Clutch: Specifications Chrysler Crossfire I

Clutches Manual & Hydraulic 6 illustrations ~239 words

SPECIFICATIONS - TORQUE

DESCRIPTIONN.mFt. Lbs.In. Lbs.
Flywheel Bolts4533398
Slave Cylinder Bolts10789
Clutch Cover Bolts2518221

TORQUE SPECIFICATIONS

Scheme 1

Scheme 1: SPECIAL TOOLS

Scheme 2

Scheme 2: REMOVAL

Scheme 3

Scheme 3
  1. Remove the transmission «(Refer to TRANSMISSION/TRANSAXLE/MANUAL - REMOVAL)»(ref-250624-S00097378472007031500000) . NOTE: Gradually remove the clutch cover bolts 1 to 1 1/2 turns at a time.
  2. Loosen the bolts (1) on the clutch cover.
  3. Mark the relation of the clutch cover to the flywheel.
  4. Remove the bolts (1) on the clutch cover.
  5. Remove the clutch cover (1) and the clutch disc (2).

Scheme 4

Scheme 4: INSTALLATION

Scheme 5

Scheme 5
  1. If the clutch cover is to be reused, adjustment is required on the clutch disc. Use an old release bearing or a length of pipe to release diaphragm pressure. Set the adjusting ring to the mark as shown in illustration.
  2. Position the clutch disc and clutch cover on the flywheel.
  3. Loosely install the clutch cover bolts (1).
  4. Install a universal clutch alignment tool (1).
  5. Align the clutch disc to the flywheel. NOTE: Gradually tighten the clutch cover bolts 1 to 1 1/2 turns at a time.
  6. Tighten the clutch cover bolts (1) until all bolts are fully seated. Tighten the bolts to 25 N.m (18 ft. lbs.).
  7. Remove the clutch alignment tool (1).
  8. Install the transmission «(Refer to TRANSMISSION/TRANSAXLE/MANUAL - INSTALLATION)»(ref-250624-S06035328202007031500000) .

Scheme 6

Scheme 6: DESCRIPTION

The clutch cover assembly (1), sometimes referred to as a pressure plate, is a diaphragm type with a one-piece spring and multiple release fingers (2). The clutch cover is attached to the engine flywheel (3) with eight bolts.
