Battery System Chrysler Crossfire I final

A single 12-volt battery is standard factory-installed equipment on this model. All of the components of the battery system are located within the engine compartment of the vehicle. The battery system for this vehicle covers the following related components, which are covered in further detail later in this service information

1. Battery - The storage battery provides a reliable means of storing a renewable source of electrical energy within the vehicle.
2. Battery Cables - The battery cables connect the battery terminal posts to the vehicle electrical system.
3. Battery Hold-down - The battery hold-down hardware secures the battery in the battery tray in the engine compartment.
4. Battery Tray - The battery tray provides a secure mounting location in the vehicle for the battery and an anchor point for the battery hold-down hardware.

For battery system maintenance schedules and jump starting procedure, see the owner's manual. Optionally, refer to the LUBRICATION & MAINTENANCE article for the recommended battery maintenance schedules and for the proper battery jump starting procedure. While battery charging can be considered a maintenance procedure, the battery charging procedures and related information are located later in this service information. This was done because the battery must be fully charged before any battery system diagnosis or testing procedures can be performed.

The battery system is designed to provide a safe, efficient, reliable and mobile means of delivering and storing electrical energy. This electrical energy is required to operate the engine starting system, as well as to operate many of the other vehicle accessory systems for limited durations while the engine and/or the charging system are not operating. The battery system is also designed to provide a reserve of electrical energy to supplement the charging system for short durations while the engine is running and the electrical current demands of the vehicle exceed the output of the charging system. In addition to delivering and storing electrical energy for the vehicle, the battery system serves as a capacitor and voltage stabilizer for the vehicle electrical system. It absorbs most abnormal or transient voltages caused by the switching of any of the electrical components or circuits in the vehicle.

The battery, starting, and charging systems in the vehicle operate with one another and must be tested as a complete system. In order for the engine to start and the battery to maintain its charge properly, all of the components that are used in these systems must perform within specifications. It is important that the battery, starting, and charging systems be thoroughly tested and inspected any time a battery needs to be charged or replaced. The cause of abnormal battery discharge, overcharging or early battery failure must be diagnosed and corrected before a battery is replaced and before a vehicle is returned to service. The service information for these systems has been separated within this service information to make it easier to locate the specific information you are seeking. However, when attempting to diagnose any of these systems, it is important that you keep their interdependency in mind.

The diagnostic procedures used for the battery, starting, and charging systems include the most basic conventional diagnostic methods, to the more sophisticated On-Board Diagnostics (OBD) built into the Powertrain Control Module (PCM). Use of an induction-type milliampere ammeter, a volt/ohmmeter, a battery charger, a carbon pile rheostat (load tester) and a 12-volt test lamp may be required. All OBD-sensed systems are monitored by the PCM. Each monitored circuit is assigned a Diagnostic Trouble Code (DTC). The PCM will store a DTC in electronic memory for any failure it detects. Refer to DIAGNOSIS AND TESTING for the proper charging system on-board diagnostic test procedures.

Scheme 6

The Micro 420 automotive battery tester is designed to help dealership technicians diagnose a defective battery. Follow the instruction manual supplied with the tester to properly diagnose a vehicle. If the instruction manual is not available, refer to STANDARD PROCEDURE , which includes the directions for using the Micro 420 electrical system tester.

ABNORMAL BATTERY DISCHARGING

Any of the following conditions can result in abnormal battery discharging

1. A faulty or incorrect charging system component. Refer to «DIAGNOSIS AND TESTING»(/chrysler/crossfire/i-final-2008-2008/remont/charging-system/#charging-system) .
2. A faulty or incorrect battery. Use the Micro 420 battery tester and refer to «DIAGNOSIS AND TESTING»(/chrysler/crossfire/i-final-2008-2008/remont/charging-system/#battery-system) for additional battery diagnosis and testing procedures.
3. A faulty circuit or component causing excessive ignition-off draw.
4. Electrical loads that exceed the output of the charging system. This can be due to equipment installed after manufacture, or repeated short trip use.
5. A faulty or incorrect starting system component. Refer to «DIAGNOSIS AND TESTING»(/chrysler/crossfire/i-final-2008-2008/remont/starter/#starting-system) .
6. Corroded or loose battery posts and/or terminal clamps.
7. Slow driving speeds (heavy traffic conditions) or prolonged idling, with high-amperage draw systems in use.

The following information details the recommended cleaning procedures for the battery and related components. In addition to the maintenance schedules found in this service information and the owner's manual, it is recommended that these procedures be performed any time the battery or related components must be removed for vehicle service.

Scheme 7

Scheme 8

Scheme 9

1. Clean the battery cable terminal clamps (2) of all corrosion. Remove any corrosion using a wire terminal brush (1) or a post and terminal cleaning tool, and a sodium bicarbonate (baking soda) and warm water cleaning solution.
2. Clean the battery tray and battery hold-down hardware of all corrosion. Remove any corrosion using a wire brush and a sodium bicarbonate (baking soda) and warm water cleaning solution. Paint any exposed bare metal.
3. If the removed battery (3) is to be reinstalled, clean the outside of the battery case and the top cover with a sodium bicarbonate (baking soda) and warm water cleaning solution (2) using a stiff bristle parts cleaning brush (1) to remove any acid film. Rinse the battery with clean water. Ensure that the cleaning solution does not enter the battery cells through the vent holes. If the battery is being replaced, refer to «SPECIFICATIONS - BATTERY SYSTEM»(/chrysler/crossfire/i-final-2008-2008/remont/charging-system/#battery-system) for the factory-installed battery specifications. Confirm that the replacement battery is the correct size and has the correct ratings for the vehicle.
4. Clean any corrosion from the battery (3) and the battery terminal posts and battery cables (2) with a wire brush or a post and terminal cleaner (1), and a sodium bicarbonate (baking soda) and warm water cleaning solution.

The following information details the recommended inspection procedures for the battery and related components. In addition to the maintenance schedules found in this service information and the owner's manual, it is recommended that these procedures be performed any time the battery or related components must be removed for vehicle service.

1. Inspect the battery cable terminal clamps for damage. Replace any battery cable that has a damaged or deformed terminal clamp.
2. Inspect the battery tray and battery hold-down hardware for damage. Replace any damaged parts.
3. Inspect the battery case for cracks or other damage that could result in electrolyte leaks. Also, check the battery terminal posts for looseness. Batteries with damaged cases or loose terminal posts must be replaced.

The battery Group Size number, the Cold Cranking Amperage (CCA) rating, and the Reserve Capacity (RC) rating or Ampere-Hours (AH) rating can be found on the original equipment battery label. Be certain that a replacement battery has the correct Group Size number, as well as CCA, and RC or AH ratings that equal or exceed the original equipment specification for the vehicle being serviced. Battery sizes and ratings are discussed in more detail below.

1. Group Size - The outside dimensions and terminal placement of the battery conform to standards established by the Battery Council International (BCI). Each battery is assigned a BCI Group Size number to help identify a correctly-sized replacement.
2. Cold Cranking Amperage - The Cold Cranking Amperage (CCA) rating specifies how much current (in amperes) the battery can deliver for thirty seconds at -18° C (0° F). Terminal voltage must not fall below 7.2 volts during or after the thirty second discharge period. The CCA required is generally higher as engine displacement increases, depending also upon the starter current draw requirements.
3. Reserve Capacity - The Reserve Capacity (RC) rating specifies the time (in minutes) it takes for battery terminal voltage to fall below 10.5 volts, at a discharge rate of 25 amperes. RC is determined with the battery fully-charged at 26.7° C (80° F). This rating estimates how long the battery might last after a charging system failure, under minimum electrical load.
4. Ampere-Hours - The Ampere-Hours (AH) rating specifies the current (in amperes) that a battery can deliver steadily for twenty hours, with the voltage in the battery not falling below 10.5 volts. This rating is also sometimes identified as the twenty-hour discharge rating.

Scheme 10

A large capacity, low-maintenance storage battery (3) is standard factory-installed equipment on this model. Male post type terminals made of a soft lead material protrude from the top of the molded plastic battery case to provide the means for connecting the battery to the vehicle electrical system. The battery positive terminal post (2) is visibly larger in diameter than the negative terminal post (4), for easy identification. The symbols + and - are also molded into the top of the battery case adjacent to their respective positive and negative terminal posts for additional identification confirmation. Refer to CABLES for the location of more information on the battery cables that connect the battery to the vehicle electrical system. See DESCRIPTION .

This battery is designed to provide a safe, efficient and reliable means of storing electrical energy in a chemical form. This means of energy storage allows the battery to produce the electrical energy required to operate the engine starting system, as well as to operate many of the other vehicle accessory systems for limited durations while the engine and/or the charging system are not operating. The battery is made up of six individual cells that are connected in series. Each cell contains positively charged plate groups that are connected with lead straps to the positive terminal post, and negatively charged plate groups that are connected with lead straps to the negative terminal post. Each plate consists of a stiff mesh framework or grid coated with lead dioxide (positive plate) or sponge lead (negative plate). Insulators or plate separators made of a non-conductive material are inserted between the positive and negative plates to prevent them from contacting or shorting against one another. These dissimilar metal plates are submerged in a sulfuric acid and water solution called an electrolyte.

The factory-installed low-maintenance battery has removable battery cell caps (1). Distilled water can be added to this battery. The battery is not sealed and has a vent (5). The chemical composition of the metal coated plates within the low-maintenance battery reduces battery gassing and water loss, at normal charge and discharge rates. Therefore, the battery should not require additional water in normal service. If the electrolyte level in this battery does become low, distilled water must be added. However, rapid loss of electrolyte can be caused by an overcharging condition. Be certain to diagnose the charging system after replenishing the water in the battery for a low electrolyte condition and before returning the vehicle to service. Refer to DESCRIPTION .

For battery maintenance schedules and jump starting procedures, see the owner's manual. Optionally, refer to Maintenance Schedules and Jump Starting, Towing and Hoisting in LUBRICATION & MAINTENANCE article for the location of the recommended battery maintenance schedules and the proper battery jump starting procedures. While battery charging can be considered a maintenance procedure, the battery charging procedures and information are located in the service procedures in this service information. This was done because the battery must be fully-charged before any battery diagnosis or testing procedures can be performed. See STANDARD PROCEDURE .

OPERATION - BATTERY

The battery is designed to store electrical energy in a chemical form. When an electrical load is applied to the terminals of the battery, an electrochemical reaction occurs. This reaction causes the battery to discharge electrical current from its terminals. As the battery discharges, a gradual chemical change takes place within each cell. The sulfuric acid in the electrolyte combines with the plate materials, causing both plates to slowly change to lead sulfate. At the same time, oxygen from the positive plate material combines with hydrogen from the sulfuric acid, causing the electrolyte to become mainly water. The chemical changes within the battery are caused by the movement of excess or free electrons between the positive and negative plate groups. This movement of electrons produces a flow of electrical current through the load device attached to the battery terminals.

As the plate materials become more similar chemically, and the electrolyte becomes less acid, the voltage potential of each cell is reduced. However, by charging the battery with a voltage higher than that of the battery itself, the battery discharging process is reversed. Charging the battery gradually changes the sulfated lead plates back into sponge lead and lead dioxide, and the water back into sulfuric acid. This action restores the difference in the electron charges deposited on the plates, and the voltage potential of the battery cells. For a battery to remain useful, it must be able to produce high-amperage current over an extended period. A battery must also be able to accept a charge, so that its voltage potential may be restored.

The battery is vented to release excess hydrogen gas that is created when the battery is being charged or discharged. However, even with these vents, hydrogen gas can collect in or around the battery. If hydrogen gas is exposed to flame or sparks, it may ignite. If the electrolyte level is low, the battery may arc internally and explode. If the battery is equipped with removable cell caps, add distilled water whenever the electrolyte level is below the top of the plates. If the battery cell caps cannot be removed, the battery must be replaced if the electrolyte level becomes low.

BATTERY TESTING

The battery must be completely charged and the terminals should be properly cleaned and inspected before diagnostic procedures are performed. Refer to CLEANING and Battery System INSPECTION for the proper battery inspection procedures. Refer to STANDARD PROCEDURE .

MICRO 420 BATTERY TESTER

The Micro 420 automotive battery tester is designed to help dealership technicians diagnose the cause of a defective battery. Follow the instruction manual supplied with the tester to properly diagnose a vehicle. If the instruction manual is not available, refer to STANDARD PROCEDURE , which includes the directions for using the Micro 420 battery tester.

A battery that will not accept a charge is faulty, and must be replaced. Further testing is not required. A fully-charged battery must be load tested to determine its cranking capacity. A battery that is fully-charged, but does not pass the load test, is faulty and must be replaced.

Note. Completely discharged batteries may take several hours to accept a charge. Refer to STANDARD PROCEDURE .

BATTERY IGNITION-OFF DRAW TEST PROCEDURE

The term Ignition-Off Draw (IOD) identifies a normal condition where power is being drained from the battery with the ignition switch in the Off position. A normal vehicle electrical system will draw from five to thirty-five milliamperes (0.005 to 0.035 ampere) with the ignition switch in the Off position, and all non-ignition controlled circuits in proper working order. Up to thirty-five milliamperes are needed to enable the memory functions for the Powertrain Control Module (PCM), and other modules which may vary with the vehicle equipment.

A vehicle that has not been operated for approximately twenty days, may discharge the battery to an inadequate level. When a vehicle will not be used for twenty days or more (stored), remove the negative battery cable from the battery. This will reduce battery discharging.

Excessive IOD can be caused by

1. Electrical items left on.
2. Faulty or improperly adjusted switches.
3. Faulty or shorted electronic modules and components.
4. An internally shorted generator.
5. Intermittent shorts in the wiring.

If the IOD is over thirty-five milliamperes, the problem must be found and corrected before replacing a battery. In most cases, the battery can be charged and returned to service after the excessive IOD condition has been corrected.

1. Verify that all electrical accessories are off. Turn off all lamps, remove the ignition key, and close all doors. If the vehicle is equipped with an illuminated entry system or an electronically tuned radio, allow the electronic timer function of these systems to automatically shut off (time out). This may take up to three minutes. See the ELECTRONIC MODULE IGNITION-OFF DRAW Table for more information. Module Time Out? (If Yes, Interval And Wake-Up Input) IOD IOD After Time Out Controller Antilock Brake (CAB) No - N/A Body Control Module (BCM) No - N/A Powertrain Control Module (PCM) No - N/A Transmission Control Module (TCM) No - N/A Instrument Cluster No - N/A Shift Lever Assembly No - N/A Garage Door Opener/Tire Pressure Monitor No - N/A A/C Heater Control Module No - N/A Occupant Restraint Control Module No - N/A Pneumatic System Equipment (PSE) Control Module No - N/A RKE Module No - N/A
2. Disconnect the negative battery cable.
3. Set an electronic digital multi-meter to its highest amperage scale. Connect the multi-meter between the disconnected battery negative cable terminal clamp and the battery negative terminal post. Make sure that the doors remain closed so that the illuminated entry system is not activated. The multi-meter amperage reading may remain high for up to three minutes, or may not give any reading at all while set in the highest amperage scale, depending upon the electrical equipment in the vehicle. The multi-meter leads must be securely clamped to the battery negative cable terminal clamp and the battery negative terminal post. If continuity between the battery negative terminal post and the negative cable terminal clamp is lost during any part of the IOD test, the electronic timer function will be activated and all of the tests will have to be repeated.
4. After about three minutes, the high-amperage IOD reading on the multi-meter should become very low or nonexistent, depending upon the electrical equipment in the vehicle. If the amperage reading remains high, remove each fuse in the Underhood Accessory Fuse Block, one at a time until the amperage reading becomes very low, or nonexistent. If the amperage reading is still high, remove each fuse one at a time in the Illumination Control Module until the amperage reading becomes very low or nonexistent. If the amperage reading is still high, remove each fuse one at a time in the Relay Control Module until the amperage reading becomes very low or nonexistent. Refer to the appropriate wiring information in this service information for complete Underhood Accessory Fuse, Illumination Control Module Fuse, Relay Control Module Fuse and circuit identification. This will isolate each circuit and identify the circuit that is the source of the high-amperage IOD. If the amperage reading remains high after removing and replacing each fuse, disconnect the wire harness from the generator. If the amperage reading now becomes very low or nonexistent, refer to «DIAGNOSIS AND TESTING»(/chrysler/crossfire/i-final-2008-2008/remont/charging-system/#charging-system) . After the high-amperage IOD has been corrected, switch the multi-meter to progressively lower amperage scales and, if necessary, repeat the fuse and circuit breaker remove-and-replace process to identify and correct all sources of excessive IOD. It is now safe to select the lowest milliampere scale of the multi-meter to check the low-amperage IOD. CAUTION: Do not open any doors, or turn on any electrical accessories with the lowest milliampere scale selected, or the multi-meter may be damaged.
5. Observe the multi-meter reading. The low-amperage IOD should not exceed thirty-five milliamperes (0.035 amperes). If the current draw exceeds thirty-five milliamperes, isolate each circuit using the fuse remove-and-replace process in step 4 . The multi-meter reading will drop to within the acceptable limit when the source of the excessive current draw is disconnected. Repair this circuit as required; whether a wiring short, incorrect switch adjustment, or a component failure is at fault.

CHECKING BATTERY ELECTROLYTE LEVEL

The following procedure can be used to check the battery electrolyte level.

Scheme 11

Scheme 12

1. Remove the battery (2) cell cap (1).
2. Look through the battery cap holes (1) to determine the level of the electrolyte in the battery. The electrolyte should be approximately 1 centimeter above the battery plates or until the lip (2) inside the battery cap holes is covered.
3. Add only distilled water until the electrolyte level is approximately one centimeter above the plates.

MICRO 420 BATTERY TESTER PROCEDURE

Always use the Micro 420 Instruction Manual that was supplied with the tester as a reference. If the Instruction Manual is not available the following procedure can be used

1. If testing the battery OUT-OF-VEHICLE, clean the battery terminals with a wire brush before testing. If the battery is equipped with side post terminals, install and tighten the supplied lead terminal stud adapters. Do not use steel bolts. Failure to properly install the stud adapters, or using stud adapters that are dirty or worn-out may result in false test readings.
2. If testing the battery IN-THE-VEHICLE, make certain all of the vehicle accessory loads are OFF, including the ignition. The preferred test position is at the battery terminal . If the battery is not accessible, you may test using both the positive and negative jumper posts. Select TESTING AT JUMPER POST when connecting to that location.
3. Connect the tester to the battery or jumper posts, the red clamp to positive (+) and the black clamp to negative (-). NOTE: Multiple batteries connected in parallel must have the ground cable disconnected to perform a battery test. Failure to disconnect may result in false battery test readings.
4. Using the ARROW key select in or out of vehicle testing and press ENTER to make a selection.
5. If not selected, choose the Cold Cranking Amp (CCA) battery rating. Or select the appropriate battery rating for your area (see menu). The tester will then run its self programmed test of the battery and display the results. Refer to the test result table noted below. CAUTION: If REPLACE BATTERY is the result of the test, this may mean a poor connection between the vehicle's cables and battery exists. After disconnecting the vehicle's battery cables from the battery, retest the battery using the OUT-OF-VEHICLE test before replacing.
6. While viewing the battery test result, press the CODE button and the tester will prompt you for the last 4 digits of the VIN. Use the UP/DOWN arrow buttons to scroll to the correct character; then press ENTER to select and move to the next digit. Then press the ENTER button to view the SERVICE CODE. Pressing the CODE button a second time will return you to the test results.

Note. The SERVICE CODE is required on every warranty claim submitted for battery replacement.

BATTERY CHARGING PROCEDURE

Battery charging is the means by which the battery can be restored to its full voltage potential. A battery is fully-charged when

1. Micro 420 electrical system tester indicates battery is OK.
2. All of the battery cells are gassing freely during battery charging.
3. Three hydrometer tests, taken at one-hour intervals, indicate no increase in the temperature-corrected specific gravity of the battery electrolyte.
4. Open-circuit voltage of the battery is 12.4 volts or above.

After the battery has been charged to 12.4 volts or greater, perform a load test to determine the battery cranking capacity. Refer to STANDARD PROCEDURE . If the battery will endure a load test, return the battery to service. If the battery will not endure a load test, it is faulty and must be replaced.

Clean and inspect the battery hold downs, tray, terminals, posts, and top before completing battery service. Refer to CLEANING and INSPECTION .

CHARGING A COMPLETELY DISCHARGED BATTERY

The following procedure should be used to recharge a completely discharged battery. Unless this procedure is properly followed, a good battery may be needlessly replaced.

Scheme 13

1. Measure the voltage at the battery posts with a voltmeter, accurate to 1/10 (0.10) volt. If the reading is below ten volts, the battery charging current will be low. It could take some time before the battery accepts a current greater than a few milliamperes. Such low current may not be detectable on the ammeters built into many battery chargers.
2. Disconnect and isolate the battery negative cable. Connect the battery charger leads. Some battery chargers are equipped with polarity-sensing circuitry. This circuitry protects the battery charger and the battery from being damaged if they are improperly connected. If the battery state-of-charge is too low for the polarity-sensing circuitry to detect, the battery charger will not operate. This makes it appear that the battery will not accept charging current. See the instructions provided by the manufacturer of the battery charger for details on how to bypass the polarity-sensing circuitry.
3. Battery chargers vary in the amount of voltage and current they provide. The amount of time required for a battery to accept measurable charging current at various voltages is shown in the CHARGE RATE TABLE. If the charging current is still not measurable at the end of the charging time, the battery is faulty and must be replaced. If the charging current is measurable during the charging time, the battery may be good and the charging should be completed in the normal manner.

CHARGING TIME REQUIRED

The time required to charge a battery will vary, depending upon the following factors

1. Battery Capacity - A completely discharged heavy-duty battery requires twice the charging time of a small capacity battery.
2. Temperature - A longer time will be needed to charge a battery at -18° C (0° F) than at 27° C (80° F). When a fast battery charger is connected to a cold battery, the current accepted by the battery will be very low at first. As the battery warms, it will accept a higher charging current rate (amperage).
3. Charger Capacity - A battery charger that supplies only five amperes will require a longer charging time. A battery charger that supplies twenty amperes or more will require a shorter charging time.
4. State-Of-Charge - A completely discharged battery requires more charging time than a partially discharged battery. Electrolyte is nearly pure water in a completely discharged battery. At first, the charging current (amperage) will be low. As the battery charges, the specific gravity of the electrolyte will gradually rise.

The BATTERY CHARGING TIME Table gives an indication of the time required to charge a typical battery at room temperature based upon the battery state-of-charge and the charger capacity.

BATTERY OPEN-CIRCUIT VOLTAGE TEST PROCEDURE

A battery open-circuit voltage (no load) test will show the approximate state-of-charge of a battery. This test can be used in place of the hydrometer test when a hydrometer is not available, or for maintenance-free batteries with non-removable cell caps.

Before proceeding with this test, completely charge the battery. See STANDARD PROCEDURE .

1. Before measuring the open-circuit voltage, the surface charge must be removed from the battery. Turn on the headlamps for fifteen seconds, then allow up to five minutes for the battery voltage to stabilize.
2. Disconnect and isolate both battery cables, negative cable first.
3. Using a voltmeter connected to the battery posts (see the instructions provided by the manufacturer of the voltmeter), measure the open-circuit voltage.

Scheme 14

1. Disconnect the negative battery cable (3). If necessary, use a battery terminal puller to remove the terminal clamp from the battery post.
2. Remove the positive battery cable protective plastic cap (2).
3. Disconnect the positive battery cable (1). If necessary, use a battery terminal puller to remove the terminal clamp from the battery post.
4. Remove the battery hold down nut (5) and strap from the battery.
5. Remove the battery (4) from the battery tray.

Scheme 15

1. Disconnect the negative battery cable (4). If necessary, use a battery terminal puller to remove the terminal clamp from the battery post.
2. Remove the protective plastic cap (1).
3. Disconnect the positive battery cable (2). If necessary, use a battery terminal puller to remove the terminal clamp from the battery post.
4. Remove the battery hold down nut (3) and strap from the battery.
5. Remove the battery (5) from the battery tray.

BATTERY - LHD

1. Clean and inspect the battery. Refer to «CLEANING»(/chrysler/crossfire/i-final-2008-2008/remont/charging-system/#battery-system) and «INSPECTION»(/chrysler/crossfire/i-final-2008-2008/remont/charging-system/#battery-system) . CAUTION: The battery cable terminal clamps must reach the correct battery terminal post without stretching the cables.
2. Position the battery (5) onto the battery tray. Ensure that the battery positive and negative terminal posts are correctly positioned.
3. Install the battery hold down onto the battery with the hold down nut (3). Tighten the battery hold down nut to 8 N.m (71 in. lbs.). CAUTION: Be certain that the battery cable terminal clamps are connected to the correct battery terminal posts. Reverse battery polarity may damage electrical components of the vehicle.
4. Clean the battery cable terminal clamps and the battery terminal posts.
5. Connect the positive battery cable (2). Tighten the terminal clamp pinch-bolt hex nut to 7 N.m (60 in. lbs.).
6. Install the positive battery terminal plastic cap (1).
7. Connect the negative battery cable (4). Tighten the terminal clamp pinch-bolt hex nut to 7 N.m (60 in. lbs.).

BATTERY - RHD

1. Clean and inspect the battery. Refer to «CLEANING»(/chrysler/crossfire/i-final-2008-2008/remont/charging-system/#battery-system) and «INSPECTION»(/chrysler/crossfire/i-final-2008-2008/remont/charging-system/#battery-system) . CAUTION: The battery cable terminal clamps must reach the correct battery terminal post without stretching the cables.
2. Position the battery (4) onto the battery tray. Ensure that the battery positive and negative terminal posts are correctly positioned.
3. Install the battery hold down onto the battery with the hold down nut (5). Tighten the battery hold down nut to 8 N.m (71 in. lbs.). CAUTION: Be certain that the battery cable terminal clamps are connected to the correct battery terminal posts. Reverse battery polarity may damage electrical components of the vehicle.
4. Clean the battery cable terminal clamps and the battery terminal posts.
5. Connect the positive battery cable (1). Tighten the terminal clamp pinch-bolt hex nut to 7 N.m (60 in. lbs.).
6. Install the positive battery terminal plastic cap (2).
7. Connect the negative battery cable (3). Tighten the terminal clamp pinch-bolt hex nut to 7 N.m (60 in. lbs.).

DESCRIPTION - CABLES

The battery cables are large gauge, stranded copper wires sheathed within a heavy plastic or synthetic rubber insulating jacket. The wire used in the battery cables combines excellent flexibility and reliability with high electrical current carrying capacity. Refer to SYSTEM WIRING DIAGRAMS article for battery cable wire gauge information.

A clamping type female battery terminal made of soft lead is die cast onto one end of the battery cable wire. A square headed pinch-bolt and hex nut are installed at the open end of the female battery terminal clamp. Large eyelet type terminals are crimped onto the opposite end of the battery cable wire and then solder-dipped. The battery positive cable has a larger female battery terminal clamp to allow connection to the larger battery positive terminal post. The battery negative cable has a smaller female battery terminal clamp.

The battery cables cannot be repaired and, if damaged or faulty they must be replaced. Both the battery positive and negative cables are available for service replacement only as a unit with the battery wire harness, which may include portions of the wiring circuits for the generator and other components. Refer to SYSTEM WIRING DIAGRAMS article for more information on the various wiring circuits included in the battery wire harness for the vehicle being serviced.

OPERATION - CABLES

The battery cables connect the battery terminal posts to the vehicle electrical system. These cables also provide a path back to the battery for electrical current generated by the charging system for restoring the voltage potential of the battery. The female battery terminal clamps on the ends of the battery cable wires provide a strong and reliable connection of the battery cable to the battery terminal posts. The terminal pinch bolts allow the female terminal clamps to be tightened around the male terminal posts on the top of the battery. The eyelet terminals secured to the opposite ends of the battery cable wires from the female battery terminal clamps provide secure and reliable connection of the battery cables to the vehicle electrical system.

The battery positive cable terminal clamp is die cast onto the ends of two wires. One wire has an eyelet terminal that connects the battery positive cable to the B(+) terminal stud of the Engine Fuse Block, and the other wire has an eyelet terminal that connects the battery positive cable to the B(+) terminal stud of the engine starter motor solenoid. The battery negative cable terminal clamp is die cast onto the end of one wire. The wire has an eyelet terminal that connects the battery negative cable to the vehicle body through a ground bolt on the right front fender inner shield, near the battery.

CABLES TESTING

A voltage drop test will determine if there is excessive resistance in the battery cable terminal connections or the battery cable. If excessive resistance is found in the battery cable connections, the connection point should be disassembled, cleaned of all corrosion or foreign material, then reassembled. Following reassembly, check the voltage drop for the battery cable connection and the battery cable again to confirm repair.

When performing the voltage drop test, it is important to remember that the voltage drop is giving an indication of the resistance between the two points at which the voltmeter probes are attached. EXAMPLE: When testing the resistance of the battery positive cable, touch the voltmeter leads to the battery positive cable terminal clamp and to the battery positive cable eyelet terminal at the starter solenoid B(+) terminal stud. If you probe the battery positive terminal post and the battery positive cable eyelet terminal at the starter solenoid B(+) terminal stud, you are reading the combined voltage drop in the battery positive cable terminal clamp-to-terminal post connection and the battery positive cable.

VOLTAGE DROP TEST

The following operation will require a voltmeter accurate to 1/10 (0.10) volt. Before performing this test, be certain that the following procedures are accomplished

1. The battery is fully-charged and load tested. Refer to «STANDARD PROCEDURE»(/chrysler/crossfire/i-final-2008-2008/remont/charging-system/#battery-system) for the proper battery charging and load test procedures
2. Fully engage the parking brake.
3. If the vehicle is equipped with an automatic transmission, place the gearshift selector lever in the Park position. If the vehicle is equipped with a manual transmission, place the gearshift selector lever in the Neutral position and block the clutch pedal in the fully depressed position.
4. Verify that all lamps and accessories are turned off.
5. To prevent the engine from starting, remove the ignition coil fuse. The ignition coil fuse is located in the Underhood Accessory Fuse Block, in the engine compartment. See the fuse layout label affixed to the underside of the fuse block cover for ignition coil fuse identification and location.

Scheme 16

Scheme 17

Scheme 18

Scheme 19

1. Connect the positive lead of the voltmeter (1) to the battery (2) negative terminal post. Connect the negative lead of the voltmeter (1) to the battery (2) negative cable terminal clamp. Rotate and hold the ignition switch in the Start position. Observe the voltmeter. If voltage is detected, correct the poor connection between the battery negative cable terminal clamp and the battery negative terminal post.
2. Connect the positive lead of the voltmeter (1) to the battery (2) positive terminal post. Connect the negative lead of the voltmeter (1) to the battery (2) positive cable terminal clamp. Rotate and hold the ignition switch in the Start position. Observe the voltmeter. If voltage is detected, correct the poor connection between the battery positive cable terminal clamp and the battery positive terminal post.
3. Connect the voltmeter (2) to measure between the battery (1) positive cable terminal clamp and the starter solenoid (3) B(+) terminal stud. Rotate and hold the ignition switch in the Start position. Observe the voltmeter (2). If the reading is above 0.2 volt, clean and tighten the battery (1) positive cable eyelet terminal connection at the starter solenoid B(+) terminal stud. Repeat the test. If the reading is still above 0.2 volt, replace the faulty battery positive cable.
4. Connect the voltmeter (1) to measure between the battery (2) negative cable terminal clamp and a good clean ground on the engine block (3). Rotate and hold the ignition switch in the Start position. Observe the voltmeter (1). If the reading is above 0.2 volt, clean and tighten the battery (2) negative cable eyelet terminal connection to the engine block. Repeat the test. If the reading is still above 0.2 volt, replace the faulty battery negative cable.

Scheme 20

The battery is mounted in a battery tray (1) located in the left rear corner of the engine compartment. The battery tray and support unit is secured at the front with a bolt (2) on the front wheelhouse inner panel, and at the rear with a bolt (2) on a bracket from the bulkhead.

Scheme 21

The battery is mounted in a battery tray (1) located in the right rear corner of the engine compartment. The battery tray and support unit is secured at the front with a bolt (2) on the front wheelhouse inner panel, and at the rear with a bolt (2) on a bracket from the bulkhead.

OPERATION - TRAY

The battery tray provides a secure mounting location and supports the battery. The battery tray also provides the anchor points for the battery hold-down hardware. The battery tray and the battery hold-down hardware combine to secure and stabilize the battery in the engine compartment, which prevents battery movement during vehicle operation. Unrestrained battery movement during vehicle operation could result in damage to the vehicle, the battery, or both.

Scheme 22

1. Remove the battery. See «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/charging-system/#battery-system) .
2. Remove the battery tray (1) retaining bolts (2).
3. Remove the battery tray (1).

TRAY - RHD

1. Remove the battery. See «REMOVAL»(/chrysler/crossfire/i-final-2008-2008/remont/charging-system/#battery-system) .
2. Remove the battery tray (1) retaining bolts (2).
3. Remove the battery tray (1).

TRAY - LHD

1. Install the battery tray (1).
2. Install the battery tray (1) retaining bolts (2). Tighten the bolts to 15 N.m (11 ft. lbs.).
3. Install the battery. See «INSTALLATION»(/chrysler/crossfire/i-final-2008-2008/remont/charging-system/#battery-system) .

1. Install the battery tray (1).
2. Install the battery tray (1) retaining bolts (2). Tighten the bolts to 15 N.m (11 ft. lbs.).
3. Install the battery. See «INSTALLATION»(/chrysler/crossfire/i-final-2008-2008/remont/charging-system/#battery-system) .
