Object Detection System - Park Assist System: Removal & Installation Chevrolet Volt I

Collision/avoidance 1 illustration ~216 words

Removal Procedure

  1. Remove front bumper fascia. Refer to «Front Bumper Fascia Removal and Installation»(ref-487445-S38885068162012072300000) .
  2. Disconnect electrical from the front object alarm sensor.
  3. Lift the locking tabs on the housing and remove the front object alarm sensor.

Installation Procedure

  1. Paint the front object alarm sensor. Refer to «Basecoat/Clearcoat Paint Systems»(ref-487471-S05875387442012072300000) .
  2. Ensure the paint does not exceed 6 mils. Use a paint thickness gauge suitable for non-ferrous metals. Refer to «Paint Gauges»(ref-487471-S37323622532012072300000) .
  3. Insert the sensor into the housing.
  4. Connect the electrical connector to the front object alarm sensor.
  5. Install the front bumper fascia. Refer to «Front Bumper Fascia Removal and Installation»(ref-487445-S38885068162012072300000) .
  1. Remove rear bumper fascia. Refer to «Rear Bumper Fascia Removal and Installation»(ref-487445-S23781135642012072300000) .
  2. Disconnect electrical from the rear object sensor.
  3. Lift the locking tabs on the housing and remove the rear object sensor.
  1. Paint the rear object sensor. Refer to «Basecoat/Clearcoat Paint Systems»(ref-487471-S05875387442012072300000) .
  2. Ensure the paint does not exceed 6 mils. Use a paint thickness gauge suitable for non-ferrous metals. Refer to «Paint Gauges»(ref-487471-S37323622532012072300000) .
  3. Insert the sensor into the housing.
  4. Connect the electrical connector to the rear object sensor.
  5. Install the rear bumper fascia. Refer to «Rear Bumper Fascia Removal and Installation»(ref-487445-S23781135642012072300000) .

Scheme 4

Scheme 4: Rearview Camera Image Display Module Replacement
Scheme 4: Rearview Camera Image Display Module Replacement
CalloutComponent Name
Preliminary Procedure Remove the rear bumper fascia. Refer to Rear Bumper Fascia Removal and Installation .
1Rearview Camera Image Display Module Screw (Qty: 2) CAUTION: Refer to Fastener Caution .
2Rearview Camera Image Display Module Procedure Disconnect the electrical connector.
CAUTION
Refer to Fastener Caution .

Rearview Camera Image Display Module Replacement
