Power Windows - Service Information: Removal & Installation Chrysler Crossfire I

Windows 3 illustrations ~250 words

REMOVAL

WARNINGREFER TO RESTRAINTS - SERVICE INFORMATION BEFORE ATTEMPTING ANY DOOR, SEAT, STEERING WHEEL, STEERING COLUMN, OR INSTRUMENT PANEL COMPONENT DIAGNOSIS OR SERVICE. FAILURE TO TAKE THE PROPER PRECAUTIONS COULD RESULT IN ACCIDENTAL AIRBAG DEPLOYMENT AND POSSIBLE PERSONAL INJURY. (Refer to ELECTRICAL/RESTRAINTS - WARNING) .

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20
  1. Disconnect the negative battery cable.
  2. Remove the door interior trim panel. «(Refer to BODY/DOOR - FRONT/TRIM PANEL - REMOVAL)»(ref-250612-S00376062812007031500000) .
  3. Carefully peel back the door watershield (1) enough to expose the power window motor attachment rivets and harness connector. NOTE: Use caution to properly support the power window motor before drilling rivets.
  4. Disconnect the power window motor harness connector (1).
  5. Drill out the three power window motor attaching rivets (2).
  6. Remove the power window motor from the door.

INSTALLATION

Note. Insure the original mounting hole pattern is used when installing the power window motor.

Note. Before installing, lightly grease the gear on the power window motor.

  1. Position the power window motor into the door.
  2. Install the three power window motor attaching rivets (2).
  3. Connect the power window motor harness connector (1).
  4. Install the door watershield (1).
  5. Install the door interior trim panel. «(Refer to BODY/DOOR - FRONT/TRIM PANEL - INSTALLATION)»(ref-250612-S10572715752007031500000) .
  6. Connect the negative battery cable.
WARNINGREFER TO RESTRAINTS - SERVICE INFORMATION BEFORE ATTEMPTING ANY DOOR, SEAT, STEERING WHEEL, STEERING COLUMN, OR INSTRUMENT PANEL COMPONENT DIAGNOSIS OR SERVICE. FAILURE TO TAKE THE PROPER PRECAUTIONS COULD RESULT IN ACCIDENTAL AIRBAG DEPLOYMENT AND POSSIBLE PERSONAL INJURY. (Refer to ELECTRICAL/RESTRAINTS - WARNING) .

Scheme 21

Scheme 21
Scheme 21
  1. Disconnect the negative battery cable.
  2. Remove the shifter cover trim panel. «(Refer to BODY/INTERIOR/CENTER CONSOLE - REMOVAL)»(ref-250612-S17954963242007031500000) .
  3. Disconnect the power window switch harness connector (1).
  4. Squeeze the clips together and remove the power window switch from the shifter cover trim panel.
  1. Install the power window switch to the shifter cover trim panel.
  2. Connect the power window switch harness connector (1).
  3. Install the shifter cover trim panel. «(Refer to BODY/INTERIOR/CENTER CONSOLE - INSTALLATION)»(ref-250612-S32158713072007031500000) .
  4. Connect the negative battery cable.
