Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Inside Rearview Mirror | 2 N.m | 18 lb in |
| Outside Rearview Mirror Bolts | 10 N.m | 89 lb in |
| Outside Rearview Mirror Motor Screws | 10 N.m | 89 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Inside Rearview Mirror Schematics
Scheme 2
Scheme 2: Outside Rearview Mirror Schematics
Scheme 3
Scheme 3: Mirror Component Views
| Callout | Component Name |
|---|
| 1 | Headlamp - Low Beam - Right |
| 2 | Headlamp - High Beam - Right |
| 3 | Cellular Antenna (UE1) |
| 4 | Headlamp - High Beam - Left |
| 5 | Headlamp - Low Beam - Left |
| 6 | Outside Rearview Mirror - Driver |
| 7 | Marker Lamp - LF |
| 8 | Park/Turn Signal Lamp - LF |
| 9 | Cornering Lamp - Left (Z88) |
| 10 | Fog Lamp - LF (T96) |
| 11 | Fog Lamp - RF (T96) |
| 12 | Cornering Lamp - Right (Z88) |
| 13 | Park/Turn Signal Lamp - RF |
| 14 | Marker Lamp - RF |
| 15 | Radio Antenna |
| 16 | Outside Rearview Mirror - Passenger |
Scheme 4
| Callout | Component Name |
|---|
| 1 | Radio Antenna |
| 2 | Headlamp - High Beam - Right |
| 3 | Headlamp - Low Beam - Right |
| 4 | Headlamp - Low Beam - Left |
| 5 | Cellular Antenna (UE1) |
| 6 | Headlamp - High Beam - Left |
| 7 | Outside Rearview Mirror - Driver |
| 8 | Marker Lamp - LF |
| 9 | Park/Turn Signal lamp - LF |
| 10 | Fog Lamp - LF (T96) |
| 11 | Fog Lamp - RF (T96) |
| 12 | Park/Turn Signal lamp - RF |
| 13 | Marker Lamp - RF |
| 14 | Outside Rearview Mirror - Passenger |
Scheme 5
| Callout | Component Name |
|---|
| 1 | Radio Antenna |
| 2 | Digital Radio Antenna |
| 3 | Cellular Antenna (UE1) |
| 4 | Outside Rearview Mirror - Driver |
| 5 | Park Lamp - LF |
| 6 | Park Lamp - LF |
| 7 | Headlamp - High Beam - Left |
| 8 | Marker Lamp - LF |
| 9 | Cornering Lamp - Left |
| 10 | Fog Lamp - LF (T96) |
| 11 | Headlamp - Low Beam - Left |
| 12 | Turn Signal Lamp - LF |
| 13 | Turn Signal Lamp - RF |
| 14 | Headlamp - Low Beam - Right |
| 15 | Fog Lamp - RF (T96) |
| 16 | Cornering Lamp - Right |
| 17 | Marker Lamp - RF |
| 18 | Headlamp - High Beam - Right |
| 19 | Park Lamp - RF |
| 20 | Park Lamp - RF |
| 21 | Outside Rearview Mirror - Passenger |
Scheme 6
| Callout | Component Name |
|---|
| 1 | Connector (Headliner Harness) |
| 2 | Inside Rearview Mirror |
Scheme 7
Scheme 7: Inside Rearview Mirror
| Connector Part Information OEM: 15324871 Service: 15306351 Description: 16-Way F 040 II Series Unsealed (BK) |
|---|
| Terminal Part Information Pins: 3, 4, 6, 7, 8, 9, 11, 12, 13, 14, 15 Terminal/Tray: 175266-5/15 Core/Insulation Crimp: J/J Release Tool/Test Probe: 15315247/J-35616-16 (L-GN) |
Inside Rearview Mirror Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1-2 | | | Not Used |
| 3 | D-BU | 2307 | Passenger Air Bag On Indicator Control (AL0) |
| 4 | D-GN | 2308 | Passenger Air Bag Off Indicator Control (AL0) |
| 5 | | | Not Used |
| 6 | L-GN/BK | 735 | Ambient Air Temperature Sensor Signal (DD7/DF5) |
| 7 | BN | 718 | Low Reference (DD7/DF5) |
| 8 | BK | 1350 | Ground (DD7/DF5) |
| 9 | L-GN | 24 | Backup Lamp Supply Voltage (DD7/DF5) |
| 10 | | | Not Used |
| 11 | D-GN/WH | 2514 | Keypad Signal (w/UE1) |
| 12 | L-GN/BK | 2515 | Keypad Supply Voltage (w/UE1) |
| 13 | PK | 639 | Ignition 1 Voltage (AL0/DD7/DF5) |
| 14 | YE/BK | 2516 | Keypad Green LED Signal (w/UE1) |
| 15 | BN/WH | 2517 | Keypad Red LED Signal (w/UE1) |
| 16 | | | Not Used |
Inside Rearview Mirror Connector Terminal Identification
