Vehicle Theft Security System - Electrical Diagnostics: Other Chrysler Crossfire I

Door Locks & Anti-Theft Systems 47 illustrations ~3424 words

When Monitored and Set Condition

  1. When Monitored: Ignition on. The Central Locking Pump/Security System Module (CLP/SSM) monitors the Fused B(+) circuit voltage for proper system voltage.
  2. Set Condition: If the voltage is below 11 volts, the Diagnostic Trouble Code (DTC) is set.
POSSIBLE CAUSES
BATTERY VOLTAGE LOW
FUSED B(+) CIRCUIT HIGH RESISTANCE
CENTRAL LOCKING PUMP/SECURITY SYSTEM MODULE

For a complete Vehicle Theft Security System Circuit Diagram, (Refer to ELECTRICAL/VEHICLE THEFT SECURITY - SCHEMATICS AND DIAGRAMS) .

Scheme 73

Scheme 73: Diagnostic Test
Scheme 73: Diagnostic Test

Scheme 74

Scheme 74
Scheme 74

Scheme 75

Scheme 75
Scheme 75

Scheme 76

Scheme 76
Scheme 76
  1. 1) WITH THE DRB III(R), READ DTCs Turn the ignition on. With the DRB III(R), erase DTCs. Turn the ignition off. Turn the ignition on. Start the engine. With the DRB III(R), read DTCs. Does the DRB III(R) display a System Undervoltage DTC? Yes Go to step 2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.
  2. 2) MEASURE THE BATTERY VOLTAGE Measure the battery voltage with the engine running. Is the battery voltage below 10 volts? Yes Refer to «VEHICLE THEFT SECURITY - SERVICE INFORMATION»(ref-250637) for charging system testing and repair. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) . No Go to step 3) .
  3. 3) MEASURE THE VOLTAGE OF THE FUSED B(+) CIRCUIT Turn the ignition off. Disconnect the CLP/SSM harness connector. NOTE: Check connectors - Clean/repair as necessary. Turn the ignition on. Measure the voltage of the Fused B(+) circuit (cavity 2) at the CLP/SSM C2 harness connector. Is the voltage above 11 volts? Yes Go to step 4) . No Repair the Fused B(+) circuit for high resistance. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .
  4. 4) MEASURE THE VOLTAGE OF THE FUSED B(+) CIRCUIT Measure the voltage of the Fused B(+) circuit (cavity 4) at the CLP/SSM C2 harness connector. Is the voltage above 11 volts? Yes Replace the Central Locking Pump/Security System Module. «(Refer to ELECTRICAL/VEHICLE THEFT SECURITY/SENTRY KEY REMOTE ENTRY MODULE - REMOVAL)»(ref-250637-S01608359972007031500000) . Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) . No Repair the Fused B(+) circuit for high resistance. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .

Scheme 77

Scheme 77: CENTRAL LOCKING PUMP/SECURITY SYSTEM MODULE SYSTEM OVERVOLTAGE
Scheme 77: CENTRAL LOCKING PUMP/SECURITY SYSTEM MODULE SYSTEM OVERVOLTAGE
  1. When Monitored: Ignition on. The Central Locking Pump/Security System Module (CLP/SSM) monitors the Fused B(+) circuit at all times for proper system voltage.
  2. Set Condition: If the voltage is above 16 volts, the Diagnostic Trouble Code (DTC) is set.
POSSIBLE CAUSES
SYSTEM VOLTAGE HIGH
GROUND CIRCUIT OPEN
CENTRAL LOCKING PUMP/SECURITY SYSTEM MODULE

For a complete Vehicle Theft Security System Circuit Diagram, (Refer to ELECTRICAL/VEHICLE THEFT SECURITY - SCHEMATICS AND DIAGRAMS) .

Scheme 78

Scheme 78
Scheme 78

Scheme 79

Scheme 79
Scheme 79
  1. 1) WITH THE DRB III(R), READ DTCs Turn the ignition on. With the DRB III(R), erase DTCs. Turn the ignition off. Turn the ignition on. Start the engine. With the DRB III(R), read DTCs. Does the DRB III(R) display a System Overvoltage DTC? Yes Go to step 2) . No The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.
  2. 2) MEASURE THE BATTERY VOLTAGE Turn the ignition off. Disconnect the CLP/SSM harness connector. NOTE: Check connectors - Clean/repair as necessary. Start the engine. Raise the engine speed above 1800 RPM. Measure the battery voltage. Is the voltage above 16 volts? Yes Refer to «VEHICLE THEFT SECURITY - SERVICE INFORMATION»(ref-250637) for charging system testing and repair. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) . No Go to step 3) .
  3. 3) MEASURE THE RESISTANCE OF THE GROUND CIRCUIT Turn the ignition off. Measure the resistance between ground and the Ground circuit. Is the resistance below 1.0 ohm? Yes Replace the Central Locking Pump/Security System Module. «(Refer to ELECTRICAL/VEHICLE THEFT SECURITY/SENTRY KEY REMOTE ENTRY MODULE - REMOVAL)»(ref-250637-S01608359972007031500000) . Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) . No Repair the Ground circuit for an open. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .

Scheme 80

Scheme 80: NO COMMUNICATION WITH BCM AND CENTRAL LOCKING PUMP/SECURITY SYSTEM MODULE
Scheme 80: NO COMMUNICATION WITH BCM AND CENTRAL LOCKING PUMP/SECURITY SYSTEM MODULE
  1. When Monitored: Continuous.
  2. Set Condition: CAN Bus communication failure between the Body Control Module (BCM) and the Central Locking Pump/Security System Module (CLP/SSM).
POSSIBLE CAUSES
CAN B BUS (+) CIRCUIT OPEN
CAN B BUS (-) CIRCUIT OPEN
CENTRAL LOCKING PUMP/SECURITY SYSTEM MODULE INTERNAL FAILURE

For a complete Vehicle Theft Security System Circuit Diagram, (Refer to ELECTRICAL/VEHICLE THEFT SECURITY - SCHEMATICS AND DIAGRAMS) .

Scheme 81

Scheme 81: Diagnostic Test
Scheme 81: Diagnostic Test

Scheme 82

Scheme 82
Scheme 82
  1. 1) MEASURE THE RESISTANCE OF THE CAN B BUS (+) CIRCUIT Turn the ignition off. Disconnect the CLP/SSM harness connector. Disconnect the BCM harness connector. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance of the CAN B Bus (+) circuit from the CLP/SSM harness connector to the BCM harness connector. Is the resistance below 1.0 ohm? Yes Go to step 2) . No Repair the CAN B Bus (+) circuit for an open. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .
  2. 2) MEASURE THE RESISTANCE OF THE CAN B BUS (-) CIRCUIT Measure the resistance of the CAN B Bus (-) circuit from the CLP/SSM harness connector to the BCM harness connector. Is the resistance below 1.0 ohm? Yes Replace the Central Locking Pump/Security System Module. «(Refer to ELECTRICAL/VEHICLE THEFT SECURITY/SENTRY KEY REMOTE ENTRY MODULE - REMOVAL)»(ref-250637-S01608359972007031500000) . Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) . No Repair the CAN B Bus (-) circuit for an open. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .

Scheme 83

Scheme 83: CAN B BUS (-) CIRCUIT FAILURE
Scheme 83: CAN B BUS (-) CIRCUIT FAILURE
  1. When Monitored: Continuous.
  2. Set Condition: CAN B Bus (-) communication failure between the Body Control Module (BCM) and the Central Locking Pump/Security System Module (CLP/SSM).
POSSIBLE CAUSES
CAN B BUS (-) CIRCUIT SHORTED TO VOLTAGE
CAN B BUS (-) CIRCUIT SHORTED TO GROUND
CAN B BUS (-) CIRCUIT OPEN
CENTRAL LOCKING PUMP/SECURITY SYSTEM MODULE

For a complete Vehicle Theft Security System Circuit Diagram, (Refer to ELECTRICAL/VEHICLE THEFT SECURITY - SCHEMATICS AND DIAGRAMS) .

Scheme 84

Scheme 84: Diagnostic Test
Scheme 84: Diagnostic Test

Scheme 85

Scheme 85
Scheme 85

Scheme 86

Scheme 86
Scheme 86
  1. 1) MEASURE THE RESISTANCE OF THE CAN B BUS (-) CIRCUIT Turn the ignition off. Disconnect the BCM harness connector. Disconnect the CLP/SSM harness connector. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance of the CAN B Bus (-) circuit from the BCM harness connector to the CLP/SSM harness connector. Is the resistance below 1.0 ohm? Yes Go to step 2) . No Repair the CAN B Bus (-) circuit for an open. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .
  2. 2) MEASURE THE VOLTAGE OF THE CAN B BUS (-) CIRCUIT Turn the ignition on. Measure the voltage of the CAN B Bus (-) circuit at the CLP/SSM harness connector. Is voltage present? Yes Repair the CAN B Bus (-) circuit for a short to voltage. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) . No Go to step 3) .
  3. 3) MEASURE THE RESISTANCE OF THE CAN B BUS (-) CIRCUIT Turn the ignition off. Measure the resistance between ground and the CAN B Bus (-) circuit at the CLP/SSM harness connector. Is the resistance below 10K ohms? Yes Repair the CAN B Bus (-) circuit for a short to ground. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) . No Replace the Central Locking Pump/Security System Module. «(Refer to ELECTRICAL/VEHICLE THEFT SECURITY/SENTRY KEY REMOTE ENTRY MODULE - REMOVAL)»(ref-250637-S01608359972007031500000) . Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .

Scheme 87

Scheme 87: CAN B BUS (+) CIRCUIT FAILURE
Scheme 87: CAN B BUS (+) CIRCUIT FAILURE
  1. When Monitored: Continuous.
  2. Set Condition: CAN B Bus (+) communication failure between the Body Control Module (BCM) and the Central Locking Pump/Security System Module (CLP/SSM).
POSSIBLE CAUSES
CAN B BUS (+) CIRCUIT SHORTED TO VOLTAGE
CAN B BUS (+) CIRCUIT SHORTED TO GROUND
CAN B BUS (+) CIRCUIT OPEN
CENTRAL LOCKING PUMP/SECURITY SYSTEM MODULE

For a complete Vehicle Theft Security System Circuit Diagram, (Refer to ELECTRICAL/VEHICLE THEFT SECURITY - SCHEMATICS AND DIAGRAMS) .

Scheme 88

Scheme 88: Diagnostic Test
Scheme 88: Diagnostic Test

Scheme 89

Scheme 89
Scheme 89

Scheme 90

Scheme 90
Scheme 90
  1. 1) MEASURE THE RESISTANCE OF THE CAN B BUS (+) CIRCUIT Turn the ignition off. Disconnect the BCM harness connector. Disconnect the CLP/SSM harness connector. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance of the CAN B Bus (+) circuit from the BCM harness connector to the CLP/SSM harness connector. Is the resistance below 1.0 ohm? Yes Go to step 2) . No Repair the CAN B Bus (+) circuit for an open. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .
  2. 2) MEASURE THE VOLTAGE OF THE CAN B BUS (+) CIRCUIT Turn the ignition on. Measure the voltage of the CAN B Bus (+) circuit at the CLP/SSM harness connector. Is voltage present? Yes Repair the CAN B Bus (+) circuit for a short to voltage. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) . No Go to step 3) .
  3. 3) MEASURE THE RESISTANCE OF THE CAN B BUS (+) CIRCUIT Turn the ignition off. Measure the resistance between ground and the CAN B Bus (+) circuit at the CLP/SSM harness connector. Is the resistance below 10K ohms? Yes Repair the CAN B Bus (+) circuit for a short to ground. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) . No Replace the Central Locking Pump/Security System Module. «(Refer to ELECTRICAL/VEHICLE THEFT SECURITY/SENTRY KEY REMOTE ENTRY MODULE - REMOVAL)»(ref-250637-S01608359972007031500000) . Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .

Scheme 91

Scheme 91: DOOR LOCK SWITCH SENSE CIRCUIT
Scheme 91: DOOR LOCK SWITCH SENSE CIRCUIT
  1. When Monitored: Continuous.
  2. Set Condition: The Sentry Key Remote Entry Module (SKREEM) reports a short to power, ground, or an open circuit failure on the Door Lock Switch Sense circuit.
POSSIBLE CAUSES
DOOR LOCK SWITCH SENSE CIRCUIT SHORTED TO VOLTAGE
DOOR LOCK SWITCH SENSE CIRCUIT SHORTED TO GROUND
DOOR LOCK SWITCH SENSE CIRCUIT OPEN
SENTRY KEY REMOTE ENTRY MODULE

For a complete Vehicle Theft Security System Circuit Diagram, (Refer to ELECTRICAL/VEHICLE THEFT SECURITY - SCHEMATICS AND DIAGRAMS) .

Scheme 92

Scheme 92: Diagnostic Test
Scheme 92: Diagnostic Test

Scheme 93

Scheme 93
Scheme 93

Scheme 94

Scheme 94
Scheme 94
  1. 1) MEASURE THE RESISTANCE OF THE DOOR LOCK SWITCH SENSE CIRCUIT Turn the ignition off. Disconnect the BCM harness connector. Disconnect the SKREEM harness connector. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance of the Door Lock Switch Sense circuit from the BCM harness connector to the SKREEM harness connector. Is the resistance below 5.0 ohms? Yes Go to step 2) . No Repair the Door Lock Switch Sense circuit for an open. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .
  2. 2) MEASURE THE VOLTAGE OF THE DOOR LOCK SWITCH SENSE CIRCUIT Turn the ignition on. Measure the voltage of the Door Lock Switch Sense circuit at the SKREEM harness connector. Is voltage present? Yes Repair the Door Lock Switch Sense circuit for a short to voltage. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) . No Go to step 3) .
  3. 3) MEASURE THE RESISTANCE OF THE DOOR LOCK SWITCH SENSE CIRCUIT Turn the ignition off. Measure the resistance between ground and the Door Lock Switch Sense circuit at the SKREEM harness connector. Is the resistance below 10K ohms? Yes Repair the Door Lock Switch Sense circuit for a short to ground. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) . No Replace the Sentry Key Remote Entry Module. «(Refer to ELECTRICAL/VEHICLE THEFT SECURITY/SENTRY KEY REMOTE ENTRY MODULE - REMOVAL)»(ref-250637-S01608359972007031500000) . Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .

Scheme 95

Scheme 95: DOOR UNLOCK SWITCH SENSE CIRCUIT
Scheme 95: DOOR UNLOCK SWITCH SENSE CIRCUIT
  1. When Monitored: Continuous.
  2. Set Condition: The Sentry Key Remote Entry Module (SKREEM) reports a short to power, ground, or an open circuit failure on the Door Unlock Switch Sense circuit.
POSSIBLE CAUSES
DOOR UNLOCK SWITCH SENSE CIRCUIT SHORTED TO VOLTAGE
DOOR UNLOCK SWITCH SENSE CIRCUIT SHORTED TO GROUND
DOOR UNLOCK SWITCH SENSE CIRCUIT OPEN
SENTRY KEY REMOTE ENTRY MODULE

For a complete Vehicle Theft Security System Circuit Diagram, (Refer to ELECTRICAL/VEHICLE THEFT SECURITY - SCHEMATICS AND DIAGRAMS) .

Scheme 96

Scheme 96: Diagnostic Test
Scheme 96: Diagnostic Test

Scheme 97

Scheme 97
Scheme 97

Scheme 98

Scheme 98
Scheme 98
  1. 1) MEASURE THE RESISTANCE OF THE DOOR UNLOCK SWITCH SENSE CIRCUIT Turn the ignition off. Disconnect the BCM harness connector. Disconnect the SKREEM harness connector. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance of the Door Unlock Switch Sense circuit from the BCM harness connector to the SKREEM harness connector. Is the resistance below 5.0 ohms? Yes Go to step 2) . No Repair the Door Unlock Switch Sense circuit for an open. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .
  2. 2) MEASURE THE VOLTAGE OF THE DOOR UNLOCK SWITCH SENSE CIRCUIT Turn the ignition on. Measure the voltage of the Door Unlock Switch Sense circuit at the SKREEM harness connector. Is voltage present? Yes Repair the Door Unlock Switch Sense circuit for a short to voltage. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) . No Go to step 3) .
  3. 3) MEASURE THE RESISTANCE OF THE DOOR UNLOCK SWITCH SENSE CIRCUIT Turn the ignition off. Measure the resistance between ground and the Door Unlock Switch Sense circuit at the SKREEM harness connector. Is the resistance below 10K ohms? Yes Repair the Door Unlock Switch Sense circuit for a short to ground. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) . No Replace the Sentry Key Remote Entry Module. «(Refer to ELECTRICAL/VEHICLE THEFT SECURITY/SENTRY KEY REMOTE ENTRY MODULE - REMOVAL)»(ref-250637-S01608359972007031500000) . Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .

Scheme 99

Scheme 99: ANTI-THEFT TOW SENSOR SIGNAL CIRCUIT
Scheme 99: ANTI-THEFT TOW SENSOR SIGNAL CIRCUIT
  1. When Monitored: Continuous.
  2. Set Condition: The Central Locking Pump/Security System Module (CLP/SSM) reports a short to power, ground, or an open circuit failure on the Anti-Theft Tow Sensor Signal circuit.
POSSIBLE CAUSES
ANTI-THEFT TOW SENSOR SIGNAL CIRCUIT SHORTED TO VOLTAGE
ANTI-THEFT TOW SENSOR SIGNAL CIRCUIT SHORTED TO GROUND
ANTI-THEFT TOW SENSOR SIGNAL CIRCUIT OPEN
ANTI-THEFT TOW SENSOR

For a complete Vehicle Theft Security System circuit diagram, (Refer to ELECTRICAL/VEHICLE THEFT SECURITY - SCHEMATICS AND DIAGRAMS) .

Scheme 100

Scheme 100: Diagnostic Test
Scheme 100: Diagnostic Test

Scheme 101

Scheme 101
Scheme 101

Scheme 102

Scheme 102
Scheme 102
  1. 1) MEASURE THE RESISTANCE OF THE ANTI-THEFT TOW SENSOR SIGNAL CIRCUIT Turn the ignition off. Disconnect the CLP/SSM harness connector. Disconnect the Anti-Theft Tow Sensor harness connector. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance of the Anti-Theft Tow Sensor Signal circuit from the CLP/SSM harness connector to the Anti-Theft Tow Sensor harness connector. Is the resistance below 5.0 ohms? Yes Go to step 2) . No Repair the Anti-Theft Tow Sensor Signal circuit for an open. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .
  2. 2) MEASURE THE VOLTAGE OF THE ANTI-THEFT TOW SENSOR SIGNAL CIRCUIT Turn the ignition on. Measure the voltage of the Anti-Theft Tow Sensor Signal circuit at the Anti-Theft Tow Sensor harness connector. Is voltage present? Yes Repair the Anti-Theft Tow Sensor Signal circuit for a short to voltage. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) . No Go to step 3) .
  3. 3) MEASURE THE RESISTANCE OF THE ANTI-THEFT TOW SENSOR SIGNAL CIRCUIT Turn the ignition off. Measure the resistance between ground and the Anti-Theft Tow Sensor Signal circuit at the Anti-Theft Tow Sensor harness connector. Is the resistance below 10K ohms? Yes Repair the Anti-Theft Tow Sensor Signal circuit for a short to ground. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) . No Replace the Anti-Theft Tow Sensor. «(Refer to ELECTRICAL/VEHICLE THEFT SECURITY/ANTI-THEFT TOW SENSOR - REMOVAL)»(ref-250637-S12022800932007031500000) . Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .

Scheme 103

Scheme 103: NO CAN COMMUNICATIONS WITH PCM
Scheme 103: NO CAN COMMUNICATIONS WITH PCM
  1. When Monitored: With the ignition on.
  2. Set Condition: CAN Bus communication failure between the Sentry Key Remote Entry Module (SKREEM) and the Powertrain Control Module (PCM).
POSSIBLE CAUSES
CAN BUS CIRCUIT(S) OPEN
SENTRY KEY REMOTE ENTRY MODULE

For a complete Vehicle Theft Security System Circuit Diagram, (Refer to ELECTRICAL/VEHICLE THEFT SECURITY - SCHEMATICS AND DIAGRAMS) .

Scheme 104

Scheme 104: Diagnostic Test
Scheme 104: Diagnostic Test

Scheme 105

Scheme 105
Scheme 105
  1. 1) MEASURE THE RESISTANCE OF THE CAN C BUS (+) CIRCUIT Turn the ignition off. Disconnect the SKREEM harness connector. Disconnect the PCM harness connector. Measure the resistance of the CAN C Bus (+) circuit from the SKREEM harness connector to the PCM harness connector. Is the resistance below 1.0 ohm? Yes Go to step 2) . No Repair the CAN C Bus (+) circuit for an open. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .
  2. 2) MEASURE THE RESISTANCE OF THE CAN C BUS (-) CIRCUIT Measure the resistance of the CAN C Bus (-) circuit from the SKREEM harness connector and the PCM harness connector. Is the resistance below 1.0 ohm? Yes Replace the Sentry Key Remote Entry Module. «(Refer to ELECTRICAL/VEHICLE THEFT SECURITY/SENTRY KEY REMOTE ENTRY MODULE - REMOVAL)»(ref-250637-S01608359972007031500000) . Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) . No Repair the CAN C Bus (-) circuit for an open. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .

Scheme 106

Scheme 106: SIREN SIGNAL OUTPUT CIRCUIT
Scheme 106: SIREN SIGNAL OUTPUT CIRCUIT
  1. When Monitored: Continuous.
  2. Set Condition: The Central Locking Pump/Security System Module (CLP/SSM) reports a short to power, ground, or an open circuit failure on the Siren Signal Output circuit.
POSSIBLE CAUSES
SIREN SIGNAL OUTPUT CIRCUIT SHORTED TO VOLTAGE
SIREN SIGNAL OUTPUT CIRCUIT SHORTED TO GROUND
SIREN SIGNAL OUTPUT CIRCUIT OPEN
SIREN INTERNAL FAILURE

For a complete Vehicle Theft Security System Circuit Diagram, (Refer to ELECTRICAL/VEHICLE THEFT SECURITY - SCHEMATICS AND DIAGRAMS) .

Scheme 107

Scheme 107: Diagnostic Test
Scheme 107: Diagnostic Test

Scheme 108

Scheme 108
Scheme 108

Scheme 109

Scheme 109
Scheme 109
  1. 1) MEASURE THE RESISTANCE OF THE SIREN SIGNAL OUTPUT CIRCUIT Turn the ignition off. Disconnect the CLP/SSM harness connector. Disconnect the Siren harness connector. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance of the Siren Signal Output circuit from the CLP/SSM harness connector to the Siren harness connector. Is the resistance below 5.0 ohms? Yes Go to step 2) . No Repair the Siren Signal Output circuit for an open. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .
  2. 2) MEASURE THE VOLTAGE OF THE SIREN SIGNAL OUTPUT CIRCUIT Turn the ignition on. Measure the voltage of the Siren Signal Output circuit at the Siren harness connector. Is voltage present? Yes Repair the Siren Signal Output circuit for a short to voltage. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) . No Go to step 3) .
  3. 3) MEASURE THE RESISTANCE OF THE SIREN SIGNAL OUTPUT CIRCUIT Turn the ignition off. Measure the resistance between ground and the Siren Signal Output circuit at the Siren harness connector. Is the resistance below 10K ohms? Yes Repair the Siren Signal Output circuit for a short to ground. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) . No Replace the Siren. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .

Scheme 110

Scheme 110: CENTRAL LOCKING PUMP/SECURITY SYSTEM MODULE INTERNAL FAILURE
Scheme 110: CENTRAL LOCKING PUMP/SECURITY SYSTEM MODULE INTERNAL FAILURE
  1. When Monitored: Continuous.
  2. Set Condition: If the Central Locking Pump/Security System Module (CLP/SSM) detects an internal malfunction, the DTC is set.
POSSIBLE CAUSES
NO POWER TO CENTRAL LOCKING PUMP/SECURITY SYSTEM MODULE
CENTRAL LOCKING PUMP/SECURITY SYSTEM MODULE

For a complete Vehicle Theft Security System Circuit Diagram, (Refer to ELECTRICAL/VEHICLE THEFT SECURITY - SCHEMATICS AND DIAGRAMS) .

Scheme 111

Scheme 111: Diagnostic Test
Scheme 111: Diagnostic Test

Scheme 112

Scheme 112
Scheme 112
  1. 1) MEASURE THE VOLTAGE OF THE CLP/SSM POWER CIRCUIT Turn the ignition off. Disconnect the CLP/SSM harness connector. Measure the voltage of the Fused B(+) circuit (cavity 2) at the CLP/SSM C2 harness connector. Is the voltage between 12 and 16 volts? Yes Go to step 2) . No System voltage must be between 12 and 16 volts. Repair the voltage concern as necessary. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .
  2. 2) MEASURE THE VOLTAGE OF THE CLP/SSM POWER CIRCUIT Measure the voltage of the Fused B(+) circuit (cavity 4) at the CLP/SSM C2 harness connector. Is the voltage between 12 and 16 volts? Yes Replace the Central Locking Pump/Security System Module. «(Refer to ELECTRICAL/VEHICLE THEFT SECURITY/SENTRY KEY REMOTE ENTRY MODULE - REMOVAL)»(ref-250637-S01608359972007031500000) . Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) . No System voltage must be between 12 and 16 volts. Repair the voltage concern as necessary. Perform «VTSS VERIFICATION TEST»(ref-250684-S20263552262007031500000) .

*ALARM TRIPS ON ITS OWN

POSSIBLE CAUSES
FALSE GLOVE BOX SWITCH SIGNAL
FALSE LIFTGATE LOCK SWITCH SIGNAL
FALSE HOOD AJAR SWITCH SIGNAL
FALSE LEFT DOOR AJAR SWITCH SIGNAL
FALSE RIGHT DOOR AJAR SWITCH SIGNAL
FALSE IGNITION SWITCH SIGNAL
FALSE BRAKE LAMP SWITCH SIGNAL
FALSE ANTI-THEFT TOW SENSOR SIGNAL
INTERMITTENT CONDITION

For a complete Vehicle Theft Security System Circuit Diagram, (Refer to ELECTRICAL/VEHICLE THEFT SECURITY - SCHEMATICS AND DIAGRAMS) .

  1. When Monitored: Continuous.
  2. Set Condition: If the Sentry Key Remote Entry Module (SKREEM) detects an internal malfunction, the DTC is set.
POSSIBLE CAUSES
NO POWER TO SENTRY KEY REMOTE ENTRY MODULE
SENTRY KEY REMOTE ENTRY MODULE

For a complete Sentry Key Remote Entry (SKREEM) Circuit Diagram, (Refer to ELECTRICAL/VEHICLE THEFT SECURITY - SCHEMATICS AND DIAGRAMS) .

Scheme 113

Scheme 113: Diagnostic Test
Scheme 113: Diagnostic Test
  1. 1) MEASURE THE VOLTAGE OF THE SKREEM POWER CIRCUIT Turn the ignition off. Disconnect the SKREEM harness connector. NOTE: Check connectors - Clean/repair as necessary. Measure the voltage of the Fused B(+) circuit (cavity 18) at the SKREEM C1 harness connector. Is the voltage between 12 and 16 volts? Yes Replace the Sentry Key Remote Entry Module. Perform «SENTRY KEY VERIFICATION TEST»(ref-250684-S22203965722007031500000) . No System voltage must be between 12 and 16 volts. Repair the voltage concern as necessary. Perform «SENTRY KEY VERIFICATION TEST»(ref-250684-S22203965722007031500000) .

Scheme 114

Scheme 114: INVALID TRANSMITTER
Scheme 114: INVALID TRANSMITTER
  1. When Monitored: Ignition on.
  2. Set Condition: The Sentry Key Remote Entry Module (SKREEM) detects an ignition key micro-chip malfunction.
POSSIBLE CAUSES
DEFECTIVE IGNITION KEY MICRO-CHIP

For a complete Sentry Key Remote Entry (SKREEM) Circuit Diagram, (Refer to ELECTRICAL/VEHICLE THEFT SECURITY - SCHEMATICS AND DIAGRAMS) .

  1. When Monitored: Ignition on.
  2. Set Condition: The Sentry Key Remote Entry Module (SKREEM) detects a Sentry Key Antenna circuit malfunction.
POSSIBLE CAUSES
SENTRY KEY ANTENNA RING
SENTRY KEY REMOTE ENTRY MODULE

For a complete Sentry Key Remote Entry (SKREEM) Circuit Diagram, (Refer to ELECTRICAL/VEHICLE THEFT SECURITY - SCHEMATICS AND DIAGRAMS) .

Scheme 115

Scheme 115: Diagnostic Test
Scheme 115: Diagnostic Test
  1. 1) MEASURE THE RESISTANCE OF THE SENTRY KEY ANTENNA CIRCUIT Disconnect the Sentry Key Antenna Ring connector from the SKREEM. Turn the ignition on. Measure the resistance of the Sentry Key Antenna circuit from cavity 1 to cavity 2 of the connector. Is the resistance between 4 and 6 ohms? Yes Replace the Sentry Key Remote Entry Module. Perform «SENTRY KEY VERIFICATION TEST»(ref-250684-S22203965722007031500000) . No Replace the Sentry Key Antenna Ring assembly. Perform «SENTRY KEY VERIFICATION TEST»(ref-250684-S22203965722007031500000) .

Scheme 116

Scheme 116: REMOTE KEYLESS ENTRY RELAY CONTROL CIRCUIT
Scheme 116: REMOTE KEYLESS ENTRY RELAY CONTROL CIRCUIT
  1. When Monitored: Continuous.
  2. Set Condition: The Sentry Key Remote Entry Module (SKREEM) reports a short to power, ground, or an open circuit failure on the Remote Keyless Entry Relay Control circuit.
POSSIBLE CAUSES
REMOTE KEYLESS ENTRY RELAY CONTROL CIRCUIT SHORTED TO VOLTAGE
REMOTE KEYLESS ENTRY RELAY CONTROL CIRCUIT SHORTED TO GROUND
REMOTE KEYLESS ENTRY RELAY CONTROL CIRCUIT OPEN
REMOTE KEYLESS ENTRY RELAY

For a complete Sentry Key Remote Entry (SKREEM) Circuit Diagram, (Refer to ELECTRICAL/VEHICLE THEFT SECURITY - SCHEMATICS AND DIAGRAMS) .

Scheme 117

Scheme 117: Diagnostic Test
Scheme 117: Diagnostic Test

Scheme 118

Scheme 118
Scheme 118

Scheme 119

Scheme 119
Scheme 119
  1. 1) MEASURE THE RESISTANCE OF THE REMOTE KEYLESS ENTRY RELAY CONTROL CIRCUIT Turn the ignition off. Disconnect the SKREEM harness connector. Remove the Remote Keyless Entry Relay. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance of the Remote Keyless Entry Relay Control circuit from the SKREEM harness connector to the Remote Keyless Entry Relay harness connector. Is the resistance below 5.0 ohms? Yes Go to step 2) . No Repair the Remote Keyless Entry Relay Control circuit for an open. Perform «SENTRY KEY VERIFICATION TEST»(ref-250684-S22203965722007031500000) .
  2. 2) MEASURE THE VOLTAGE OF THE REMOTE KEYLESS ENTRY RELAY CONTROL CIRCUIT Turn the ignition on. Measure the voltage of the Remote Keyless Entry Relay Control circuit at the Remote Keyless Entry Relay harness connector. Is voltage present? Yes Repair the Remote Keyless Entry Relay Control circuit for a short to voltage. Perform «SENTRY KEY VERIFICATION TEST»(ref-250684-S22203965722007031500000) . No Go to step 3) .
  3. 3) MEASURE THE RESISTANCE OF THE REMOTE KEYLESS ENTRY RELAY CONTROL CIRCUIT Turn the ignition off. Measure the resistance between ground and the Remote Keyless Entry Relay Control circuit at the Remote Keyless Entry Relay harness connector. Is the resistance below 10K ohms? Yes Repair the Remote Keyless Entry Relay Control circuit for a short to ground. Perform «SENTRY KEY VERIFICATION TEST»(ref-250684-S22203965722007031500000) . No Replace the Remote Keyless Entry Relay. Perform «SENTRY KEY VERIFICATION TEST»(ref-250684-S22203965722007031500000) .
