Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| 300-Volt Battery Positive and Negative Cable Bolt (Drive Motor Battery-to-APM Module) | 9 N.m | 80 lb in |
| 300-Volt Battery Positive and Negative Cable Bolt (Drive Motor Battery-to-Inverter) | 9 N.m | 80 lb in |
| Accessory DC Power Control Module Bolts | 19 N.m | 14 lb ft |
| Accessory DC Power Control Module Nuts | 22 N.m | 16 lb ft |
| Accessory DC Power Control Module Ground Cable Nut | 22 N.m | 16 lb ft |
| Accessory DC Power Control Module to Battery Fuse Block Nut | 22 N.m | 16 lb ft |
| Accessory DC Power Control Module Nut to Rear Floor Panel Nut | 10 N.m | 89 lb in |
| Drive Motor Generator Power Inverter Module Bolts | 9 N.m | 80 lb in |
| Drive Motor Generator Power Inverter Module Cover Bolts | 9 N.m | 80 lb in |
| Drive Motor Generator Power Inverter Module Fitting Bolts | 3 N.m | 27 lb in |
| Drive Motor Power Inverter Module Cable Replacement - First Position | 9 N.m | 80 lb in |
| Drive Motor Power Inverter Module Cable Replacement - Second Position | 9 N.m | 80 lb in |
| Drive Motor Generator Power Inverter Module Ground Cable Bolt | 9 N.m | 80 lb in |
| Engine Wiring Harness Ground Cable Bolt | 9 N.m | 80 lb in |
| High Voltage Interlock Loop Connector Bolts | 6 N.m | 53 lb in |
Fastener Tightening Specifications
Scheme 95
Scheme 95: Power, Ground and Data Communication Wiring Schematics
Scheme 96
Scheme 96: Drive Motors Monitoring Wiring Schematics
Scheme 97
Scheme 97: Transmission Internal Mode Switch Wiring Schematics
Scheme 98
Scheme 98: Drive Motors and Transmission Fluid Pump Controls Wiring Schematics
Scheme 99
Scheme 99: Hybrid Control Electronic Component Views
| Callout | Component Name |
|---|
| 1 | Drive Motor Battery High Voltage Manual Disconnect Lever |
| 2 | Drive Motor Battery Assembly |
| 3 | Heater Coolant Heater |
| 4 | Battery Positive and Negative (300 V) Cable Assembly - Inverter to Coolant Heater |
| 5 | Battery Positive and Negative (300 V) Cable Assembly - Charger to Charge Receptacle |
| 6 | Battery Positive and Negative (300 V) Cable Assembly - Inverter to Drive Motor Battery |
| 7 | Drive Motor Power Inverter Module Assembly |
| 8 | Drive Motor Power Inverter Module 3 Phase Cable Assembly - B |
| 9 | Drive Motor Power Inverter Module 3 Phase Cable Assembly - A |
| 10 | Battery Positive and Negative (300 V) Cable Assembly - Inverter to Cooling Compressor |
| 11 | Automatic Transmission |
| 12 | AC and Drive Motor Battery Cooling Compressor Assembly |
| 13 | Drive Motor Battery Charger Assembly |
| 14 | Battery Positive and Negative (300 V) Cable Assembly - Drive Motor Battery to Charger |
| 15 | Battery Positive and Negative (300 V) Cable Assembly - Drive Motor Battery to APM Module |
| 16 | Accessory DC Power Control Module Assembly |
Scheme 100
Scheme 100: High Voltage Ring Terminal Locator
| Callout | Component Name |
|---|
| 1 | Drive Motor Generator Battery 300 V B |
| 2 | Drive Motor Generator Battery 300 V B+ |
| 3 | Motor 3 Phase U |
| 4 | Motor 3 Phase V |
| 5 | Motor 3 Phase W |
| 6 | Motor 2 Phase V |
| 7 | Motor 2 Phase U |
| 8 | Motor 2 Phase W |
| 9 | Motor 1 Phase V |
| 10 | Motor 1 Phase U |
| 11 | Motor 1 Phase W |
| 12 | Cabin Conditioning 300 V B+ |
| 13 | Cabin Conditioning 300 V B |
