Scheme 148
Scheme 148: Shift Lock Control Schematics
Scheme 149
Scheme 149: Shift Lock Control Component Views
| Callout | Component Name |
|---|
| 1 | Lower Console |
| 2 | Automatic Transmission Shift Lock Actuator |
Scheme 150
Scheme 150: Automatic Transmission Shift Lock Actuator
| Connector Part Information OEM: 12064762 Service: 12125665 Description: 6-Way F Metri-Pack 150 Series Unealed (L-GY) |
|---|
| Terminal Part Information Pins: A-C, E-F Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit |
Automatic Transmission Shift Lock Actuator Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | BK | 150 | Ground |
| B | RD | 275 | A/T Shift Lock Control Switch Supply Voltage |
| C | PU | 961 | Remote Shift Selector Signal |
| D | | | Not Used |
| E | OG | 1135 | A/T Shift Lock Control Solenoid Supply Voltage |
| F | YE | 1020 | Ignition 3 Voltage |
Automatic Transmission Shift Lock Actuator Connector Terminal Identification
