Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| AC/DC Power Outlet Control Module Bracket Nuts | 10 N.m | 89 lb in |
| AC/DC Power Outlet Control Module Bracket Screw/Bolt | 10 N.m | 89 lb in |
| AC/DC Power Outlet Control Module Screw/Bolt | 2 N.m | 18 lb in |
| AC/DC Power Outlet Receptacle Screw/Bolt | 2 N.m | 18 lb in |
Fastener Tightening Specifications
Scheme 83
Scheme 83: Cigar Lighter/Auxiliary Outlets Schematics
Scheme 84
Scheme 84: Power Outlet Component Views
| Callout | Component Name |
|---|
| 1 | Steering Wheel Control Switch Assembly - Right (UK3) |
| 2 | Instrument Panel Cluster (IPC) |
| 3 | Multifunction Switch - I/P |
| 4 | Theft Light Emitted Diode (LED) (UA6) |
| 5 | Ambient Light Sensor |
| 6 | Hazard Switch |
| 7 | Inflatable Restraint PASSENGER AIR BAG ON/OFF Indicator |
| 8 | Inflatable Restraint I/P Module |
| 9 | Radio |
| 10 | HVAC Control Module |
| 11 | Cigar Lighter |
| 12 | Cruise Control Lever (K34) |
| 13 | Inflatable Restraint Steering Wheel Module |
| 14 | Steering Wheel Control Switch Assembly - Left (Uk3) |
| 15 | Headlamp Switch |
| 16 | Turn Signal/Multifunction Switch |
Scheme 85
| Callout | Component Name |
|---|
| 1 | Automatic Level Control (ALC) Solenoid Valve (G67 w/o Z10) |
| 2 | ALC Harness (G67) |
| 3 | Auxiliary Power Outlet - Rear |
| 4 | Automatic Level Control (ALC) Inflator Air Switch (G67 w/o Z10) |
| 5 | Left Rear Cargo Trim Panel |
Scheme 86
| Callout | Component Name |
|---|
| 1 | Speaker - Rear Tweeter - Right |
| 2 | Accessory AC/DC Power Control Module (KC7) |
| 3 | C420 Rear Parking Assist Display Jumper Harness to Body Harness (UD7) |
| 4 | Rear Quarter Window Actuator - Right (A20) |
| 5 | C402 and C400 Liftgate Harness to Body Harness |
| 6 | Rear Parking Assist (RPA) Display (UD7) |
| 7 | G400 |
| 8 | Auxiliary Power Outlet - 115VAC (KC7) |
| 9 | Sliding Door Jamb Switch - Right |
| 10 | Rear Object Sensor Control Module (UD7) |
| 11 | Rear Parking Assist (RPA) Diagnostic Connector (UD7) |
Scheme 87
Scheme 87: Accessory AC/DC Power Control Module C1 (KC7)
| Connector Part Information OEM: 6098-4542 Service: See Catalog Description: 6-Way F Receptacle 6.3 (OG) |
|---|
| Terminal Part Information Terminal: Not Serviced in Kit Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A |
Power Outlet Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | | | Not Used |
| 2 | D-BU | 6807 | 120 VAC Inverter Control |
| 3 | | | Not Used |
| 4 | RD | 5684 | APO Neutral |
| 5 | | | Not Used |
| 6 | BK | 5683 | APO Phase A |
Accessory AC/DC Power Control Module C1 (KC7)
Scheme 88
Scheme 88: Accessory AC/DC Power Control Module C2 (KC7)
| Connector Part Information OEM: 15473590 Service: 88987988 Description: 2-Way F Receptacle 6.3 (BK) |
|---|
| Terminal Part Information Terminal: 7116-4122-02/Tray 10 Core/Insulation Crimp: D/G Release Tool/Test Probe: 12094430/J-35616-42 |
Power Outlet Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | BK | 1750 | Ground |
| 2 | BK/RD | 1342 | Battery Positive Voltage |
Accessory AC/DC Power Control Module C2 (KC7)
Scheme 89
Scheme 89: Auxiliary Power Outlet - 115VAC (KC7)
| Connector Part Information OEM: 6098-4536 Service: See Catalog Description: 6-Way F (OG) |
|---|
| Terminal Part Information Terminal: Not Serviced in Kit Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A |
Power Outlet Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | D-BU | 6807 | 120 VAC Inverter Control |
| 2 | | | Not Used |
| 3 | RD | 5684 | APO Neutral |
| 4 | BN | 1141 | Ignition 3 Voltage |
| 5 | | | Not Used |
| 6 | BK | 5683 | APO Phase A |
Auxiliary Power Outlet - 115VAC (KC7)
Scheme 90
Scheme 90: Auxiliary Power Outlet - Rear
| Connector Part Information OEM: 12176836 Service: 15305923 Description: 3-Way F Metri-Pack 280 Series (GY) |
|---|
| Terminal Part Information Terminal: 12110844/Tray 4 Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: 15315247/J-35616-4A |
Power Outlet Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | RD/WH | 2540 | Battery Positive Voltage |
| B | | | Not Used |
| C | BK | 550 | Ground |
Auxiliary Power Outlet - Rear
