SPECIFICATIONS - CHARGE CAPACITY
The R-134a refrigerant system charge capacity for this vehicle is 0.88 kilograms (1.97 lbs.).
SPECIFICATIONS - TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Expansion Valve Nut | 10 | 7 | 88 |
| Expansion Valve Bolt | 8 | 6 | 71 |
| Reservoir Fluid Lines | 17 | 12 | 150 |
| Compressor to Condenser Fluid Line | 22 | 16 | 195 |
| Condenser to Reservoir Fluid Line | 17 | 12 | 150 |
| Refrigerant Pressure Sensor | 12 | 9 | 106 |
| Refrigerant Temperature Sensor | 6 | 5 | 53 |
| High Pressure Line to Condenser | 33 | 24 | 292 |
TORQUE SPECIFICATIONS
Scheme 1
| 1 - PULLEY |
|---|
| 2 - MELTING FUSE |
| 3 - BEARING |
| 4 - INPUT SHAFT |
| 5 - SOLENOID |
| 6 - PRESSURE PLATE |
| 7 - RUBBER INSERT |
| 8 - SPLINES |
The pulley (1) on the A/C compressor drive shaft (4) is driven by the poly-V-belt. The clutch turns on the ball bearing (3) around the magnetic coil (5) fastened to the A/C compressor housing. The pressure plate (6) with rubber insert (7) is connected to the A/C compressor drive shaft (4) by splines (8) allowing it to move in the axial direction.
