignition off. Disconnect each of the modules noted above, one at a time. Turn the ignition on. Using the scan tool, attempt to communicate with the other module still connected. Is the scan tool able to communicate with the other module? Yes Replace the module that was disconnected when communication was restored to the other module. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Go to step 8) .
8. 8) SCI TRANSMIT CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Disconnect the harness connectors for the Body Control Module and Sentry Key Remote Entry Module. Turn the ignition on. Measure the voltage of the SCI Transmit circuit at DLC cavity 1. Is the voltage below 0.5 volt? Yes Go to step 9) . No Repair the SCI Transmit circuit for a short to voltage. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
9. 9) SCI TRANSMIT CIRCUIT SHORTED TO GROUND OR OPEN Turn the ignition off. Measure the resistance between ground and the SCI Transmit circuit. Is the resistance above 100 kohms? Yes Repair the SCI Transmit circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Repair the SCI Transmit circuit for a short to ground. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .

Scheme 80

For a complete Data Link Connector Circuit Diagram, see SCHEMATICS AND DIAGRAMS .

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

1. 1) CHECK COMMUNICATION WITH OTHER MODULES Turn the ignition on. Using the scan tool, attempt to communicate with the PCM. Is the scan tool able to communicate with the PCM? Yes Go to step 2) . No Perform «*NO RESPONSE FROM ALL MODULES»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) .
2. 2) CHECK COMMUNICATION WITH OTHER MODULES ON SCI TRANSMIT CIRCUIT With the ignition on. Using the scan tool, attempt to communicate with the Controller Antilock Brake. Is the scan tool able to communicate with the Controller Antilock Brake? Yes Go to step 3) . No Go to step 7) .
3. 3) TRACTION SYSTEM RELAY OUTPUT CIRCUIT OPEN Turn the ignition off. Disconnect the SLA harness connector. NOTE: Check connector - Clean/repair as necessary. Turn the ignition on. Measure the voltage of the Traction System Relay Output circuit at the SLA harness connector. Is the voltage above 10 volts? Yes Go to step 4) . No Repair the Traction System Relay Output circuit for an open. Perform «NAG1 TRANSMISSION VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/automatic-trans/#nag1-automatic-transmission-electrical-diagnostics__nag1-transmission-verification-test) .
4. 4) FUSED IGNITION SWITCH OUTPUT CIRCUIT OPEN With the ignition on. Measure the voltage of the Fused Ignition Switch Output circuit at the SLA harness connector. Is the voltage above 10 volts? Yes Go to step 5) . No Repair the Fused Ignition Switch Output circuit for an open. Perform «NAG1 TRANSMISSION VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/automatic-trans/#nag1-automatic-transmission-electrical-diagnostics__nag1-transmission-verification-test) .
5. 5) GROUND CIRCUIT OPEN Turn the ignition off. Measure the resistance of the Ground circuit from the SLA harness connector to ground. Is the resistance below 5.0 ohms? Yes Go to step 6) . No Repair the Ground circuit for an open. Perform «NAG1 TRANSMISSION VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/automatic-trans/#nag1-automatic-transmission-electrical-diagnostics__nag1-transmission-verification-test) .
6. 6) SCI TRANSMIT CIRCUIT OPEN With the ignition off. Measure the resistance of the SCI Transmit circuit from the SLA harness connector to the DLC. Is the resistance below 5.0 ohms? Yes Replace the Shift Lever Assembly. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/automatic-trans/#nag1-automatic-transmission-service-information) . Perform «NAG1 TRANSMISSION VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/automatic-trans/#nag1-automatic-transmission-electrical-diagnostics__nag1-transmission-verification-test) . No Repair the SCI Transmit circuit for an open. Perform «NAG1 TRANSMISSION VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/automatic-trans/#nag1-automatic-transmission-electrical-diagnostics__nag1-transmission-verification-test) .
7. 7) DISCONNECT MODULES NOTE: The Controller Antilock Brake and Shift Lever Assembly both use the SCI Transmit circuit at DLC cavity 9 to communicate with the scan tool. If one of these modules keeps the SCI Transmit circuit artificially high or low, the scan tool will not be able to communicate with any of the modules. NOTE: Perform the following steps for each of the modules until communication is restored with the other module or until each of the modules has been eliminated as the cause of the fault. Turn the ignition off. Disconnect each of the modules noted above, one at a time. Turn the ignition on. Using the scan tool, attempt to communicate with the other module still connected. Is the scan tool able to communicate with the other module? Yes Replace the module that was disconnected when communication was restored to the other module. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Go to step 8) .
8. 8) SCI TRANSMIT CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Disconnect the harness connectors for the Controller Antilock Brake and Shift Lever Assembly. Turn the ignition on. Measure the voltage of the SCI Transmit circuit at the SLA harness connector. Is the voltage below 0.5 volt? Yes Go to step 9) . No Repair the SCI Transmit circuit for a short to voltage. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
9. 9) SCI TRANSMIT CIRCUIT SHORTED TO GROUND OR OPEN Turn the ignition off. Measure the resistance between ground and the SCI Transmit circuit. Is the resistance above 100 kohms? Yes Repair the SCI Transmit circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Repair the SCI Transmit circuit for a short to ground. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .

Scheme 87

For a complete Data Link Connector Circuit Diagram, see SCHEMATICS AND DIAGRAMS .

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

1. 1) CHECK COMMUNICATION WITH OTHER MODULES Turn the ignition on. Using the scan tool, attempt to communicate with any other module. Is the scan tool able to communicate with the module selected? Yes Go to step 2) . No Perform «*NO RESPONSE FROM ALL MODULES»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) .
2. 2) TRACTION SYSTEM RELAY OUTPUT CIRCUIT OPEN Turn the ignition off. Disconnect the TCM harness connector. NOTE: Check connector - Clean/repair as necessary. Turn the ignition on. Measure the voltage of the Traction System Relay Output circuit at the TCM harness connector. Is the voltage above 10 volts? Yes Go to step 3) . No Repair the Traction System Relay Output circuit for an open. Perform «NAG1 TRANSMISSION VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/automatic-trans/#nag1-automatic-transmission-electrical-diagnostics__nag1-transmission-verification-test) .
3. 3) GROUND CIRCUIT OPEN Turn the ignition off. Measure the resistance of the Ground circuit from the TCM harness connector to ground. Is the resistance below 5.0 ohms? Yes Go to step 4) . No Repair the Ground circuit for an open. Perform «NAG1 TRANSMISSION VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/automatic-trans/#nag1-automatic-transmission-electrical-diagnostics__nag1-transmission-verification-test) .
4. 4) SCI TRANSMIT CIRCUIT OPEN With the ignition off. Measure the resistance of the SCI Transmit circuit from the TCM harness connector to the DLC. Is the resistance below 5.0 ohms? Yes Go to step 5) . No Repair the SCI Transmit circuit for an open. Perform «NAG1 TRANSMISSION VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/automatic-trans/#nag1-automatic-transmission-electrical-diagnostics__nag1-transmission-verification-test) .
5. 5) SCI TRANSMIT CIRCUIT SHORTED TO GROUND With the ignition off. Measure the resistance between ground and the SCI Transmit circuit. Is the resistance above 100 kohms? Yes Go to step 6) . No Repair the SCI Transmit circuit for a short to ground. Perform «NAG1 TRANSMISSION VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/automatic-trans/#nag1-automatic-transmission-electrical-diagnostics__nag1-transmission-verification-test) .
6. 6) SCI TRANSMIT CIRCUIT SHORTED TO VOLTAGE Turn the ignition on. Measure the voltage of the SCI Transmit circuit at the DLC. Is the voltage below 0.5 volt? Yes Replace the Transmission Control Module. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-service-information) . Perform «NAG1 TRANSMISSION VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/automatic-trans/#nag1-automatic-transmission-electrical-diagnostics__nag1-transmission-verification-test) . No Repair the SCI Transmit circuit for a short to voltage. Perform «NAG1 TRANSMISSION VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/automatic-trans/#nag1-automatic-transmission-electrical-diagnostics__nag1-transmission-verification-test) .

Scheme 93

For a complete Data Link Connector Circuit Diagram, see SCHEMATICS AND DIAGRAMS .

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

1. 1) CHECK COMMUNICATION WITH OTHER MODULES Turn the ignition on. Using the scan tool, attempt to communicate with the PCM. Is the scan tool able to communicate with the PCM? Yes Go to step 2) . No Perform «*NO RESPONSE FROM ALL MODULES»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics) .
2. 2) CHECK COMMUNICATION WITH OTHER MODULES ON SCI TRANSMIT CIRCUIT With the ignition on. Using the scan tool, attempt to communicate with either the Instrument Cluster, A/C Heater Control Module, or Power Top Control Module (if equipped). Is the scan tool able to communicate with the module selected? Yes Go to step 3) . No Go to step 7) .
3. 3) FUSED B+ CIRCUIT OPEN Turn the ignition off. Disconnect the UGDO/TPM harness connector. NOTE: Check connector - Clean/repair as necessary. Turn the ignition on. Measure the voltage of the Fused B+ circuit at the UGDO/TPM harness connector. Is the voltage above 10 volts? Yes Go to step 4) . No Repair the Fused B+ circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
4. 4) FUSED IGNITION SWITCH OUTPUT CIRCUIT OPEN With the ignition on. Measure the voltage of the Fused Ignition Switch Output circuit at the UGDO/TPM harness connector. Is the voltage above 10 volts? Yes Go to step 5) . No Repair the Fused Ignition Switch Output circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
5. 5) GROUND CIRCUIT OPEN Turn the ignition off. Measure the resistance of the Ground circuit from the UGDO/TPM harness connector to ground. Is the resistance below 5.0 ohms? Yes Go to step 6) . No Repair the Ground circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
6. 6) SCI TRANSMIT CIRCUIT OPEN With the ignition off. Measure the resistance of the SCI Transmit circuit from the UGDO/TPM harness connector to the DLC. Is the resistance below 5.0 ohms? Yes Replace the Universal Garage Door Opener/Tire Pressure Monitor. Refer to «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/door-locks-anti-theft-systems/#homelink-universal-transmitter) . Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Repair the SCI Transmit circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
7. 7) DISCONNECT MODULES NOTE: The Instrument Cluster, Universal Garage Door Opener/Tire Pressure Monitor, A/C Heater Control Module, and Power Top Control Module (if equipped) all use the SCI Transmit circuit at DLC cavity 15 to communicate with the scan tool. If one of these modules keeps the SCI Transmit circuit artificially high or low, the scan tool will not be able to communicate with any of the four modules. NOTE: Perform the following steps for each of the modules until communication is restored with the other modules or until each of the modules has been eliminated as the cause of the fault. Turn the ignition off. Disconnect each of the modules noted above, one at a time. Turn the ignition on. Using the scan tool, attempt to communicate with any of the three modules still connected. Is the scan tool able to communicate with the module selected? Yes Replace the module that was disconnected when communication was restored to the other two modules. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Go to step 8) .
8. 8) SCI TRANSMIT CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Disconnect the harness connectors for the IC, UGDO/TPM, A/C Heater Control Module, and Power Top Control Module (if equipped). Turn the ignition on. Measure the voltage of the SCI Transmit circuit at the UGDO/TPM harness connector. Is the voltage below 0.5 volt? Yes Go to step 9) . No Repair the SCI Transmit circuit for a short to voltage. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
9. 9) SCI TRANSMIT CIRCUIT SHORTED TO GROUND OR OPEN Turn the ignition off. Measure the resistance between ground and the SCI Transmit circuit. Is the resistance above 100 kohms? Yes Repair the SCI Transmit circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Repair the SCI Transmit circuit for a short to ground. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .

Scheme 100

For a complete Data Link Connector Circuit Diagram, see SCHEMATICS AND DIAGRAMS .

Scheme 101

Scheme 102

1. 1) MEASURE THE VOLTAGE OF THE DLC POWER CIRCUIT NOTE: If the LEDs do not light or no sound is emitted at start up, check for loose cable connections or a bad cable. Check the vehicle battery voltage (data link 16-way connector cavity 16). A minimum of 11 volts is required to adequately power the scan tool. Check for a proper ground at DLC cavity 4. If all connections are proper between the scan tool and the vehicle or other devices and the vehicle battery is fully charged, an inoperative scan tool may be the result of a faulty cable. Turn the ignition off. Measure the voltage of the Fused B(+) circuit at cavity 16 of the Data Link Connector. Is the voltage above 11 volts? Yes Go to step 2) . No System voltage must be above 11 volts. Check Fuse 14 in the Underhood Accessory Fuse Block. Repair the voltage concern as necessary. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .
2. 2) MEASURE THE RESISTANCE OF THE DLC GROUND CIRCUIT Measure the resistance between ground the Ground circuit at cavity 4 of the Data Link Connector. Is the resistance below 5.0 ohms? Yes Inspect the scan tool for a possible malfunction. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) . No Repair the DLC Ground circuit for an open. Perform «*BODY VERIFICATION TEST»(/chrysler/crossfire/i-final-2008-2008/remont/communication-devices/#electronic-control-modules-electrical-diagnostics__body-verification-test) .

*BODY VERIFICATION TEST

Turn the ignition off.

Disconnect all jumper wires and reconnect all previously disconnected components and connectors.

Note. If the SKREEM or the PCM was replaced, refer to the service information for proper programming procedures.

If the Body Control Module was replaced, turn the ignition on for 15 seconds (to allow the new BCM to learn VIN) or engine may not start.

Program all RKE transmitters and other options as necessary.

With the scan tool, erase all Diagnostic Trouble Codes (DTCs) from ALL modules. Start the engine and allow it to run for 2 minutes. Operate all functions of the system that caused the original complaint.

Ensure that all accessories are turned off and the battery is fully charged.

Turn the ignition off and wait 5 seconds. Turn the ignition on and using the scan tool, read DTCs from ALL modules.

Are any DTCs present or is the original complaint still present?

Are any DTCs present?

YES

1. Repair is not complete, refer to appropriate symptom.

NO

1. Repair is complete.

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109
