Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| A/C Condenser Tube Clip Screw | 6 N.m | 53 lb in |
| Coolant Heater | 50 N.m | 37 lb ft |
| Cooling Fan Shroud Bolts | 6 N.m | 53 lb in |
| Discharge Hose to Condenser Block Nut | 16 N.m | 12 lb ft |
| Engine Block Drain Plug | 22 N.m | 16 lb ft |
| Engine Mount Strut Bracket Bolt - Upper Radiator Support | 28 N.m | 21 lb ft |
| Engine Mount Strut Nut | 48 N.m | 35 lb ft |
| Evaporator Inlet Tube to Condenser Bolt | 16 N.m | 12 lb ft |
| Radiator Drain Cock | 2 N.m | 18 lb in |
| Radiator Lower Air Deflector Bolt | 20 N.m | 15 lb ft |
| Radiator to Condenser Bolt | 2.5 N.m | 22 lb in |
| Radiator Upper Mount Bolt | 10 N.m | 89 lb in |
| Thermostat Bypass Pipe Bolt | 11 N.m | 98 lb in |
| Thermostat Bypass Pipe Nut | 25 N.m | 18 lb ft |
| Thermostat Housing Bolt | 25 N.m | 18 lb ft |
| Water Pump Bolt | 10 N.m | 89 lb in |
| Water Pump Pulley Bolt | 25 N.m | 18 lb ft |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Engine Cooling Schematics
Scheme 2
Scheme 2: Cooling System Component Views
| Callout | Component Name |
|---|
| 1 | Hood Ajar Switch (AP3) |
| 2 | Inflatable Restraint Front End Sensor - Left |
| 3 | Horn - Left |
| 4 | Cooling Fan - Left |
| 5 | Cooling Fan - Right |
| 6 | Ambient Air Temperature Sensor (UH8 or UH9) |
| 7 | Horn - Right |
| 8 | Inflatable Restraint Front End Sensor - Right |
| 9 | Hood Ajar Switch Connector (AP3) |
Scheme 3
Scheme 3: Multifunction Switch - Overhead Console C1 (E58)
| Connector Part Information OEM: 12041301 Service: 12102481 Description: 8-Way F Metri-Pack 280 Series (BK) |
|---|
| Terminal Part Information Terminal: 12034046/Tray 2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094430/J-35616-4A |
Cooling System Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | GY | 8 | Instrument Panel Lamp Supply Voltage |
| B | BK | 750 | Ground |
| C | L-BU/BK | 2618 | Left Sliding Door Open/Close Switch Signal (E59) |
| D | BK/WH | 2619 | Left Sliding Door Enable Switch Signal (E59) |
| E | | | Not Used |
| F | TN/WH | 1896 | Right Sliding Door Enable Switch Signal |
| G | L-BU | 1894 | Right Sliding Door Open/Close Switch Signal |
| H | | | Not Used |
Multifunction Switch - Overhead Console C1 (E58)
Scheme 4
Scheme 4: Multifunction Switch - Overhead Console C2 (A20)
| Connector Part Information OEM: 12047976 Service: 12102480 Description: 8-Way F Metri-Pack 280 Series (BU) |
|---|
| Terminal Part Information Terminal: 12034046/Tray 2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094430/J-35616-4A |
Cooling System Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | GY | 8 | Instrument Panel Lamp Supply Voltage |
| B | BK | 750 | Ground |
| C | TN | 1018 | Power Window Motor Rear Vents Open Control |
| D | BN | 1019 | Power Window Motor Rear Vents Close Control |
| E | YE | 643 | Accessory Voltage |
| F | GY | 2616 | Rear Parking Assist Disable Switch Signal |
| G-H | | | Not Used |
Multifunction Switch - Overhead Console C2 (A20)
Scheme 5
Scheme 5: Rear Quarter Window Actuator - Left (A20)
| Connector Part Information OEM: 12052832 Service: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal: 12047767/Tray 2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-2A |
Cooling System Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | BN | 1019 | Power Window Motor Rear Vents Close Control |
| B | TN | 1018 | Power Window Motor Rear Vents Open Control |
Rear Quarter Window Actuator - Left (A20)
