INSTALLATION - RHD

1. Connect the PCM harness electrical connector to the powertrain control module (2).
2. Install the powertrain control module into the control module box (5).
3. Install the plastic control module box cover (1) and slide the clips rearward to lock the cover.
4. Connect the negative battery cable.

Scheme 6

The Transmission Control Module (1) is located in the interior passenger compartment on the passenger side. It is mounted behind a base plate (3) in the passenger side footwell next to the Radio Amplifier (2). The carpet must be pulled pack and the base plate unfastened and flipped down in order to access the Transmission Control Module.

INSTALLATION

1. Install the Controller Antilock Brake (CAB) to the Hydraulic Control Unit (HCU) with the retaining screws.
2. Check the seating and condition of the Integrated Control Unit (ICU) rubber grommets and replace if necessary.
3. Install the ICU to the retaining bracket with the retaining screws. CAUTION: Do not wrongfully connect hydraulic lines. Trace the line routing to the corresponding wheel if necessary.
4. Install the brake lines (1-6). Pay close attention to the markings when attaching the hydraulic lines.
5. Reconnect the CAB harness connector (1).
6. Connect the negative battery cable.
7. Bleed the brake system. «(Refer to BRAKES - STANDARD PROCEDURE)»(ref-250638-S31141655702007031500000) .
8. Read the fault memory and erase.

Scheme 7

The Central Locking Pump/Security System Module (3) uses a combination of electrical wires (2) and air pressure/vacuum lines (1). The Central Locking Pump/Security System Module is located in the right rear of the luggage compartment underneath the trunk floor covering (4). It is wrapped in a sound deadening material in order to operate quietly without disturbing the vehicle operator.

The Central Locking Pump/Security System Module controls the air and vacuum lines that handle the locking and unlocking of the vehicle doors, the liftgate, and the fuel tank door.

1. Install the central locking pump/security system module (3) into the trunk and connect the air lines (2) and the electrical harness (1).
2. Install the central locking pump/security system module into sound deadening foam covering and slide it back into place.
3. Install the right half of the trunk floor covering (3).
4. Install the rear interior trim panel (2).
5. Install the right side interior trim panel (4).
6. Install the right upper trim panel (1).
7. Install the trunk floor carpet.
8. Connect the negative battery cable.

Scheme 8

The Sentry Key Remote Entry Module (SKREEM) (1) is located underneath the top pad of the instrument panel (2) behind the Instrument Cluster. The SKREEM works in conjunction with the vehicle locking/unlocking remote control and the Central Locking Pump/Security System Module to lock and unlock the vehicle.

The SKREEM is also the primary component of the sentry key system. The SKREEM has a halo-like Antenna Ring that connects by wires to the SKREEM and is mounted around the Ignition Lock Cylinder. The SKREEM cannot be adjusted or repaired. If faulty or damaged, the unit must be replaced.

1. Install the SKREEM module to the base plate.
2. Connect the 18-pin harness connector and the 2-pin CAN BUS harness connector (1) to the SKREEM module.
3. Connect the 2-pin harness connector for the sentry key antenna ring.
4. Install the Instrument Cluster. «(Refer to ELECTRICAL/INSTRUMENT CLUSTER - INSTALLATION)»(ref-250619-S35440140392007031500000) .
5. Connect the negative battery cable.

Scheme 9

REMOVAL - RHD

1. Disconnect the negative battery cable.
2. Slide the clips forward to remove the plastic control module box cover (1).
3. Holding the metal body control module retaining clip back, pull the body control module (6) up and out of the control module box (5).
4. Disconnect the BCM harness connectors by first sliding the grey motor harness wiper connector lock to the right and disconnecting the windshield wiper harness connector. Then, pull the metal body control module connector lock up to unlock and disconnect the rest of the body control module harness connectors.

1. Connect the electrical connectors (1) to the body control module and push the metal body control module connector lock down to lock the connector assembly. Then, connect the windshield wiper electrical connector to the body control module and slide the grey windshield wiper connector lock to the left to lock it.
2. Push the body control module into the control module box until the metal clip attaches to the body control module.
3. Install the plastic control module box cover (1) and slide the clips rearward to lock the cover.
4. Connect the negative battery cable (2).

1. Connect the harness connectors to the body control module (6) and push the metal body control module connector lock down to lock the connector assembly. Then, connect the windshield wiper electrical connector to the body control module and slide the grey windshield wiper connector lock to the left to lock it.
2. Install body control module into the control module box (5).
3. Install the plastic control module box cover (1) and slide the clips rearward to lock the cover.
4. Connect the negative battery cable.

Scheme 10

The Power Top Control Module (PTCM) (1) is located in the trunk below the left rear tail light assembly and next to the power top hydraulic assembly.

The PTCM is mounted to an attaching bracket at the power top hydraulic assembly. The PTCM is a microprocessor based module that monitors and operates the power top functions.

1. Install the power top control module to the hydraulic pump bracket (4).
2. Install the power top control module retaining screw (1).
3. Connect the power top control module harness connectors (2) and (3).
4. Install the trunk interior trim panel (1).
5. Install the plastic panel retainers (2).
6. Connect the negative battery cable.
7. Perform the Standard Procedure to complete the installation and programing of the new power top control module. «(Refer to ELECTRICAL/ELECTRONIC CONTROL MODULES/POWER TOP CONTROL MODULE - STANDARD PROCEDURE)»(ref-250625-S24643046442007031500000)
