Intermittent
Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .
Reference Information
Schematic Reference
Outside Rearview Mirror Schematics
Connector End View Reference
COMPONENT CONNECTOR END VIEWS
Description and Operation
Outside Mirror Description and Operation
Electrical Information Reference
- «Circuit Testing»(ref-487461-S14472700752012072300000)
- «Connector Repairs»(ref-487461-S16008896872012072300000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-487461-S02545222692012072300000)
- «Wiring Repairs»(ref-487461-S20629117392012072300000)
Scan Tool Reference
Control Module References for scan tool information.
Circuit/System Verification
- Vehicle ON, press the rear window defogger switch. Verify the rear window defogger turns ON and the rear window becomes warm. If the rear window defogger does not turn on, refer to «Rear Window Defogger Malfunction»(ref-487472-S34228651402012072300000) .
- Verify both the left and right outside mirror glass become warm.
Repair Instructions
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
Outside Rearview Mirror Glass Replacement
Schematic Reference
Inside Rearview Mirror Schematics
Connector End View Reference
COMPONENT CONNECTOR END VIEWS
Description and Operation
Automatic Day-Night Mirror Description and Operation
Electrical Information Reference
- «Circuit Testing»(ref-487461-S14472700752012072300000)
- «Connector Repairs»(ref-487461-S16008896872012072300000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-487461-S02545222692012072300000)
- «Wiring Repairs»(ref-487461-S20629117392012072300000)
Scan Tool Reference
Control Module References for scan tool information
- Vehicle in Service Mode, headlamps ON, vehicle in PARK, cover the front light sensor with a towel or other suitable item. Shine a flashlight at the rear light sensor while observing the inside rearview mirror face. The inside rearview mirror face should dim.
- Vehicle ON, park brake applied, place the transmission in REVERSE. The inside rearview mirror face should transition from dim to bright.
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
Inside Rearview Mirror Replacement
Schematic Reference
Outside Rearview Mirror Schematics
Connector End View Reference
COMPONENT CONNECTOR END VIEWS
Description and Operation
Outside Mirror Description and Operation
Electrical Information Reference
- «Circuit Testing»(ref-487461-S14472700752012072300000)
- «Connector Repairs»(ref-487461-S16008896872012072300000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-487461-S02545222692012072300000)
- «Wiring Repairs»(ref-487461-S20629117392012072300000)
Scan Tool Reference
Control Module References for scan tool information
- Vehicle in Service Mode, with the mirror selector switch in the DRIVER position, command the mirrors UP, DOWN, LEFT, and RIGHT using the mirror directional switch. The A9A driver outside rearview mirror should move in the commanded direction.
- With the mirror selector switch in the PASSENGER position, command the mirrors UP, DOWN, LEFT, and RIGHT using the mirror directional switch. The A9B passenger outside rearview mirror should move in the commanded direction.
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
- «Outside Rearview Mirror Replacement»(ref-487469-S39144389522012072300000)
- «Outside Remote Control Rearview Mirror Switch Replacement»(ref-487469-S00734889742012072300000)
Scheme 4
| Callout | Component Name |
|---|---|
| 1 | Outside Rearview Mirror Applique Procedure It's necessary to remove the outside rearview mirror, loosen the bolts to allow the mirror to move. Refer to Outside Rearview Mirror Replacement . Insert a plastic tool between the door frame and the edge of the mirror applique. Push inward, turn clockwise releasing the retaining clips from the door frame. It may be necessary to remove the old retaining clips from the door frame. When reinstalling the applique, set the bottom of the applique in first then rotate the part into place clipping the top first then the bottom. |
Outside Rearview Mirror Applique Replacement
Scheme 5
| Callout | Component Name |
|---|---|
| WARNING: Refer to Glass and Sheet Metal Handling Warning . Preliminary Procedure Remove the front side door trim panel. Refer to Front Side Door Trim Replacement . | |
| 1 | Outside Rearview Mirror Nuts (Qty: 3) CAUTION: Refer to Fastener Caution . Procedure Remove the water deflector cover at the top of the door panel to expose the nuts. Disconnect the electrical connector. Tighten 10 N.m (89 lb in) |
| 2 | Outside Rearview Mirror Front Lower Base Retainer Procedure When pulling the mirror assembly off the vehicle it Must be pulled straight forward to prevent the retainer from falling in the door. NOTE: If the retainer stay in the door when removing the mirror, remove and reinstall to the mirror base. |
| 3 | Outside Rearview Mirror TIP: Inspect the outside rearview mirror for proper operation before installing the door trim. |
| WARNING |
|---|
| Refer to Glass and Sheet Metal Handling Warning . |
| CAUTION |
|---|
| Refer to Fastener Caution . |
| NOTE |
|---|
| If the retainer stay in the door when removing the mirror, remove and reinstall to the mirror base. |
Outside Rearview Mirror Replacement
Scheme 6
| Callout | Component Name |
|---|---|
| WARNING: Refer to Glass and Sheet Metal Handling Warning . Preliminary Procedure Remove the outside rearview mirror housing bezel. Refer to Outside Rearview Mirror Housing Bezel Replacement . | |
| 1 | Outside Rearview Mirror Housing Cover Retainers (Qty: 3) Procedure The housing cover has three molded retainers on the front edge that retains it to the housing. Lift and slide the housing cover straight forward to release the retainers from the housing. NOTE: The housing cover fits in the edge of the turning signal house and it must slid forward to release completely. |
| 2 | Outside Rearview Mirror Housing Cover Procedure Reinstall the housing cover to the housing. Inner actuator to housing, ensure proper operation. Position the housing cover to the housing and turn signal, push rearward until fully seated. Place your hand on the back of the mirror housing. Using the flat part of your hand press inward until the mirror glass fully seats to the inner actuator retaining tabs. Inspect the outside rearview mirror for proper operation. |
| WARNING |
|---|
| Refer to Glass and Sheet Metal Handling Warning . |
| NOTE |
|---|
| The housing cover fits in the edge of the turning signal house and it must slid forward to release completely. |
Outside Rearview Mirror Housing Cover Replacement
Scheme 7
| Callout | Component Name |
|---|---|
| WARNING: Refer to Glass and Sheet Metal Handling Warning . Preliminary Procedure Remove the outside rearview mirror inner actuator. Refer to Outside Rearview Mirror Inner Actuator Replacement . | |
| 1 | Outside Rearview Mirror Housing Bezel Procedure Inspect the outside rearview mirror inner actuator for proper operation before installing the mirror glass. NOTE: When removing the housing bezel it Must be pulled up and turn from the lower inside corner only to release. |
| WARNING |
|---|
| Refer to Glass and Sheet Metal Handling Warning . |
| NOTE |
|---|
| When removing the housing bezel it Must be pulled up and turn from the lower inside corner only to release. |
Outside Rearview Mirror Housing Bezel Replacement
Scheme 8
| Callout | Component Name |
|---|---|
| Preliminary Procedure Remove the drivers side door accessory switch mount plate. Refer to Front Side Door Accessory Switch Mount Plate Replacement (Passenger Side Door) , Front Side Door Accessory Switch Mount Plate Replacement (Drivers Side Door) . | |
| 1 | Outside Remote Control Rearview Mirror Switch Assembly Procedure Disconnect the electrical connector. |
Outside Remote Control Rearview Mirror Switch Replacement
Scheme 9
| Callout | Component Name |
|---|---|
| WARNING: Refer to Glass and Sheet Metal Handling Warning . Preliminary Procedure Remove the outside rearview mirror glass. Refer to Outside Rearview Mirror Glass Replacement . | |
| 1 | Outside Rearview Mirror Inner Actuator Screws (Qty: 3) CAUTION: Refer to Fastener Caution . Procedure Disconnect the electrical connector. Tighten 3 N.m (27 lb in) |
| 2 | Outside Rearview Mirror Inner Actuator Procedure Inspect the outside rearview mirror inner actuator for proper operation before installing the mirror glass. |
| WARNING |
|---|
| Refer to Glass and Sheet Metal Handling Warning . |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Outside Rearview Mirror Inner Actuator Replacement
Scheme 10
| Callout | Component Name |
|---|---|
| 1 | Outside Rearview Mirror Glass Retainers (Qty :6) WARNING: Refer to Glass and Sheet Metal Handling Warning . Procedure Apply several layers of masking tape to the bottom and inner edge of the outside rearview mirror housing in order to protect the painted finish. DO Not use the tool (flat plastic) to pry with, it Must be used in a twisting motion counter clockwise only to release the mirror glass from the inner actuator. Retain pressure on the top inner corner of the mirror glass (2). Insert a suitable tool (flat plastic) between the two tabs (1) located behind the glass. Twist the suitable tool (flat plastic) until the mirror glass releases from the inner actuator. Disconnect electrical connectors from mirror glass. |
| 2 | Outside Rearview Mirror Glass Procedure Align the mirror glass retaining tabs with the inner actuator. Place your hand on the back of the mirror housing. Using the flat part of your hand press inward on the mirror glass until the tabs are fully seated on the inner actuator retainers. Inspect the outside rearview mirror for proper operation before installing the door trim. |
| WARNING |
|---|
| Refer to Glass and Sheet Metal Handling Warning . |
Outside Rearview Mirror Glass Replacement
Scheme 11
| Callout | Component Name |
|---|---|
| 1 | Inside Rearview Mirror Set Screw CAUTION: Refer to Fastener Caution . Procedure Adjust the mirror to the full upward position. Loosen the set screw located at the base of the mirror. Slide the mirror upward off of the rearview mirror button. Tighten 1.8 N.m (16 lb in) |
| 2 | Inside Rearview Mirror |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Inside Rearview Mirror Replacement
Scheme 12
- Determine the location of the mirror mounting base by marking the outside of the windshield with a marking pencil where the base was previously located. If it is not clear where the base was mounted, use the following steps to determine where the base should be installed: Using a measuring tape, measure the distance between the windshield pillars from the base of the shade line. Using a marking pencil, halfway between the windshield pillars, draw a centerline (1) on the windshield from the roof panel to the windshield base. Draw a perpendicular line intersecting the centerline (2) at that location. The top center of the mirror mounting base will be at the intersection of these lines.
- Scrape the inside windshield glass thoroughly with a safety razor or utility knife in order to remove all old adhesive.
- If reinstalling the original mounting base, place the mirror mounting base in a suitable holding device, such as a vice.
- Scrape the mirror mounting base thoroughly with a safety razor or utility knife in order to remove all old adhesive.
- Clean the inside windshield glass and the mounting surface of the mirror mounting base thoroughly with a clean cloth saturated with naphtha or a 50/50 mixture (by volume) of clean water and isopropyl alcohol.
- Using the Inside Mirror Adhesive Kit, or equivalent to apply a small amount of activator to the mounting surface of the mirror mounting base.
- Apply a small amount of activator to the windshield where the mounting base is to be installed.
- Allow the activator to dry 5 minutes.
- Apply 1 drop of adhesive to the center of the mirror mounting base.
- Immediately apply the mounting base to the windshield, ensuring that the mounting base aligns correctly to the marks made on the outside of the windshield.
- Hold the mounting base firmly in place for 1 minute.
- Allow the adhesive to set for 15 minutes.
- Install the mirror to the mirror mounting base and fasten, if necessary.
- Connect the electrical connector and install the wire cover, if equipped.
Heated Mirrors (If Equipped)
The heated mirrors are controlled through the rear defog relay. Whenever the rear window defogger is turned on battery voltage is supplied to the mirror heater elements through the left and right mirror heater element control circuits.
