FLUID CAPACITIES (CONCORDE, INTREPID, LHS & 300M)
| Application | (1) Quantity |
|---|
| Automatic Transaxle (2) |
| Drain & Refill | (3) 4.5 Qts. (4.3L) |
| Dry Refill | 9.3 Qts. (8.8L) |
| Cooling System (4) |
| 2.7L, 3.2L & 3.5L | 9.4 Qts. (8.9L) |
| Crankcase (Includes Filter) (5) |
| 2.7L, 3.2L & 3.5L | 5.0 Qts. (4.7L) |
| Differential (6) | .78 Qt. (.74L) |
| Power Steering Fluid (7) | (8) |
| (1) Approximate quantity listed. (2) Use Mopar® ATF+4, Type 9602. (3) Estimated service refill capacity. (4) Quantity includes heater and coolant recovery tank. (5) Use an API energy conserving engine oil that is certified for gasoline engines. Use 5W-30 (preferred for 2.7L) or 10W-30 (preferred for 3.2L & 3.5L). (6) Differential has a separate sump from the automatic transaxle. Use Mopar® 75W-90 hypoid gear oil. DO NOT use synthetic gear oil in differential. (7) Use only Mopar® power steering fluid. DO NOT use automatic transmission fluid. (8) Capacity is not available from manufacturer. |
| (1) | Approximate quantity listed. |
| (2) | Use Mopar® ATF+4, Type 9602. |
| (3) | Estimated service refill capacity. |
| (4) | Quantity includes heater and coolant recovery tank. |
| (5) | Use an API energy conserving engine oil that is certified for gasoline engines. Use 5W-30 (preferred for 2.7L) or 10W-30 (preferred for 3.2L & 3.5L). |
| (6) | Differential has a separate sump from the automatic transaxle. Use Mopar® 75W-90 hypoid gear oil. DO NOT use synthetic gear oil in differential. |
| (7) | Use only Mopar® power steering fluid. DO NOT use automatic transmission fluid. |
| (8) | Capacity is not available from manufacturer. |
FLUID CAPACITIES (CONCORDE, INTREPID, LHS & 300M)
FLUID CAPACITIES (NEON)
| Application | (1) Quantity |
|---|
| Automatic Transaxle (2) |
| Drain & Refill | (3) 4.0 Qts. (3.8L) |
| Dry Refill | 8.6 Qts. (8.1L) |
| Cooling System (4) | 6.5 Qts. (6.1L) |
| Crankcase (Includes Filter) (5) | 4.5 Qts. (4.3L) |
| Manual Transaxle (6) | 2.5-2.8 Qts. (2.4-2.7L) |
| Power Steering Fluid (7) | 1.0 Qt. (.95L) |
| (1) Approximate quantity listed. (2) Use Mopar® ATF+4, Type 9602. (3) Estimated service refill capacity. (4) Quantity includes heater and coolant recovery tank. (5) Use an API energy conserving engine oil that is certified for gasoline engines. Use 5W-30 (preferred) or 10W-30. (6) Use only Mopar® MS9417 manual transaxle fluid. DO NOT use hypoid gear oil, engine oil or automatic transmission fluid. (7) Use only Mopar® power steering fluid. DO NOT use automatic transmission fluid. |
| (1) | Approximate quantity listed. |
| (2) | Use Mopar® ATF+4, Type 9602. |
| (3) | Estimated service refill capacity. |
| (4) | Quantity includes heater and coolant recovery tank. |
| (5) | Use an API energy conserving engine oil that is certified for gasoline engines. Use 5W-30 (preferred) or 10W-30. |
| (6) | Use only Mopar® MS9417 manual transaxle fluid. DO NOT use hypoid gear oil, engine oil or automatic transmission fluid. |
| (7) | Use only Mopar® power steering fluid. DO NOT use automatic transmission fluid. |
FLUID CAPACITIES (PT CRUISER)
| Application | (1) Quantity |
|---|
| Automatic Transaxle (2) |
| Drain & Refill | (3) 4.0 Qts. (3.8L) |
| Dry Refill | 9.2 Qts. (8.7L) |
| Cooling System (4) | 7.4 Qts. (7.0L) |
| Crankcase (Includes Filter) (5) | 5.0 Qts. (4.7L) |
| Manual Transaxle (6) | 2.5-2.8 Qts. (2.4-2.6L) |
| Power Steering Fluid (7) | (8) |
| (1) Approximate quantity listed. (2) Use Mopar® ATF+4, Type 9602. (3) Estimated service refill. (4) Quantity includes heater and coolant recovery tank. (5) Use an API energy conserving engine oil that is certified for gasoline engines. Use 5W-30 (preferred) or 10W-30. (6) Use Mopar® Manual Transaxle Fluid or equivalent. (7) Use only Mopar® power steering fluid. DO NOT use automatic transmission fluid. (8) Capacity is not available from manufacturer. |
| (1) | Approximate quantity listed. |
| (2) | Use Mopar® ATF+4, Type 9602. |
| (3) | Estimated service refill. |
| (4) | Quantity includes heater and coolant recovery tank. |
| (5) | Use an API energy conserving engine oil that is certified for gasoline engines. Use 5W-30 (preferred) or 10W-30. |
| (6) | Use Mopar® Manual Transaxle Fluid or equivalent. |
| (7) | Use only Mopar® power steering fluid. DO NOT use automatic transmission fluid. |
| (8) | Capacity is not available from manufacturer. |
FLUID CAPACITIES (PT CRUISER)
FLUID CAPACITIES (SEBRING COUPE & STRATUS COUPE)
| Application | (1) Quantity |
|---|
| Automatic Transaxle (2) |
| 4-Cylinder | (3) 8.1 Qts. (7.7L) |
| V6 | (3) 8.5 Qts. (8.0L) |
| Cooling System (4) |
| 4-Cylinder | 7.4 Qts. (7.0L) |
| V6 | 8.5 Qts. (8.0L) |
| Crankcase (Includes Filter) (5) | 4.5 Qts. (4.3L) |
| Manual Transaxle (6) |
| 4-Cylinder | 2.3 Qts. (2.2L) |
| V6 | 3.0 Qts. (2.8L) |
| Power Steering Fluid (7) | 1.3 Qts. (1.2L) |
| (1) Approximate quantity listed. (2) Use DIAMOND ATF SP-II or SP-IIM. (3) Dry refill capacity. (4) Quantity includes heater and coolant recovery tank. (5) Use an API engine oil that is certified for gasoline engines on all engines. Use 5W-30 (preferred) or 10W-30. (6) Use API GL-4 SAE 75W-90 or 75W/85W. (7) Use Dexron-II ATF. |
| (1) | Approximate quantity listed. |
| (2) | Use DIAMOND ATF SP-II or SP-IIM. |
| (4) | Quantity includes heater and coolant recovery tank. |
| (5) | Use an API engine oil that is certified for gasoline engines on all engines. Use 5W-30 (preferred) or 10W-30. |
| (6) | Use API GL-4 SAE 75W-90 or 75W/85W. |
FLUID CAPACITIES (SEBRING COUPE & STRATUS COUPE)
FLUID CAPACITIES (SEBRING CONVERTIBLE, SEBRING SEDAN & STRATUS SEDAN)
| Application | (1) Quantity |
|---|
| Automatic Transaxle (2) |
| Drain & Refill | (3) 4.0 Qts. (3.8L) |
| Dry Refill | 9.2 Qts. (8.7L) |
| Cooling System (4) |
| 2.4L | 10.5 Qts. (9.9L) |
| 2.7L | 9.5 Qts. (9.0L) |
| Crankcase (Includes Filter) (5) | 5.0 Qts. (4.7L) |
| Power Steering Fluid (6) | (7) |
| (1) Approximate quantity listed. (2) Use Mopar® ATF+4, Type 9602. (3) Estimated service refill. (4) Quantity includes heater and coolant recovery tank. (5) Use an API energy conserving engine oil that is certified for gasoline engines. Use 5W-30 (preferred) or 10W-30. (6) Use only Mopar® power steering fluid. DO NOT use automatic transmission fluid. (7) Capacity is not available from manufacturer. |
| (1) | Approximate quantity listed. |
| (2) | Use Mopar® ATF+4, Type 9602. |
| (3) | Estimated service refill. |
| (4) | Quantity includes heater and coolant recovery tank. |
| (5) | Use an API energy conserving engine oil that is certified for gasoline engines. Use 5W-30 (preferred) or 10W-30. |
| (6) | Use only Mopar® power steering fluid. DO NOT use automatic transmission fluid. |
| (7) | Capacity is not available from manufacturer. |
FLUID CAPACITIES (SEBRING CONVERTIBLE, SEBRING SEDAN & STRATUS SEDAN)
4-CYLINDER COMPRESSION SPECIFICATIONS
| Application | Specification |
|---|
| Normal Compression Pressure |
| Neon |
| 2.0L SOHC | 170-225 psi (12-16 kg/cm 2 ) |
| PT Cruiser |
| 2.4L DOHC | 170-225 psi (12-16 kg/cm 2 ) |
| Sebring Coupe & Stratus Coupe |
| 2.4L SOHC | 185 psi (13 kg/cm 2 ) |
| Sebring Sedan & Stratus Sedan |
| 2.4L DOHC | 170-225 psi (12-16 kg/cm 2 ) |
| Minimum Compression Pressure |
| Neon |
| 2.0L SOHC | 100 psi (7 kg/cm 2 ) |
| PT Cruiser |
| 2.4L DOHC | 100 psi (7 kg/cm 2 ) |
| Sebring Coupe & Stratus Coupe |
| 2.4L SOHC | 139 psi (10 kg/cm 2 ) |
| Sebring Sedan & Stratus Sedan |
| 2.4L DOHC | 100 psi (7 kg/cm 2 ) |
| Maximum Variation Between Cylinders |
| Except Sebring Coupe & Stratus Coupe | (1) |
| Sebring Coupe & Stratus Coupe | 14 psi (1 kg/cm 2 ) |
| (1) Maximum variation between cylinders is 25 percent. |
| (1) | Maximum variation between cylinders is 25 percent. |
4-CYLINDER COMPRESSION SPECIFICATIONS
V6 COMPRESSION SPECIFICATIONS
| Application | Specification |
|---|
| Normal Compression Pressure |
| Concorde, Intrepid, LHS & 300M |
| 2.7L, 3.2L & 3.5L | 170-225 psi (12-16 kg/cm 2 ) |
| Sebring Coupe & Stratus Coupe |
| 3.0L | 119 psi (8 kg/cm 2 ) |
| Sebring Convertible, Sebring Sedan & Stratus Sedan |
| 2.7L | 170-225 psi (12-16 kg/cm 2 ) |
| Minimum Compression Pressure |
| Concorde, Intrepid, LHS & 300M |
| 2.7L, 3.2L & 3.5L | 100 psi (7 kg/cm 2 ) |
| Sebring Coupe & Stratus Coupe |
| 3.0L | 83 psi (6 kg/cm 2 ) |
| Sebring Convertible, Sebring Sedan & Stratus Sedan |
| 2.7L | 100 psi (7 kg/cm 2 ) |
| Maximum Variation Between Cylinders |
| Except Sebring Coupe & Stratus Coupe | (1) |
| Sebring Coupe & Stratus Coupe | 14 psi (1 kg/cm 2 ) |
| (1) Maximum variation between cylinders is 25 percent. |
| (1) | Maximum variation between cylinders is 25 percent. |
V6 COMPRESSION SPECIFICATIONS
4-CYLINDER SPARK PLUG SPECIFICATIONS
| Application | Gap - In. (mm) | Torque - Ft. Lbs. (N.m) |
|---|
| Neon |
| 2.0L SOHC | .033-.038 (.84-.97) | 20 (27) |
| PT Cruiser |
| 2.4L DOHC | .048-.053 (1.22-1.35) | 11-15 (15-20) |
| Sebring Coupe & Stratus Coupe |
| 2.4L SOHC | .039-.043 (1.00-1.10) | 15-21 (21-29) |
| Sebring Sedan & Stratus Sedan |
| 2.4L DOHC | .050 (1.27) | 20 (27) |
| (1) Check spark plug gap specification on underhood vehicle emission control label. If specification differs from that listed above, use specification on underhood vehicle emission control label. |
| (1) | Check spark plug gap specification on underhood vehicle emission control label. If specification differs from that listed above, use specification on underhood vehicle emission control label. |
4-CYLINDER SPARK PLUG SPECIFICATIONS (1)
V6 SPARK PLUG SPECIFICATIONS
| Application | Gap - In. (mm) | Torque - Ft. Lbs. (N.m) |
|---|
| Concorde, Intrepid, LHS & 300M |
| 2.7L | .048-.058 (1.22-1.47) | 13 (18) |
| 3.2L & 3.5L | .048-.053 (1.22-1.35) | 20 (27) |
| Sebring Coupe & Stratus Coupe |
| 3.0L | .039-.043 (1.00-1.10) | 15-21 (21-29) |
| Sebring Convertible, Sebring Sedan & Stratus Sedan |
| 2.7L | .050 (1.27) | 15 (21) |
| (1) Check spark plug gap specification on underhood vehicle emission control label. If specification differs from that listed above, use specification on underhood vehicle emission control label. |
| (1) | Check spark plug gap specification on underhood vehicle emission control label. If specification differs from that listed above, use specification on underhood vehicle emission control label. |
V6 SPARK PLUG SPECIFICATIONS (1)
Firing Order (2.0L & 2.4L). Scheme 1
Scheme 1: Firing Order (2.0L & 2.4L)
Firing Order & Distributor Rotation (3.0L). Scheme 2
Scheme 2: Firing Order & Distributor Rotation (3.0L)
Scheme 3
Scheme 4
Scheme 4: Firing Order (2.7L, 3.2L & 3.5L)
4-CYLINDER THROTTLE POSITION SENSOR VOLTAGE SPECIFICATIONS
| Application & Throttle Opening | (1) (2) Volts |
|---|
| Neon |
| 2.0L SOHC |
| Idle | About .8 |
| Full Throttle | More Than 3.5 |
| PT Cruiser |
| 2.4L DOHC |
| Idle | About .5 |
| Full Throttle | 3.7 Or More |
| Sebring Coupe & Stratus Coupe |
| 2.4L SOHC |
| Idle | .54-.74 |
| Full Throttle | 4.5-5.5 |
| Sebring Sedan & Stratus Sedan |
| 2.4L DOHC |
| Idle | About .8 |
| Full Throttle | More Than 3.5 |
| (1) Measure voltage at center terminal on throttle position sensor with ignition on. (2) Voltage should increase smoothly when moving throttle from idle to full throttle. |
| (1) | Measure voltage at center terminal on throttle position sensor with ignition on. |
| (2) | Voltage should increase smoothly when moving throttle from idle to full throttle. |
4-CYLINDER THROTTLE POSITION SENSOR VOLTAGE SPECIFICATIONS
V6 THROTTLE POSITION SENSOR VOLTAGE SPECIFICATIONS
| Application & Throttle Opening | (1) (2) Volts |
|---|
| Concorde, Intrepid, LHS & 300M |
| 2.7L, 3.2L & 3.5L |
| At Idle | About .8 |
| At Full Throttle | More Than 3.5 |
| Sebring Coupe & Stratus Coupe |
| 3.0L |
| Idle | .54-.74 |
| Full Throttle | 4.5-5.5 |
| Sebring Convertible, Sebring Sedan & Stratus Sedan |
| 2.7L |
| At Idle | About .8 |
| At Full Throttle | More Than 3.5 |
| (1) Measure voltage at center terminal on throttle position sensor with ignition on. (2) Voltage should smoothly increase when moving throttle from idle to full throttle. |
| (1) | Measure voltage at center terminal on throttle position sensor with ignition on. |
| (2) | Voltage should smoothly increase when moving throttle from idle to full throttle. |
V6 THROTTLE POSITION SENSOR VOLTAGE SPECIFICATIONS
