Emissions Control System: Specifications Chrysler Crossfire I

Emission Applications 8 illustrations ~213 words

SPECIFICATIONS - TORQUE

DESCRIPTIONN.mFt. Lbs.In. Lbs.
EGR VALVE TO CYLINDER HEAD3123275
EGR TUBE TO EGR VALVE1195
EGR TUBE TO INTAKE MANIFOLD1195
EGR SOLENOID TO EGR VALVE1195

TORQUE SPECIFICATIONS

Scheme 3

Scheme 3: REMOVAL

Scheme 4

Scheme 4
  1. Disconnect the negative battery cable.
  2. Remove the air cleaner housing.
  3. Disconnect the solenoid harness connector (1).
  4. Disconnect the solenoid vacuum lines (2).
  5. Remove the solenoid to valve mounting bolt (2).
  6. Remove the valve to cylinder head mounting bolt (1).
  7. Clean the gasket surfaces. Discard the old gasket.
  8. Clean the EGR passages as necessary.

SPECIFICATIONS

DESCRIPTIONN.mFt. Lbs.In. Lbs.
AIR PUMP RETAINING BRACKET20177

TORQUE SPECIFICATIONS

Scheme 5

Scheme 5: REMOVAL - 3.2L

Scheme 6

Scheme 6
  1. Disconnect the negative battery cable.
  2. Remove the air cleaner housing.
  3. Disconnect the air pump switchover tube (1).
  4. Disconnect the air pump harness connector (2).
  5. Remove the air pump retaining bolt (2).
  6. Remove the air pump (1) from the air pump retaining bracket (3).

Scheme 7

Scheme 7: REMOVAL - 3.2L SRT

Scheme 8

Scheme 8
  1. Disconnect the negative battery cable.
  2. Disconnect the air pump tube assembly (1) from the air pump.
  3. Disconnect the air pump harness connector (2).
  4. Remove the air pump retaining nuts (1).
  5. Remove air pump from air pump mounting bracket.

Scheme 9

Scheme 9: INSTALLATION - 3.2L

Scheme 10

Scheme 10
  1. Position the air pump (1) into the air pump retaining bracket (3).
  2. Install the air pump retaining bolt (2). Tighten bolt to 20 N.m (177 in. lbs.).
  3. Connect the air pump harness connector (2).
  4. Connect the air pump switchover tube (1).
  5. Install the air cleaner housing.
  6. Connect the negative battery cable.
