FLUID CAPACITIES (AVENGER & SEBRING COUPE)
| Application | (1) Quantity |
|---|
| Crankcase (Includes Filter) (2) | 4.5 Qts. (4.3L) |
| Cooling System (3) | 7.4 Qts. (7.0L) |
| Automatic Transaxle (4) |
| Drain & Refill | (5) 4.0 Qts. (3.8L) |
| Dry Refill | 9.1 Qts. (8.6L) |
| Power Steering Fluid (4) | .95 Qt. (.9L) |
| (1) Approximate quantity listed. (2) Use an API engine oil that is certified for gasoline engines on all engines. Use 5W-30 (preferred) or 10W-30. (3) Quantity includes heater and coolant recovery tank. (4) Mopar® ATF+3, Type 7176 or Dexron II. (5) Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/8" below the ADD mark on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range on dipstick. |
| (1) | Approximate quantity listed. |
| (2) | Use an API engine oil that is certified for gasoline engines on all engines. Use 5W-30 (preferred) or 10W-30. |
| (3) | Quantity includes heater and coolant recovery tank. |
| (4) | Mopar® ATF+3, Type 7176 or Dexron II. |
| (5) | Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/8" below the ADD mark on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range on dipstick. |
FLUID CAPACITIES (AVENGER & SEBRING COUPE)
FLUID CAPACITIES (BREEZE, CIRRUS & STRATUS)
| Application | (1) Quantity |
|---|
| Crankcase (Includes Filter) (2) |
| 2.0L | 4.5 Qts. (4.3L) |
| 2.4L | 5.0 Qts. (4.7L) |
| 2.5L | 4.5 Qts. (4.3L) |
| Cooling System (3) |
| 2.0L | 8.5 Qts. (8.0L) |
| 2.4L | 9.0 Qts. (8.5L) |
| 2.5L | 10.5 Qts. (10.0L) |
| Automatic Transaxle (4) |
| Drain & Refill | (5) 4.0 Qts. (3.8L) |
| Dry Refill | 9.1 Qts. (8.6L) |
| Manual Transaxle (6) |
| NV T350 | 2.2 Qts. (2.1L) |
| NV T350HD | 2.6 Qts. (2.5L) |
| Power Steering Fluid (7) | (8) |
| (1) Approximate quantity listed. (2) Use an API energy conserving engine oil that is certified for gasoline engines. Use 5W-30 (preferred) or 10W-30. (3) Quantity includes heater and coolant recovery tank. (4) Use Mopar® ATF+4, Type 9602. (5) Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/8" below the ADD mark on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range on dipstick. (6) Use only Mopar® MS9417 manual transaxle fluid. Two different transaxles are used. Refer to capacity label near left driveshaft. (7) Use only Mopar® power steering fluid. DO NOT use automatic transmission fluid. (8) Capacity is not available from manufacturer. |
| (1) | Approximate quantity listed. |
| (2) | Use an API energy conserving engine oil that is certified for gasoline engines. Use 5W-30 (preferred) or 10W-30. |
| (3) | Quantity includes heater and coolant recovery tank. |
| (4) | Use Mopar® ATF+4, Type 9602. |
| (5) | Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/8" below the ADD mark on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range on dipstick. |
| (6) | Use only Mopar® MS9417 manual transaxle fluid. Two different transaxles are used. Refer to capacity label near left driveshaft. |
| (7) | Use only Mopar® power steering fluid. DO NOT use automatic transmission fluid. |
| (8) | Capacity is not available from manufacturer. |
FLUID CAPACITIES (BREEZE, CIRRUS & STRATUS)
FLUID CAPACITIES (CONCORDE, INTREPID, LHS & 300M)
| Application | (1) Quantity |
|---|
| Crankcase (Includes Filter) (2) |
| 2.7L, 3.2L & 3.5L | 5.0 Qts. (4.7L) |
| Cooling System (3) |
| 2.7L, 3.2L & 3.5L | 9.4 Qts. (8.9L) |
| Automatic Transaxle (4) |
| Drain & Refill | (5) 4.5 Qts. (4.3L) |
| Dry Refill | 9.9 Qts. (9.4L) |
| Differential (6) | 1.0 Qt. (.95L) |
| Power Steering Fluid (7) | (8) |
| (1) Approximate quantity listed. (2) Use an API energy conserving engine oil that is certified for gasoline engines. Use 5W-30 (preferred) or 10W-30. (3) Quantity includes heater and coolant recovery tank. (4) Use Mopar® ATF+4, Type 9602. (5) Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/4" above the bottom hole on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range on dipstick. (6) Differential has a separate sump from the automatic transaxle. Use Mopar® 75W-90 hypoid gear oil. DO NOT use synthetic gear oil in differential. (7) Use only Mopar® power steering fluid. DO NOT use automatic transmission fluid. (8) Capacity is not available from manufacturer. |
| (1) | Approximate quantity listed. |
| (2) | Use an API energy conserving engine oil that is certified for gasoline engines. Use 5W-30 (preferred) or 10W-30. |
| (3) | Quantity includes heater and coolant recovery tank. |
| (4) | Use Mopar® ATF+4, Type 9602. |
| (5) | Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/4" above the bottom hole on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range on dipstick. |
| (6) | Differential has a separate sump from the automatic transaxle. Use Mopar® 75W-90 hypoid gear oil. DO NOT use synthetic gear oil in differential. |
| (7) | Use only Mopar® power steering fluid. DO NOT use automatic transmission fluid. |
| (8) | Capacity is not available from manufacturer. |
FLUID CAPACITIES (CONCORDE, INTREPID, LHS & 300M)
FLUID CAPACITIES (NEON)
| Application | (1) Quantity |
|---|
| Crankcase (Includes Filter) (2) | 4.5 Qts. (4.3L) |
| Cooling System (3) |
| With A/C | 7.0 Qts. (6.5L) |
| Without A/C | 6.5 Qts. (6.1L) |
| Automatic Transaxle (4) |
| Drain & Refill | (5) 4.0 Qts. (3.8L) |
| Dry Refill | 8.9 Qts. (8.4L) |
| Manual Transaxle (6) | 2.1 Qts. (1.9L) |
| Power Steering Fluid (7) | 1.0 Qt. (.95L) |
| (1) Approximate quantity listed. (2) Use an API energy conserving engine oil that is certified for gasoline engines. Use 5W-30 (preferred) or 10W-30. (3) Quantity includes heater and coolant recovery tank. (4) Use Mopar® ATF+4, Type 9602. (5) Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/8" below the ADD mark on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range on dipstick. (6) Use only Mopar® MS9417 manual transaxle fluid. DO NOT use hypoid gear oil, engine oil or automatic transmission fluid. (7) Use only Mopar® power steering fluid. DO NOT use automatic transmission fluid. |
| (1) | Approximate quantity listed. |
| (2) | Use an API energy conserving engine oil that is certified for gasoline engines. Use 5W-30 (preferred) or 10W-30. |
| (3) | Quantity includes heater and coolant recovery tank. |
| (4) | Use Mopar® ATF+4, Type 9602. |
| (5) | Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/8" below the ADD mark on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range on dipstick. |
| (6) | Use only Mopar® MS9417 manual transaxle fluid. DO NOT use hypoid gear oil, engine oil or automatic transmission fluid. |
| (7) | Use only Mopar® power steering fluid. DO NOT use automatic transmission fluid. |
FLUID CAPACITIES (SEBRING CONVERTIBLE)
| Application | (1) Quantity |
|---|
| Crankcase (Includes Filter) (2) | 4.5 Qts. (4.3L) |
| Cooling System (3) | 10.5 Qts. (10.0L) |
| Automatic Transaxle (4) |
| Drain & Refill | (5) 4.0 Qts. (3.8L) |
| Dry Refill | 9.1 Qts. (8.6L) |
| Power Steering Fluid (6) | (7) |
| (1) Approximate quantity listed. (2) Use an API engine oil that is certified for gasoline engines on all engines. Use 5W-30 (preferred) or 10W-30. (3) Quantity includes heater and coolant recovery tank. (4) Use Mopar® ATF+4, Type 9602. (5) Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/8" below the ADD mark on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range on dipstick. (6) Use only Mopar® power steering fluid. DO NOT use automatic transmission fluid. (7) Capacity is not available from manufacturer. |
| (1) | Approximate quantity listed. |
| (2) | Use an API engine oil that is certified for gasoline engines on all engines. Use 5W-30 (preferred) or 10W-30. |
| (3) | Quantity includes heater and coolant recovery tank. |
| (4) | Use Mopar® ATF+4, Type 9602. |
| (5) | Add this amount of fluid. Start engine and shift transaxle through all gears and back to Park. Add additional fluid to bring fluid level to 1/8" below the ADD mark on dipstick. Recheck fluid level with transaxle at normal operating temperature. Adjust fluid level so fluid level is within the HOT range on dipstick. |
| (6) | Use only Mopar® power steering fluid. DO NOT use automatic transmission fluid. |
| (7) | Capacity is not available from manufacturer. |
FLUID CAPACITIES (SEBRING CONVERTIBLE)
4-CYLINDER COMPRESSION SPECIFICATIONS
| Application | Specification |
|---|
| Normal Compression Pressure |
| Breeze, Cirrus & Stratus |
| 2.0L & 2.4L | 170-225 psi (12-16 kg/cm 2 ) |
| Neon |
| 2.0L DOHC & SOHC | 170-225 psi (12-16 kg/cm 2 ) |
| Minimum Compression Pressure |
| Breeze, Cirrus & Stratus |
| 2.0L & 2.4L | 100 psi (7 kg/cm 2) ) |
| Neon |
| 2.0L SOHC | 100 psi (7 kg/cm 2) ) |
| Maximum Variation Between Cylinders |
| All Models | (1) |
| (1) Maximum variation between cylinders is 25 percent. |
| (1) | Maximum variation between cylinders is 25 percent. |
4-CYLINDER COMPRESSION SPECIFICATIONS
V6 COMPRESSION SPECIFICATIONS
| Application | Specification |
|---|
| Normal Compression Pressure |
| Avenger, Cirrus, Sebring Convertible, Sebring Coupe & Stratus |
| 2.5L |
| Calif. Emission Vehicles | 154-202 psi (11-14 kg/cm 2 ) |
| Except Calif. Emission Vehicles | 192-211 psi (13-15 kg/cm 2 ) |
| Concorde, Intrepid, LHS & 300M |
| 2.7L, 3.2L & 3.5L | (1) |
| Minimum Compression Pressure |
| Avenger, Cirrus, Sebring Convertible, Sebring Coupe & Stratus |
| 2.5L | 100 psi (7 kg/cm 2) ) |
| Concorde, Intrepid, LHS & 300M |
| 2.7L, 3.2L & 3.5L | 100 psi (7 kg/cm 2) ) |
| Maximum Variation Between Cylinders |
| Avenger, Cirrus, Sebring Convertible, Sebring Coupe & Stratus |
| 2.5L | 14 psi (1 kg/cm 2 ) |
| Concorde, Intrepid, LHS & 300M |
| 2.7L, 3.2L & 3.5L | (2) |
| (1) Information is not available from manufacturer. (2) Maximum variation between cylinders is 25 percent. |
| (1) | Information is not available from manufacturer. |
| (2) | Maximum variation between cylinders is 25 percent. |
V6 COMPRESSION SPECIFICATIONS
4-CYLINDER SPARK PLUG SPECIFICATIONS
| Application | Gap In. (mm) | Torque Ft. Lbs. (N.m) |
|---|
| Breeze, Cirrus & Stratus |
| 2.0L | .033-.038 (.84-.97) | 20 (27) |
| 2.4L | .048-.053 (1.22-1.35) | 20 (27) |
| Neon |
| 2.0L SOHC | .033-.038 (.84-.97) | 20 (27) |
| (1) Check spark plug gap specification on underhood vehicle emission control label. If specification differs from that listed above, use specification on underhood vehicle emission control label. |
| (1) | Check spark plug gap specification on underhood vehicle emission control label. If specification differs from that listed above, use specification on underhood vehicle emission control label. |
4-CYLINDER SPARK PLUG SPECIFICATIONS (1)
V6 SPARK PLUG SPECIFICATIONS
| Application | Gap In. (mm) | Torque Ft. Lbs. (N.m) |
|---|
| Avenger & Sebring Coupe |
| 2.5L | .039-.043 (1.00-1.10) | 18 (24) |
| Cirrus & Stratus |
| 2.5L | .038-.043 (.97-1.10) | 20 (27) |
| Concorde, Intrepid, LHS & 300M |
| 2.7L | .048-.058 (1.22-1.47) | 13 (18) |
| 3.2L & 3.5L | .048-.053 (1.22-1.35) | 20 (27) |
| Sebring Convertible |
| 2.5L | .038-.043 (.97-1.10) | 20 (27) |
| (1) Check spark plug gap specification on underhood vehicle emission control label. If specification differs from that listed above, use specification on underhood vehicle emission control label. |
| (1) | Check spark plug gap specification on underhood vehicle emission control label. If specification differs from that listed above, use specification on underhood vehicle emission control label. |
V6 SPARK PLUG SPECIFICATIONS (1)
Firing Order (2.0L & 2.4L - Breeze, Cirrus, Neon & Stratus). Scheme 1
Scheme 1: Firing Order (2.0L & 2.4L - Breeze, Cirrus, Neon & Stratus)
Scheme 2
Scheme 2: Firing Order (2.5L - Avenger, Cirrus, Sebring Convertible, Sebring Coupe & Stratus)
Scheme 3
Scheme 3: Firing Order (2.7L, 3.2L & 3.5L - Concorde, Intrepid, LHS & 300M)
4-CYLINDER THROTTLE BODY MINIMUM AIRFLOW IDLE SPEED SPECIFICATIONS
| Application | (1) RPM |
|---|
| Breeze, Cirrus & Stratus |
| 2.0L & 2.4L | 500-1000 |
| Neon |
| 2.0L SOHC | 550-1300 |
| (1) Specification is with Air Metering Fitting (6457) installed and scan tool actuating minimum airflow. |
| (1) | Specification is with Air Metering Fitting (6457) installed and scan tool actuating minimum airflow. |
4-CYLINDER THROTTLE BODY MINIMUM AIRFLOW IDLE SPEED SPECIFICATIONS
V6 THROTTLE BODY MINIMUM AIRFLOW IDLE SPEED SPECIFICATIONS
| Application | RPM |
|---|
| Avenger & Sebring Coupe |
| 2.5L (1) |
| 1000 Miles Or Less | (2) 450-1100 |
| More Than 1000 Miles | (2) 500-1100 |
| Cirrus & Stratus |
| 2.5L | (2) 500-1000 |
| Concorde, Intrepid, LHS & 300M |
| 2.7L, 3.2L & 3.5L | (2) 550-1300 |
| Sebring Convertible |
| 2.5L | (2) 500-1000 |
| (1) Specification listed in accordance with vehicle mileage. (2) Specification is with Air Metering Fitting (6457) installed and scan tool actuating minimum airflow. |
| (1) | Specification listed in accordance with vehicle mileage. |
| (2) | Specification is with Air Metering Fitting (6457) installed and scan tool actuating minimum airflow. |
V6 THROTTLE BODY MINIMUM AIRFLOW IDLE SPEED SPECIFICATIONS
4-CYLINDER THROTTLE POSITION SENSOR VOLTAGE SPECIFICATIONS
| Application & Throttle Opening | (1) (2) Volts |
|---|
| Breeze, Cirrus & Stratus |
| 2.0L & 2.4L |
| At Idle | 1.5 Or Less |
| At Full Throttle | At Least 3.4 |
| Neon |
| 2.0L SOHC |
| At Idle | .92 Or Less |
| At Full Throttle | (3) |
| (1) Measure voltage at center terminal on throttle position sensor with ignition on. (2) Voltage should increase smoothly when moving throttle from idle to full throttle. (3) Information is not available from manufacturer. |
| (1) | Measure voltage at center terminal on throttle position sensor with ignition on. |
| (2) | Voltage should increase smoothly when moving throttle from idle to full throttle. |
| (3) | Information is not available from manufacturer. |
4-CYLINDER THROTTLE POSITION SENSOR VOLTAGE SPECIFICATIONS
V6 THROTTLE POSITION SENSOR VOLTAGE SPECIFICATIONS
| Application & Throttle Opening | (1) (2) Volts |
|---|
| Avenger & Sebring Coupe |
| 2.5L | (3) |
| Cirrus & Stratus |
| 2.5L |
| At Idle | 1.5 Or Less |
| At Full Throttle | At Least 3.4 |
| Concorde, Intrepid, LHS & 300M |
| 2.7L, 3.2L & 3.5L |
| At Idle | .92 Or Less |
| At Full Throttle | (4) |
| Sebring Convertible |
| 2.5L |
| At Idle | 1.5 Or Less |
| At Full Throttle | At Least 3.4 |
| (1) Measure voltage at center terminal on throttle position sensor with ignition on. (2) Voltage should smoothly increase when moving throttle from idle to full throttle. (3) Using scan tool, reading should be 400 mV (at idle) to 3800 mV (at full throttle). (4) Information is not available from manufacturer. |
| (1) | Measure voltage at center terminal on throttle position sensor with ignition on. |
| (2) | Voltage should smoothly increase when moving throttle from idle to full throttle. |
| (3) | Using scan tool, reading should be 400 mV (at idle) to 3800 mV (at full throttle). |
| (4) | Information is not available from manufacturer. |
V6 THROTTLE POSITION SENSOR VOLTAGE SPECIFICATIONS
