Engine Control System - Self-Diagnostics - 5.3L: Diagnosis Chevrolet TrailBlazer I

ON-BOARD DIAGNOSTICS

PCM is equipped with a self-diagnostic system which detects system failures or abnormalities. When a malfunction occurs, PCM will store a Diagnostic Trouble Code (DTC) and, in most cases, illuminate the Malfunction Indicator Light (MIL) located on instrument cluster.

There are 2 paths for accessing on-board diagnostics. It is necessary to access information through both paths, as each path presents some different information.

1. Generic OBD-II This provides all generic codes and some OEM codes, serial data PIDs required for generic OBD-II and some OEM PIDs, monitor status, pending codes and freeze frame.
2. OEM All DTCs, all PIDs, failure records, enhanced scan tool information and all other OEM scanner functions.

Scan Tool Snapshot

The scan tool can be set up to take a snapshot of the parameters available via serial data. The snapshot function records live data over a period of time. The recorded data can be played back and analyzed. The scan tool can also graph parameters singly or in combinations of parameters for comparison. The snapshot can be triggered manually at the time the symptom is noticed, or set up in advance to trigger when a DTC sets. An abnormal value captured in the recorded data may point to a system or component that needs to be investigated further. Refer to the scan tool user instructions for more information on the Snapshot function.

DIAGNOSTIC STARTING POINT - ENGINE CONTROLS

Diagnosis of computerized engine control system should be performed in the following order

1. Ensure all engine systems not related to computer system are operating properly. DO NOT proceed with testing unless all other problems have been repaired. Diagnostic system check must be performed before using specific DTC testing procedure. See «DIAGNOSTIC SYSTEM CHECK - ENGINE CONTROLS»(ref-158882-S07978614742003102900000) .
2. If no DTCs are present and a driveability problem exists, see «SYMPTOMS»(ref-152986-S01524682752003030700000) in TROUBLE SHOOTING - NO CODES - 4.8L, 5.3L & 6.0L "C", "G", "H", "K", "N", "S" & "T" SERIES - FLEX FUEL & GASOLINE article. Doing so will help identify proper system or component to check in «SYSTEM & COMPONENT TESTING - 4.8L, 5.3L & 6.0L "C", "G", "H", "K", "N", "S" & "T" SERIES - FLEX FUEL & GASOLINE»(ref-153204) article.
3. After necessary repairs are made, clear DTCs, verify vehicle will enter "closed loop" operation and ensure DTC does not reset.

Diagnostic Procedure

Note. Do not perform this diagnostic if there is not a driveability concern, unless another procedure directs you to this diagnostic. Before you proceed with diagnosis, search for applicable service bulletins. Unless a diagnostic procedure instructs you, do NOT clear the DTCs. If there is a condition with the starting system, see appropriate STARTERS article in ELECTRICAL. Ensure the battery has a full charge. Ensure the battery cables are clean and tight. Ensure the PCM grounds are clean, tight, and in the correct location.

1. Install a scan tool. Does the scan tool turn ON? If yes, go to next step. If no, see SCAN TOOL DOES NOT POWER UP in appropriate BODY CONTROL MODULES article in ACCESSORIES & EQUIPMENT.
2. Turn ON the ignition, with the engine OFF. Attempt to establish communication with the listed control modules. If you are using a Tech 2(R), obtain the information using the Class 2 Message Monitor feature: PCM. Body Control Module (BCM). Instrument Panel (IP) cluster. Electronic Brake Control Module (EBCM). Driver Information Center (DIC). Heating, Ventilation, and Air Conditioning (HVAC). Does the scan tool communicate with all the listed control modules? If yes, go to next step. If no, see SCAN TOOL DOES NOT COMMUNICATE WITH CLASS 2 DEVICE in appropriate BODY CONTROL MODULES article in ACCESSORIES & EQUIPMENT.
3. Access CLASS 2 POWER MODE in DIAGNOSTIC CIRCUIT CHECK on scan tool. Rotate ignition switch through all positions while observing IGNITION SWITCH POWER MODE parameter. Actual ignition switch position should match IGNITION SWITCH POWER MODE parameter on scan tool. (Scheme 209) Do all ignition switch positions match all IGNITION SWITCH POWER MODE parameters on scan tool? If yes, go to next step. If no, see «POWER MODE MISMATCH»(ref-158882-S03417233572003102900000).
4. Attempt to start the engine. Does the engine start and idle? If yes, go to next step. If no, see «NO-START DIAGNOSIS»(ref-152751-S39268930542003022400000) in BASIC DIAGNOSTIC PROCEDURES - 4.8L, 5.3L & 6.0L "C", "G", "H", "K", "N", "S" & "T" SERIES - FLEX FUEL & GASOLINE article.
5. Select the DTC display function for the following control modules: PCM, BCM, IP Cluster, EBCM, DIC and HVAC. Does the scan tool display any DTCs? If yes, go to next step. If no, go to step 10.
6. Using a scan tool, select CAPTURED INFO in order to store the powertrain DTC information. When complete, go to next step.
7. Does the scan tool display DTCs which begin with a "U"? If yes, see appropriate BODY CONTROL MODULES article in ACCESSORIES & EQUIPMENT for diagnosis. If no, go to next step.
8. Does the scan tool display DTC P0601, P0602, P0604 or P0606? If yes, see «DTC P0601-P0607, P1600, P1621, P1627, P1680, P1681, P1683 & P2610: PCM MEMORY»(ref-158882-S29362106252003102900000) under DIAGNOSTIC TESTS. If no, go to next step.
9. Does the scan tool display DTC P0562, P0563, P1637 or P1638? If yes, see appropriate GENERATORS & REGULATORS article in STARTING & CHARGING SYSTEMS. If no, see «DIAGNOSTIC TROUBLE CODE DEFINITIONS»(ref-158882-S38387953612003102900000).
10. Is the customer's concern with the automatic transmission? If yes, see appropriate DIAGNOSIS article in AUTOMATIC TRANSMISSIONS. If no, go to next step.
11. Is the customer's concern with Inspection/Maintenance (I/M) testing? If yes, see «INSPECTION/MAINTENANCE SYSTEM CHECK»(ref-158882-S42355913272003102900000) under DRIVE CYCLES.
12. Review the following symptoms. Hard start, surges/chuggles, lack of power, sluggishness, sponginess, detonation/spark knock, hesitation, sag, stumble, cuts out, misses, poor fuel economy, poor fuel fill quality, rough, unstable, or incorrect idle and stalling, dieseling, run-on and backfire. Proceed to «SYMPTOMS»(ref-152986-S01524682752003030700000) in TROUBLE SHOOTING - NO CODES - 4.8L, 5.3L & 6.0L "C", "G", "H", "K", "N", "S" & "T" SERIES - FLEX FUEL & GASOLINE article. Did you find and correct the condition? If yes, system is okay. If no, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000).

Note. This procedure is used if the observed vehicle power mode does not match the actual ignition switch position. Open the driver's door and leave it open during this test. This will disable the RAP power mode and eliminate this power mode from the power mode parameter list.

1. Connect a scan tool to Data Link Connector (DLC). Turn OFF the ignition. Using a scan tool, under the DIAGNOSTIC CIRCUIT CHECK menu, observe the CLASS 2 POWER MODE parameter. Does the displayed power mode parameter match the actual ignition switch position? If yes, go to next step. If no, go to step 6 .
2. Turn the ignition switch to the UNLOCK position. Using a scan tool, under the DIAGNOSTIC CIRCUIT CHECK menu, observe the CLASS 2 POWER MODE parameter. Does the displayed power mode parameter match the actual ignition switch position? If yes, go to next step. If no, go to step 6 .
3. Turn ON the ignition, with the engine OFF. Using a scan tool, under the DIAGNOSTIC CIRCUIT CHECK menu, observe the CLASS 2 POWER MODE parameter. Does the displayed power mode parameter match the actual ignition switch position? If yes, go to next step. If no, go to step 6 .
4. Turn the ignition switch to the CRANK position. Using a scan tool, under the DIAGNOSTIC CIRCUIT CHECK menu, observe the CLASS 2 POWER MODE parameter. Does the displayed power mode parameter match the actual ignition switch position? If yes, go to next step. If no, go to step 6 .
5. Turn the ignition switch to the ACCY position. Using a scan tool, under the DIAGNOSTIC CIRCUIT CHECK menu, observe the CLASS 2 POWER MODE parameter. Does the displayed power mode parameter match the actual ignition switch position? If yes, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) . If no, go to next step.
6. Turn OFF the ignition. Disconnect the BCM. Hold the ignition switch in the position that indicated the incorrect power mode. Using a test light connected to a good ground, test the BCM ignition switch inputs for voltage. See BODY CONTROL MODULES in appropriate SYSTEM WIRING DIAGRAMS article in ELECTRICAL. Is voltage present on only the inputs specified for the ignition switch position? If yes, go to next step. If no, go to step 8 .
7. Hold the ignition switch in the position that indicated the incorrect power mode. Using a test light connected to a good ground, test the BCM ignition switch inputs for voltage. See BODY CONTROL MODULES in appropriate SYSTEM WIRING DIAGRAMS article in ELECTRICAL. If voltage does not exist on any inputs specified for the ignition switch position, go to step 9 . If voltage exists on any inputs specified for the ignition switch position, go to step 11 .
8. Disconnect the ignition switch. See appropriate STEERING COLUMN SWITCHES article in ACCESSORIES & EQUIPMENT. Test the BCM ignition switch input circuits for a short to voltage. Test the BCM ignition switch circuits for a short between circuits. See BODY CONTROL MODULES in appropriate SYSTEM WIRING DIAGRAMS article in ELECTRICAL. Did you find and correct the condition? If yes, go to step 14 . If no, go to step 10 .
9. Disconnect the ignition switch. See appropriate STEERING COLUMN SWITCHES article in ACCESSORIES & EQUIPMENT. Test the BCM ignition switch input circuits for an open. See BODY CONTROL MODULES in appropriate SYSTEM WIRING DIAGRAMS article in ELECTRICAL. Did you find and correct the condition? If yes, go to step 14 . If no, go to next step.
10. Inspect for poor connections and terminal tension at the harness connector of the ignition switch. Did you find and correct the condition? If yes, go to step 14 . If no, go to step 12 .
11. Inspect for poor connections and terminal tension at the harness connector of the BCM. Did you find and correct the condition? If yes, go to step 14 . If no, go to step 13 .
12. Replace the ignition switch. See appropriate STEERING COLUMN SWITCHES article in ACCESSORIES & EQUIPMENT. After ignition switch replacement, go to step 14 .
13. Replace the BCM. See appropriate BODY CONTROL MODULES article in ACCESSORIES & EQUIPMENT. After BCM replacement, go to next step.
14. Reconnect all disconnected components and connectors. Using a scan tool, under the DIAGNOSTIC CIRCUIT CHECK menu, observe the CLASS 2 POWER MODE parameter. Cycle the ignition switch through all possible positions, one at a time. Does the displayed power mode parameter match the actual ignition switch position? If yes, system is okay. If no, go to step 1 .

1. The Diagnostic System Check will provide the following information: The identification of the control module(s) which command the system. The ability of the control module(s) to communicate through the serial data circuit. The identification of any stored Diagnostic Trouble Codes (DTCs) and their status. The use of the Diagnostic System Check will identify the correct procedure for diagnosing the system and where the procedure is located.
2. Install a scan tool. Does the scan tool turn ON? If yes, go to next step. If no, see SCAN TOOL DOES NOT POWER UP in appropriate BODY CONTROL MODULES article in ACCESSORIES & EQUIPMENT.
3. Turn ON the ignition, with the engine OFF. Attempt to establish communication with the listed control modules. If you are using a Tech 2(R), obtain the information using the Class 2 Message Monitor feature: Instrument Panel Cluster (IPC). PCM. Does the scan tool communicate with all the listed control modules? If yes, go to next step. If no, see SCAN TOOL DOES NOT COMMUNICATE WITH CLASS 2 DEVICE in appropriate BODY CONTROL MODULES article in ACCESSORIES & EQUIPMENT.
4. Select the powertrain control module display DTCs function on the scan tool. Does the scan tool display any DTCs? If yes, go to next step. If no, see «COOLING SYSTEM TROUBLE SHOOTING»(ref-27342-S11025938142001112800000) under ENGINE MECHANICAL in TROUBLE SHOOTING - BASIC PROCEDURES article in GENERAL INFORMATION.
5. Does the scan tool display DTCs which begin with a "U"? If yes, see appropriate BODY CONTROL MODULES article in ACCESSORIES & EQUIPMENT for diagnosis. If no, go to next step.
6. See «DIAGNOSTIC TROUBLE CODE DEFINITIONS»(ref-158882-S38387953612003102900000) .

RETRIEVING DIAGNOSTIC TROUBLE CODES

DTCs are retrieved using a Tech 2(R) scan tool, or other OBD-II compatible scan tool connected to OBD-II 16-pin Data Link Connector (DLC). See DIAGNOSTIC SYSTEM CHECK - ENGINE CONTROLS . DLC is located below left side of dash.

CLEARING DIAGNOSTIC TROUBLE CODES

There are 3 methods to clear DTCs.

Scan Tool

Scan tool is preferable way to clear DTC information. Freeze frame and failure record data will also be cleared.

Diagnostic Aids

The I/M System Status display provides an indication of when the control module has completed the required tests. This does not necessarily mean that the test has passed, only that a decision was made. If the diagnostic fails, a DTC will indicate the failure. If a failure indication is present for a DTC associated with one of the I/M regulated systems, the failure indication may prevent other required tests from running. For example, a DTC for the control circuit of the relay controlling an AIR pump may not be listed in the INSPECTION/MAINTENANCE SYSTEM DTCS table because this is a continuous test. If this DTC is set, the Active Tests for the AIR system may not run. The I/M System Status information may be useful for a technician to determine if diagnostics have run when verifying repairs.

Conditions for Running

Cold Start

1. The Barometric (BARO) pressure is more than 74 kPa.
2. The Engine Coolant Temperature (ECT) is below 86°F (30°C).
3. The Intake Air Temperature (IAT) is below 86°F (30°C).
4. The difference between the Intake Air Temperature (IAT) and the Engine Coolant Temperature (ECT) is 14°F (8°C) or less.
5. The battery voltage is between 9-18 volts.
6. The fuel level is between 1/4 and 3/4.

Rough road conditions may prevent some of the tests from running. Extreme high or low ambient temperatures may prevent tests such as Heated Oxygen Sensor (HO2S) Heater and Evaporative (EVAP) emission System from initiating. If a step is interrupted before completion, perform the remaining portion of the set procedures. Any portion of the set procedure that requires the engine at operating temperature may be repeated. This allows most of the diagnostics to run and the remaining tests can be performed using the individual System Set Procedures. If the vehicle has recently run, start this procedure at step 3 . This will allow the tests that require the engine at operating temperature to run. Using this method allows shorter cool down periods if the tests requiring a cold start do not initiate. The scan tool can be used to monitor each of the I/M System Status indicators during the I/M Complete System Set Procedure. When all of the indicators for a test step have updated to YES, testing can move on to the next step even if the remaining portion of the test is not complete. For example, step 3 is designed to run the EVAP, secondary Air Injection (AIR), and HO2S tests. The procedure instructs the technician to operate the vehicle in the enable conditions for 6 minutes. If all 3 tests have updated to YES within 4 minutes, it is not necessary to continue with the enable conditions and testing can advance to the next step.

1. The Barometric (BARO) pressure is more than 74 kPa.
2. The engine coolant is at operating temperature, 160-248°F (71-120°C).
3. The Intake Air Temperature (IAT) is between 5-167°F (-15 to 75°C).
4. The engine is in Closed Loop fuel control.
5. The engine has run for 6-8 minutes off idle in order to initiate test.
6. The battery voltage is between 11-18 volts.

The control module runs a maximum of 6 tests per trip until the Catalyst System Status updates to YES. If the status does not update, the test outlined in this procedure can be repeated until the I/M System Status updates to YES. The I/M System Status does not indicate whether the test has passed or failed, only that a decision was made. When all of the diagnostics for a specific system have run and passed, the I/M System Status will update to YES. If a test for a specific system has failed, the I/M System Status will update to YES, indicating a determination was made, even if all of the required tests have not run. When a failure occurs, the Emission Related DTC portion of the I/M System Status display will indicate the Malfunction Indicator Lamp (MIL) is requested. The I/M System Status also registers the number of diagnostic trouble codes (DTCs). The first failure of a type "B" DTC does not constitute a final determination of pass or fail, and will not update the I/M System Status to YES. A second trip is required, and all the conditions to run must be met in order for the test to run again. These conditions may include a partial to complete engine cool down. The I/M System Status will update only when an emission related DTC fails the second time, or when all of the tests pass. If there is an impending failure, the system may require more time to run the diagnostic than was allotted in the set procedure. If the test does not run after numerous attempts and no DTC is set, review the appropriate scan tool data list and the service information for an indication of why the test does not complete. Some tests may abort due to changes in the conditions while the test is running. For example, changes in engine load, such as a cooling fan or an A/C compressor clutch turning ON, may cause the test to abort. If a diagnostic test is difficult to run, observe the I/M System Status display while maintaining the necessary enable conditions until the system status updates to YES.

1. DTCs P0442, P0446, P0455, P0496 are not set.
2. The barometric pressure is more than 75 kPa.
3. The fuel level is between 1/4 and 3/4.
4. The battery voltage is between 10-18 volts.
5. The test will initiate only after a cold start. The control module considers the engine to be cold if the following conditions are met: The Engine Coolant Temperature (ECT) is between 39-86°F (3.8-30.0°C). The Intake Air Temperature (IAT) is between 39-86°F (3.8-30.0°C). The difference between the ECT and the IAT is less than 14°F (8°C).

If there is an impending failure, the system may require more time to run the diagnostic than was allotted in the set procedure. If the test does not run after numerous attempts and no DTC is set, review the appropriate scan tool data list and the service information for an indication of why the test does not complete. Some tests may abort due to changes in the conditions while the test is running. For example, changes in engine load such as cooling fan or an A/C compressor clutch turning ON may cause the test to abort.

1. The Engine Coolant Temperature (ECT) is more than 135°F (57°C).
2. The engine is running in Closed Loop fuel control.
3. The engine has been running for more than 160 seconds.
4. The battery voltage is between 9-18 volts.

If the status does not update, the test outlined in this procedure can be repeated until the I/M System Status updates to YES. The I/M System Status does not indicate whether the test has passed or failed, only that a decision was made. When all of the diagnostics for a specific system have run and passed, the I/M System Status will update to YES. If a test for a specific system has failed, the I/M System Status will update to YES, indicating a determination was made, even if all of the required tests have not run. When a failure occurs, the Emission Related DTC portion of the I/M System Status display will indicate the Malfunction Indicator Lamp (MIL) is requested. The I/M System Status also registers the number of diagnostic trouble codes (DTCs). The first failure of a type "B" DTC does not constitute a final determination of pass or fail, and will not update the I/M System Status to YES. A second trip is required, and all the conditions to run must be met in order for the test to run again. These conditions may include a partial to complete engine cool down. The I/M System Status will update only when an emission related DTC fails the second time, or when all of the tests pass. If there is an impending failure, the system may require more time to run the diagnostic than was allotted in the set procedure. If the test does not run after numerous attempts and no DTC is set, review the appropriate scan tool data list and the service information for an indication of why the test does not complete. Some tests may abort due to changes in the conditions while the test is running. For example, changes in engine load, such as a cooling fan or an A/C compressor clutch turning ON, may cause the test to abort. If a diagnostic test is difficult to run, observe the I/M System Status display while maintaining the necessary enable conditions until the system status updates to YES.

1. The start-up Engine Coolant Temperature (ECT) is less than 122°F (50°C).
2. The start-up Intake Air Temperature (IAT) is less than 122°F (50°C).
3. The difference between the IAT and the ECT is less than 14°F (8°C).
4. The battery voltage is between 11-18 volts.

The HO2S Heater Tests will normally run within the 2 minutes allotted in the procedure. If there is an indeterminate condition, the test may take up to 8 minutes on some vehicles before a decision of pass or fail is made. If the test does not update within the allotted period of time, continue operation within the enable conditions until the test updates to YES. If the test does not update to YES, it may have failed or aborted due to the loss of enabling conditions. Extremely high ambient temperatures may prevent the HO2S Heater Test from initiating. The I/M System Status does not indicate whether the test has passed or failed, only that a decision was made. When all of the diagnostics for a specific system have run and passed, the I/M System Status will update to YES. If a test for a specific system has failed, the I/M System Status will update to YES, indicating a determination was made, even if all of the required tests have not run. When a failure occurs, the Emission Related DTC portion of the I/M System Status display will indicate the Malfunction Indicator Lamp (MIL) is requested. The I/M System Status also registers the number of diagnostic trouble codes (DTCs). The first failure of a type "B" DTC does not constitute a final determination of pass or fail, and will not update the I/M System Status to YES. A second trip is required, and all the conditions to run must be met in order for the test to run again. These conditions may include a partial to complete engine cool down. The I/M System Status will update only when an emission related DTC fails the second time, or when all of the tests pass. If there is an impending failure, the system may require more time to run the diagnostic than was allotted in the set procedure. If the test does not run after numerous attempts and no DTC is set, review the appropriate scan tool data list and the service information for an indication of why the test does not complete. Some tests may abort due to changes in the conditions while the test is running. For example, changes in engine load, such as a cooling fan or an A/C compressor clutch turning ON, may cause the test to abort. If a diagnostic test is difficult to run, observe the I/M System Status display while maintaining the necessary enable conditions until the system status updates to YES.

DIAGNOSTIC TROUBLE CODE DEFINITIONS

DIAGNOSTIC TROUBLE CODE INDEX

Scheme 209

Scheme 210

Scheme 211

Scheme 212

Scheme 213

Scheme 214

Scheme 215

Scheme 216

Scheme 217

Scheme 218

Scheme 219

Scheme 220

Scheme 221

Scheme 222

Scheme 223

Scheme 224

Scheme 225

Scheme 226

Scheme 227

Scheme 228

Scheme 229

Scheme 230

Scheme 231

Scheme 232

Scheme 233

Scheme 234

Scheme 235

Scheme 236

Scheme 237

Scheme 238

Scheme 239

Scheme 240

Scheme 241

Scheme 242

Scheme 243

Scheme 244

Scheme 245

Scheme 246

Scheme 247

Scheme 248

Scheme 249

Scheme 250

Scheme 251

Scheme 252

Scheme 253

Scheme 254

Scheme 255

Scheme 256

Scheme 257

Scheme 258

Scheme 259

Scheme 260

Scheme 261

Scheme 262

Scheme 263

Scheme 264

Scheme 265

1. Did you perform the Diagnostic System Check-Engine Controls? If yes, go to next step. If no, see «DIAGNOSTIC SYSTEM CHECK - ENGINE CONTROLS»(ref-158882-S07978614742003102900000) under SELF-DIAGNOSTIC SYSTEM.
2. Verify whether the instrument cluster is operational. If the Instrument Panel (IP) is completely inoperative, see appropriate ANALOG INSTRUMENT PANELS article in ACCESSORIES & EQUIPMENT. Command the MIL ON and OFF with a scan tool. Does the MIL turn ON and OFF when commanded with a scan tool? If yes, problem is intermittent. See «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM. If no, go to next step.
3. Inspect the fuse that supplies ignition voltage to the instrument cluster. Is the fuse open? If yes, go to step 11 . If no, go to next step.
4. Turn OFF the ignition. Remove the fuse that supplies voltage to the instrument cluster. Disconnect the Powertrain Control Module (PCM) harness connectors. See «COMPONENT LOCATIONS»(ref-158882-S11767971642003102900000) . Turn ON the ignition with the engine OFF. Measure the voltage from the MIL control circuit in the PCM harness connector to a good ground. Is the voltage less than .3 volt? If yes, go to next step. If no, go to step 11 .
5. Turn OFF the ignition. Install the fuse that supplies voltage to the cluster. Turn ON the ignition with the engine OFF. Connect a 3-amp fused jumper wire between the MIL control circuit in the PCM harness connector and a good ground. Is the MIL illuminated? If yes, go to step 9 . If no, go to next step.
6. Turn OFF the ignition. Remove the Instrument Panel Cluster (IPC). See appropriate ANALOG INSTRUMENT PANELS article in ACCESSORIES & EQUIPMENT. Turn ON the ignition. Probe the MIL battery positive voltage circuit at the IPC harness connector with a test lamp connected to a good ground. Does the test lamp illuminate? If yes, go to next step. If no, go to step 12 .
7. Test the MIL control circuit for an open or high resistance between the PCM and the IPC and repair as necessary. Did you find and correct the condition? If yes, go to step 15 . If no, go to next step.
8. Inspect for poor connections at the harness connector of the IPC and repair as necessary. Did you find and correct the condition? If yes, go to step 15 . If no, go to step 13 .
9. Inspect for poor connections at the harness connector of the PCM and repair as necessary. Did you find and correct the condition? If yes, go to step 15 . If no, go to step 14 .
10. Repair the short to ground in the MIL battery positive voltage circuit. Replace the fuse. After repairs, go to step 15 .
11. Repair the short to voltage in the MIL control circuit. After repairs, go to step 15 .
12. Repair the open in the ignition voltage circuit. After repairs, go to step 15 .
13. Repair or replace the IPC. See appropriate ANALOG INSTRUMENT PANELS article in ACCESSORIES & EQUIPMENT. After repairs, go to step 15 .
14. Replace the PCM. See «POWERTRAIN CONTROL MODULE»(ref-159085-S36870747962003111100000) under COMPUTERIZED ENGINE CONTROLS in REMOVAL & INSTALLATION - BRAVADA, ENVOY, ENVOY XL, TRAILBLAZER & TRAILBLAZER EXT article. Reprogram PCM. See «POWERTRAIN CONTROL MODULE»(ref-158882-S34623407162003102900000) under PROGRAMMING. After repairs, go to next step.
15. Turn OFF the ignition for 30 seconds. Does the vehicle operate correctly, without any MIL illumination and without any stored DTCs? If yes, system is okay. If no, see «DIAGNOSTIC TROUBLE CODE DEFINITIONS»(ref-158882-S38387953612003102900000) .

1. Did you perform the Diagnostic System Check-Engine Controls? If yes, go to next step. If no, see «DIAGNOSTIC SYSTEM CHECK - ENGINE CONTROLS»(ref-158882-S07978614742003102900000) under SELF-DIAGNOSTIC SYSTEM.
2. Turn OFF the ignition. Disconnect the PCM. See «COMPONENT LOCATIONS»(ref-158882-S11767971642003102900000) . Turn ON the ignition, with the engine OFF. Observe the MIL. Is the MIL illuminated? If yes, go to next step. If no, go to step 5 .
3. Remove the Instrument Panel Cluster (IPC). See appropriate ANALOG INSTRUMENT PANELS article in ACCESSORIES & EQUIPMENT. Test the MIL control circuit for a short to ground between the PCM and the IPC. Did you find and correct the condition? If yes, go to step 6 . If no, go to next step.
4. Repair or replace the IPC. See appropriate ANALOG INSTRUMENT PANELS article in ACCESSORIES & EQUIPMENT. After repairs, go to step 6 .
5. Replace the PCM. See «POWERTRAIN CONTROL MODULE»(ref-159085-S36870747962003111100000) under COMPUTERIZED ENGINE CONTROLS in REMOVAL & INSTALLATION - BRAVADA, ENVOY, ENVOY XL, TRAILBLAZER & TRAILBLAZER EXT article. Reprogram PCM. See «POWERTRAIN CONTROL MODULE»(ref-158882-S34623407162003102900000) under PROGRAMMING. After repairs, go to next step.
6. Turn OFF the ignition for 30 seconds. Does the vehicle operate correctly, without any MIL illumination and without any stored DTCs? If yes, system is okay. If no, see «DIAGNOSTIC TROUBLE CODE DEFINITIONS»(ref-158882-S38387953612003102900000) .

If the problem is intermittent, see INTERMITTENT CONDITIONS under SELF-DIAGNOSTIC SYSTEM.

DIAGNOSTIC TESTS

Note. Before clearing DTCs, perform powertrain diagnostic system check. See DIAGNOSTIC SYSTEM CHECK - ENGINE CONTROLS under SELF-DIAGNOSTIC SYSTEM. Record FREEZE FRAME and FAILURE RECORDS for reference during testing. Data will be erased when DTCs are cleared. If PCM is replaced, NEW PCM must be programmed using special manufacturer's equipment. See POWERTRAIN CONTROL MODULE under PROGRAMMING.

Conditions For Running DTC

1. DTCs P0102, P0103, P0106, P0107, P0108, P0120, P0220, P0442, P0443, P0446, P0449, P0455, P0496, P2135 are not set.
2. The engine is cranking or running.
3. The ignition 1 signal is between 11 volts and 18 volts.
4. The Throttle Position (TP) sensor angle is less than 95 percent.
5. The change in the TP sensor angle is less than 5 percent.
6. The MAP sensor is more than 17 kPa.
7. The change in the MAP sensor is less than 3 kPa.
8. The above conditions are met for 1.5 seconds.

Conditions For Setting DTC

The PCM detects that the actual MAF sensor frequency signal is not within a predetermined range of the calculated MAF value for more than 4 seconds.

Action Taken When DTC Sets

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

Conditions For Clearing MIL/DTC

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

Inspect for the following conditions

1. An incorrectly routed harness. Inspect the harness of the MAF sensor in order to verify that it is not routed too close to the following components: The secondary ignition wires or coils. Any solenoids. Any relays. Any motors.
2. A low minimum air rate through the sensor bore may cause this DTC to set at idle or during deceleration. Inspect for any vacuum leaks downstream of the MAF sensor.
3. Inspect for any contamination or debris on the sensing elements of the MAF sensor.
4. Inspect the air induction system for any water intrusion. Any water that reaches the MAF sensor will skew the sensor and may cause this DTC to set.
5. A wide open throttle acceleration from a stop should cause the MAF sensor g/s display on the scan tool to increase rapidly. This increase should be from 3-10 g/s at idle to 170 g/s or more at the time of the 1-2 shift. If the increase is not observed, inspect for a restriction in the induction system or the exhaust system.
6. A high resistance of 15 ohms or more on the ignition 1 voltage circuit may cause this DTC to set. A high resistance may cause a driveability concern before this DTC sets.
7. The barometric pressure that is used in order to calculate the predicted mass air flow value is initially based on the MAP sensor at key ON. When the engine is running, the MAP sensor value is continually updated near wide open throttle. A skewed MAP sensor will cause the calculated mass air flow value to be inaccurate. The value shown for the MAP sensor display varies with the altitude. With the ignition ON and the engine OFF, 103 kPa is the approximate value near sea level. This value will decrease by approximately 3 kPa for every 1000 feet (305 meters) of altitude.
8. A high resistance on the 5-volt reference circuit of the MAP sensor may cause this DTC to set.
9. A high resistance on the low reference circuit of the MAP sensor may cause this DTC to set.
10. If the condition is intermittent, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

1. The engine is running for more than 2 seconds.
2. The engine speed is more than 400 RPM.
3. The ignition 1 signal is more than 8 volts.
4. The MAF sensor frequency is stable for more than one second.

The PCM detects that the MAF sensor frequency signal is less than 1200 Hz for more than 0.6 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. Inspect the harness of the MAF sensor to verify that it is not routed too close to the following components: The secondary ignition wires or coils. Any solenoids. Any relays. Any motors.
2. A low minimum air rate through the sensor bore at idle or during deceleration may cause this DTC to set. Inspect for any vacuum leak downstream of the MAF sensor.
3. Inspect for any contamination or debris on the sensing elements of the MAF sensor.
4. A wide open throttle acceleration from a stop should cause the MAF sensor g/s parameter on the scan tool to increase rapidly. This increase should be from 3-10 g/s at idle to 170 g/s or more at the time of the 1-2 shift. If the increase is not observed, inspect for a restriction in the induction system or the exhaust system.
5. A high resistance of 15 ohms or more on the ground circuit of the MAF sensor may cause this DTC to set. A high resistance may cause a driveability concern before this DTC sets.
6. A high resistance of 15 ohms or more on the ignition 1 voltage circuit can cause this DTC to set. A high resistance may cause a driveability concern before this DTC sets.
7. If the condition is intermittent, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

1. The engine is running for more than 2 seconds.
2. The engine speed is more than 400 RPM.
3. The ignition 1 signal is more than 8 volts.
4. The MAF sensor parameter is stable for more than one second.

The PCM detects that the MAF sensor frequency signal is more than 13,500 Hertz for more than 1.2 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. Inspect the air induction system for any water intrusion. The water rapidly cools the hot sensing elements in the sensor causing a false indication of excessive air flow. Any water that reaches the MAF sensor will skew the sensor and may cause this DTC to set.
2. A poor connection in the ignition 1 voltage circuit of the MAF sensor may cause this DTC to set.
3. If the condition is intermittent, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

1. DTC P0101, P0102, P0103, P0107, P0108, P0120, P0220, P0442, P0443, P0446, P0455, P1125, P1514, P1515, P1516, P1518, P2108, P2120, P2121, P2125, P2126, P2130, P2131, P2135 are not set.
2. The engine speed is between 400-5,000 RPM.
3. The change in engine speed is less than 125 RPM.
4. Traction control, if equipped, is not active.
5. The A/C compressor clutch is steady.
6. The power steering is stable.
7. The power take-off (PTO), if equipped, is not active.
8. The clutch switch state does not change, if equipped with a manual transmission.
9. The brake switch state does not change.
10. The above conditions are met for 1 second.

The PCM detects that the MAP sensor voltage is not within the predicted range for 2 seconds.

1. The Powertrain Control Module (PCM) illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The PCM records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the PCM stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the PCM records the operating conditions at the time of the failure. The PCM writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The PCM turns OFF the Malfunction Indicator Light (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. DTC P0120, P0220, P1125, P1514, P1515, P1516, P1518, P2108, P2120, P2121, P2125, P2126, P2130, P2131, P2135 are not set.
2. The engine is running.
3. The throttle angle is zero percent when the engine speed is less than 800 RPM, or the throttle angle is more than 12.5 percent when the engine speed is more than 800 RPM.

The PCM detects that the MAP sensor voltage is less than 0.10 volt for more than 4 seconds.

1. The Powertrain Control Module (PCM) illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The Powertrain Control Module (PCM) turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. DTC P0120, P0220, P1125, P1514, P1515, P1516, P1518, P2108, P2120, P2121, P2125, P2126, P2130, P2131, P2135 are not set.
2. Engine is running.
3. The throttle angle is less than one percent when the engine speed is less than 1,200 RPM, or the throttle angle is less than 20 percent when the engine speed is more than 1,200 RPM.

The PCM detects that the MAP sensor voltage is more than 4.9 volts for more than 4 seconds.

1. The Powertrain Control Module (PCM) illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The Powertrain Control Module (PCM) records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the PCM stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the PCM records the operating conditions at the time of the failure. The PCM writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The Powertrain Control Module (PCM) turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. DTCs P0502, P0503 are not set.
2. The engine run time is more than 45 seconds.
3. The Vehicle Speed Sensor (VSS) indicates that vehicle speed is more than 25 MPH.

The IAT is more than 262°F (128°C) for 5 seconds.

1. The Powertrain Control Module (PCM) illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The PCM records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the PCM records the operating conditions at the time of the failure. The PCM writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The PCM turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. When the vehicle is at ambient temperature the IAT sensor and ECT sensor temperatures should be relatively close to each other.
2. If an intermittent condition exists, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

Scheme 266

Scheme 267

1. DTCs P0101, P0102, P0103, P0116, P0117, P0118, P0125, P0128, P0502, P0503 are not set.
2. The engine run time is more than 120 seconds.
3. The Vehicle Speed Sensor (VSS) indicates that vehicle speed is less than 7 MPH.
4. The Engine Coolant Temperature (ECT) is more than 140°F (60°C).
5. The Mass Air Flow (MAF) is less than 15 g/s.

The PCM detects that the IAT Sensor parameter is less than -38°C (-36°F) for more than 5 seconds.

1. The Powertrain Control Module (PCM) illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The PCM records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the PCM stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the PCM records the operating conditions at the time of the failure. The PCM writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The PCM turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. When the vehicle is at ambient temperature the IAT sensor and ECT sensor temperatures should be relatively close to each other.
2. If a short to a separate 5-volt source occurs, this DTC may set. If this condition exists, a continuity test to all other PCM 5-volt reference circuits will be necessary.
3. If an intermittent condition exists, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

1. The ignition is ON.
2. DTCs P0112, P0113, P0117, P0118, P0125, P0128, P0601, P0602, P1621, P1683 are not set.
3. The start-up IAT is more than 59°F (15°C).
4. The vehicle has a minimum ignition OFF time of 10 hours.
5. This DTC will only run once during the ignition cycle within the enabling conditions.

If the PCM detects a temperature difference between the ECT sensor and the IAT sensor of more than 27°F (15°C), then the vehicle must be driven for more than 400 seconds over 15 mph. If the IAT sensor temperature decreases more than 5°F (3°C), a block heater is detected and the test is aborted. If the IAT sensor temperature does not decrease, a block heater was not detected and DTC P0116 sets.

1. The Powertrain Control Module (PCM) illuminates the Malfunction Indicator Light (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The PCM records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the PCM stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the PCM records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The Powertrain Control Module turns OFF the Malfunction Indicator Light (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

The engine run time is more than 10 seconds; or, the engine run time is less than 10 seconds when IAT is less than 122°F (50°C).

The ECT sensor temperature is more than 282°F (139°C) for more than 20 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

Conditions For Clearing MIL or DTC

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. An overheating condition may cause this DTC to set.
2. After starting the engine, the ECT sensor temperature should rise steadily to about 194°F (90°C) then stabilize after the thermostat opens.
3. Use the Temperature vs. Resistance Value Table in order to test the ECT sensor at various temperature levels in order to evaluate the possibility of a skewed sensor. A skewed sensor could result in poor driveability concerns. See «SENSOR OPERATING RANGE CHARTS - TRUCKS»(ref-159155) article.
4. If the malfunction is not present at this time, See «DTC P1114: ECT SENSOR CIRCUIT - INTERMITTENT LOW VOLTAGE»(ref-158882-S37406869492003102900000) .
5. If an intermittent condition exists, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

Scheme 268

The engine has been running for more than 60 seconds; or, the engine run time is less than 60 seconds when the Intake Air Temperature (IAT) is more than 32°F (0°C).

The ECT sensor temperature is less than -36°F (-38°C) for 20 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. If a short to a separate 5-volt source occurs, this DTC may set.
2. After starting the engine, the ECT should rise steadily to about 194°F (90°C) then stabilize after the thermostat opens.
3. Use the Temperature vs. Resistance Table in order to test the ECT sensor at various temperature levels in order to evaluate the possibility of a skewed sensor. A skewed sensor could result in poor driveability concerns. See «SENSOR OPERATING RANGE CHARTS - TRUCKS»(ref-159155) article.
4. If a malfunction is not present at this time, see «DTC P1115: ECT SENSOR CIRCUIT - INTERMITTENT HIGH VOLTAGE»(ref-158882-S17889948182003102900000) .
5. If an intermittent condition exists, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

Scheme 269

Scheme 270

1. DTCs P1518 or P2108 are not set.
2. The ignition switch is in the crank or run position.
3. The ignition voltage is more than 5.23 volts.

1. The TP sensor 1 signal voltage is less than 0.37 volt or more than 4.51 volts.
2. The above condition is present for more than 1 second.

1. The control module illuminates the malfunction indicator lamp (MIL) when the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Freeze Frame and/or the Failure Records.
3. The control module commands the TAC system to operate in the Reduced Engine Power Mode.
4. Under certain conditions the control module commands the engine OFF.
5. The message center displays Reduced Engine Power.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. Inspect the Throttle Actuator Control (TAC) module connectors for signs of water intrusion. When this occurs, multiple DTCs could be set with no circuit or component conditions found during diagnostic testing.
2. When the TAC module detects a condition within the TAC system, more than one TAC system related DTC may set. This is due to the many redundant tests run continuously on this system. Locating and repairing one individual condition may correct more than one DTC. Disconnecting components during testing may set additional DTCs. Keep this in mind when reviewing the stored information, Capture info.
3. If this DTC is determined to be intermittent, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

1. DTCs P0101, P0102, P0103, P0112, P0113, P0116, P0117, P0118, P0500, P0502, P0503, P1111, P1112, P1114, or P1115 are not present.
2. The engine run time is between 120-1600 seconds.
3. The minimum air temperature is 19° F (-7° C).
4. The start-up coolant temperature is less than 83°F (28.5°C).
5. The Mass Air Flow (MAF) is between 20-75 g/s with the average more than 15 g/s.
6. The vehicle speed is more than 5 MPH for more than 0.5 mi.
7. This diagnostic has not previously run this ignition cycle.

1. The PCM detects that the calibrated amount of engine run time has been met.
2. The calibrated amount of engine air flow has been met.
3. The engine coolant temperature for Closed Loop of 90° F (34° C) has not been met.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

Scheme 271

Scheme 272

1. DTCs P0101, P0102, P0103, P0112, P0113, P0116, P0117, P0118, P0125, P0500, P0502, P0503, P1111, P1112, P1114, or P1115 are not present.
2. The start-up engine coolant temperature is less than 158°F (70°C).
3. The Air Intake Temperature (IAT) sensor is 19°F (-7°C) or more.
4. The engine is running more than 2 minutes and less than 27 minutes.
5. The vehicle speed is more than 5 MPH for more than 1.5 miles.
6. The mass airflow (MAF) average reading is between 20-75 g/s with an average of more than 15 g/s.
7. The diagnostic has not previously run this ignition cycle.

1. The calibrated amount of engine run time has been met.
2. The calibrated amount of engine air flow has been met.
3. The calibrated minimum engine coolant temperature of 167° F (75° C) has not been met.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

Scheme 273

Scheme 274

Power Enrichment Test Enable

1. DTCs P0101, P0102, P0103, P0106, P0107, P0108, P0112, P0113, P0116, P0117, P0118, P0120, P0200, P0220, P0300, P0442, P0446, P0452, P0453, P0455, P0496, P1125, P1258, P1514, P1515, P1516, P1518, P2108 or P2135 are not set.
2. The loop status is closed.
3. The ignition 1 signal is between 10-18 volts.
4. The fuel tank level remaining is more than 10 percent.
5. The TP indicated Angle parameter is between 3-70 percent more than the value observed at idle.

Lean Test Enable

1. DTCs P0101, P0102, P0103, P0106, P0107, P0108, P0112, P0113, P0116, P0117, P0118, P0120, P0200, P0220, P0300, P0442, P0446, P0452, P0453, P0455, P0496, P1125, P1258, P1514, P1515, P1516, P1518, P2108 or P2135 are not set.
2. The loop status is closed.
3. The ignition 1 signal is between 10-18 volts.
4. The fuel tank level remaining is more than 10 percent.
5. The Engine Run Time parameter is more than 30 seconds.
6. The Power Enrichment parameter is active for more than 2 seconds.

Lean Test

1. The HO2S voltage is less than 200 mV for 165 seconds.

Power Enrichment Test

1. The HO2S voltage is less than 400 mV for 10 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.
3. The control module commands Open Loop.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

Rich Test Enable

1. DTCs P0101, P0102, P0103, P0106, P0107, P0108, P0112, P0113, P0116, P0117, P0118, P0120, P0200, P0220, P0300, P0442, P0446, P0452, P0453, P0455, P0496, P1125, P1258, P1514, P1515, P1516, P1518, P2108, or P2135 are not set.
2. The loop status is closed.
3. The ignition 1 signal is between 10-18 volts.
4. The fuel tank level remaining is more than 10 percent.
5. The TP indicated angle parameter is between 3-70 percent more than the value observed.

Decel Fuel Cut-Off Test Enable

1. DTCs P0101, P0102, P0103, P0106, P0107, P0108, P0112, P0113, P0116, P0117, P0118, P0120, P0200, P0220, P0300, P0442, P0446, P0452, P0453, P0455, P0496, P1125, P1258, P1514, P1515, P1516, P1518, P2108, or P2135 are not set.
2. The loop status is closed.
3. The ignition 1 signal is between 10-18 volts.
4. The fuel tank level remaining is more than 10 percent.
5. The engine run time parameter is more than 30 seconds.
6. The Decel. Fuel Cutoff parameter is active for more than 4 seconds.

Rich Test

1. The HO2S voltage is more than 900 mV for 165 seconds.

Decel Fuel Cut-Off Test

1. The HO2S voltage is more than 250 mV for 5 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.
3. The control module commands Open Loop.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. DTCs P0101, P0102, P0103, P0106, P0107, P0108, P0112, P0113, P0117, P0116, P0118, P0120, P0131, P0132, P0134, P0135, P0151, P0152, P0154, P0155, P0200, P0220, P0300, P0442, P0446, P0452, P0453, P0455, P0496, P1125, P1258, P1514, P1515, P1516, P1518, P2108 or P2135 are not set.
2. The Engine Coolant Temperature (ECT) sensor is more than 149°F (65°C).
3. The Evaporative (EVAP) emissions purge solenoid command is more than 1 percent.
4. The mass airflow (MAF) sensor is between 23-50 g/s.
5. The engine speed is between 1200-3000 RPM.
6. The TP Indicated Angle parameter is 5 percent more than the value observed at idle.
7. The loop status is closed.
8. The ignition 1 signal is between 10-18 volts.
9. The fuel tank level remaining is more than 10 percent.
10. The engine run time is more than 160 seconds.
11. The above conditions are met for 50 seconds.

The rich-to- lean and lean-to-rich average response time is more than a calibrated value.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. DTCs P0101, P0102, P0103, P0106, P0107, P0108, P0112, P0113, P0116, P0117, P0118, P0120, P0200, P0220, P0300, P0442, P0446, P0452, P0453, P0455, P0496, P1125, P1258, P1514, P1515, P1516, P1518, P2108 or P2135 are not set.
2. The engine run time is more than 300 seconds.
3. The ignition 1 signal is between 10-18 volts.

The PCM detects that the affected HO2S voltage parameter is between 350-550 mV for 60 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.
3. The control module commands Open Loop.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. DTCs P0101, P0102, P0103, P0106, P0107, P0108, P0112, P0113, P0116, P0117, P0118, P0120, P0200, P0220, P0300, P0442, P0446, P0452, P0453, P0455, P0496, P1125, P1258, P1514, P1515, P1516, P1518, P02108 or P2135 are not set.
2. The ECT Sensor parameter is more than 122°F (50° C).
3. The Ignition 1 Signal parameter is between 10-18 volts.
4. The MAF sensor parameter is between 3-40 g/s.
5. The engine speed parameter is between 500-3000 RPM.
6. The engine run time parameter is more than 120 seconds.

1. The PCM detects that the affected HO2S Heater current parameter is less than 0.25 amps, or more than 1.375 amps.
2. The above condition is met for 10 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

Lean Test Enable

1. DTCs P0101, P0102, P0103, P0106, P0107, P0108, P0112, P0113, P0116, P0117, P0118, P0120, P0200, P0220, P0300, P0442, P0446, P0452, P0453, P0455, P0496, P1125, P1258, P1514, P1515, P1516, P1518, P2108 or P2135 are not set.
2. The loop status is closed.
3. The ignition 1 signal is between 10-18 volts.
4. The fuel tank level remaining is more than 10 percent.
5. The TP Indicated Angle parameter is between 3-70 percent more than the value observed at idle.

Power Enrichment Test Enable

1. DTCs P0101, P0102, P0103, P0106, P0107, P0108, P0112, P0113, P0116, P0117, P0118, P0120, P0200, P0220, P0300, P0442, P0446, P0452, P0453, P0455, P0496, P1125, P1258, P1514, P1515, P1516, P1517, P1518 or P2135 are not set.
2. The loop status is closed.
3. The ignition 1 signal is between 10-18 volts.
4. The fuel tank level remaining is more than 10 percent.
5. The engine run time parameter is more than 30 seconds.
6. The power enrichment parameter is active for more than 2 seconds.

Lean Test

1. The HO2S voltage is less than 80 mV for 200 seconds.

Power Enrichment Test

1. The HO2S voltage is less than 490 mV for 10 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

Rich Test Enable

1. DTCs P0101, P0102, P0103, P0106, P0107, P0108, P0112, P0113, P0116, P0117, P0118, P0120, P0200, P0220, P0300, P0442, P0446, P0452, P0453, P0455, P0496, P1125, P1258, P1514, P1515, P1516, P1518, P2108, or P2135 are not set.
2. The loop status is closed.
3. The ignition 1 signal is between 10-18 volts.
4. The fuel tank level remaining is more than 10 percent.
5. The TP indicated angle parameter is between 3-70 percent more than the value observed at idle.

Decel Fuel Cut-Off Test Enable

1. DTCs P0101, P0102, P0103, P0106, P0107, P0108, P0112, P0113, P0116, P0117, P0118, P0120, P0200, P0220, P0300, P0442, P0446, P0452, P0453, P0455, P0496, P1125, P1258, P1514, P1515, P1516, P1518, P2108, or P2135 are not set.
2. The loop status is closed.
3. The ignition 1 signal is between 10-18 volts.
4. The fuel tank level remaining is more than 10 percent.
5. The engine run time parameter is more than 30 seconds.
6. The Decel. Fuel Cutoff parameter is active for more than 4 seconds.

Rich Test

1. The PCM detects that the affected HO2S voltage parameter is more than 950 mV for 200 seconds.

Decel Fuel Cut-Off Test

1. The PCM detects that the affected HO2S voltage parameter is more than 250 mV for 5 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. DTCs P0101, P0102, P0103, P0106, P0107, P0108, P0112, P0113, P0116, P0117, P0118, P0120, P0141, P0161, P0200, P0220, P0300, P0442, P0446, P0452, P0453, P0455, P0496, P1125, P1258, P1514, P1515, P1516, P1518, P2108 or P2135 are not set.
2. The engine run time is more than 300 seconds.
3. The loop status is closed.
4. The ignition 1 signal is between 10-18 volts.

1. The HO2S signal voltage is steady between 410-490 mV for 150 seconds.
2. The Throttle Position (TP) changes more than 5 percent within 1 second, 6 times.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. DTCs P0101, P0103, P0108, P0135, P0137, P0141, P0200, P0300, P0410, P0420, P0430, P0440, P0442, P0443, P0446, P0449, P0506, P0507 or P1441 are not set.
2. The Engine Coolant Temperature (ECT) is between 167-239°F (75-115°C).
3. The Intake Air Temperature (IAT) is between 4-194° F (-20-90° C).
4. The Manifold Absolute Pressure (MAP) is between 3.7-13 psi (26-90 kPa).
5. The vehicle speed is less than 85 mph (137 km/h).
6. The engine speed is between 400-3000 RPM.
7. The Barometric pressure (BARO) is more than 10.7 psi (74 kPa).
8. The Mass Airflow (MAF) is between 5-90 g/s.
9. The fuel level is more than 10 percent.
10. The Throttle Position (TP) is less than 90 percent.

1. The average long term fuel trim cell value is above 23 percent.
2. All of the above conditions are present for 6 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. The system will go lean if an injector is not supplying enough fuel.
2. A lean condition could be present during high fuel demand.
3. Using a scan tool, review the Failure Records. If an intermittent condition is suspected, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

1. DTCs P0101, P0103, P0108, P0135, P0137, P0141, P0200, P0300, P0410, P0420, P0430, P0440, P0442, P0443, P0446, P0449, P0506, P0507 or P1441 are not set.
2. The Engine Coolant Temperature (ECT) is between 167-239°F (75-115°C).
3. The Intake Air Temperature (IAT) is between 4-194°F (-20 to 90°C).
4. The Manifold Absolute Pressure (MAP) is between 26-90 kPa.
5. The vehicle speed is less than 85 MPH.
6. The engine speed is between 400-3000 RPM.
7. The Barometric (BARO) pressure is more than 74 kPa .
8. The mass airflow (MAF) is between 5-90 g/s.
9. The fuel level is more than 10 percent.
10. The Throttle Position (TP) is less than 90 percent.

1. The average long term fuel trim value is below -13 percent.
2. All of the above conditions are present for 40 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. Fuel contamination, such as water or alcohol will effect fuel trim.
2. A malfunctioning mass air flow sensor can cause a rich condition and set this DTC. See «DTC P0101: MASS AIR FLOW SENSOR PERFORMANCE»(ref-158882-S08936540042003102900000) .
3. Using a scan tool, review the Failure Records. If an intermittent condition is suspected, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

1. The engine speed is more than 400 RPM.
2. The ignition voltage is between 6-18 volts.

1. The PCM detects an incorrect voltage on the fuel injector control circuit.
2. The condition exists for 5 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. Performing the Fuel Injector Coil test may help isolate an intermittent condition. See «FUEL INJECTOR COIL TEST»(ref-153204-S40214991842003032400000) under SYSTEM & COMPONENT TESTING - 4.8L, 5.3L & 6.0L "C", "G", "H", "K", "N", "S" & "T" SERIES - FLEX FUEL & GASOLINE article.
2. For an intermittent condition, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

1. DTCs P1518 or P2108 are not set.
2. The ignition switch is in the crank or run position.
3. The ignition voltage is more than 5.23 volts.

1. The TP sensor 2 voltage is less than 0.28 volt or greater than 4.60 volts.
2. The above condition is present for more than 1 second.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) when the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Freeze Frame and/or the Failure Records.
3. The control module commands the TAC system to operate in the Reduced Engine Power mode.
4. Under certain conditions the control module commands the engine OFF.
5. The message center displays Reduced Engine Power.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL/DTC with a scan tool.

1. Inspect the Throttle Actuator Control (TAC) module connectors for signs or water intrusion. If water intrusion occurs, multiple DTCs may set without any circuit or component found during diagnostic testing.
2. When the TAC module detects a condition within the TAC system, more than 1 TAC system related DTC may set. This is due to the many redundant tests run continuously on this system. Locating and repairing 1 individual condition may correct more than 1 DTC. Disconnecting components during testing may set additional DTC. Remember this if you review the stored information in Capture Info.
3. For an intermittent condition, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

1. The engine speed is more than 400 RPM.
2. The ignition voltage is between 6-18 volts.

1. The PCM detects that the commanded state of the driver and the actual state of the control circuit do not match.
2. The above conditions are present for a minimum of 2.5 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Use a scan tool in order to clear the MIL and the DTC.

1. DTCs P0101, P0102, P0103, P0106, P0107, P0108, P0116, P0117, P0118, P0125, P0128, P0220, P0315, P0335, P0336, P0341, P0342, P0343, P0502, P0503, P1114, P1115, P1120, or P1258 are not set.
2. The engine speed is between 450-5000 RPM.
3. The ignition voltage is between 10-18 volts.
4. The Engine Coolant Temperature (ECT) is between 19-266°F (-7-130°C).
5. The fuel level is more than 10 percent.
6. The Throttle Position (TP) sensor angle is steady within 1 percent.
7. The Anti-Lock Brake System (ABS) and the traction control system are not active.
8. The transmission is not changing gears.
9. The A/C clutch is not changing states.
10. The PCM is not in fuel shut-off or Decel Fuel Cut-Off (DFCO) mode.
11. The PCM is not receiving a rough road signal.

The PCM is detecting a crankshaft rotation speed variation indicating a misfire sufficient to cause emission levels to exceed mandated standards.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. Excessive vibration from sources other than the engine can cause a misfire DTC. The following are possible sources of vibration: Variable thickness brake rotor. Drive shaft not balanced. Certain rough road conditions.
2. There may be more or less cylinders actually misfiring than indicated by the scan tool.
3. Spray water on the secondary ignition components using a spray bottle. Look and listen for arcing or misfiring.
4. Observe, if more then one cylinder is misfiring, the scan tool may only display one cylinder misfiring. This will not be apparent until the repair is completed. Also, if an ignition coil ground circuit is open for one side of the engine, the scan tool may only display 2 or 3 cylinders misfiring. Inspect the ground circuit for the ignition coil on the cylinder bank of the engine that has more then one cylinder misfiring.

DTCs P0335, P0336, P0341, P0342, or P0343 are not set.

The CKP system variation values are not stored in the PCM memory.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) when the diagnostic runs and fails.
2. the control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Freeze Frame/Failure Records.

1. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
2. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
3. Clear the MIL and the DTC with a scan tool.

The CKP system variation values are not stored in the PCM memory after a learn procedure has been performed. If the actual CKP variation is not within the CKP system variation compensating values stored in the PCM, DTC P0300 may set.

The CKP system variation learn procedure is also required when the following service procedures have been performed, regardless of whether DTC P0315 is set.

1. An engine replacement.
2. A PCM replacement.
3. A harmonic balancer replacement.
4. A crankshaft replacement.
5. Any engine repairs which disturb the CKP sensor relationship.

If the CKP system variation learn procedure cannot be performed successfully, check for the following conditions and correct as necessary

1. A damaged reluctor wheel.
2. Excessive crankshaft runout.
3. A damaged crankshaft.
4. Interference in the signal circuit of the CKP sensor.
5. A coolant temperature that is not within the Conditions For Running DTC.
6. The ignition switch is in the ON position until the battery is drained.
7. A PCM power disconnect with the ignition ON may erase the stored value and set the DTC P0315.

Scheme 275

1. The engine run time is more than 10 seconds.
2. The ignition voltage is more than 10 volts.

1. A malfunction with the KS system within the PCM are faulty.
2. All of the above conditions are present for 12 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

Scheme 276

1. DTCs P0117, P0118, or P0125 are not set.
2. The minimum noise level must be learned. The minimum noise level is learned when the following conditions are met: The Engine Coolant Temperature (ECT) must be greater than 140°F (60°C). The engine RPM is between 475-975 for 10 seconds.
3. The engine speed is between 1500-3000 RPM.
4. The Manifold Absolute Pressure (MAP) is less than 49 kPa.
5. The Engine Coolant Temperature (ECT) is more than 140°F (60°C).
6. The throttle angle is more than 0 percent.
7. The engine run time is more than 10 seconds.
8. The ignition voltage is more than 10 volts.

1. The PCM detects that the KS signal is within the calculated voltage range or the KS signal is not present.
2. The above conditions are met for more than 9 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. If DTCs P0327 and P0332 are set at the same time, inspect for poor connections at the KS harness jumper, located at the left rear side of the intake manifold.
2. Inspect the KS for physical damage. A KS that is dropped may cause a DTC to set.
3. Inspect the KS for proper installation. A KS that is loose or over torqued may cause a DTC to set. The KS should be free of thread sealant. The KS mounting surface should be free of burrs, casting flash, and foreign material.
4. For an intermittent condition, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

1. DTCs P0101, P0102, P0103, P0341, P0342, or P0343 are not set.
2. The camshaft position (CMP) sensor signal is incrementing.
3. The Mass Air Flow (MAF) is more than 3 g/s.
4. The ignition switch is in the Crank position.

The PCM determines there is no signal from the CKP sensor for less than 8 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

The following conditions may cause this DTC to set

1. Excessive air gap between the CKP sensor and the reluctor wheel.
2. Crankshaft reluctor wheel damage or improper installation.
3. The CKP sensor coming in contact with the reluctor wheel.
4. Foreign material passing between the CKP sensor and the reluctor wheel.
5. Insufficient fuel.

Excess crankshaft end play causes the CKP sensor reluctor wheel to move out of alignment with the CKP sensor. This could result in any one of the following

1. A no-start.
2. A start and stall.
3. Erratic performance.

For an intermittent, see INTERMITTENT CONDITIONS under SELF-DIAGNOSTIC SYSTEM.

The engine is cranking or running.

The PCM determines that the CKP sensor signal is out of range for less than 2 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

The following problems may cause this DTC to set

1. Crankshaft reluctor wheel damage or improper installation.
2. The CKP sensor coming in contact with the reluctor wheel.
3. The engine running out of fuel.
4. If the crankshaft rotates backwards, this DTC sets. This condition is only with vehicles equipped with a manual transmission. This condition can occur when a vehicle is on an incline and the clutch is released and an engine stall occurs.

Excess crankshaft end play will cause the CKP sensor reluctor wheel to move out of alignment with the CKP sensor. This could result in any one of the following conditions

1. A no-start.
2. A start and stall.
3. Erratic performance.

For an intermittent, see INTERMITTENT CONDITIONS under SELF-DIAGNOSTIC SYSTEM.

The engine speed is less than 4,000 RPM.

The PCM detects that a CMP to CKP mis-match has occurred.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

The following conditions may cause this DTC to set

1. Camshaft reluctor wheel damage.
2. Sensor contact with the reluctor wheel.
3. Foreign material passing between the sensor and the reluctor wheel.
4. Excessive camshaft end-play.
5. Wiring routed too close to secondary ignition components.

If you find any damage to the reluctor wheel or to the camshaft, see appropriate article in ENGINES.

If the condition is intermittent, see INTERMITTENT CONDITIONS under SELF-DIAGNOSTIC SYSTEM.

The engine speed is less than 4000 RPM.

The PCM detects the cam signal is stuck low for 1.5 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

The following conditions may cause this DTC to set

1. Camshaft reluctor ring damage.
2. The sensor coming in contact with the reluctor ring.
3. Foreign material passing between the sensor and the reluctor ring.
4. Excessive camshaft end-play.
5. Wiring routed too close to secondary ignition components.

If the condition is intermittent, see INTERMITTENT CONDITIONS under SELF-DIAGNOSTIC SYSTEM.

The engine speed is less than 4000 RPM.

The PCM detects the CAM signal is high for 1.5 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

The following conditions may cause this DTC to set

1. Camshaft reluctor ring damage.
2. The sensor coming in contact with the reluctor ring.
3. Foreign material passing between the sensor and the reluctor ring.
4. Excessive camshaft end-play.
5. Wiring routed too close to secondary ignition components.

If the condition is intermittent, see INTERMITTENT CONDITIONS under SELF-DIAGNOSTIC SYSTEM.

The engine is operating.

The PCM detects the IC circuit is grounded, open, or shorted to voltage for less than 1 second.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. DTCs P0101-P0103, P0106-P0108, P0112, P0113, P0117, P0118, P0120, P0125, P0128, P0131-P0135, P0137, P0138, P0140, P0141, P0151-P0155, P0157, P0158, P0160, P0161, P0171, P0172, P0174, P0175, P0177, P0178, P0179, P0200, P0220, P0300, P0325, P0327, P0332, P0335, P0336, P0341-P0343, P0351-P0358, P0442, P0443, P0446, P0452, P0453, P455, P0496, P0502, P0503, P1125, P1133, P1153, P1258, P1514, P1516, P1518, P2108 or P2135 are not set.
2. The Intake Air Temperature (IAT) is 5-185°F (-15-85°C).
3. The Barometric (BARO) pressure is more than 74 kPa.
4. The engine is operating.
5. The Engine Coolant Temperature (ECT) is 158-248°F (70-120°C).
6. Since the end of the last idle period, the engine speed is more than 900 RPM for one of the following amounts of time: 45 seconds for manual transmissions. 40 seconds for automatic transmissions.
7. The Closed Loop fuel control is enabled.

The PCM determines the oxygen storage capability of the catalytic converter has degraded below a calibrated threshold.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) the first time the diagnostic runs and fails.
2. The control module will set the DTC and records the operating conditions at the time the diagnostic fails. The control module stores the failure information in the scan tools Freeze Frame/Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. DTCs P0100, P0101, P0102, P0103, P0106, P0107, P0108, P0112, P0113, P0116, P0117, P0118, P0125, P0335, P0336, P0443, P0446, P0449, P0452, P0453, P0455, P0496, P0500, P0502, P1106, P1107, or P1683 are not set.
2. The diagnostic runs once with a 10 hour minimum between tests after a fail.
3. DTC P0455 must run and pass.
4. The start up intake air temperature (IAT) is between 39-86° F (4-30° C).
5. The start up Engine Coolant Temperature (ECT) is less than 86° F (30° C).
6. The start up IAT and ECT are within 15° F (8° C).
7. The Barometric Pressure (BARO) is more than 74 kPa.
8. The ambient air temperature is between 36-90° F (2-32° C).
9. The engine run time minimum is 600 seconds.
10. The odometer displays more than 10 miles.
11. The vehicle has traveled more than 3 miles this trip.
12. The ECT is more than 158° F (70° C).
13. The fuel level is between 15-85 percent.
14. The ignition is OFF.

The control module detects a pressure change that is less than a calibrated amount.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) when the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Freeze Frame/Failure Records.

1. The PCM will turn the MIL OFF during the first consecutive trip in which the diagnostic has been run and passed.
2. A last test failed (current DTC) clears when the PCM turns OFF the MIL.
3. The history DTC will clear after the PCM runs and passes 40 consecutive warm up cycles with no failure.
4. The DTC can be cleared by using a scan tool.

1. To help locate intermittent leaks, use the J 41413-200 Evaporative Emissions System Tester (EEST) to introduce smoke into the EVAP system. Move all EVAP components while observing smoke with the J 41413-SPT High Intensity White Light.
2. To improve visibility of the smoke exiting the EVAP system, observe the suspected leak area from different angles with the J 41413-SPT.
3. If the condition is intermittent, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

1. The engine speed is more than 400 RPM.
2. The system voltage is between 6-18 volts.

1. The control module detects that the commanded state of the driver and the actual state of the control circuit do not match.
2. The above conditions are present for a minimum of 5 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. DTCs P0106, P0107, P0108, P0112, P0113, P0116, P0117, P0118, P0120, P0121, P0122, P0123, P0125, P0131, P0132, P0133, P0134, P0135, P0137, P0138, P0140, P0141, P0147, P0151, P0152, P0153, P0154, P0155, P0157, P0158, P0160, P0161, P0167, P0220, P0442, P0443, P0449, P0452, P0453, P0455, P0502, P0503, P1111, P1112, P1114, P1115, or P1120 are not set.
2. The ignition voltage is between 10-18 volts.
3. The Barometric (BARO) pressure is more than 75 kPa.
4. The fuel level is between 15-85 percent.
5. The Engine Coolant Temperature (ECT) is between 39-86°F (4-30°C).
6. The Intake Air Temperature (IAT) is between 39-86°F (4-30°C).
7. The start up ECT and IAT are within 16°F (9°C) of each other.

1. The Fuel Tank Pressure (FTP) is less than -10 in. H2O.
2. The condition is present for more than 30 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

An intermittent Condition could be caused by a damaged EVAP vent housing, a temporary blockage at the EVAP vent valve inlet, or a pinched vent hose. A blockage in the vent system will also cause a poor fuel fill problem. If the condition is intermittent, see INTERMITTENT CONDITIONS under SELF-DIAGNOSTIC SYSTEM.

1. The engine speed is more than 400 RPM.
2. The system voltage is between 6-18 volts.

1. The control module detects that the commanded state of the driver and the actual state of the control circuit do not match.
2. The above conditions are present for a minimum of 5 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

The engine is running.

1. The fuel tank pressure sensor voltage is less than 0.1 volt.
2. All conditions are present for greater than 5 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

The engine is running.

1. The fuel tank pressure sensor voltage is more than 4.9 volts.
2. All conditions are present for greater than 5 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. DTC P0106, P0107, P0108, P0112, P0113, P0116, P0117, P0118, P0120, P0121, P0122, P0123, P0125, P0131, P0132, P0133, P0134, P0135, P0137, P0138, P0140, P0141, P0147, P0151, P0152, P0153, P0154, P0155, P0157, P0158, P0160, P0161, P0167, P0220, P0442, P0443, P0449, P0452, P0453, P0455, P0502, P0503, P1111, P1112, P1114, P1115, or P1120 are not set.
2. The engine is running.
3. The ignition voltage is between 10-18 volts.
4. The Barometric Pressure (BARO) is more than 75 kPa.
5. The fuel level is between 15-85 percent.
6. The Engine Coolant Temperature (ECT) is between 39-149° F (4-65° C).
7. The Intake Air Temperature (IAT) is between 39-167° F (4-75° C).
8. The start-up ECT and IAT are within 16° F (9° C) of each other.

The EVAP system is not able to achieve or maintain vacuum during the diagnostic test.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The fires time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. To help locate intermittent leaks, use the J 41413-200 Evaporative Emissions System Tester (EEST) to introduce smoke into the EVAP system. Move all EVAP components while observing smoke with the J 41413-SPT High Intensity White Light. Introducing smoke in 15 second intervals will allow less pressure into the EVAP system. When the system is less pressurized, the smoke will sometimes escape in a more condensed manner.
2. A temporary blockage in the EVAP purge solenoid purge pipe or EVAP canister could cause an intermittent condition. Inspect and repair intermittent condition. Inspect and repair any restriction in the EVAP system.
3. To improve visibility of the smoke exiting the EVAP system, observe the suspected leak area from different angles with the J 41413-SPT.
4. Reviewing the Failure Records vehicle mileage since the diagnostic test last failed may help determine how often the condition that caused the DTC to be set occurs. This may assist in diagnosing the condition.
5. If the condition is intermittent, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

1. DTC P0106, P0107, P0108, P0112, P0113, P0116, P0117, P0118, P0120, P0121, P0122, P0123, P0125, P0131, P0132, P0133, P0134, P0135, P0137, P0138, P0140, P0141, P0147, P0151, P0152, P0153, P0154, P0155, P0157, P0158, P0160, P0161, P0167, P0220, P0442, P0443, P0449, P0452, P0453, P0455, P0502, P0503, P1111, P1112, P1114, P1115, P1120 are not set.
2. The ignition voltage is between 10-18 volts.
3. The Barometric Pressure (BARO) is more than 75 kPa.
4. The fuel level is between 15-85 percent.
5. The Engine Coolant Temperature (ECT) is between 39-86° F (4-30° C).
6. The Intake Air Temperature (IAT) is between 39-86° F (4-30° C).
7. The start-up ECT and IAT are within 16° F (9° C) of each other.

1. A continuous open purge flow condition is detected during the diagnostic test.
2. The fuel tank pressure decreases to less than -11 inches H2O.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

Scheme 277

1. DTCs P0101-P0103, P0107, P0108, P0112, P0113, P0117, P0118, P0125, P0171, P0172, P0174, P0175, P0200, P0300, P0440, P0442, P0443, P0500, P0502, P0503, P1120, P1220, P1221 or P1441 are not set.
2. The engine is running for greater than 60 seconds.
3. The Engine Coolant Temperature (ECT) is greater than 140°F (60°C).
4. The Intake Air Temperature (IAT) is greater than 14°F (-10°C).
5. The Barometric (BARO) pressure is greater than 65 kPa.
6. The system voltage is between 9-18 volts.
7. The vehicle speed is less than 1 MPH.
8. The Accelerator Pedal Position (APP) sensor is at zero percent.

1. The actual idle speed is 100 RPM less than the desired idle speed.
2. All of the above conditions are present for 5 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. DTCs P0101, P0102, P0103, P0107, P0108, P0112, P0113, P0117, P0118, P0125, P0171, P0172, P0174, P0175, P0200, P0300, P0440, P0442, P0443, P0500, P0502, P0503, P1120, P1220, P1221, or P1441 are not set.
2. The engine is running for greater than 60 seconds.
3. The Engine Coolant Temperature (ECT) is greater than 140°F (60°C).
4. The Intake Air Temperature (IAT) is greater than 14°F (-10°C).
5. The Barometric (BARO) pressure is greater than 65 kPa.
6. The system voltage is between 9-18 volts.
7. The vehicle speed is less than 1 MPH.
8. The Accelerator Pedal Position (APP) sensor is at 0 percent.

1. The actual idle speed is 200 RPM greater than the desired idle speed.
2. All of the above conditions present for 5 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

The engine is running.

1. The PCM detects a voltage out of tolerance condition on the 5-volt reference circuit.
2. The above condition is present for longer than 10 seconds.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating condition to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

Scheme 278

Scheme 279

The ignition is ON.

1. The control module detects that the commanded start of the MIL driver and the actual state of the control circuit do not match.
2. The conditions are present for a minimum of 30 seconds.

The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. A last test failed, or current DTC, clears when the diagnostic runs and does not fail.
2. A history DTC will clear after 40 consecutive warm-up cycles, if no failures are reported by this or any other non-emission related diagnostic.
3. Use a scan tool in order to clear the DTC.

The engine is running.

1. The PCM detects a voltage out of tolerance condition on the 5-volt reference circuit.
2. The above condition is present for longer than 2 seconds.

Action Take When DTC Sets

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating condition s at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malefaction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

Scheme 280

Scheme 281

1. DTC P0120, P0220, P1125, P1514, P1515, P1516, P1518, P2108, P2120, P2121, P2125, P2126, P2130, P2131, P2135 are not set.
2. The engine is running.
3. The throttle angle is less than 1 percent when the engine speed is less than 1200 RPM.
4. The throttle angle is less than 20 percent when the engine speed is more than 1200 RPM.

The PCM detects that the MAP sensor voltage is more than 4.9 volts for more than 6 seconds.

1. The control module stores the DTC information into memory when the diagnostic runs and fails.
2. The Malfunction Indicator Lamp (MIL) will not illuminate.
3. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Failure Records.
4. The driver information center, if equipped, may display a message.

Conditions For Clearing DTC

1. A current DTC Last Test Failed clears when the diagnostic runs and passes.
2. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other non-emission related diagnostic.
3. Clear the DTC with a scan tool.

1. DTC P0120, P0220, P1125, P1514, P1515, P1516, P1518, P2108, P2120, P2121, P2125, P2126, P2130, P2131, P2135 are not set.
2. The engine is running.
3. The throttle angle is 0 percent when the engine speed is less than 800 RPM.
4. The throttle angle is more than 12.5 percent when engine speed is more than 800 RPM.

The PCM detects that the MAP sensor voltage is less than 0.1 volt for more than 6 seconds.

1. The control module stores the DTC information into memory when the diagnostic runs and fails.
2. The Malfunction Indicator Lamp (MIL) will not illuminate.
3. The control nodule records the operating conditions at the time the diagnostic fails. The control module stores this information in the Failure Records.
4. The driver information center, if equipped, may display a message.

1. A current DTC Last Test Failed clears when the diagnostic runs and passes.
2. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other non-emission related diagnostic.
3. Clear the DTC with a scan tool.

1. DTCs P0101, P0102, P0103, or P0113 are not set.
2. The engine run time is more than 120 seconds.
3. The engine coolant temperature is more than 140°F (60°C).
4. The vehicle speed is less than 7 MPH.
5. The mass air flow is less than 15 g/s.

The intake air temperature is less than -36°F (-38°C) for a calibrated amount of time.

1. The control module stores the DTC information into memory when the diagnostic runs and fails.
2. The Malfunction Indicator Lamp (MIL) will not illuminate.
3. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Failure Records.
4. The driver information center, if equipped, may display a message.

1. A current DTC Last Test Failed clears when the diagnostic runs and passes.
2. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other non-emission related diagnostic.
3. Clear the MIL and the DTC with a scan tool.

1. An IAT sensor or PCM which is intermittently shorted, open, or skewed is possible, yet very unlikely.
2. A skewed sensor could result in poor driveability conditions.
3. If an intermittent condition is suspected, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

Scheme 282

1. DTCs P0112, P0500, P0502, and P0503 are not set.
2. The engine run time is more than 45 seconds.
3. The vehicle speed is more than 25 MPH.
4. The ECT sensor parameter is less than 257° F (125° C).

The PCM detects that the IAT sensor parameter is more than 252° F (128° C) intermittently for a calibrated amount of time.

1. The control module stores the DTC information into memory when the diagnostic runs and fails.
2. The Malfunction Indicator Lamp (MIL) will not illuminate.
3. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Failure Records.
4. The driver information center, if equipped, may display a message.

1. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
2. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
3. Clear the MIL and the DTC with a scan tool.

1. An IAT sensor or PCM which is intermittently shorted, open, or skewed is possible, yet very unlikely.
2. A skewed sensor could result in poor driveability complaints.
3. If an intermittent condition is suspected, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

Scheme 283

Engine run time is more than 10 seconds.

The PCM detects an ECT of more than 139°C (282°F), as measured by the ECT sensor, and the intermittent condition exists for a calibrated amount of time.

1. The control module stores the DTC information into memory when the diagnostic runs and fails.
2. The Malfunction Indicator Lamp (MIL) will not illuminate.
3. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Failure Records.
4. The driver information center, if equipped, may display a message.

1. A current DTC Last Test Failed clears when the diagnostic runs and passes.
2. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other non-emission related diagnostic.
3. Clear the DTC with a scan tool.

1. An ECT sensor or PCM which is intermittently shorted, open, or skewed is possible, yet very unlikely.
2. An intermittent short to ground in the ECT sensor signal circuit could result in a DTC P1114.
3. Use the Temperature vs Resistance Value scale in order to test the coolant sensor at various temperature levels in order to evaluate the possibility of a skewed sensor. A skewed sensor could result in poor driveability complaints. See «SENSOR OPERATING RANGE CHARTS - TRUCKS»(ref-159155) article.
4. If an intermittent condition is suspected, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

Scheme 284

Engine run time is more than 60 seconds.

The PCM detects an ECT of less than -36°F (-38°C), intermittently for a calibrated amount of time.

1. The control module stores the DTC information into memory when the diagnostic runs and fails.
2. The Malfunction Indicator Lamp (MIL) will not illuminate.
3. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Failure Records.
4. The driver information center, if equipped, may display a message.

1. A current DTC Last Test Failed clears when the diagnostic runs and passes.
2. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other non-emission related diagnostic.
3. Clear the DTC with a scan tool.

1. An ECT sensor or PCM which is intermittently shorted, open, or skewed is possible, yet very unlikely.
2. An intermittent open or short to voltage in the ECT sensor signal circuit could result in a DTC P1115.
3. Use the Temperature vs Resistance Value scale in order to test the coolant sensor at various temperature levels in order to evaluate the possibility of a skewed sensor. A skewed sensor could result in poor driveability complaints. See «SENSOR OPERATING RANGE CHARTS - TRUCKS»(ref-159155) article.
4. If an intermittent condition is suspected, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

Scheme 285

1. DTCs P2108 or P1518 are not set.
2. The ignition switch is in the crank or run position.
3. The ignition voltage is greater than 5.23 volts.

1. Two or more APP sensors are out of range or all 3 APP sensors disagree or 1 APP sensor is out of range, and the other 2 APP sensors disagree.
2. All of the above conditions present for less than 1 second.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) when the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Freeze Frame and/or the Failure Records.
3. The control module commands the TAC system to operate in the Reduced Engine Power mode; or, under certain conditions the control module commands the engine OFF.
4. The message center displays Reduced Engine Power.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. Inspect the TAC module connectors for signs of water intrusion. If water intrusion occurs, multiple DTCs may set without any circuit or component conditions found during diagnostic testing.
2. The APP sensor 1 and the Throttle Position (TP) sensor 1, 5-volt reference circuits are internally connected within the TAC module.
3. The APP sensor 2 and the TP sensor 2, 5-volt reference circuits are internally connected within the TAC module.
4. When the TAC module detects a condition within the TAC system more than 1 TAC system related DTC may set. This is due to the many redundant tests run continuously on this system. Locating and repairing 1 individual condition may correct more than 1 DTC. Remember this if you review the information stored in Captured Info.
5. If an intermittent condition is suspected, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

1. DTCs P0101, P0102, P0103, P0106, P0107, P0108, P0112, P0113, P0116, P0117, P0118, P0120, P0131, P0132, P0134, P0135, P0151, P0152, P0154, P0155, P0200, P0220, P0300, P0442, P0446, P0452, P0453, P0455, P0496, P1125, P1258, P1514, P1515, P1516, P1518, P2108, or P2135 are not set.
2. The Engine Coolant Temperature (ECT) sensor is more than 149°F (65°C).
3. The engine run time is more than 160 seconds.
4. The Evaporative (EVAP) emissions purge solenoid command is more than 1 percent.
5. The mass airflow (MAF) sensor is between 23-50 g/s.
6. The engine speed is between 1200-3000 RPM.
7. For vehicles with TAC, the TP indicated angle is 5 percent more than the value observed at idle.
8. The loop status is Closed.
9. The ignition 1 signal voltage is between 10-18 volts.
10. The fuel tank level remaining is more than 10 percent.
11. The above conditions are met for 50 seconds.

The PCM detects that the affected HO2S lean-to-rich or rich-to-lean transitions are less than a calibrated value.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) on the second consecutive ignition cycle that the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The first time the diagnostic fails, the control module stores this information in the Failure Records. If the diagnostic reports a failure on the second consecutive ignition cycle, the control module records the operating conditions at the time of the failure. The control module writes the operating conditions to the Freeze Frame and updates the Failure Records.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. DTCs P0101, P0102, P0103, P0120, P0335, P0336, or P0742 are not set.
2. The vehicle speed is more than 10 MPH.
3. The engine load is less than 60 percent.
4. The engine misfire is detected and DTC P0300 set.
5. The engine speed is less than 3200 RPM.

An ABS malfunction exists preventing the PCM from receiving rough road detection data.

1. The control module stores the DTC information into memory when the diagnostic runs and fails.
2. The Malfunction Indicator Lamp (MIL) will not illuminate.
3. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Failure Records.
4. The driver information center, if equipped, may display a message.

1. A current DTC Last Test Failed clears when the diagnostic runs and passes.
2. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other non-emission related diagnostic.
3. Clear the DTC with a scan tool.

Scheme 286

1. The engine load is less than 60 percent.
2. The engine speed is less than 3200 RPM.
3. The vehicle speed is more than 10 MPH.
4. Engine misfire is detected and DTC P0300 is set.

1. A serial data malfunction exists preventing the PCM from receiving rough road detection data.
2. The above conditions are met for 20 seconds.

1. The control module stores the DTC information into memory when the diagnostic runs and fails.
2. The Malfunction Indicator Lamp (MIL) will not illuminate.
3. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Failure Records.
4. The driver information center, if equipped, may display a message.

1. A current DTC Last Test Failed clears when the diagnostic runs and passes.
2. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other non-emission related diagnostic.
3. Clear the DTC with a scan tool.

1. DTCs P0601, P0602, P0604, P0606, P1515, P1516, P1517, or P1518 are not set.
2. The following DTCs are not active at the same time: P1120, P1220 and P1221.
3. The following DTCs are not active at the same time: P1120 and P1220.
4. The engine operates longer than 1 second.
5. The engine speed is greater than 500 RPM.

1. The PCM detects that the difference between the actual airflow (MAF) and the Speed Density calculated air flow is greater than expected.
2. All of the above conditions met for less than 1 second.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) when the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Freeze Frame and/or the Failure Records.
3. The control module commands the TAC system to operate in the Reduced Engine Power mode; or, under certain conditions the control module commands the engine OFF.
4. The message center displays Reduced Engine Power.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. Inspect the throttle blade for being broken, bent, or missing.
2. Inspect the Throttle Position (TP) sensor for proper installation. A sensor that is mis-aligned could set this DTC.
3. Inspect the Throttle Actuator Control (TAC) module connectors for signs of water intrusion. If water intrusion occurs, multiple DTCs may set without any circuit or component conditions found during diagnostic testing.
4. Physically and visually inspect the throttle body assembly and correct any problems that you observe. Manually move the throttle blade from closed to Wide Open Throttle (WOT). You should not need to use excess force. The throttle blade should move smoothly through the full range and then should independently return to a slightly open position.
5. When the TAC module detects a condition within the TAC system, more than 1 TAC system related DTC may set. This is due to the many redundant tests run continuously on this system. Locating and repairing 1 individual condition may correct more than 1 DTC. Disconnecting components during testing may set additional DTCs. Remember this if you review the stored information in Capture Info.
6. For an Intermittent condition, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

1. DTCs P0601, P0602, P0604, P0606, P1516, P1518 or P2108 are not set.
2. The following DTCs are not active at the same time: P0120, P0220 and P2135.
3. The following DTCs are not active at the same time: P0120 and P0220.
4. The ignition switch is in the crank or run position.
5. The ignition voltage is greater than 8.5 volts.
6. The TAC system is not in the battery saver mode.

1. The PCM detects that the commanded and actual throttle positions are not within a calibrated range of each other.
2. All above conditions met for less than 1 second.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) when the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Freeze Frame and/or the Failure Records.
3. The control module commands the TAC system to operate in the Reduced Engine Power mode; or, under certain conditions the control module commands the engine OFF.
4. The message center displays Reduced Engine Power.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. Inspect for mechanical concerns or binding that may be temperature related. Components may not move freely in extreme heat or cold due to the presence of contaminants or ice formation.
2. Inspect the TAC module connectors for signs of water intrusion. If water intrusion occurs, multiple DTCs may set without any circuit or component conditions found during diagnostic testing.
3. When the TAC module detects a condition within the TAC system, more than 1 TAC system related DTC may set. This is due to the many redundant tests run continuously on this system. Locating and repairing an individual condition may correct more than 1 DTC. Disconnecting components during testing may set additional DTCs. Remember this if you review the stored information in Capture Info.
4. For an Intermittent condition, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

1. DTC P1518 is not set.
2. The ignition switch is in the crank or run position.
3. The ignition voltage is greater than 5.23 volts.
4. The TAC system is not in the battery saver mode.

1. The TAC module detects that the predicted and actual throttle positions are not within a calibrated range of each other or the PCM and the TAC cannot determine throttle position or both TP sensors are invalid.
2. The PCM and the TAC cannot determine the throttle position.
3. Both the TP sensors are invalid.
4. All of the above conditions met for less than 1 second.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) when the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Freeze Frame and/or the Failure Records.
3. The control module commands the TAC system to operate in the Reduced Engine Power mode; or, under certain conditions the control module commands the engine OFF.
4. The message center displays Reduced Engine Power.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. Inspect the TAC module connectors for signs of water intrusion. If water intrusion occurs, multiple DTCs may set without any circuit or component conditions found during diagnostic testing.
2. Verify that the starting and charging systems are operating properly. Low system voltage can cause this DTC to set.
3. When the TAC module detects a condition within the TAC system, more than 1 TAC system related DTC may set. This is due to the many redundant tests run continuously on this system. Locating and repairing an individual condition may correct more than 1 DTC. Disconnecting components during testing may set additional DTCs. Remember this if you review the stored information in Capture Info.
4. For an Intermittent condition, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

1. The ignition switch is in the crank or run position.
2. The ignition voltage is greater than 5.23 volts.

1. Invalid or missing serial data messages are detected for a predetermined amount of time.
2. All of the above conditions met for less than 1 second.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) when the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Freeze Frame and/or the Failure Records.
3. The control module commands the TAC system to operate in the Reduced Engine Power mode; or, under certain conditions the control module commands the engine OFF.
4. The message center displays Reduced Engine Power.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

DTC P1518 sets

1. If the battery voltage is low. If the customer's concern is slow cranking or no crank because battery voltage is low, ignore DTC P1518. Clear any DTCs from memory that may have set from the low battery voltage condition.
2. When there is a short to battery voltage on the TAC module ground circuit. Inspect the fuses for the circuits that are in the TAC module harness, (i.e., cruise or brake). An inspection of the fuses may lead you to the circuit that is shorted to the TAC module ground circuit.
3. If the TAC module ignition feed circuit is shorted to a battery voltage supply circuit. The TAC module stays powered-up when the ignition switch is turned OFF. When the ignition switch is turned ON, the TAC module is powered-up before the PCM. DTC P1518 sets because no communication is detected by the TAC module from the PCM. Inspect related circuits for being shorted to a battery voltage supply circuit.

Inspect the TAC module power and ground circuits and the TAC module/PCM serial data circuits for intermittent connections.

Inspect the TAC module connectors for signs of water intrusion. If water intrusion occurs, multiple DTCs may set without any circuit or component conditions found during diagnostic testing.

When the TAC module detects a problem within the TAC system, more than 1 TAC system related DTC may set. This is due to the many redundant tests run continuously on this system. Locating and repairing an individual condition may correct more than 1 DTC. Remember this if you review the stored information in Capture Info.

For an Intermittent condition, see INTERMITTENT CONDITIONS under SELF-DIAGNOSTIC SYSTEM.

1. DTC P1518 is not set.
2. The ignition switch is in the crank or run position.
3. The ignition voltage is greater than 6 volts.

1. The TAC module determines than an internal data test did not pass.
2. The above condition is met for more than 1 second.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) when the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostics fails. The control module stores this information in the Freeze Frame and/or the Failure Records.
3. The control module commands the TAC system to operate in the Reduced Engine Power mode.
4. Under certain conditions the control module commands the engine OFF.
5. The message center displays Reduced Engine Power.

1. The control module turns off the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL and the DTC with a scan tool.

1. Verify that the starting and charging systems are operating properly. Low system voltage can cause this DTC to set.
2. Inspect the TAC module connectors for signs of water intrusion. If water intrusion occurs, multiple DTCs may set without any circuit or component conditions found during diagnostic testing.
3. When the TAC module detects a condition within the TAC system, more than 1 TAC system related DTC may set. This is due to the many redundant tests run continuously on this system. Locating and repairing an individual conditions may correct more than 1 DTC. Disconnecting components during testing may set additional DTCs. Remember this if you review the stored information in Capture Info.

1. DTCs P0601, P0602, P0606, P1518, or P2108 are not set.
2. The ignition switch is in the crank or run position.
3. The ignition voltage is more than 5.23 volts.

1. The APP sensor 1 voltage is less than 0.24 volts or more than 4.49 volts.
2. The 5-volt reference is less than 4.54 volts or more than 5.21 volts.
3. One of the above conditions is present for more than 1 second.

1. The control module stored the DTC information into memory when the diagnostic runs and fails.
2. The Malfunction Indicator Lamp (MIL) will not illuminate.
3. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Failure Records.
4. If one or more APP sensor DTCs are set, the following occurs: The control module commands Reduced Engine Power mode. The APP indicated angle is limited to a predetermined value to limit the amount or throttle control. The APP indicated angle is limited to 0 percent. The control module only allows the engine to idle. The message center displays Reduced Engine Power.

1. A current DTC Last Test Failed clears when the diagnostic runs and passes.
2. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other non-emission related diagnostic.
3. Clear the DTC with a scan tool.

1. Inspect the Throttle Actuator Control (TAC) module connectors for signs of water intrusion. If water intrusion occurs, multiple DTCs may set without any circuit or component conditions found during diagnostic testing.
2. When the TAC module detects a condition within the TAC system, more than 1 TAC system related DTC may set. This is due to the many redundant tests run continuously on this system. Locating and repairing 1 individual condition may correct more than 1 DTC. Disconnecting components during testing may set additional DTCs. Remember this if you review the stored information in Capture Info.
3. For an Intermittent condition, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

1. DTCs P0606, P1518 or P2108 are not set.
2. The ignition switch is in the crank or run position.
3. The ignition volage is more than 5.23 volts.

1. APP sensor 1 disagrees with APP sensor 2 by more than 10.5 percent.
2. The above condition is present for more than 1 second.

1. The control module stored the DTC information into memory when the diagnostic runs and fails.
2. The Malfunction Indicator Lamp (MIL) will not illuminate.
3. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Failure Records.
4. If one or more APP sensor DTCs are set, the following occurs: The control module commands Reduced Engine Power mode. The APP indicated angle is limited to a predetermined value to limit the amount or throttle control. The APP indicated angle is limited to 0 percent. The control module only allows the engine to idle. The message center displays Reduced Engine Power.

1. A current DTC Last Test Failed clears when the diagnostic runs and passes.
2. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other non-emission related diagnostic.
3. Clear the DTC with a scan tool.

1. Inspect the Throttle Actuator Control (TAC) module connectors for signs of water intrusion. If water intrusion occurs, multiple DTCs may set without any circuit or component conditions found during diagnostic testing.
2. When the TAC module detects a condition within the TAC system, more than 1 TAC system related DTC may set. This is due to the many redundant tests run continuously on this system. Locating and repairing 1 individual condition may correct more than 1 DTC. Disconnecting components during testing may set additional DTCs. Remember this if you review the stored information in Capture Info.
3. For an Intermittent condition, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

1. DTCs P0601, P0602, P0606, P1518 or P2108 are not set.
2. The ignition switch is in the crank or run position.
3. The ignition voltage is more than 5.23 volts.

1. The APP sensor 2 voltage is less than 0.24 volt or more than 4.49 volts.
2. The 5-volt reference is less than 4.54 volts or more than 5.21 volts.
3. One of the above conditions is present for more than 1 second.

1. The control module stores the DTC information into memory when the diagnostic runs and fails.
2. The Malfunction Indicator Lamp (MIL) will not illuminate.
3. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Failure Records.
4. If one or more APP sensor DTCs are set, the following occurs: The control module commands Reduced Engine Power mode. the APP indicated angle is limited to a predetermined value to limit the amount of throttle control. The APP indicated angle is limited to 0 percent. The control module only allows the engine to idle. The message center displays Reduced Engine Power.

1. A current DTC Last Test Failed clears when the diagnostic runs and passes.
2. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other non-emission related diagnostic.
3. Clear the DTC with the scan tool.

1. Inspect the Throttle Actuator Control (TAC) module connectors for signs or water intrusion. If water intrusion occurs, multiple DTCs may set without any circuit or component conditions found during diagnostic testing.
2. When the TAC module detects a condition within the TAC system, more than 1 TAC system related DTC may set. This is due to the many redundant tests run continuously on this system. Locating and repairing 1 individual condition may correct more than 1 DTC. Disconnecting components during testing may set additional DTCs. Remember this if you review the stored information in Capture Info.
3. For an Intermittent condition, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.

1. DTCs P1518 or P2108 are not set.
2. The ignition switch is in the crank or run position.
3. The ignition voltage is more than 5.23 volts.

1. The TP sensor 2 disagrees with the TP sensor 1 by more than 7.5 percent.
2. The above condition is present for more than 1 second.

1. The control module illuminates the Malfunction Indicator Lamp (MIL) when the diagnostic runs and fails.
2. The control module records the operating conditions at the time the diagnostic fails. The control module stores this information in the Freeze Frame and/or the Failure Records.
3. The control module commands the TAC system to operate in the Reduced Engine Power mode.
4. Under certain conditions the control module commands the engine OFF.
5. The message center displays Reduced Engine Power.

1. The control module turns OFF the Malfunction Indicator Lamp (MIL) after 3 consecutive ignition cycles that the diagnostic runs and does not fail.
2. A current DTC, Last Test Failed, clears when the diagnostic runs and passes.
3. A history DTC clears after 40 consecutive warm-up cycles, if no failures are reported by this or any other emission related diagnostic.
4. Clear the MIL/DTC with a scan tool.

1. Inspect the Throttle Actuator Control (TAC) module connectors for signs of water intrusion. If water intrusion occurs, multiple DTCs may set without any circuit or component conditions found during diagnostic testing.
2. When the TAC module detects a condition within the TAC system, more than 1 TAC system related DTC may set. This is due to the many redundant tests run continuously on this system. Locating and repairing 1 individual condition may correct more than 1 DTC. Disconnecting components during testing may set additional DTCs. Remember this if you review the stored information in Capture Info.
3. For an Intermittent condition, see «INTERMITTENT CONDITIONS»(ref-158882-S25670426342003102900000) under SELF-DIAGNOSTIC SYSTEM.
