Scheme 11
A dual-note electro-magnetic Horn System is standard equipment on this model. The horn circuit consists of a Horn Switch, Fuse, Horn Relay, and Horns. Both high and low note horn units are located behind the front grille.
Scheme 12
| 1 - CONTROL MODULE BOX COVER |
|---|
| 2 - POWERTRAIN CONTROL MODULE |
| 3 - RELAY CONTROL MODULE |
| 4 - CONTROL MODULE BOX COOLING FAN |
| 5 - CONTROL MODULE BOX |
| 6 - BODY CONTROL MODULE |
The Horn circuit feed is from the fuse to the horn relay within the Relay Control Module (3), both of which are located inside the Control Module Box (5). When the Horn Switch is depressed, it completes the ground circuit to the horn relay. The horn relay coil closes a set of contacts which allows current to flow to the Horns.
