Engine Controls - Service & Adjustment Specifications: Other Chevrolet Venture I

Specifications 5 illustrations ~284 words

BELT TENSION

Application(1) Belt Deflection
1.6L
A/C Compressor.236-.354" (6-9 mm)
Generator/Water Pump
New Belt.197-.278" (5-7 mm)
Used Belt (2).236-.315" (6-8 mm)
Power Steering Pump.236-.354" (6-9 mm)
2.0L
Accessory Drive Belt(3)
Cooling Fan
New Belt.157-.197" (4-5 mm)
Used Belt (2).197-.276" (5-7 mm)
All Others (Serpentine Belt)(3)
(1) Deflection is with 22 lbs. (10 kg) pressure applied midway on longest belt run. (2) Used belt is a belt in operation for more than 5 minutes. (3) Adjustment of serpentine belt is not necessary. Belt tension is maintained by spring-tensioned idler pulley (some equipped with belt wear indicator).
(1)Deflection is with 22 lbs. (10 kg) pressure applied midway on longest belt run.
(2)Used belt is a belt in operation for more than 5 minutes.
(3)Adjustment of serpentine belt is not necessary. Belt tension is maintained by spring-tensioned idler pulley (some equipped with belt wear indicator).

BELT ADJUSTMENT

ENGINE COMPRESSION

ApplicationSpecification
Normal Compression Pressure
1.6L & 2.0L199 psi (14.0 kg/cm 2 )
2.2L, 3.4L, 4.3L, 4.8L, 5.0L, 5.3L, 5.7L, 6.0L & 7.4L(1)
6.5L(2)
Minimum Compression Pressure
1.6 & 2.0L170 psi (12.0 kg/cm 2 )
2.2L, 3.4L, 4.3L, 4.8L, 5.0L, 5.3L, 5.7L, 6.0L & 7.4L(1)
6.5L(2)
(1) Lowest compression reading should not be less than 70 percent of highest compression reading. No cylinder compression reading should be less than 100 psi (7 kg/cm 2 ). (2) Lowest compression reading should not be less than 80 percent of highest compression reading. No cylinder compression reading should be less than 370 psi (27 kg/cm 2 ).
(1)Lowest compression reading should not be less than 70 percent of highest compression reading. No cylinder compression reading should be less than 100 psi (7 kg/cm 2 ).
(2)Lowest compression reading should not be less than 80 percent of highest compression reading. No cylinder compression reading should be less than 370 psi (27 kg/cm 2 ).

ENGINE COMPRESSION SPECIFICATIONS

VALVE CLEARANCE

ApplicationIn. (mm)
1.6L
Intake
Cold.005-.007 (.13-.17)
Hot.007-.008 (.17-.21)
Exhaust
Cold.009-.011 (.23-.27)
Hot.011-.013 (.28-.32)
All Others(1)
(1) Equipped with hydraulic lifters. Adjustment is not required.
(1)Equipped with hydraulic lifters. Adjustment is not required.

VALVE CLEARANCE SPECIFICATIONS

IGNITION COIL

ApplicationOhms
1.6L8500-11,500
All Others(1)
(1) Information is not available from manufacturer.
(1)Information is not available from manufacturer.

IGNITION COIL RESISTANCE

HIGH TENSION WIRE RESISTANCE

ApplicationOhms
1.6L1200-3000 Per Ft.
2.0L(1)
3.4L600 Per Ft.
All Others30,000 Maximum
(1) Not equipped with high tension secondary wires.
(1)Not equipped with high tension secondary wires.

HIGH TENSION WIRE RESISTANCE

SPARK PLUGS

ApplicationTypePart No.
1.6LDensoK20PR-U11
NGKBKR6E-11
2.0LDensoSK16PR11 Or PK16PR11
NGKIFR5G11 Or PFR5G-11
2.2LAC41-948
3.4LAC41-940
4.3LACCR43TSM
4.8L, 5.0L, 5.3L, 5.7L, 6.0L & 7.4LAC41-932

SPARK PLUG TYPE

ApplicationGap In. (mm)Torque Ft. Lbs. (N.m)
1.6L & 2.0L.039-.043 (1.0-1.1)18 (25)
2.2L.050 (1.27)11 (15)
3.4L.060 (1.52)20 (27)
4.3L
VIN W.060 (1.52)(1) 11 (15)
VIN X.045 (1.14)(1) 11 (15)
4.8L, 5.0L, 5.3L, 5.7L & 6.0L.060 (1.52)(2) 11 (15)
7.4L.060 (1.52)(2) 15 (20)
(1) Tighten spark plugs to 22 ft. lbs. (30 N.m) if installing into NEW cylinder head. (2) Tighten spark plugs to 22 ft. lbs. (30 N.m) when using NEW iron cylinder head. Tighten spark plugs to 15 ft. lbs. (20 N.m) when using NEW aluminum cylinder head.
(1)Tighten spark plugs to 22 ft. lbs. (30 N.m) if installing into NEW cylinder head.
(2)Tighten spark plugs to 22 ft. lbs. (30 N.m) when using NEW iron cylinder head. Tighten spark plugs to 15 ft. lbs. (20 N.m) when using NEW aluminum cylinder head.

SPARK PLUG SPECIFICATIONS

FIRING ORDER

Note. For firing order, refer to appropriate illustration. (Scheme 1)- (Scheme 5).

Scheme 1

Scheme 1: Firing Order (1.6L, 2.0L & 2.2L)

Scheme 2

Scheme 2: Firing Order, Cylinder Identification & Spark Plug Wire Routing (3.4L)

Scheme 3

Scheme 3: Firing Order, Cylinder Identification & Spark Plug Wire Routing (4.3L)

Scheme 4

Scheme 4: Firing Order & Cylinder identification (4.8L, 5.3L, 6.0L & 6.5L Diesel)

Scheme 5

Scheme 5: Firing Order, Cylinder Identification & Spark Plug Wire Routing (5.0L, 5.7L & 7.4L)

IGNITION TIMING (GASOLINE)

All models are equipped with an electronic computer-controlled ignition system. Timing on this system is only adjustable on Tracker equipped with 2.0L engine. Timing should be set to 5 degrees BTDC. For adjustment procedure, see ON-VEHICLE ADJUSTMENTS - TRUCKS - EXCEPT TRACKER article.

INJECTION PUMP TIMING (DIESEL)

Injection pump timing can be checked using scan tool. See DIESEL INJECTION PUMP TIMING table. For adjustment procedure, see ON-VEHICLE ADJUSTMENTS - TRUCKS - EXCEPT TRACKER article.

ApplicationRPMDegrees BTDC
6.5LIdle3.5

DIESEL INJECTION PUMP TIMING

FUEL PUMP

ApplicationPsi (kg/cm 2 )
1.6L & 2.0L(1) 36-43 (2.5-3.0)
2.2L41-47 (2.9-3.3)
3.4L52-59 (3.7-4.1)
4.3L, 5.0L & 5.7L60-66 (4.2-4.6)
4.8L, 5.3L, 6.0L & 7.4L55-62 (4.0-4.4)
(1) Pressure should maintain at least 26 psi (1.8 kg/cm 2 ) for one minute after fuel pump is turned off.
(1)Pressure should maintain at least 26 psi (1.8 kg/cm 2 ) for one minute after fuel pump is turned off.

FUEL PUMP PERFORMANCE

INJECTOR RESISTANCE

ApplicationOhms
1.6L & 2.0L13-16
2.2L2.0-2.3
3.4L11.4-12.6
4.8L, 5.3L & 6.0L11.8-12.6
All Others(2)
(1) Injector resistance specification is at 50-95°F (10-35°C). (2) Resistance values are not available from manufacturer. To check fuel injectors, perform appropriate injector test. See FUEL SYSTEM in appropriate SYSTEM & COMPONENT TESTING article.
(1)Injector resistance specification is at 50-95°F (10-35°C).
(2)Resistance values are not available from manufacturer. To check fuel injectors, perform appropriate injector test. See FUEL SYSTEM in appropriate SYSTEM & COMPONENT TESTING article.

INJECTOR RESISTANCE SPECIFICATIONS (1)

IDLE SPEED & MIXTURE

Note. Idle speed and mixture is not adjustable on vehicles equipped with diesel engines.

Idle mixture on fuel injected models is controlled by PCM and is not adjustable. Controlled idle speed and IAC count can be checked using scan tool. See CONTROLLED IDLE SPEED & IAC COUNT table. For controlled idle speed adjustment procedures, see appropriate ON-VEHICLE ADJUSTMENTS article.

ApplicationIdle RPMIAC Counts
1.6L & 2.0L725-775(1) 17-30
2.2L(2)5-60
3.4LVariesVaries
4.3L65018
4.8L, 5.3L & 6.0L(2)Varies
5.0L & 5.7L65048
7.4L65060
(1) Specification is duty cycle percentage. (2) Information is not available from manufacturer.
(1)Specification is duty cycle percentage.
(2)Information is not available from manufacturer.

CONTROLLED IDLE SPEED & IAC COUNT

THROTTLE POSITION (TP) SENSOR

Note. On 6.5L diesel engines, throttle control is electronic with NO mechanical link from engine to accelerator pedal. The PCM monitors the position of accelerator pedal based on signals from a nonadjustable Accelerator Pedal Position (APP) module. The APP module is mounted above the accelerator pedal.

ApplicationVoltage
1.6L & 2.0L.50-.80
2.2L.20-.90
3.4L.20-.74
4.3L, 5.0L, 5.7L & 7.4L.47
4.8L, 5.3L & 6.0L.40-.90
(1) Specification is with engine idling (throttle closed) at normal operating temperature.
(1)Specification is with engine idling (throttle closed) at normal operating temperature.

THROTTLE POSITION (TP) SENSOR VOLTAGE (1)
